RR DIFF not engaging

Discussion in 'Technical Chat' started by willie64, Mar 25, 2013.

  1. Mar 25, 2013 at 11:59 AM
    #1
    willie64

    willie64 [OP] Willie64

    Joined:
    Oct 21, 2011
    Member:
    #65611
    Messages:
    150
    Gender:
    Male
    First Name:
    willie64
    BEND OR
    Vehicle:
    (becoming less) Stock '03 3.4L 4x4 TRD SR5
    KN drop-in filter, Hella lights (+1 generic) on the front and generic 1.5"x3" lights on the back, cb, toytec 3" lift, 285/75/16 Fierce Attitude tires, JoeZilla sliders.
    03 TRD 3.4
    :help:went to play in the snow this w/e and pressed my Rear Diff lock button and it just blinked at me mockingly. Backed up about .25 mile, drove forward, backed up, drove forward, etc. Finally gave up. I checked all connections and everything seems to be in place and in working order. Any suggestions?:notsure:

  2. Mar 25, 2013 at 12:28 PM
    #2
    willie64

    willie64 [OP] Willie64

    Joined:
    Oct 21, 2011
    Member:
    #65611
    Messages:
    150
    Gender:
    Male
    First Name:
    willie64
    BEND OR
    Vehicle:
    (becoming less) Stock '03 3.4L 4x4 TRD SR5
    KN drop-in filter, Hella lights (+1 generic) on the front and generic 1.5"x3" lights on the back, cb, toytec 3" lift, 285/75/16 Fierce Attitude tires, JoeZilla sliders.
    Honestly, I can't tell. I can't feel any difference. The light just blinks, and blinks and blinks and blinks..........

  3. Mar 25, 2013 at 12:50 PM
    #3
    VolcomTacoma2011

    VolcomTacoma2011 Well-Known Member

    Joined:
    May 25, 2011
    Member:
    #57205
    Messages:
    7,560
    Gender:
    Male
    First Name:
    Jeff
    Fairfield, NorCal
    Vehicle:
    2011 TRD TX|Pro PreRunner DC
    Stock-trading in soon
    Try turning? I always come to a complete stop, hit the button, then drive forward and turn back and Forth a little bit and hear it snap into place

  4. Mar 25, 2013 at 1:04 PM
    #4
    willie64

    willie64 [OP] Willie64

    Joined:
    Oct 21, 2011
    Member:
    #65611
    Messages:
    150
    Gender:
    Male
    First Name:
    willie64
    BEND OR
    Vehicle:
    (becoming less) Stock '03 3.4L 4x4 TRD SR5
    KN drop-in filter, Hella lights (+1 generic) on the front and generic 1.5"x3" lights on the back, cb, toytec 3" lift, 285/75/16 Fierce Attitude tires, JoeZilla sliders.
    OKTHIS sounds more encouraging that PSU's response. :D I'll try that second. I would hate for actuator to be fried. What's up with the turning bit? Is the system hooked up to the steering?

  5. Mar 25, 2013 at 1:41 PM
    #5
    VolcomTacoma2011

    VolcomTacoma2011 Well-Known Member

    Joined:
    May 25, 2011
    Member:
    #57205
    Messages:
    7,560
    Gender:
    Male
    First Name:
    Jeff
    Fairfield, NorCal
    Vehicle:
    2011 TRD TX|Pro PreRunner DC
    Stock-trading in soon
    Yea but hitting a button and moving back and forth for a few feet is way less work :)

    But yea, like someone said above, the way I remember it is the wheels moving at different speeds or whatever allows it to lock into place. I used to just hit the button and drive on and just see it blinking...and it took a while before I realized it was when I was barely moving and turning that I'd hear it snap in. So my way works every time for me :)

  6. Mar 25, 2013 at 1:57 PM
    #6
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    8,823
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Kragen HID, 1 Cibie Halogen.
    1) Have you ever used it before and know it worked?
    2) Are you in LOW RANGE? (Have you been in low range before?)
    3) From a stop, press the RR button (in L4) and note light blinks until it engages and goes solid... Begin to drive slowly... if still blinking turn your wheel all the way ONE direction, not back and forth and roll that direction. The light should go solid. Remember, using the rear locker is for emergencies only to get through an area or obstacle. Turning is more difficult if the tires cannot rotate independently.

  7. Mar 25, 2013 at 1:57 PM
    #7
    willie64

    willie64 [OP] Willie64

    Joined:
    Oct 21, 2011
    Member:
    #65611
    Messages:
    150
    Gender:
    Male
    First Name:
    willie64
    BEND OR
    Vehicle:
    (becoming less) Stock '03 3.4L 4x4 TRD SR5
    KN drop-in filter, Hella lights (+1 generic) on the front and generic 1.5"x3" lights on the back, cb, toytec 3" lift, 285/75/16 Fierce Attitude tires, JoeZilla sliders.
    however, I never tried turning. AND, that .25 mile may have been a bit of an exageration; maybe it was more like 50 ft.
    If the turning doesn't work I will take stuff apart. That's always fun, too.

  8. Mar 25, 2013 at 1:58 PM
    #8
    BulletToothTony

    BulletToothTony Gold Member

    Joined:
    Feb 20, 2008
    Member:
    #4833
    Messages:
    11,228
    First Name:
    You can call me Susan if it makes you happy.
    Were you in 4lo?

  9. Mar 25, 2013 at 1:59 PM
    #9
    willie64

    willie64 [OP] Willie64

    Joined:
    Oct 21, 2011
    Member:
    #65611
    Messages:
    150
    Gender:
    Male
    First Name:
    willie64
    BEND OR
    Vehicle:
    (becoming less) Stock '03 3.4L 4x4 TRD SR5
    KN drop-in filter, Hella lights (+1 generic) on the front and generic 1.5"x3" lights on the back, cb, toytec 3" lift, 285/75/16 Fierce Attitude tires, JoeZilla sliders.

    Yep, used this a few times before with no issues, just clicked right in.

  10. Mar 25, 2013 at 2:02 PM
    #10
    willie64

    willie64 [OP] Willie64

    Joined:
    Oct 21, 2011
    Member:
    #65611
    Messages:
    150
    Gender:
    Male
    First Name:
    willie64
    BEND OR
    Vehicle:
    (becoming less) Stock '03 3.4L 4x4 TRD SR5
    KN drop-in filter, Hella lights (+1 generic) on the front and generic 1.5"x3" lights on the back, cb, toytec 3" lift, 285/75/16 Fierce Attitude tires, JoeZilla sliders.
    never used in 4lo. IDK, isn't that redundant? I've used when in 2hi and 4hi. each time the light flashed for a moment then went solid.

  11. Mar 25, 2013 at 2:09 PM
    #11
    BulletToothTony

    BulletToothTony Gold Member

    Joined:
    Feb 20, 2008
    Member:
    #4833
    Messages:
    11,228
    First Name:
    You can call me Susan if it makes you happy.
    So you've done the locker mod?

  12. Mar 25, 2013 at 2:10 PM
    #12
    VolcomTacoma2011

    VolcomTacoma2011 Well-Known Member

    Joined:
    May 25, 2011
    Member:
    #57205
    Messages:
    7,560
    Gender:
    Male
    First Name:
    Jeff
    Fairfield, NorCal
    Vehicle:
    2011 TRD TX|Pro PreRunner DC
    Stock-trading in soon
    Also, roll your window down, turn the music down, when you try my way, you will definitely hear it *CLACK* into place

  13. Mar 25, 2013 at 2:12 PM
    #13
    VolcomTacoma2011

    VolcomTacoma2011 Well-Known Member

    Joined:
    May 25, 2011
    Member:
    #57205
    Messages:
    7,560
    Gender:
    Male
    First Name:
    Jeff
    Fairfield, NorCal
    Vehicle:
    2011 TRD TX|Pro PreRunner DC
    Stock-trading in soon
    Thought I broke something the first time I did it :) honestly my first two times offloading on my own, I probably only got it to pop in place on accident. Just hit the button, assumed it was on...and then probably stopped to take a photo or something and turned a little as I was starting again and it popped into place.

  14. Mar 25, 2013 at 2:13 PM
    #14
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    8,823
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Kragen HID, 1 Cibie Halogen.
    Stock 4WD Tacomas can only use the locker when in Low Range 4WD. Otherwise, you have done a mod (Gray Wire?)... or a previous owner did.

    2WD Off Road PreRunners have a locker that works in 2WD...

    [​IMG]

  15. Mar 25, 2013 at 3:22 PM
    #15
    willie64

    willie64 [OP] Willie64

    Joined:
    Oct 21, 2011
    Member:
    #65611
    Messages:
    150
    Gender:
    Male
    First Name:
    willie64
    BEND OR
    Vehicle:
    (becoming less) Stock '03 3.4L 4x4 TRD SR5
    KN drop-in filter, Hella lights (+1 generic) on the front and generic 1.5"x3" lights on the back, cb, toytec 3" lift, 285/75/16 Fierce Attitude tires, JoeZilla sliders.
    All great input from every one.
    Being rather new to the sport (still learning and getting schooled :D) I am gathering that when I pushed the button in 2hi and 4hi (even though the ligh stayed on) I was not actually engaged. I was thinking about doing the grey wire mod but haven't done it..... yet. There aren't many justifiable reasons to do this in Portland.

  16. Mar 25, 2013 at 6:06 PM
    #16
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    8,823
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Kragen HID, 1 Cibie Halogen.
    Willie, if it is locked, it will be VERY easily noticed... try parallel parking (or turning sharp while moving slow). The back tires will skuff... if locked. More so than the binding you feel when trying to turn sharply while in 4WD, on hard surfaces.

  17. Mar 26, 2013 at 11:04 AM
    #17
    willie64

    willie64 [OP] Willie64

    Joined:
    Oct 21, 2011
    Member:
    #65611
    Messages:
    150
    Gender:
    Male
    First Name:
    willie64
    BEND OR
    Vehicle:
    (becoming less) Stock '03 3.4L 4x4 TRD SR5
    KN drop-in filter, Hella lights (+1 generic) on the front and generic 1.5"x3" lights on the back, cb, toytec 3" lift, 285/75/16 Fierce Attitude tires, JoeZilla sliders.
    So, thanks again for all the input. I tried again last night after work (don't tell my boss I'm doing this on company time) and ripped up the yard, and part of my neighbor's.
    CLUNK!:headbang: it seems that just turning the steering wheel to hard left/ right is the ticket to success.
    Now, I guess it's time to do the gray wire mod.
    Thanks again for all the help.

  18. Mar 26, 2013 at 11:05 AM
    #18
    BulletToothTony

    BulletToothTony Gold Member

    Joined:
    Feb 20, 2008
    Member:
    #4833
    Messages:
    11,228
    First Name:
    You can call me Susan if it makes you happy.
  19. Mar 26, 2013 at 11:05 AM
    #19
    VolcomTacoma2011

    VolcomTacoma2011 Well-Known Member

    Joined:
    May 25, 2011
    Member:
    #57205
    Messages:
    7,560
    Gender:
    Male
    First Name:
    Jeff
    Fairfield, NorCal
    Vehicle:
    2011 TRD TX|Pro PreRunner DC
    Stock-trading in soon
    What it is- you need to get your rear wheels to turn at different speeds. So just turning the wheel wont do much, gotta actually get your truck turning and those rear wheels moving, ya know? ;) Glad it worked out for ya!

  20. Mar 26, 2013 at 11:37 AM
    #20
    127.0.0.1

    127.0.0.1 AKA ::1

    Joined:
    Dec 24, 2012
    Member:
    #93641
    Messages:
    1,474
    Gender:
    Male
    /etc/hosts
    Vehicle:
    2013 NBM AC 4.0 4x4 Auto OR
    find a dirt road to engage and disengage that sucker in 4lo about 20 times

    and go back and do it the next week

    eventually it should loosen up and engage faster

    this procedure is what sometimes needs to be done on brand new
    4runners/tacos...I don't know if it helps a really old one

    my 4runner brand new in 1998 hated the locker and took
    a lot of tweaking to get it to 'klang' locked

    after using it a lot for a month, it became very smooth
    and reliable. still sometimes it won't engage right away, but
    instead of having to fight it, I only go from d-n-r-n-d
    and during that maybe move an inch and it will find the sweet spot
    and engage. if I pre-engage it (10 feet before i need it) 100% the time
    it will lock
