Shackle Flip Kit - The Official Armor Tech Offroad Thread!

Discussion in 'Armor Tech Offroad' started by ArmorTech, Mar 6, 2013.

  1. Mar 15, 2013 at 6:25 PM
    #41
    hard2kill

    hard2kill Well-Known Member

    Joined:
    Apr 28, 2011
    Member:
    #55714
    Messages:
    3,860
    Gender:
    Male
    First Name:
    John
    Rhinebeck NY
    Vehicle:
    06 4door trd sport white 6spd
    ...315's,2in bora wheel spacers,safari snorkel,wheel spacers,bruteforcefab rear bumper and sliders,afe filter,hi-lift jack,5100 with OME 886 & 1/2in spacer,allpro expo's,icon 10in rear shox,flip kit,ss brake lines,cobra cb,fog light mod,yellow fogs,weathertech mats,fullsize spare tire and extra sport rim,tinted windows,aeroturbine 2525 muffler dumped over axle...rear diff breather mod...removed factory spare...removed 2nd air filter...THULE roof rack and fairing....bud builts front to back,allpoo front bumper,BAMF lca skids,overland Offroad roof and bed racks,
    not exactly but with my expo springs at full droop im almost at full extension with my 10in icon shocks but 12in shocks are alittle to long without the relocating the shock up further allow to run a longer shock with greater up/down travel....so i have a decent setup now but will revamp shocks,shackles and mounts all at once for a big improvement at one time done right and ato is top quality parts :)

  2. Mar 16, 2013 at 7:51 PM
    #42
    jberry813

    jberry813 The Mad Scientist

    Joined:
    Jan 21, 2011
    Member:
    #49636
    Messages:
    14,166
    Gender:
    Male
    First Name:
    Jason
    Lake Tahoe
    Vehicle:
    Resurrected LT TRD S/C 4x4
    TRD Supercharger, URD 7th Injector Kit, Total Chaos LT, King Coilov....too much shit to list.
    You're not really going to be able to cycle the expos more than 11" without going wicked negative arch, which you can easily do with a 10" stroke shock.
    And no matter what, you're not going to get the same amount of uptravel, let alone more uptravel with a shackle flip unless you've got some mad sting bug ride height.

  3. Mar 16, 2013 at 8:04 PM
    #43
    HomerTaco

    HomerTaco That "grill guy" Vendor

    Joined:
    Mar 28, 2010
    Member:
    #34129
    Messages:
    27,684
    Gender:
    Male
    First Name:
    Craig
    Bucks County Pa.
    Vehicle:
    07' DCSB cut to pieces...
    Core-Hurst short throw shifter & T-handle / Carbon Fiber Interior / custom console light / De-badged / leather interior / Heated Front seats / Red Line Hood Struts / Painted speaker grills /one-off TRD Satoshi Grill/ Pioneer AVIC-X920BT HU / Scangauge II / Black LED Tails / Dash Mount for iPad / Safari Snorkel / Illuminated 4x4 switch / Leer 100XQ Cap / 4x Innovations sliders / Rear Diff Breather Mod / front windows tinted to 35% / Brute Force Fab Hybrid Front Bumper / BAMF Rear Diff Skid / Budbuilt Skids / CBI Trail Master 2.0 rear hybrid bumper / Fox rr coils/ TC UCA's/ TC spindle gussets/ TC Cam Tab gussets / Dakar leafs / Defined Engineering shackles / All pro U bolt flip / Timbren Rear Bumpstops / BAMF LCA skids / Exhaust Dump / Fog Light anytime Mod / LowRange Off Road extended rear brake lines / ATO Shackle Flip / sectioned Bushwhacker flares / re-geared to 4.56 / ARB Front & Rear Locking Diff / ARB CKMA12 compressor / PrInSu full rack system / 1" body lift
    I've got the original ATO version of this kit.
    Standard stock 3leaf pack with a wheelers progressive 3leaf AAL
    RCD 5100's

    I like it :thumbsup:

    [​IMG]

    [​IMG]

  4. Mar 16, 2013 at 8:24 PM
    #44
    skidooman

    skidooman I'm your huckleberry

    Joined:
    Apr 6, 2011
    Member:
    #54438
    Messages:
    4,697
    Gender:
    Male
    First Name:
    TJ
    Idaho
    Vehicle:
    sold everything
    My rear set up is a single aal, and OME shocks. Would I need new shocks to run this?

  5. Mar 16, 2013 at 8:26 PM
    #45
    HomerTaco

    HomerTaco That "grill guy" Vendor

    Joined:
    Mar 28, 2010
    Member:
    #34129
    Messages:
    27,684
    Gender:
    Male
    First Name:
    Craig
    Bucks County Pa.
    Vehicle:
    07' DCSB cut to pieces...
    Core-Hurst short throw shifter & T-handle / Carbon Fiber Interior / custom console light / De-badged / leather interior / Heated Front seats / Red Line Hood Struts / Painted speaker grills /one-off TRD Satoshi Grill/ Pioneer AVIC-X920BT HU / Scangauge II / Black LED Tails / Dash Mount for iPad / Safari Snorkel / Illuminated 4x4 switch / Leer 100XQ Cap / 4x Innovations sliders / Rear Diff Breather Mod / front windows tinted to 35% / Brute Force Fab Hybrid Front Bumper / BAMF Rear Diff Skid / Budbuilt Skids / CBI Trail Master 2.0 rear hybrid bumper / Fox rr coils/ TC UCA's/ TC spindle gussets/ TC Cam Tab gussets / Dakar leafs / Defined Engineering shackles / All pro U bolt flip / Timbren Rear Bumpstops / BAMF LCA skids / Exhaust Dump / Fog Light anytime Mod / LowRange Off Road extended rear brake lines / ATO Shackle Flip / sectioned Bushwhacker flares / re-geared to 4.56 / ARB Front & Rear Locking Diff / ARB CKMA12 compressor / PrInSu full rack system / 1" body lift
    To take full advantage of the flip kit you would want to. The stock shocks will limit the downtravel.

  6. Mar 16, 2013 at 8:32 PM
    #46
    skidooman

    skidooman I'm your huckleberry

    Joined:
    Apr 6, 2011
    Member:
    #54438
    Messages:
    4,697
    Gender:
    Male
    First Name:
    TJ
    Idaho
    Vehicle:
    sold everything
    Ok, another question, would these affect towing at all? I don't haul much. Heaviest is a little flatbed with my rhino on it, probably 2k#.

  7. Mar 16, 2013 at 8:34 PM
    #47
    HomerTaco

    HomerTaco That "grill guy" Vendor

    Joined:
    Mar 28, 2010
    Member:
    #34129
    Messages:
    27,684
    Gender:
    Male
    First Name:
    Craig
    Bucks County Pa.
    Vehicle:
    07' DCSB cut to pieces...
    Core-Hurst short throw shifter & T-handle / Carbon Fiber Interior / custom console light / De-badged / leather interior / Heated Front seats / Red Line Hood Struts / Painted speaker grills /one-off TRD Satoshi Grill/ Pioneer AVIC-X920BT HU / Scangauge II / Black LED Tails / Dash Mount for iPad / Safari Snorkel / Illuminated 4x4 switch / Leer 100XQ Cap / 4x Innovations sliders / Rear Diff Breather Mod / front windows tinted to 35% / Brute Force Fab Hybrid Front Bumper / BAMF Rear Diff Skid / Budbuilt Skids / CBI Trail Master 2.0 rear hybrid bumper / Fox rr coils/ TC UCA's/ TC spindle gussets/ TC Cam Tab gussets / Dakar leafs / Defined Engineering shackles / All pro U bolt flip / Timbren Rear Bumpstops / BAMF LCA skids / Exhaust Dump / Fog Light anytime Mod / LowRange Off Road extended rear brake lines / ATO Shackle Flip / sectioned Bushwhacker flares / re-geared to 4.56 / ARB Front & Rear Locking Diff / ARB CKMA12 compressor / PrInSu full rack system / 1" body lift
    I tow a trailer w/ 2 ATV's with no issues... :notsure:

  8. Mar 16, 2013 at 8:37 PM
    #48
    OZ-T

    OZ-T Did you get your precious photos ?

    Joined:
    Dec 15, 2009
    Member:
    #27584
    Messages:
    24,983
    Gender:
    Male
    First Name:
    Peter North
    British Columbia
    Vehicle:
    Mag Grey 09 Trd Sport DCLB 4x4
    OME 885x , OME shocks and Dakars , Wheelers SuperBumps front and rear , 275/70/17 Hankook ATm , OEM bed mat , Weathertech digifit floor liners , Weathertech in-channel vents , headache rack , Leer 100RCC commercial canopy , TRD bedside decals removed , Devil Horns by Andres , HomerTaco Satoshi
    OME not OEM :)

  9. Mar 16, 2013 at 8:45 PM
    #49
    HomerTaco

    HomerTaco That "grill guy" Vendor

    Joined:
    Mar 28, 2010
    Member:
    #34129
    Messages:
    27,684
    Gender:
    Male
    First Name:
    Craig
    Bucks County Pa.
    Vehicle:
    07' DCSB cut to pieces...
    Core-Hurst short throw shifter & T-handle / Carbon Fiber Interior / custom console light / De-badged / leather interior / Heated Front seats / Red Line Hood Struts / Painted speaker grills /one-off TRD Satoshi Grill/ Pioneer AVIC-X920BT HU / Scangauge II / Black LED Tails / Dash Mount for iPad / Safari Snorkel / Illuminated 4x4 switch / Leer 100XQ Cap / 4x Innovations sliders / Rear Diff Breather Mod / front windows tinted to 35% / Brute Force Fab Hybrid Front Bumper / BAMF Rear Diff Skid / Budbuilt Skids / CBI Trail Master 2.0 rear hybrid bumper / Fox rr coils/ TC UCA's/ TC spindle gussets/ TC Cam Tab gussets / Dakar leafs / Defined Engineering shackles / All pro U bolt flip / Timbren Rear Bumpstops / BAMF LCA skids / Exhaust Dump / Fog Light anytime Mod / LowRange Off Road extended rear brake lines / ATO Shackle Flip / sectioned Bushwhacker flares / re-geared to 4.56 / ARB Front & Rear Locking Diff / ARB CKMA12 compressor / PrInSu full rack system / 1" body lift
    Are OME aftermarket shocks longer than OEM?

    The RCD billies have 11" of travel. I'm not sure what OME ones are...

  10. Mar 16, 2013 at 8:47 PM
    #50
    OZ-T

    OZ-T Did you get your precious photos ?

    Joined:
    Dec 15, 2009
    Member:
    #27584
    Messages:
    24,983
    Gender:
    Male
    First Name:
    Peter North
    British Columbia
    Vehicle:
    Mag Grey 09 Trd Sport DCLB 4x4
    OME 885x , OME shocks and Dakars , Wheelers SuperBumps front and rear , 275/70/17 Hankook ATm , OEM bed mat , Weathertech digifit floor liners , Weathertech in-channel vents , headache rack , Leer 100RCC commercial canopy , TRD bedside decals removed , Devil Horns by Andres , HomerTaco Satoshi
    IDK , you said stock shocks I thought you mixed up , but I think there's a thread here with shock lengths , I'll see if I can find it

  11. Mar 16, 2013 at 8:51 PM
    #51
    OZ-T

    OZ-T Did you get your precious photos ?

    Joined:
    Dec 15, 2009
    Member:
    #27584
    Messages:
    24,983
    Gender:
    Male
    First Name:
    Peter North
    British Columbia
    Vehicle:
    Mag Grey 09 Trd Sport DCLB 4x4
    OME 885x , OME shocks and Dakars , Wheelers SuperBumps front and rear , 275/70/17 Hankook ATm , OEM bed mat , Weathertech digifit floor liners , Weathertech in-channel vents , headache rack , Leer 100RCC commercial canopy , TRD bedside decals removed , Devil Horns by Andres , HomerTaco Satoshi
  12. Mar 16, 2013 at 8:52 PM
    #52
    NYCO

    NYCO ┌∩┐‹(ಠ_ಠ)›┌∩┐

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    16,319
    Gender:
    Male
    First Name:
    bOb
    Colorado/Vermont
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    ome is something like 16/24? I have measurements in my build of the collapse/ext lengths but I'm on my phone.

    I was definitely being limited on my down travel then got some 10" Fox and saw big improvements.

  13. Mar 16, 2013 at 8:54 PM
    #53
    NYCO

    NYCO ┌∩┐‹(ಠ_ಠ)›┌∩┐

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    16,319
    Gender:
    Male
    First Name:
    bOb
    Colorado/Vermont
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
  14. Mar 16, 2013 at 8:55 PM
    #54
    OZ-T

    OZ-T Did you get your precious photos ?

    Joined:
    Dec 15, 2009
    Member:
    #27584
    Messages:
    24,983
    Gender:
    Male
    First Name:
    Peter North
    British Columbia
    Vehicle:
    Mag Grey 09 Trd Sport DCLB 4x4
    OME 885x , OME shocks and Dakars , Wheelers SuperBumps front and rear , 275/70/17 Hankook ATm , OEM bed mat , Weathertech digifit floor liners , Weathertech in-channel vents , headache rack , Leer 100RCC commercial canopy , TRD bedside decals removed , Devil Horns by Andres , HomerTaco Satoshi
    Sweet

  15. Mar 16, 2013 at 9:01 PM
    #55
    HomerTaco

    HomerTaco That "grill guy" Vendor

    Joined:
    Mar 28, 2010
    Member:
    #34129
    Messages:
    27,684
    Gender:
    Male
    First Name:
    Craig
    Bucks County Pa.
    Vehicle:
    07' DCSB cut to pieces...
    Core-Hurst short throw shifter & T-handle / Carbon Fiber Interior / custom console light / De-badged / leather interior / Heated Front seats / Red Line Hood Struts / Painted speaker grills /one-off TRD Satoshi Grill/ Pioneer AVIC-X920BT HU / Scangauge II / Black LED Tails / Dash Mount for iPad / Safari Snorkel / Illuminated 4x4 switch / Leer 100XQ Cap / 4x Innovations sliders / Rear Diff Breather Mod / front windows tinted to 35% / Brute Force Fab Hybrid Front Bumper / BAMF Rear Diff Skid / Budbuilt Skids / CBI Trail Master 2.0 rear hybrid bumper / Fox rr coils/ TC UCA's/ TC spindle gussets/ TC Cam Tab gussets / Dakar leafs / Defined Engineering shackles / All pro U bolt flip / Timbren Rear Bumpstops / BAMF LCA skids / Exhaust Dump / Fog Light anytime Mod / LowRange Off Road extended rear brake lines / ATO Shackle Flip / sectioned Bushwhacker flares / re-geared to 4.56 / ARB Front & Rear Locking Diff / ARB CKMA12 compressor / PrInSu full rack system / 1" body lift
    Thx OZ. ;)

    So the rear OME shocks are slightly less than 24" fully extended.

    The RCD's i have are 27.28" fully extended.

  16. Mar 16, 2013 at 9:01 PM
    #56
    skidooman

    skidooman I'm your huckleberry

    Joined:
    Apr 6, 2011
    Member:
    #54438
    Messages:
    4,697
    Gender:
    Male
    First Name:
    TJ
    Idaho
    Vehicle:
    sold everything
    Too slow.

  17. Mar 16, 2013 at 9:02 PM
    #57
    OZ-T

    OZ-T Did you get your precious photos ?

    Joined:
    Dec 15, 2009
    Member:
    #27584
    Messages:
    24,983
    Gender:
    Male
    First Name:
    Peter North
    British Columbia
    Vehicle:
    Mag Grey 09 Trd Sport DCLB 4x4
    OME 885x , OME shocks and Dakars , Wheelers SuperBumps front and rear , 275/70/17 Hankook ATm , OEM bed mat , Weathertech digifit floor liners , Weathertech in-channel vents , headache rack , Leer 100RCC commercial canopy , TRD bedside decals removed , Devil Horns by Andres , HomerTaco Satoshi
    Big difference alright

  18. Mar 16, 2013 at 9:38 PM
    #58
    dcvt16

    dcvt16 Well-Known Member

    Joined:
    Oct 29, 2012
    Member:
    #90077
    Messages:
    238
    Gender:
    Male
    First Name:
    Ehren
    PDX
    Vehicle:
    MGM long travel 5lug
    Total Chaos 5 lug long travel kit, Fox coilovers. Mcneil fiberglass. Defined engineering sua, 14 in kings, Defined shock hoops rear. Weathertech digital liners and vent visors. Paint match grille and added fogs. 4.56 gears, detriot truetrac LSD (gear type), LCE header
    Order placed. Hope these work on the 5 lug. Leafs are same length as 6 lug..

  19. Mar 18, 2013 at 10:11 AM
    #59
    ArmorTech

    ArmorTech [OP] Well-Known Member

    Joined:
    Dec 3, 2012
    Member:
    #92339
    Messages:
    223
    Gender:
    Male
    First Name:
    Adam
    Most likely. You will want a 16/27 shock to maximize both the use of the kit and the life of your shocks.

    There should be no difference while towing.

    Thank you for the order!

  20. Mar 18, 2013 at 8:04 PM
    #60
    jandrews

    jandrews Carolina Alliance Southwest Region Ambassador

    Joined:
    Jun 7, 2009
    Member:
    #18122
    Messages:
    12,235
    Gender:
    Male
    Vehicle:
    '09 FourDubDee TRD OR
    A-TRUCK, Fat Kid in the Bed, Custom Pinstriping, Ported and Polished Muffler Bearing, Hi-Performance Bed Mat
    For those wondering, to fully maximize axle travel with use of a shackle flip kit, you're gonna need replacement brake lines and I would bet at least a 12" shock. More may be better.

    Obviously, travel characteristics vary a bit depending on your spring pack, rate, and shackle setup. That said, with OME leafs and a (one off custom) ATO kit with a 3" shackle I was pulling ~13" of travel eyelet to eyelet at the stock shock mounts. A 12" shock wouldn't have done the trick. I ended up with some custom fab to stuff a 15" travel Icon shock under each fender. But that involved more rigamarole than most here will want to deal with.

    My recommendation: Get the shackle flip in, get the brake lines extended, then take your shocks off the rear axle, cycle and measure exactly what your shock travel will need to be. Set up bumpstops accordingly, then order shocks. Until then, either leave the shocks off or stay on pavement.

    Life gets a lot easier if you're willing to relocate the shock mounts. But then, it gets pricier as well.
