Stuck in 4hi

Discussion in 'Technical Chat' started by hryn88, Oct 23, 2010.

  1. Oct 23, 2010 at 12:28 PM
    #1
    hryn88

    hryn88 [OP] Member

    Joined:
    Oct 23, 2010
    Member:
    #45110
    Messages:
    15
    Gender:
    Male
    Iowa
    Vehicle:
    08 Trd off road
    Truxedo bed cover Grill guard
    I have been trying to periodically use my 4wd hi when I am on gravel roads etc. Lately it has been taking it's sweet time going from 2wd to 4. Today I shifted into 4wd and it went right in but then when I selected 2wd it just flashes continuously on the cluster. I was thinking maybe the actuator is just stuck. Any ideas?

    08 Tacoma trd offroad
    68k miles

  2. Oct 23, 2010 at 12:30 PM
    #2
    eight3one_offroad

    eight3one_offroad Honey your two French Fries short of a Happy Meal.

    Joined:
    Dec 8, 2009
    Member:
    #27261
    Messages:
    742
    Gender:
    Male
    First Name:
    Richard
    Santa Cruz, California
    Vehicle:
    TRD Sport 4x4 with a few things.
    Optima Red Top 34R, OME 885 / N140S + 5100 rear, TSB leaf pack, Camburg Ball Joint UCA, Wheelers Diff drop, AEM Brute Force Intake with filter wrap, Summit Super Turbo muffler, Llumar 5% tint, Pioneer single din head unit, PIAA 510 Ion Crystal Fogs in stock location, Sonar LED tails. Sway Bar removal. Charcoal filter delete. Stant 11509 Locking Gas Cap.
    Try putting it in Neutral then shift from 4H to 2.

    - Rich

  3. Oct 23, 2010 at 1:10 PM
    #3
    Janster

    Janster Old & Forgetful

    Joined:
    Mar 25, 2007
    Member:
    #1138
    Messages:
    14,253
    Gender:
    Female
    First Name:
    Jandy
    Lancaster, PA
    Vehicle:
    2016 GMC Canyon SLT w/ LineX and....
    What are you doing when you're switching it in & out of 4WD.?
    If there is any 'torque' on the driveline - it won't engage/disengage.

    When engaging/disengaging 4WD - be on flat ground and if you're moving - take your foot off the gas. Sometimes if you turn the wheels left to right - can help relieve the torque on the front axle shafts.

    And if all that doesn't help...try stopping and moving the truck in reverse a little bit, try again. Move forward, try again.

  4. Oct 24, 2010 at 8:58 AM
    #4
    hryn88

    hryn88 [OP] Member

    Joined:
    Oct 23, 2010
    Member:
    #45110
    Messages:
    15
    Gender:
    Male
    Iowa
    Vehicle:
    08 Trd off road
    Truxedo bed cover Grill guard
    still nothing. I think the actuator is stuck because usually when i open my door and turn the selector I can here it click. It's completely silent right now. I have tried p, r, n, d, flat surface, on a small hill, rocking it, pry bar to the t-case j/k. Looks like Ill just take it to shop some time this week. Luckily I have a back up beater. Any ideas what the cost is for a new actuator?

  5. Oct 25, 2010 at 4:11 AM
    #5
    Janster

    Janster Old & Forgetful

    Joined:
    Mar 25, 2007
    Member:
    #1138
    Messages:
    14,253
    Gender:
    Female
    First Name:
    Jandy
    Lancaster, PA
    Vehicle:
    2016 GMC Canyon SLT w/ LineX and....
    Have you crawled underneath and checked for some obvious problems? Wires and/or vacuum hoses being disconnected?

    P.s. Don't use a pry bar on the t-case. :rolleyes:

  6. Oct 25, 2010 at 5:50 PM
    #6
    hryn88

    hryn88 [OP] Member

    Joined:
    Oct 23, 2010
    Member:
    #45110
    Messages:
    15
    Gender:
    Male
    Iowa
    Vehicle:
    08 Trd off road
    Truxedo bed cover Grill guard
    yes everything looks good I unhooked the one wide black plug and hooked it back up. Today when i went to move the truck back a few feet in the driveway i heard a click and the indicator light on the cluster went solid. So it must have made a complete connection with the front wheels. When I switched the dial back to 2hi it still blinks though. I have an appointment at the local shop Wednesday, they are pretty knowledgeable. Fingers crossed.. hopefully it doesn't make me dig too deep in the pocketbook.

    Thanks for the advice so far. much appreciated!

  7. Oct 26, 2010 at 10:38 AM
    #7
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,928
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
  8. Oct 30, 2010 at 7:45 PM
    #8
    hryn88

    hryn88 [OP] Member

    Joined:
    Oct 23, 2010
    Member:
    #45110
    Messages:
    15
    Gender:
    Male
    Iowa
    Vehicle:
    08 Trd off road
    Truxedo bed cover Grill guard
    So I took the truck in to the local shop, they were able to get it out of 4wd and told me the actuator was stuck but they greased it up and it was working fine. Took the truck around the block and selected 4HI to confirm that it was working properly. When I did that the light just keeps blinking. I went back to the shop and spoke to the mechanic. We took it for a drive and he tried everything.. no luck. When I turn the dial I can hear the actuator on the t-case doing its thing. So this leads me to believe its the vacuum actuator on the front differential that is acting up. I'm either just going to buy a new front diff actuator or take it to the stealership to have them take a look.

  9. Oct 31, 2010 at 3:50 PM
    #9
    hryn88

    hryn88 [OP] Member

    Joined:
    Oct 23, 2010
    Member:
    #45110
    Messages:
    15
    Gender:
    Male
    Iowa
    Vehicle:
    08 Trd off road
    Truxedo bed cover Grill guard
    Does anybody know if I should be able to hear the front actuator when laying under the front of the truck? When the 4wd switch is turned.

  10. Nov 1, 2010 at 4:15 AM
    #10
    Janster

    Janster Old & Forgetful

    Joined:
    Mar 25, 2007
    Member:
    #1138
    Messages:
    14,253
    Gender:
    Female
    First Name:
    Jandy
    Lancaster, PA
    Vehicle:
    2016 GMC Canyon SLT w/ LineX and....
    If you can hear it while sitting inside the truck, then you should hear it while laying underneath it. But - that's just my guess.

    You might want to try jacking up the front end to get the pressure off the wheels (so to speak). Aside from that, it'll give you more room to lay under there. While you're under it, have someone else inside the truck and have them cycle the switch back-n-forth (2WD-4WD hi) while you listen for the actuator.
    Also, while you're down there - you can move the wheels (rotate or turn) to see if that makes any difference.

    I don't even know where the actuator is or what's hooked up to it (assuming its vacuum actuated), but if you can run some tests while pulling certain wires/vacuum hoses on/off to see what happens. Are you sure you have vacuum and all connections are good?
    If you have even the smallest of vacuum leaks, your actuator will be weak and work sporadically. Look for cracks and/or kinks in the vacuum hoses...
