Sundown dual SD3/Hybrid Audio audio build Q & A

Discussion in 'Audio & Video' started by Zac of all trades, May 9, 2016.

  1. Dec 2, 2016 at 1:43 PM
    #141
    ratcityrain

    ratcityrain Well-Known Member

    Joined:
    Jun 3, 2015
    Member:
    #156667
    Messages:
    1,374
    Gender:
    Male
    Seattle, WA
    Vehicle:
    2017 Double Cab Off Road
    OEM Running boards |oemassive headlights | winjet tail lights | led lighting | hid headlight & fogs | oem tri-fold Bed cover | Custom dual JL Audio 10tw3-d4 sub box and custom amp rack | black off road wheels | painted oem grille | jbl door speakers |
    From what I can gather the mounting depth of the SD3-12 will work since that is only 5.25", but they state they want 1.0 cubic feet per sub and not sure if you have that in the box you currently have.

  2. Dec 2, 2016 at 1:59 PM
    #142
    Zac of all trades

    Zac of all trades [OP] FWP Fabrication Vendor

    Joined:
    Jun 9, 2015
    Member:
    #157073
    Messages:
    8,877
    Gender:
    Male
    First Name:
    Zac
    fwpfab.com
    Vehicle:
    2013 4x4 Locked DCLB
    886/5100s/AAL/UCAs/360 armor/RTT/295 17s
    I can rebuild!!!! haha. Not that i want to though. And i think my boxes are around 0.6-0.7 cubic feet. I could play with the design a bit. I know i could modify the passenger side to fit a 12. Maybe run 1 10" and 1 12". I dont know. I like to play with shit and see what happens.

  3. Dec 2, 2016 at 2:01 PM
    #143
    ratcityrain

    ratcityrain Well-Known Member

    Joined:
    Jun 3, 2015
    Member:
    #156667
    Messages:
    1,374
    Gender:
    Male
    Seattle, WA
    Vehicle:
    2017 Double Cab Off Road
    OEM Running boards |oemassive headlights | winjet tail lights | led lighting | hid headlight & fogs | oem tri-fold Bed cover | Custom dual JL Audio 10tw3-d4 sub box and custom amp rack | black off road wheels | painted oem grille | jbl door speakers |
    I'm all over the map too - someday's I want 8's to make it easy, but don't know if I will be happy overall so then I learn towards 10's. I want 12's, but space is such a commodity

  4. Dec 2, 2016 at 10:57 PM
    #144
    manethon

    manethon TTAS

    Joined:
    Oct 9, 2013
    Member:
    #114161
    Messages:
    3,579
    Gender:
    Male
    First Name:
    Steven
    Unknow
    Many
    no mixing sub sizes....

  5. Jan 9, 2017 at 10:25 AM
    #145
    Zac of all trades

    Zac of all trades [OP] FWP Fabrication Vendor

    Joined:
    Jun 9, 2015
    Member:
    #157073
    Messages:
    8,877
    Gender:
    Male
    First Name:
    Zac
    fwpfab.com
    Vehicle:
    2013 4x4 Locked DCLB
    886/5100s/AAL/UCAs/360 armor/RTT/295 17s
    @ETXTacoma

    Biscuits likes this.
  6. Jan 9, 2017 at 10:30 AM
    #146
    Zac of all trades

    Zac of all trades [OP] FWP Fabrication Vendor

    Joined:
    Jun 9, 2015
    Member:
    #157073
    Messages:
    8,877
    Gender:
    Male
    First Name:
    Zac
    fwpfab.com
    Vehicle:
    2013 4x4 Locked DCLB
    886/5100s/AAL/UCAs/360 armor/RTT/295 17s
    Why do you say no mixing? Back in 2002 i had a friend running 2 12s and 2 10s in the back of an accura integra hatchback and it sounded good! There were sealed boxes, not sure how many amps though...

  7. Jan 9, 2017 at 3:33 PM
    #147
    manethon

    manethon TTAS

    Joined:
    Oct 9, 2013
    Member:
    #114161
    Messages:
    3,579
    Gender:
    Male
    First Name:
    Steven
    Unknow
    Many
    To be honest, there isn't really a point to it. Your way better off running all the same size, changing box type etc if you want a better sound or different sound.
    There are numerous issues with running different size subs. They all have to run off their own amps, be in their own respective enclosures and also have their own band width to play within. I.e having a 10 and 12 play the same freq impacts the over all sound stage in a negative way.

    The sub freq range is not really large enough 20-60/80hz to really run multi sized subs unless you do 15/18 vs 8/10s for mid bass
    I can go more into it but this is the general concept and theory

  8. Jan 9, 2017 at 6:18 PM
    #148
    rob feature

    rob feature Tacos!

    Joined:
    Aug 10, 2011
    Member:
    #61468
    Messages:
    1,770
    Gender:
    Male
    Colorado
    Vehicle:
    2003 4x4 V6 X-Cab SR5
    Shocks. Pegs. Lucky.
    I had this conversation with someone I trust with such matters recently - he runs the back of house for a busy local shop. He's also of the opinion that multiple sub types/sizes, etc will cause issues - mostly with phase. Seems to me with the right DSP in the right hands, you could make it work, but it may be a challenge. My proposal was 2 subs - a dedicated low-range subwoofer (20-45 Hz) and a more traditional subwoofer (~50 - 120ish). People use dedicated midbasses, so why not, right? Apparently he's tried this a number of times and the results have been disappointing.

    Zac of all trades[OP] likes this.
  9. Jan 9, 2017 at 7:15 PM
    #149
    manethon

    manethon TTAS

    Joined:
    Oct 9, 2013
    Member:
    #114161
    Messages:
    3,579
    Gender:
    Male
    First Name:
    Steven
    Unknow
    Many
    Its possible to achieve in a home audio setup but not so much in an auto application unless you do those big Brazilian builds made for outdoor sound stages.
    There is Nothing wrong with having a Super strong mid bass build 60hz+ played by 8/10 inch mid bass woofers with your Traditional subs playing sub 60hz if you have some serious bass! Like when i had 4 15s walled and playing music 154db. ( SQ is not a factor at this point ) but the punch from a big mid bass setup is unreal and required with a big low tuned box made for big bass. Your double kicks aren't there anymore so its needed BUT the reality of the situation is on an every day vanilla regular setup in 99% of these trucks there is ZERO point, not even in a hatch etc. If the application calls for it and there is actual reason to do so, I'm sure it can be done right but out of practicality wouldn't work really in our trucks.

    As you said, serious processing would be required and phase will be a pain in the ass and you will be messing with your eq all day long on every genre

  10. Jan 10, 2017 at 8:49 AM
    #150
    Zac of all trades

    Zac of all trades [OP] FWP Fabrication Vendor

    Joined:
    Jun 9, 2015
    Member:
    #157073
    Messages:
    8,877
    Gender:
    Male
    First Name:
    Zac
    fwpfab.com
    Vehicle:
    2013 4x4 Locked DCLB
    886/5100s/AAL/UCAs/360 armor/RTT/295 17s
    Im glad that people are trying the things i am thinking about! Haha. Thanks for the input!
    Phase!!!! Didnt think about that.... I dont really have much room to play with speaker placement either. Oh well...

    Ok so now i am looking at silver flutes....
    https://www.madisoundspeakerstore.c.../silver-flute-w17rc38-04-ohm-6-1/2-wool-cone/
    i would put these in the rear doors, these would be probably powered by my Factory HU but i would put some passive crossovers on them. I have a set that was not used as i went with a front stage setup.

    Also they would be replacing some Hybrid Audio 6.5 convertible coaxial speakers. Would i be better off keeping the Hybrids, or would the silver flutes provide a bit better mid bass?

  11. Jan 10, 2017 at 8:55 AM
    #151
    HAVVOKK

    HAVVOKK Well-Known Member

    Joined:
    Apr 1, 2015
    Member:
    #152280
    Messages:
    9,086
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2014 DGAF Long Bed
    Fucking look it up
    So I haven't done my door speakers yet so I have a couple questions. Did you sound deaden the doors? Did you need an adapter to fit the 6x9 and what do you mean by if you mount the subs the rattles will go away I have almost this same set up with different components and get rattles all the time it drives me nuts

  12. Jan 10, 2017 at 9:14 AM
    #152
    Zac of all trades

    Zac of all trades [OP] FWP Fabrication Vendor

    Joined:
    Jun 9, 2015
    Member:
    #157073
    Messages:
    8,877
    Gender:
    Male
    First Name:
    Zac
    fwpfab.com
    Vehicle:
    2013 4x4 Locked DCLB
    886/5100s/AAL/UCAs/360 armor/RTT/295 17s
    Yes i dampened the shit out of my front doors, overkill for sure but i wanted to try to kill some road noise also. Ive seen many people just put some dampener around the speaker hole on the inside shell, and then a small piece on the outer shell. They seem to be happy with it...

    You will need the door adapters, the factory speakers are almost molded into the mounts so you can not remove the factory speakers from the mounts. Taco Tunes has some "budget friendly" adapters made of plastic, I got mine from Mr Marv made of MDF.

    If you mount the woofer box to the rear panel then the box will not rattle as much. HUGE difference!

    HAVVOKK[QUOTED] likes this.
  13. Jan 10, 2017 at 9:25 AM
    #153
    HAVVOKK

    HAVVOKK Well-Known Member

    Joined:
    Apr 1, 2015
    Member:
    #152280
    Messages:
    9,086
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2014 DGAF Long Bed
    Fucking look it up
    OK I already have my sound deadner ready just have to install will need to order the speaker adapters and mount the subs. Did you just use some L brackets and screw into back of truck and box? @Mr Marv how can I order your adapters?

  14. Jan 10, 2017 at 9:56 AM
    #154
    Mr Marv

    Mr Marv 1-831-383-0308 7am-10pm pst Vendor

    Joined:
    Mar 6, 2007
    Member:
    #1009
    Messages:
    992
    Gender:
    Male
    First Name:
    Marv
    Monterey Bay California
    Vehicle:
    Custom Built Enclosures/speaker adapters etc
    I custom make each set to ensure proper fitment so just send me a message with specs on the speakers you have (or a link to the owners manual) and I'll get a cost for you.

  15. Jan 10, 2017 at 11:08 AM
    #155
    HAVVOKK

    HAVVOKK Well-Known Member

    Joined:
    Apr 1, 2015
    Member:
    #152280
    Messages:
    9,086
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2014 DGAF Long Bed
    Fucking look it up
    OK cool. I haven't bought my speakers yet was gunna message you and find out a few things I hate the box I have will pm you

    Zac of all trades[OP] likes this.
  16. Jan 10, 2017 at 2:55 PM
    #156
    Zac of all trades

    Zac of all trades [OP] FWP Fabrication Vendor

    Joined:
    Jun 9, 2015
    Member:
    #157073
    Messages:
    8,877
    Gender:
    Male
    First Name:
    Zac
    fwpfab.com
    Vehicle:
    2013 4x4 Locked DCLB
    886/5100s/AAL/UCAs/360 armor/RTT/295 17s
    No i just used self tapping screws, mounted each box to the floor and to the back wall.

  17. Jan 10, 2017 at 3:22 PM
    #157
    HAVVOKK

    HAVVOKK Well-Known Member

    Joined:
    Apr 1, 2015
    Member:
    #152280
    Messages:
    9,086
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2014 DGAF Long Bed
    Fucking look it up
    Sweet will mount mine tonight hope that helps till Mr Marv gets ahold of my wallet

  18. Jan 10, 2017 at 6:48 PM
    #158
    rob feature

    rob feature Tacos!

    Joined:
    Aug 10, 2011
    Member:
    #61468
    Messages:
    1,770
    Gender:
    Male
    Colorado
    Vehicle:
    2003 4x4 V6 X-Cab SR5
    Shocks. Pegs. Lucky.
    Not sure which HATs you have, so hard to say how that would work out. Here's this though - your factory head unit isn't going to give either of them enough to keep up with the rest of your system and certainly not for midbass. I have 75W available to each of the 5.5 inch flutes & am pretty sure I could feed them a good bit more. You're talking about a larger driver with maybe 1/10 that power. I think without a good DSP and at least one more channel with WAY more than head unit power it wouldn't be worth the effort. If I were to go down that road though, I'd probably use the Flutes for a bit more cone area (I'm thinking you either use a phase plug or coax mode with the HAT...both eat cone area). Then again, the HATs are installed and paid for.

    Edit - guess I could have just read your first post. The Flutes will give you more cone area and much greater X-max. I'd totally go with the Flutes and offer them at least 100W each.

    Last edited: Jan 10, 2017
  19. Jan 11, 2017 at 1:42 PM
    #159
    Zac of all trades

    Zac of all trades [OP] FWP Fabrication Vendor

    Joined:
    Jun 9, 2015
    Member:
    #157073
    Messages:
    8,877
    Gender:
    Male
    First Name:
    Zac
    fwpfab.com
    Vehicle:
    2013 4x4 Locked DCLB
    886/5100s/AAL/UCAs/360 armor/RTT/295 17s
    How did it work out for you?

  20. Jan 11, 2017 at 1:46 PM
    #160
    HAVVOKK

    HAVVOKK Well-Known Member

    Joined:
    Apr 1, 2015
    Member:
    #152280
    Messages:
    9,086
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2014 DGAF Long Bed
    Fucking look it up
    Haha went back there to go do it and realized I'm going to need a bit of time to get it mounted haha thought it would be a 5 second job UT Tunstall out I gotta have some finesse so I'll get back at it tomorrow night and get them screwed in. Thanks for the tip though
