The SR thread, let's see them!

Discussion in '3rd Gen. Tacomas (2016+)' started by jeepinoutwest, Jan 19, 2016.

  1. Jun 12, 2020 at 9:21 AM
    #4741
    davidstacoma

    davidstacoma Well-Known Member

    Joined:
    Nov 2, 2019
    Member:
    #309695
    Messages:
    292
    Gender:
    Male
    First Name:
    David
    NC
    Vehicle:
    2019 Tacoma SR Access cab - Utility
    * Intermittent wiper mod * GE Megalight Ultra +130 low beams installed * Bed Extender (factory, dealer install)
    Where does that little blue and green striped piece in the upper right of the photo go? o_O
    How much lift? For bigger tires?

    MikeyD.25 likes this.
  2. Jun 12, 2020 at 10:04 AM
    #4742
    skierd

    skierd Well-Known Member

    Joined:
    Mar 11, 2018
    Member:
    #247038
    Messages:
    921
    Gender:
    Male
    First Name:
    David
    Fairbanks, AK
    Vehicle:
    2017 SR DCSB
    Every parent needs a small child distraction device, especially when working on vehicles on jack stands. :thumbsup:

    2” front and rear. The rear shocks and springs suck when loaded up, either pulling our camper or full of product for work deliveries, so I got an AAL and 5100’s. Since the backs going up I figured I should do the front too. :spending: I’ve already got 255/85r16’s.

    Burns and davidstacoma like this.
  3. Jun 12, 2020 at 12:54 PM
    #4743
    skierd

    skierd Well-Known Member

    Joined:
    Mar 11, 2018
    Member:
    #247038
    Messages:
    921
    Gender:
    Male
    First Name:
    David
    Fairbanks, AK
    Vehicle:
    2017 SR DCSB
    Halfway done DA47D6CE-2FA8-4CA8-B315-A791BB5A61EB.jpg

  4. Jun 12, 2020 at 1:45 PM
    #4744
    Fleischwagen

    Fleischwagen 2.7 > 3.5

    Joined:
    Aug 8, 2017
    Member:
    #226281
    Messages:
    207
    Gender:
    Male
    North Jersey
    Vehicle:
    2017 SR 5MT 4X4
    6112/5100, Deaver AAL, LCE 2TR Header, aFe dry-flo intake filter, CBI T3 Front, Warn Winch, Ditch LEDs, CB/VHF Radio equipment, Backrack, KC G4 foglights
    I gotta make the jump to the 255/85, looks perfect on these trucks

    davidstacoma likes this.
  5. Jun 12, 2020 at 6:24 PM
    #4745
    skierd

    skierd Well-Known Member

    Joined:
    Mar 11, 2018
    Member:
    #247038
    Messages:
    921
    Gender:
    Male
    First Name:
    David
    Fairbanks, AK
    Vehicle:
    2017 SR DCSB
    Buttoned up, all done!

    before:

    After:
    1830D9BE-E0A8-49B9-BA37-28B89A1B8FF3.jpg 3486F9C3-EC1B-481F-878F-026E916B4224.jpg

    BobcatSR, bbahunter, Snaeper and 4 others like this.
  6. Jun 12, 2020 at 6:25 PM
    #4746
    Fleischwagen

    Fleischwagen 2.7 > 3.5

    Joined:
    Aug 8, 2017
    Member:
    #226281
    Messages:
    207
    Gender:
    Male
    North Jersey
    Vehicle:
    2017 SR 5MT 4X4
    6112/5100, Deaver AAL, LCE 2TR Header, aFe dry-flo intake filter, CBI T3 Front, Warn Winch, Ditch LEDs, CB/VHF Radio equipment, Backrack, KC G4 foglights
    Love it, kinda wish I found a red one, silver is pretty boring but I couldn't find any other 5MT ones by me

    skierd likes this.
  7. Jun 12, 2020 at 6:38 PM
    #4747
    Fleischwagen

    Fleischwagen 2.7 > 3.5

    Joined:
    Aug 8, 2017
    Member:
    #226281
    Messages:
    207
    Gender:
    Male
    North Jersey
    Vehicle:
    2017 SR 5MT 4X4
    6112/5100, Deaver AAL, LCE 2TR Header, aFe dry-flo intake filter, CBI T3 Front, Warn Winch, Ditch LEDs, CB/VHF Radio equipment, Backrack, KC G4 foglights
    Big round driving lights or bust!


  8. Jun 12, 2020 at 6:59 PM
    #4748
    davidstacoma

    davidstacoma Well-Known Member

    Joined:
    Nov 2, 2019
    Member:
    #309695
    Messages:
    292
    Gender:
    Male
    First Name:
    David
    NC
    Vehicle:
    2019 Tacoma SR Access cab - Utility
    * Intermittent wiper mod * GE Megalight Ultra +130 low beams installed * Bed Extender (factory, dealer install)
    Looking good! I like the setup, may do something like that when it’s time to replace my tires. Did you have any clearance issues with the larger tires before the lift? How much effect on gas milage? Some big cleats on those tires, should be good for rough dirt roads and snow. Side steps like mine, Tygers?

  9. Jun 12, 2020 at 8:33 PM
    #4749
    skierd

    skierd Well-Known Member

    Joined:
    Mar 11, 2018
    Member:
    #247038
    Messages:
    921
    Gender:
    Male
    First Name:
    David
    Fairbanks, AK
    Vehicle:
    2017 SR DCSB
    They’re 255/85r16 Maxxis Bighorn MT-762’s, by the specs they’re 33.2” tall. They rubbed on the front mudflaps on big bumps and and there’s a polish mark on the UCA’s, nothing I’m worried about. I lost about 1mpg on the highway and 2mpg in town. I’m still getting 20mpg Highway, 17-18 in town, and 14 mph towing our pop up trailer.

    Lift is 5100’s front (on the top perch) and rear, and a tuff country 85250 2” single AAL. Rides great! It’s much more controllable on big road bumps and the washboards on the dirt roads by the house. It feels properly
    damped finally and imo the stock rear springs are way too soft.

    Greenbean and davidstacoma like this.
  10. Jun 12, 2020 at 9:37 PM
    #4750
    davidstacoma

    davidstacoma Well-Known Member

    Joined:
    Nov 2, 2019
    Member:
    #309695
    Messages:
    292
    Gender:
    Male
    First Name:
    David
    NC
    Vehicle:
    2019 Tacoma SR Access cab - Utility
    * Intermittent wiper mod * GE Megalight Ultra +130 low beams installed * Bed Extender (factory, dealer install)
    Excellent info, I appreciate it! I don’t typically carry a lot of weight in the back but thinking of getting either a Gator Tailback hard cover or a softopper for camping gear, both of those are pretty light. I’d love an aluminum camper shell but sometime haul brush out so need something I can take off easily. I’d love to have a setup like yours if I ever go on long cross country trips sometimes on unimproved roads, I made a 8000 mile trip all around the US and Canada like that with a fiberglass camper shell years ago in an Ford F-150 and want to do maybe a shorter trip like that again in my Tacoma.

    Last edited: Jun 12, 2020
  11. Jun 12, 2020 at 10:44 PM
    #4751
    skierd

    skierd Well-Known Member

    Joined:
    Mar 11, 2018
    Member:
    #247038
    Messages:
    921
    Gender:
    Male
    First Name:
    David
    Fairbanks, AK
    Vehicle:
    2017 SR DCSB
    I’ve only put 20 miles on this setup so far but I’m so happy with it. The damping is so much better overall than the stock SR shocks its not even funny.

    I decided on this setup based on a ton of reading on here and info on various vender sites. I felt the front spring rates (and therefore springs) were fine, especially since several of the lift springs for this truck are nearly the same spring rate as stock just longer overall. The front 5100’s are longer than stock to compensate for 2” of lift:

    So that choice was done: 5100’s only up front. I wanted to match shocks front and rear, so I got the full set.

    I went with a single AAL because I do carry heavy loads pretty frequently both for work and for home, and we camp and pull a trailer. Just from how the truck rode stock I knew the stock rear springs were way too soft and the shocks are severely under-damped too, not helped by the fact that I think the drivers side was leaking oil.

    A lot of people on here complain that the single AAL rides harsh compared to the 3 leaf setups. I wanted to know why... So I found a calculator online for figuring out leaf spring spring rates and did the math. Stock mathed out to about 400#; 3 leafs, overload in, at 650; the single AAL at 950. I’m not afraid of heavy spring rates, and with the heavy tires and heavy loads I decided I was ok with the single AAL.

    So far I think I was 100% correct. The back end is so much more controllable over washboard roads and big frost heaves. The front end feels great. I took my truck down a rutted up forest road and it’s so much better there too.

    davidstacoma likes this.
  12. Jun 13, 2020 at 12:52 AM
    #4752
    supamedik

    supamedik New Member

    Joined:
    Jun 12, 2020
    Member:
    #331243
    Messages:
    1
    Gender:
    Male
    First Name:
    Manny
    Vehicle:
    2017 Taco
    F31A8AED-9D86-4129-8131-30F7B279A310.jpg A7413D1D-7553-4C34-9822-FE1DD6154677.jpg
    Just got mine about 2 weeks ago. Looking for some inspiration not sure which route to go.

    bbahunter and davidstacoma like this.
  13. Jun 13, 2020 at 3:10 AM
    #4753
    Blockhead

    Blockhead Well-Known Member

    Joined:
    Jun 6, 2015
    Member:
    #156849
    Messages:
    1,409
    Gender:
    Male
    Pittsburgh, Pa.
    Vehicle:
    2019 magnetic gray DCLB
    Nice-looking truck :thumbsup:

    Fleischwagen likes this.
  14. Jun 13, 2020 at 10:34 PM
    #4754
    Snaeper

    Snaeper Four Cylinders Strong!

    Joined:
    Jan 9, 2018
    Member:
    #240752
    Messages:
    784
    Gender:
    Male
    First Name:
    Martin
    Phoenix, AZ
    Vehicle:
    2019 Quicksand SX 2.7 4x4
    SnugTop Rebel, Infinity Kappa's, ToughDog 40mm
    Joined @skierd in the lifted SR club this weekend. Had some help to put the Tough Dog kit on.


    Had been researching suspension options for ages and finally settled on these because they seemed to check all of my boxes. This is the first kit they have made for a Tacoma, but the Land Cruiser guys love these shocks. Ride is great and there's no strange vibes or other issues yet. Very happy.


    Shocks are 40mm twin tubes with rebound adjustability. They are foam cell shocks to combat fade and increase shock's cooling ability as more oil can be imbued within and allow more air to cool it on the larger shock body.

    Shocks were paired with a Headstrong AAL and that has worked marvels so far.

  15. Jun 14, 2020 at 3:41 PM
    #4755
    Fleischwagen

    Fleischwagen 2.7 > 3.5

    Joined:
    Aug 8, 2017
    Member:
    #226281
    Messages:
    207
    Gender:
    Male
    North Jersey
    Vehicle:
    2017 SR 5MT 4X4
    6112/5100, Deaver AAL, LCE 2TR Header, aFe dry-flo intake filter, CBI T3 Front, Warn Winch, Ditch LEDs, CB/VHF Radio equipment, Backrack, KC G4 foglights
    Is that a newfoundland in your profile pic? I have one as well! 160lbs of hair and slobber hah

    Blockhead likes this.
  16. Jun 14, 2020 at 4:23 PM
    #4756
    Blockhead

    Blockhead Well-Known Member

    Joined:
    Jun 6, 2015
    Member:
    #156849
    Messages:
    1,409
    Gender:
    Male
    Pittsburgh, Pa.
    Vehicle:
    2019 magnetic gray DCLB
    haha Yes it is a Newfi. She passed away 5 yrs ago, still miss her every day. And you’re right, she was 160 lbs of hair and slobber...great dogs, they’re lazy and lovable. :thumbsup:

    ExplorHer, BobcatSR and Fleischwagen like this.
  17. Jun 20, 2020 at 3:05 PM
    #4757
    Monopod

    Monopod Well-Known Member

    Joined:
    Jan 29, 2017
    Member:
    #208973
    Messages:
    368
    Gender:
    Male
    Vehicle:
    2017 Silver sky tacoma SR I4 4x4
    plasti dip emblems, TRD off road wheels, pro clips cell phone mount. 20 percent tint.
    Just added Entune premium radio to my SR. Also put a gps antenna


  18. Jun 20, 2020 at 3:17 PM
    #4758
    09 Redneck

    09 Redneck Well-Known Member

    Joined:
    Jan 17, 2009
    Member:
    #12668
    Messages:
    907
    Gender:
    Male
    Ga
    Looks good. Did you modify your original radio bezel?

  19. Jun 20, 2020 at 8:36 PM
    #4759
    Monopod

    Monopod Well-Known Member

    Joined:
    Jan 29, 2017
    Member:
    #208973
    Messages:
    368
    Gender:
    Male
    Vehicle:
    2017 Silver sky tacoma SR I4 4x4
    plasti dip emblems, TRD off road wheels, pro clips cell phone mount. 20 percent tint.
    I bought the radio bezel from a junk yard for 125.00 and took my outer bezel and put it on the new inner bezel. Also took the black rings off my old bezel and replaced the chrome rings around the vent to match black. Just basically took the stuff i liked off my old bezel and placed it on the new bezel to match the rest of the stuff.

    Snaeper and 09 Redneck like this.
  20. Jun 20, 2020 at 8:38 PM
    #4760
    Monopod

    Monopod Well-Known Member

    Joined:
    Jan 29, 2017
    Member:
    #208973
    Messages:
    368
    Gender:
    Male
    Vehicle:
    2017 Silver sky tacoma SR I4 4x4
    plasti dip emblems, TRD off road wheels, pro clips cell phone mount. 20 percent tint.
    its nice to have HD radio and Nav. XM i dont need but if i want it all i have to do is run the wire and its rdy.

    Greenbean likes this.
