TRD Power Inverter

Discussion in 'Technical Chat' started by HighPlains, Dec 26, 2008.

  1. Dec 26, 2008 at 8:48 AM
    #1
    HighPlains

    HighPlains [OP] Well-Known Member

    Joined:
    Nov 22, 2008
    Member:
    #10954
    Messages:
    127
    Has anyone else with the TRD package that includes the in bed power inverter found it to be totally useless? 100w-400w?! I guess you could run a charger from it but not much else in my estimation.

    So here is the question: Has anyone attempted to replace the stock one with a larger wattage unit? A search of the threads revealed that the stock unit is underneath the center console. Would the wiring and related hardware require upgrading?

  2. Dec 26, 2008 at 8:59 AM
    #2
    lsocoee

    lsocoee My hair is all natural Thor

    Joined:
    Feb 9, 2007
    Member:
    #872
    Messages:
    10,101
    First Name:
    Hotdog
    Vehicle:
    2007 PreRunner SR5 Double Cab
    Wet Okole Underwear
    It really depends on how big you want to go. You could probably upgrade to a 600 Watt inverter and you wouldn't have any issues with wiring in between the outlet and the inverter, but I would want to run a fresh power going directly from the battery and install a relay going to a dash switch. I think that there was a 600(it might have been 800) watt coleman that would fit in the OEM location.

  3. Dec 26, 2008 at 9:32 AM
    #3
    HighPlains

    HighPlains [OP] Well-Known Member

    Joined:
    Nov 22, 2008
    Member:
    #10954
    Messages:
    127
    Are you suggesting the existing wiring and switches/relays are not spec'ed high enough for the larger wattage inverter? I have the worthless stock one now. I have somewhere if I can find it, a 750w Black and Decker inverter. When I first saw the inverter on the TRD trucks, I thought "how innovative is that?". I thought up at least 100 uses. Only later did it occur to me that 400w is only good enough to run very few of the things I dreamed up.
    Thanks.

  4. Dec 26, 2008 at 9:46 AM
    #4
    lsocoee

    lsocoee My hair is all natural Thor

    Joined:
    Feb 9, 2007
    Member:
    #872
    Messages:
    10,101
    First Name:
    Hotdog
    Vehicle:
    2007 PreRunner SR5 Double Cab
    Wet Okole Underwear
    One of my concerns is the way they switch between 100/400 Watts and Off.

    You also need to realize that the 400W inverter requires roughyl 33 Amps, and the 750W inverter could require as much as 62.5 Amps. Those wires are probably going to need to be about 12 (OEM) and 8 gauge, respectively.

  5. Dec 26, 2008 at 10:02 AM
    #5
    Ahaszard

    Ahaszard Active Member

    Joined:
    Jun 9, 2008
    Member:
    #7189
    Messages:
    42
    St Augustine, FL
    Vehicle:
    08 Black TRD Off Road Rugged Trail
    I use my inverter all the time. I use it for my ARB Fridge/Freezer and it works great!

  6. Dec 26, 2008 at 10:40 AM
    #6
    311offroad

    311offroad Stock Taco For Now

    Joined:
    Sep 11, 2008
    Member:
    #9161
    Messages:
    1,304
    Gender:
    Male
    Milledgeville, GA
    Vehicle:
    2005 TRD OffRoad SR5 4x4 Short Bed Debadged
    20% tint, Debadged, Pioneer AVIC-Z110BT, Infinity component door speakers, MagLite mod
    Nice

    Ive only needed to use mine for charging batteries

  7. Dec 26, 2008 at 10:58 AM
    #7
    sonjay

    sonjay Well-Known Member

    Joined:
    Oct 9, 2008
    Member:
    #9834
    Messages:
    701
    Gender:
    Male
    I got one for christmas to run my vaporizer when I'm camping

  8. Dec 26, 2008 at 11:04 AM
    #8
    lsocoee

    lsocoee My hair is all natural Thor

    Joined:
    Feb 9, 2007
    Member:
    #872
    Messages:
    10,101
    First Name:
    Hotdog
    Vehicle:
    2007 PreRunner SR5 Double Cab
    Wet Okole Underwear
    :confused: I got one too, but I'm planning on running my foot massager and makeup mirror.

  9. Dec 26, 2008 at 12:38 PM
    #9
    Evil Monkey

    Evil Monkey There's an evil monkey in my truck

    Joined:
    Aug 8, 2007
    Member:
    #2352
    Messages:
    8,383
    Gender:
    Male
    First Name:
    Robert
    Escondido, CA
    Vehicle:
    07 4x4 DC SR5 TRD Off-road
    Weathertech front & rear mats, rear suspension TSB, Toytec AAL for TSB, Hi-Lift Jack, Bilstein 5100 & Toytec Adjustable coilovers, Built Right UCAs, KMC XD 795 Hoss Wheels, Definity Dakota MTs 285/75R16, Leer XR, Thule Tracker II & Thule MOAB basket
    So you do a lot of voguing on the trail?
    [​IMG]

  10. Dec 26, 2008 at 12:42 PM
    #10
    lsocoee

    lsocoee My hair is all natural Thor

    Joined:
    Feb 9, 2007
    Member:
    #872
    Messages:
    10,101
    First Name:
    Hotdog
    Vehicle:
    2007 PreRunner SR5 Double Cab
    Wet Okole Underwear
    I'll come up with a response when you come up with a doggy zoolander. :D

  11. Dec 26, 2008 at 1:26 PM
    #11
    Evil Monkey

    Evil Monkey There's an evil monkey in my truck

    Joined:
    Aug 8, 2007
    Member:
    #2352
    Messages:
    8,383
    Gender:
    Male
    First Name:
    Robert
    Escondido, CA
    Vehicle:
    07 4x4 DC SR5 TRD Off-road
    Weathertech front & rear mats, rear suspension TSB, Toytec AAL for TSB, Hi-Lift Jack, Bilstein 5100 & Toytec Adjustable coilovers, Built Right UCAs, KMC XD 795 Hoss Wheels, Definity Dakota MTs 285/75R16, Leer XR, Thule Tracker II & Thule MOAB basket
    [​IMG]

  12. Dec 26, 2008 at 1:41 PM
    #12
    famousfernando

    famousfernando Well-Known Member

    Joined:
    Apr 1, 2008
    Member:
    #5661
    Messages:
    85
    oregon
    Vehicle:
    2007 tacoma trd package 6" fabtech l
    so how does the inverter work i never used it do you have to have the truck running or do you just have to have the key turned on?:confused:

  13. Dec 26, 2008 at 1:57 PM
    #13
    lsocoee

    lsocoee My hair is all natural Thor

    Joined:
    Feb 9, 2007
    Member:
    #872
    Messages:
    10,101
    First Name:
    Hotdog
    Vehicle:
    2007 PreRunner SR5 Double Cab
    Wet Okole Underwear
    those were the days...they used to give out blow for free.

  14. Dec 26, 2008 at 4:19 PM
    #14
    HighPlains

    HighPlains [OP] Well-Known Member

    Joined:
    Nov 22, 2008
    Member:
    #10954
    Messages:
    127
    Yeah, I did not think about the system switching between 100w to 400w and how all that works. I just wish they had made the capacity a little higher. I don't really have anything in particular in mind. I just want to know that if I want to charge my proton pack away from home, I can do it.

    Thanks for the input.

  15. Dec 26, 2008 at 4:43 PM
    #15
    SC4333

    SC4333 Well-Known Member

    Joined:
    Dec 9, 2008
    Member:
    #11412
    Messages:
    2,194
    Gender:
    Male
    First Name:
    Grant
    San Antonio, TX
    Vehicle:
    '08 PreRunner SR5
    SOLD!
    Another wonderful thing... Last year I found out the hard way when on a project out of town, that 12v DC to 120v AC inverters will create reproduced sin wave issues. This will prohibit you from using certain chargers and other sensitive devices from the inverted power source. Doubt this would be of issue for most applications, but it sure did screw my work schedule that weekend.

  16. Mar 27, 2009 at 10:30 PM
    #16
    LEDtoma

    LEDtoma Keep 'em smiling

    Joined:
    Sep 26, 2008
    Member:
    #9490
    Messages:
    8
    Gender:
    Male
    Stanfield NC
    Vehicle:
    05 TRD Sport Pre-runner
    Bed Lights w/Cab & bed switch Inverter in Cab : dual plug, continuous 12V socket & USB power port Anytime driving/fog light OEM DRL install w/on-off Parking light Mod Borla cat-back Fresh air cab filter Engine compartment light Hbeam enable Garage door opener
    I also found that the 400w output (in park) was too low. I go camping alot and needed more power so I installed an 800W Inverter and mounted under the drivers seat. I then extended all wiring to the rear of the center counsel and re-mounted the switch, LEDs and plug. The inverter I choose had a USB output that I also extended to the counsel strictly for the kids to charge their toys. I have since installed a 12V power outlet wired/fused directly to the battery for continuous power.





    Although I take credit for my labor I can't take credit for the know how.
    Please see link below for some awesome ideas/mods.

    http://www.cardomain.com/ride/832238

    Meet Kramer. He loves to ride and I think he loves my truck more than I do...


  17. Sep 16, 2014 at 8:43 AM
    #17
    AnewKINDofFEELIN

    AnewKINDofFEELIN Member

    Joined:
    May 8, 2013
    Member:
    #103762
    Messages:
    16
    Gender:
    Male
    First Name:
    Billy
    Baton Rouge, LA
    Vehicle:
    2013 Double Cab SR5 4x4
    Does anyone know if non-TRD models are pre-wired for an inverter? I'm considering adding one for camping and tailgating, but I''m trying to get an idea of what's there before I go reinventing the wheel.

    2013 TSS. Speaking of which, I need to find a good way to remove those decals.
