TSB T-SB-0213-17: Moisture in Tag Lights

Discussion in '3rd Gen. Tacomas (2016+)' started by panda_taco, May 3, 2017.

  1. May 3, 2017 at 7:15 PM
    #21
    smitty99

    smitty99 I also bought a 4Runner

    Joined:
    Sep 10, 2015
    Member:
    #163923
    Messages:
    13,026
    Gender:
    Male
    Scottsdale
    Vehicle:
    16 TRDORDCSB 4x4 A/T (loaded w/ JBL)
    6112s/5160s & 3-leaf AAL;ubolt flip kit;Superbumps
    Sheesh at least you guys took it easy on me.


    oldschoolczar likes this.
  2. May 4, 2017 at 5:48 AM
    #22
    panda_taco

    panda_taco [OP] Well-Known Member

    Joined:
    May 16, 2016
    Member:
    #187066
    Messages:
    83
    Gender:
    Male
    SWFL
    Vehicle:
    '16 TRD Off-Road 4x4
    I had 40mi on my truck & the crawl control and 4x4 was already broken in quite well. That being said - at my 5k my leafs were squeaking. I mentioned it & the shop foreman came out and told me I needed to stop beating it up off road.. walked him back to the end of the bed side and presented the 4x4 sticker and then proceeded to show him the crawl control panel inside and explained that it was all for OFF ROAD and not exactly PAVEMENT conditions. End result: Leaf springs replaced!:muscleflexing:

    Went in for 10k - normal servicing... oil change, rotation, fluids etc - all good, except tag light was out. Same shop foreman basically says he knows I push this truck hard and it probably had something to do with that. They replaced it on "good will". :jerkoff:

    Fast forward to the 15k service - between the 10k and 15k I developed a very strange "pendulum" swinging in the rear is how I can best describe it as. I then again got the look of "stop beating your truck". I then reverted back to battle plan "A" and presented the 4x4 stickers. They said they'd "take a look at it and let me know..." turns out when they replaced the leafs originally they torqued them down while the truck was in the air, not on the ground (I think that's what they said at least - roles might be reversed) and that's what caused the over torque on the leafs. End result: replaced leafs again. Yay!

    Today, rear tag light is out again. 20k service is coming up.

    Best believe I will be polishing up that bed side sticker to have it ready for show case along with my printed off TSB papers :quickdraw:

  3. May 4, 2017 at 7:54 AM
    #23
    smitty99

    smitty99 I also bought a 4Runner

    Joined:
    Sep 10, 2015
    Member:
    #163923
    Messages:
    13,026
    Gender:
    Male
    Scottsdale
    Vehicle:
    16 TRDORDCSB 4x4 A/T (loaded w/ JBL)
    6112s/5160s & 3-leaf AAL;ubolt flip kit;Superbumps
    Pendulum is either gas in gas tank slopping around or it is a loose spare tire. One you cannot really fix. The other is a quick fix. Let us know how it turns out! Make sure you post your pic of "Chillin in the Service Dept"

  4. May 4, 2017 at 8:09 AM
    #24
    Nitori

    Nitori Well-Known Member

    Joined:
    May 3, 2016
    Member:
    #186058
    Messages:
    3,153
    Tempe AZ
    Vehicle:
    2016 Tacoma SR 6AT 4x2

    Why are you pointing at the 4x4 part and not the part that says "OFF-ROAD" ?? :boink:

  5. May 4, 2017 at 8:17 AM
    #25
    panda_taco

    panda_taco [OP] Well-Known Member

    Joined:
    May 16, 2016
    Member:
    #187066
    Messages:
    83
    Gender:
    Male
    SWFL
    Vehicle:
    '16 TRD Off-Road 4x4
    Stick to specifics when dealing with a dealership. Off-Road could mean driving on grass, or gravel, etc. Plus, there is just a Off-Road trim that looks identical to the 4x4 OR but is NOT 4x4 in which they would pitch you with "well its not the 4x4 so why would you take it there? the vehicle is not meant for that". I was a service advisor - I know how the game works. :hattip:

  6. Jun 22, 2017 at 7:20 PM
    #26
    tallpilot

    tallpilot Well-Known Member

    Joined:
    Feb 19, 2016
    Member:
    #178749
    Messages:
    474
    Gender:
    Male
    First Name:
    David
    Florida
    Vehicle:
    2016 TRD OR 4X4 DC SB AT Silver
    Mobtown sliders, RCI skids, Bilstein 6112/5160/Dakar, DuroBumps
    I got mine fixed not long after I bought it and now a year later they are still clear. I wonder if this would make any difference?

  7. Jun 25, 2017 at 12:32 PM
    #27
    Z50king

    Z50king DCLBOR4X4FTW

    Joined:
    Jun 9, 2015
    Member:
    #157056
    Messages:
    8,467
    Gender:
    Male
    First Name:
    Eric
    Southern California
    Vehicle:
    2016 DCLB Off Road 4x4 Super White
    Stock and loving it
    Toyota only pays the service center for 6 minutes of labor if they replace the entire lamp housings.

    Wow

  8. Jun 25, 2017 at 1:08 PM
    #28
    mesojdm

    mesojdm Major Modder

    Joined:
    Feb 16, 2015
    Member:
    #148809
    Messages:
    10,320
    Gender:
    Male
    State of Jefferson
    Vehicle:
    2016 DCLB TRD OR QS
    Should it take longer? I was thinking 3min. 4 tops

  9. Jun 25, 2017 at 1:47 PM
    #29
    Nitori

    Nitori Well-Known Member

    Joined:
    May 3, 2016
    Member:
    #186058
    Messages:
    3,153
    Tempe AZ
    Vehicle:
    2016 Tacoma SR 6AT 4x2
    Have you ever tried to get one out yourself?

    Maybe I just have giant clumsy hands but you have to reach your hand through a small opening to depress the tabs that hold it in. Took me an hour of cursing and cutting the shit out of my hand.

    ToyoVL likes this.
  10. Jun 25, 2017 at 2:05 PM
    #30
    mesojdm

    mesojdm Major Modder

    Joined:
    Feb 16, 2015
    Member:
    #148809
    Messages:
    10,320
    Gender:
    Male
    State of Jefferson
    Vehicle:
    2016 DCLB TRD OR QS
    Cake. Swapped my bulbs in seconds.(okay, maybe a minute). Bottom tab is easy access, top tab just needs a long hook tool to depress it.
    Luckily I'm switching out to Baja flush's so I'll never have to deal with these POS again

  11. Jun 25, 2017 at 2:09 PM
    #31
    Nitori

    Nitori Well-Known Member

    Joined:
    May 3, 2016
    Member:
    #186058
    Messages:
    3,153
    Tempe AZ
    Vehicle:
    2016 Tacoma SR 6AT 4x2
    Ok well in the absence of a long hook tool fingers will eventually get it, though only once half of your sanity is gone. :rofl:

  12. Jun 25, 2017 at 2:51 PM
    #32
    sethhawaii

    sethhawaii Well-Known Member

    Joined:
    Mar 21, 2016
    Member:
    #181874
    Messages:
    289
    Vehicle:
    2016 TRD offroad 4x4
    no photos of the problem in this thread yet?

  13. Jun 25, 2017 at 2:54 PM
    #33
    Nitori

    Nitori Well-Known Member

    Joined:
    May 3, 2016
    Member:
    #186058
    Messages:
    3,153
    Tempe AZ
    Vehicle:
    2016 Tacoma SR 6AT 4x2
    [​IMG]

    Mine was a mild but recurring case. Others had it completely full of brown muck.

    sethhawaii likes this.
  14. Jun 25, 2017 at 2:59 PM
    #34
    KenLyns

    KenLyns 8-in. Third Member

    Joined:
    May 23, 2010
    Member:
    #37674
    Messages:
    28,919
    Gender:
    Male
    Belly of the Beast
    Vehicle:
    4x4 TRD Off Road Full-Auto
    Pelfrey Bumper, CBI Sliders, Icon Coilovers, BudBuilt Skids, aFe Intake, Icon VS Rear Shocks, Timbren Bumpstops, All-Pro UCAs, JDM Steering Wheel, ViAir Compressor, Klearz LED 3rd Brake Light, Pop-N-Lock Tailgate Handle, Husky Front Flaps
    The dealer is paid 3 hours to replace the wiring harness, which is the actual culprit. Note the lamp housing is being replaced with the same P/N. 6 minutes incremental time to replace the lamp housings is tight but not unreasonable.

    But yeah, dealers typically don't make a profit on warranty work. This is why some dealers are reluctant to do TSBs like rear spring harsh ride - the dealer would prefer to keep the service bays occupied with more profitable out-of-warranty work.

  15. Jun 25, 2017 at 3:06 PM
    #35
    mesojdm

    mesojdm Major Modder

    Joined:
    Feb 16, 2015
    Member:
    #148809
    Messages:
    10,320
    Gender:
    Male
    State of Jefferson
    Vehicle:
    2016 DCLB TRD OR QS
    Here is my toilet bowl light;
    [​IMG]

    Stuart762, 16tacoblue and sethhawaii like this.
  16. Jun 25, 2017 at 3:48 PM
    #36
    Z50king

    Z50king DCLBOR4X4FTW

    Joined:
    Jun 9, 2015
    Member:
    #157056
    Messages:
    8,467
    Gender:
    Male
    First Name:
    Eric
    Southern California
    Vehicle:
    2016 DCLB Off Road 4x4 Super White
    Stock and loving it
    Have you tried sticking your hand up behind the bumper to change the light bulbs with the tow package?

  17. Jun 25, 2017 at 3:50 PM
    #37
    Z50king

    Z50king DCLBOR4X4FTW

    Joined:
    Jun 9, 2015
    Member:
    #157056
    Messages:
    8,467
    Gender:
    Male
    First Name:
    Eric
    Southern California
    Vehicle:
    2016 DCLB Off Road 4x4 Super White
    Stock and loving it
    the wiring harness is only replaced when the parking sensors are wacked. If you don't have parking sensors and have water in your light fixtures, the service center is paid 6 minutes to replace the fixtures

  18. Jun 25, 2017 at 3:56 PM
    #38
    Nitori

    Nitori Well-Known Member

    Joined:
    May 3, 2016
    Member:
    #186058
    Messages:
    3,153
    Tempe AZ
    Vehicle:
    2016 Tacoma SR 6AT 4x2
    No, I have no parking sensors whatsoever on my SR and my harness was replaced.

    The harness is the cause for the water intrusion.

    Previous to this TSB the standard procedure was to only replace the housings, however in most cases the issue was not resolved, even after pointing out that the customer had already recieved 4 or more replacement housings. Toyota finally caught on that this was a symptom and not the cause, and issued the TSB.

    16tacoblue likes this.
  19. Jun 25, 2017 at 3:57 PM
    #39
    KenLyns

    KenLyns 8-in. Third Member

    Joined:
    May 23, 2010
    Member:
    #37674
    Messages:
    28,919
    Gender:
    Male
    Belly of the Beast
    Vehicle:
    4x4 TRD Off Road Full-Auto
    Pelfrey Bumper, CBI Sliders, Icon Coilovers, BudBuilt Skids, aFe Intake, Icon VS Rear Shocks, Timbren Bumpstops, All-Pro UCAs, JDM Steering Wheel, ViAir Compressor, Klearz LED 3rd Brake Light, Pop-N-Lock Tailgate Handle, Husky Front Flaps
    Wrong.

    "For vehicles without blind spot monitor sensors or ultrasonic sensors, use Repair Procedure 2 (page 10)."

    "Repair Procedure 2
    For vehicles without blind spot monitor sensor system and/or ultrasonic sensors, use the following Repair Procedure:
    1. Disconnect the negative (–) battery cable.
    2. Remove the No. 3 frame wire harness and license plate lamp(s).
    ...
    3. Install the NEW No. 3 frame wire harness and license plate lamp(s)."

  20. Aug 29, 2017 at 6:38 AM
    #40
    16tacoblue

    16tacoblue Well-Known Member

    Joined:
    Nov 12, 2015
    Member:
    #169430
    Messages:
    56
    Gender:
    Male
    Vehicle:
    2016 sport taco
    Colored chrome fenders name plates & tailgate emblem flat black.
    I had a total of three tag light fails,on the fourth they replaced it with light and harness ,they didn't give me paperwork I suppose it was covered by the TSB. and still under 25,000 miles .My original post from Mar.
    they tried the "Must have been wheeling" But you'd have to bury the back end to get water in, they will try anything not to fix it correctly.
