Ultragauge Codes

Hey guys, I just ordered an Ultragauge MX 1.4 for my 2012 Tacoma TRDOF 4x4. I’m looking for the codes for my transmission pan temp and my torque converter temp. If anyone has these codes I would greatly appreciate you posting them below. Thank you!



Try here

https://www.tacomaworld.com/threads/ulragauge-trans-temp-err.530988/#post-17003495



Codes for 2012-2015 Trans temps *F:
TDATA: 07E02182
MTCH: 6182
RPOS: 2808
RCTRL:21
TCTRL:92
X: 0009
/: 0005
+: FFD8
Output format: 00
Left/Right is 31

From https://www.tacomaworld.com/threads/ultragauge-transmission-temp.318340/

My 07 trany has two ATF temp sensors, one for pan temp and one for torque converter. And my UltraGauge can display temps from both sensors. Don't know about the 2012, you may have do read the threads.



Ok I’ll give this a try when it comes in. Hopefully it works! Thank you guys



Wireless or Wired model. Assume wireless is fully programmable?? If wired you need the MXv1.4 variant and the codes are here:
https://ultra-gauge.com/ultragauge/support/UG-MX1.4-Supplement.pdf



Thank you! I ordered the mx1.4. I appreciate the link. Thank you.
