What Have You Done To Your 3rd Gen Today?

1st Oil change and did the AC drain Mod tube. Added a couple pieces of mesh in the tube because we have such a large population of mud wasp. Those things build a nest in every hole they can find if it isn't moving.



Installing these today.



mmm KC lighting.



would you mind letting me know which dealership you were at?



Looks great! One of the many items on my wish list...



Well, this has quickly gone sideways. Blows the 3A fuse immediately upon hitting the switch. One light or two. No visible shorts and wired correctly. Any ideas out there?



Amp Draw: 6.7A @ 12V



Got a matching hood decal for my bedside one...



Other than they're demon brackets?



This is when I tell you I can speak Japanese and am an air traffic controller. Then follow it up with I know nothing about wiring lights. I'm just following the directions and using the harness KC provided. Did they likely send me the wiring harness for something with a smaller draw i.e. Flex Era 3 (3.4)?


From the power source before the relay is a 25A fuse. That wire goes to the relay, then spliced out of that same wire is a 3A fuse leading directly to the switch.



My guess it that you have the switch wire connected to the wrong place on the relay. The switch just tells the relay to open and close. The relay handles power delivery to the lights. There should be very little draw on the switch wire.



Few nearby fires again. A little hard not to notice.



Okay, so I'll add that there is only one way to plug the harness into the relay. So if your guess is correct, then the harness is wired incorrectly from KC? I say that because it's essentially "plug and play" assuming I've plugged things into the correct places.



Some pics might help.



I just added my bed rack and smitty bilt gen 2 xl tent. Can't wait to use it this week.



Unfortunately, KC doesn't provide the wiring diagram online, so I don't know how the harness is prewired. All we can see from the initial post is that the the amperage in the circuit with the 3A fuse is exceeding 3A.



- Relay plugged in the only way it can be.
- Yellow ring terminal to battery.
- Black ring terminal to ground.
- Switched wired as instructed in the diagram.
- Only weird thing to me is how the diagram illustrates that the green wire is in the center, but then states that yellow goes to center of switch.



@caribe makaira



Yeah, I looked for one also. I've posted an image of the one that came in the box a few posts ahead.
