What have you done to your Tacoma today? 1st Gen Edition

Discussion in '1st Gen. Tacomas (1995-2004)' started by SlimDigg, Feb 7, 2011.

  1. Aug 2, 2020 at 2:21 PM
    ToyotaDriver

    ToyotaDriver Well-Known Member

    Joined:
    Nov 23, 2017
    Member:
    #236721
    Messages:
    830
    Gender:
    Male
    First Name:
    Jason
    Idaho
    Vehicle:
    ‘04 V6 5 Speed SR5 TRD downward spiraling project, ‘15 V6 6speed TRD daily
    The 1st Gen: All pro 3” lift (650 lbs coils, expedition rears with bilstiens),Timbren rear bumpstops, ubolt flip, diff drop, carrier bearing drop, 33’s on beadlocks ,ARB Bumper, winch, hand throttle, ARE canopy, roof bars, poly bushings all around minus the body mounts. The 2nd Gen: Leveling kit, roll up tonneau cover. 265/75/16’s
    When I did my rear end last year, I just did the 500 mile break in and went about abusing it as I always have after that. Pulled the ring and pinion this year and 10,000 miles later to regear, and it doesn’t show any signs of abnormal wear or abuse.

    kuntry09 likes this.
  2. Aug 2, 2020 at 3:22 PM
    Robmonster117

    Robmonster117 Well-Known Member

    Joined:
    Sep 29, 2013
    Member:
    #113490
    Messages:
    1,715
    Gender:
    Male
    First Name:
    Robert
    Gilroy
    Vehicle:
    02 ext. cab 4x4
    Truck parts
    Dont worry.. I was not gentle ;)

    BYJOSHCOOK, m3bassman and cruiserguy like this.
  3. Aug 2, 2020 at 3:51 PM
    Fernando

    Fernando Hammerdown

    Joined:
    Aug 25, 2012
    Member:
    #85507
    Messages:
    22,461
    Gender:
    Male
    First Name:
    Fernando
    Sacramento
    Vehicle:
    04 Tacoma DC 4x4
    Too many, See Build

    Well fuck it. I need to sas

    Lol

    You sound like a responsible man

    So bite the bullet and go Atlas is what your saying? Does the atlas come with hella sticks? I dont care for them.....

    You nasty MF!!!

  4. Aug 2, 2020 at 3:59 PM
    Squeaky Penguin

    Squeaky Penguin Nothing Ventured, Nothing Gained

    Joined:
    Apr 5, 2012
    Member:
    #76340
    Messages:
    8,479
    Gender:
    Male
    First Name:
    Brett
    Steamboat Springs, Colorado
    Vehicle:
    '01 4WD, SR5, TRD & '13 TRDOR AC
    Lots of dust and custom dents, Check Build
    While we're talking crawlboxes-

    Aside from cost, is there a reason not to put a Marlin or a TG in front of the stock chain tcase?

    Running Board Man likes this.
  5. Aug 2, 2020 at 4:26 PM
    Madjik_Man

    Madjik_Man The Rembrandt of Rattle Can

    Joined:
    Dec 2, 2009
    Member:
    #26893
    Messages:
    17,700
    Gender:
    Male
    Boulder County
    Vehicle:
    1998 Ext Cab 3.4 4x4 TRD 5MT
    2004 DC 3.4 4x4 TRD
    Replaced my lower ball joints on the 2004 I bought last year. Not knowing the full service history of this vehicle I wanted to do this as soon as possible. Of course that means 12 months later.

    The boots must have been leaking grease for a long time. Tons of fresh grease and gunk on the lower control arms. Ugh.

    First side took me 1.25 hours because I had to make two separate trips to the same parts store :anonymous:. Second side took me 15 mins.

    Questions:

    1. Has anyone ever seen this rubber cover (thingamagiggy) over the ball joint boots? It's not on my 1998 and in all my years on TW I've never seen it. Clearly it does nothing.

    IMG_1654.jpg IMG_1655.jpg

    2. I don't have a bench vise but I figured I'd check out the old LBJ versus the new. The old one had a megashitton of movement to it within the ball joint. Laterally, up and down and it spun so easily... without any force whatsoever. For shits and giggles... were the old LBJs shot?

    https://www.youtube.com/watch?v=wQtZJ13DErw

    3. After I lowered the truck I noticed that the camber looked off and maybe even toe. I drove it around and it seemed to have gotten better but it still looks off. I always thought that an alignment is unnecessary after changing the LBJs... they only go back on one way. Do I need to get an alignment or am I imagining things because I'm super dehydrated?

    @Blackdawg @Squeaky Penguin (interested in your thoughts on #3, thanks fellas).

  6. Aug 2, 2020 at 4:36 PM
    eon_blue

    eon_blue Unknown Member

    Joined:
    Mar 4, 2016
    Member:
    #180213
    Messages:
    50,235
    Gender:
    Male
    First Name:
    Ryan
    Monrovia, CA
    Vehicle:
    Supercharged 2004 3.4l TRD 4x4 Tacoma XtraCab w/5 speed
    The dust boot came on later model 1st gens...2000 or 2001+ I'm not sure. But the early models didn't have them covering the LBJ boots. They can break off easily.

    Madjik_Man likes this.
  7. Aug 2, 2020 at 4:37 PM
    Shortman5

    Shortman5 Well-Known Member

    Joined:
    Mar 30, 2013
    Member:
    #100952
    Messages:
    2,248
    Gender:
    Male
    ..
    Vehicle:
    Supercharged TRD
    TRD S/C, ADS coilovers.
    I have them on my 04 but didn’t on my 02.

    Madjik_Man likes this.
  8. Aug 2, 2020 at 4:39 PM
    eon_blue

    eon_blue Unknown Member

    Joined:
    Mar 4, 2016
    Member:
    #180213
    Messages:
    50,235
    Gender:
    Male
    First Name:
    Ryan
    Monrovia, CA
    Vehicle:
    Supercharged 2004 3.4l TRD 4x4 Tacoma XtraCab w/5 speed
    I'm fairly certain they were on the 02s but maybe not all. But they do break off easily especially if they're old, one of my original ones broke off last time I changed out my LBJs. They can still be bought new, I prefer to have them on so rocks/road debris doesn't puncture the LBJ boot resulting in needed to change it

    Madjik_Man likes this.
  9. Aug 2, 2020 at 4:43 PM
    Madjik_Man

    Madjik_Man The Rembrandt of Rattle Can

    Joined:
    Dec 2, 2009
    Member:
    #26893
    Messages:
    17,700
    Gender:
    Male
    Boulder County
    Vehicle:
    1998 Ext Cab 3.4 4x4 TRD 5MT
    2004 DC 3.4 4x4 TRD
    I also appreciate that it contained all the LBJ grease within the dust boot and not sling it all over the rest of the truck :)

    eon_blue likes this.
  10. Aug 2, 2020 at 4:45 PM
    Reh5108

    Reh5108 Well-Known Member

    Joined:
    Feb 18, 2013
    Member:
    #97832
    Messages:
    4,846
    Gender:
    Male
    First Name:
    Ryan
    Idaho
    Vehicle:
    2004 SR5 4X4 2.7L Extra Cab
    OME lift, 4x sliders, Demello rear bumper, custom front bumper, Engo 9000lb winch
    Either the last alignment was done with the shitty ball joints or you are seeing things. When you first set the truck back in the ground it will be off since the tires are not resting in there natural position.

    Grab a tape measure and measure the same tread block in front of the wheels and behind them. A simple level guage and flat plate that reaches opposite sides of your rim should give you an idea on camber. Smartphone app may even be good enough.

    Squeaky Penguin and m3bassman like this.
  11. Aug 2, 2020 at 4:47 PM
    Madjik_Man

    Madjik_Man The Rembrandt of Rattle Can

    Joined:
    Dec 2, 2009
    Member:
    #26893
    Messages:
    17,700
    Gender:
    Male
    Boulder County
    Vehicle:
    1998 Ext Cab 3.4 4x4 TRD 5MT
    2004 DC 3.4 4x4 TRD
    Appreciate the insight.

    The previous owner either had the alignment done with the crapped out LBJs or not at all when he bought new wheels/tires for it last year. My guess is he didn’t have the wherewithal to get an alignment with new wheels/tires.

    With the tread blocks (front and back) what exactly am I measuring and from what?

    Thanks.

    Last edited: Aug 2, 2020
  12. Aug 2, 2020 at 4:57 PM
    Reh5108

    Reh5108 Well-Known Member

    Joined:
    Feb 18, 2013
    Member:
    #97832
    Messages:
    4,846
    Gender:
    Male
    First Name:
    Ryan
    Idaho
    Vehicle:
    2004 SR5 4X4 2.7L Extra Cab
    OME lift, 4x sliders, Demello rear bumper, custom front bumper, Engo 9000lb winch
    The distance from one tire to the other. Just use the same tread block edge to keep things accurate. Try to keep your tape perpendicular too.

    Madjik_Man likes this.
  13. Aug 2, 2020 at 4:58 PM
    slander

    slander Well-Known Member

    Joined:
    May 10, 2013
    Member:
    #103909
    Messages:
    7,350
    Gender:
    Male
    Hickory, NC
    Vehicle:
    02 Tacoma, fixed with curse words.
    I stripped out the factory chain drive input shaft and from that point on I didnt trust it, hence why I built the lefty. The gear drive cases have a much longer input shaft that reduces the ammount the coupler and input shaft wobbles and starts fretting corrosion. The chain drive case itself is strong as hell, I just never could trust that input shaft again. I know a lot of people run them in front of the chain drive case with no issues. I think the claims that running the 4.7s in front of the chain drive case can break the chain drive case internals is mostly unfounded at this point.

  14. Aug 2, 2020 at 5:04 PM
    malburg114

    malburg114 Well-Known Member

    Joined:
    Dec 26, 2012
    Member:
    #93766
    Messages:
    2,956
    Gender:
    Male
    Las Vegas, NV
    Vehicle:
    2001 Toyota Tacoma TRD
    Atlas over duals all day. Especially a lefty dual setup since that’ll run you to essentially atlas cost. Get a 2speed with 4.3:1 or 5:1 (what I want).


    If you do go duals I have no regrets on my tg cases. Bought them from low range and have had zero issues with them and ordered on Monday and had by Thursday. All my issues have been the adapter between transmission and tcase from inchworm but they discontinued it cause of the issues.

    or do an automatic swap and axle gears. 4.7 is perfect with any auto. More than low enough to do serious crawling while still having halfway speed.


    Twin sticks is nice too. 2wd low is cool and I use it a lot. Takes unneeded stress off the front components when not needed and can be used to slide the rear over on climbs to line up straight.

    either an atlas or duals will be a lot of work. Requires clearencing of the tunnel, a crossmember, new support, shortened rear shaft and long front shaft, center console/floor work, etc. definitely not a bolt in deal.

  15. Aug 2, 2020 at 5:12 PM
    joemauma

    joemauma Well-Known Member

    Joined:
    Jun 26, 2013
    Member:
    #107089
    Messages:
    356
    Gender:
    Male
    Oregon
    Vehicle:
    97 Double Cab
  16. Aug 2, 2020 at 5:13 PM
    Madjik_Man

    Madjik_Man The Rembrandt of Rattle Can

    Joined:
    Dec 2, 2009
    Member:
    #26893
    Messages:
    17,700
    Gender:
    Male
    Boulder County
    Vehicle:
    1998 Ext Cab 3.4 4x4 TRD 5MT
    2004 DC 3.4 4x4 TRD
    Got it. Thanks.

  17. Aug 2, 2020 at 5:13 PM
    Snowy

    Snowy Is neither here nor there

    Joined:
    Feb 5, 2014
    Member:
    #122349
    Messages:
    2,765
    Gender:
    Male
    First Name:
    Connor
    Winnebago, IL
    Vehicle:
    3 linked 98 Xtra cab
    Stock-ish
    Nope that’s what I run and is definitely the only way left hand drop dual Toyota cases make sense. I actually don’t think you can get a lefty anymore. If one is solid axle swapping and wants a right hand drop, just drop a 4.7 rear case in behind a 2.28 stock 23 spline case

    Squeaky Penguin and malburg114 like this.
  18. Aug 2, 2020 at 5:22 PM
    slander

    slander Well-Known Member

    Joined:
    May 10, 2013
    Member:
    #103909
    Messages:
    7,350
    Gender:
    Male
    Hickory, NC
    Vehicle:
    02 Tacoma, fixed with curse words.
    Doesnt TG still has their shitty chinese attempt at a lefty called the verso?

  19. Aug 2, 2020 at 5:32 PM
    malburg114

    malburg114 Well-Known Member

    Joined:
    Dec 26, 2012
    Member:
    #93766
    Messages:
    2,956
    Gender:
    Male
    Las Vegas, NV
    Vehicle:
    2001 Toyota Tacoma TRD
    And people will always say marlin is superior to tg but plenty of people running tg stuff with little to no issues. (Myself included) Supply and demand is a big thing and tg filled that role. If you have a year to wait for parts. Go marlin and hope you get actual marlin parts (last batch shipped sith inchworm adapters). If you want it now, go tg.

    Atlas will take 2-6 weeks depending on their lead time and is superior in every way. Stronger. Sealed unit so no leaks. Front digs. Can use cable shifters and mount them anywhere. Run yoke style driveshaft ends if wanted. Etc.

  20. Aug 2, 2020 at 5:36 PM
    Snowy

    Snowy Is neither here nor there

    Joined:
    Feb 5, 2014
    Member:
    #122349
    Messages:
    2,765
    Gender:
    Male
    First Name:
    Connor
    Winnebago, IL
    Vehicle:
    3 linked 98 Xtra cab
    Stock-ish
    I think that was pretty short lived and I haven’t seen them for sale in a while. I think they didn’t make enough sense money wise.

    @Squeaky Penguin this was my chain drive transfer case input after 6 years and 30k+ miles behind a crawl box with TG adapter plates. No problems with fretting at all with anti-seize on the splines at assembly.
