What have you done to your Tacoma today? 1st Gen Edition

Discussion in '1st Gen. Tacomas (1995-2004)' started by SlimDigg, Feb 7, 2011.

  1. Apr 26, 2021 at 4:18 PM
    Uphillshunter

    Uphillshunter El Taco Diablo

    Joined:
    Nov 6, 2017
    Member:
    #235223
    Messages:
    9,561
    Gender:
    Male
    First Name:
    Matt - KN6DZP
    Hughson, CA
    Vehicle:
    Impulse Red 02 TRD Tacoma Prerunner "now it's 4x4 muthafukas" DC 5vz-fe
    Swapped 4x4, Twin sticks, Tundra Brakes, FOX Resi, AllPro leafs, Pro-Comp 17x8.5, Transgo shift kit, Dual batteries

    Yes, No way I wasn't going to do all of it, if I was already in there. (especially with the amount of miles that were on them)

    At least next time won't be so expensive, cause now I have a press and the press fixture for it.

    Dan8906 likes this.
  2. Apr 26, 2021 at 6:06 PM
    Dan8906

    Dan8906 Well-Known Member

    Joined:
    Jul 26, 2016
    Member:
    #192977
    Messages:
    4,354
    Gender:
    Male
    First Name:
    Daniel
    Concord, California
    Vehicle:
    2004 Tacoma ext cab TRD 4x4
    CBI sliders, ADS extend travel with compression adjuster coil overs, 9” Bilstein 5125 rear shocks, Icon Tubular UCA, Alcan custom leafs, All Pro Apex bumper and skids, NWTI rear diy bumper, 295/70/17 Cooper St Maxxs and nitro 4.88s.
    Okay so just took my truck for a test drive after doing the big 3 upgrade. Charges at 14.2 while driving but then drops to 12.9-13.4 at a stop. If I put it in park it jumps back to 14.2. Any ideas? Little confused on the voltage drop

  3. Apr 26, 2021 at 6:17 PM
    Blackdawg

    Blackdawg Dr. Frankenstein

    Joined:
    Dec 31, 2010
    Member:
    #48500
    Messages:
    78,323
    Gender:
    Male
    First Name:
    Monte
    Wyoming/St. Louis
    Vehicle:
    The Trifecta of Taco's
    ALL OF THEM!...Then some more.
    I bet your RPMS are about what, 2-300rpms lower when in drive vs park?

    THat alt your swapped in is higher output but only at higher rpms, and by rpms I mean the alt's rpms.

    If you wanted high output at low rpms you should go with the CS144 swap as that's it's party trick. It'll do around 100amps at our trucks idle speed. Vs about 40 from the stock alt. Your's isn't stock granted but its the same case/housing. So all that is different is the windings are tighter.

    turbodb, betterbuckleup and Dan8906 like this.
  4. Apr 26, 2021 at 6:17 PM
    Blackdawg

    Blackdawg Dr. Frankenstein

    Joined:
    Dec 31, 2010
    Member:
    #48500
    Messages:
    78,323
    Gender:
    Male
    First Name:
    Monte
    Wyoming/St. Louis
    Vehicle:
    The Trifecta of Taco's
    ALL OF THEM!...Then some more.
    yeah I woudn't worry too much about it long as you're not laying down massive beads like an axle truss or something. It should be just fine.

    Uphillshunter likes this.
  5. Apr 26, 2021 at 6:18 PM
    Uphillshunter

    Uphillshunter El Taco Diablo

    Joined:
    Nov 6, 2017
    Member:
    #235223
    Messages:
    9,561
    Gender:
    Male
    First Name:
    Matt - KN6DZP
    Hughson, CA
    Vehicle:
    Impulse Red 02 TRD Tacoma Prerunner "now it's 4x4 muthafukas" DC 5vz-fe
    Swapped 4x4, Twin sticks, Tundra Brakes, FOX Resi, AllPro leafs, Pro-Comp 17x8.5, Transgo shift kit, Dual batteries

    I think that's pretty normal. The alt is generating more (Amps) current at the higher rpm.

    Mine stays around 14.1 at idle and holds pretty solid at 14.7 driving. (but I have the big 3 and Cadillac alt now)

  6. Apr 26, 2021 at 6:28 PM
    Dan8906

    Dan8906 Well-Known Member

    Joined:
    Jul 26, 2016
    Member:
    #192977
    Messages:
    4,354
    Gender:
    Male
    First Name:
    Daniel
    Concord, California
    Vehicle:
    2004 Tacoma ext cab TRD 4x4
    CBI sliders, ADS extend travel with compression adjuster coil overs, 9” Bilstein 5125 rear shocks, Icon Tubular UCA, Alcan custom leafs, All Pro Apex bumper and skids, NWTI rear diy bumper, 295/70/17 Cooper St Maxxs and nitro 4.88s.
    Interesting. I guess what is confusing me is that it was holding 14.2 all the time this weekend before swapping the wires.

  7. Apr 26, 2021 at 6:37 PM
    Digiratus

    Digiratus Adventurer

    Joined:
    Mar 26, 2010
    Member:
    #34006
    Messages:
    20,280
    Gender:
    Male
    First Name:
    Mike
    Roaming the PNW
    Vehicle:
    The RedHead
    2002 XtraCab TRD 4x4 v6 Auto Trans With Lots of Mods ADS COs w/Compression Adjusters Camburg Uniball UCAs Whiteline Lower Control Arm Bushings Kartek 7" Limit Straps Plastics Guy Front Bumpstops Custom Alcan Springs +800 lbs +3" ADS 10" Stroke Triple Bypass w/Resi Rear Shocks Custom Rear Shock Relocate All-Pro U-bolt Flip w/Timbren Bumpstops 4.88 Nitro Gears ARB Front Locker ARB Twin Compressor Gunmetal 16x8 SCS Ray10s 255/85r16 Maxxis Bighorns Limited Edition (Relentless) Elite Front Bumper Smittybilt X2O 10K Winch Diode Dynamics SS3 Sport Selective Yellow Fog Lights in the Bumper Diode Dynamics SS3 Pro 4,000K Driving Lights on the Bumper Mini D2S Projectors XB35 Ballasts + 4500K Bulbs Badland Sliders FrankenFab Tire Carrier Swingout bumper w/kitchen BudBuilt Front & Bellypan Skids BAMF Rear Diff Skid Whynter 65 qt. Fridge/Freezer CVT Mt Bachelor RTT Badland Custom Bed Rack GM 140 amp alternator Dual Northstar 24F AGM batteries BlueSea 7622 ML-ACR Battery controller Peak DBI Dual Battery Voltage Monitor Doug Thorley Headers Magnaflow 18" Muffler w/upstream CAT delete 13WL Brake Calipers Braided Steel Brake Lines AFE Pro Dry S air filter ScanGauge II OBDII Scanner Kenwood TM-71A Dual Band Ham Radio Larson 70CM/2M Antenna Uniden 520xl CB radio 3' Firestik Adjustable tip antenna Pioneer DEH-P9400BH HU Alpine Amps & Type R components (F) and coaxials (R) Wet Okole Seat Covers Weathertech Digital Liners Deck Plate Mod 1" Diff Drop Carrier Bearing Drop
    What all is connected directly to the negative post on your battery? Is it more that what this pic shows?

    [​IMG]

  8. Apr 26, 2021 at 6:40 PM
    Dan8906

    Dan8906 Well-Known Member

    Joined:
    Jul 26, 2016
    Member:
    #192977
    Messages:
    4,354
    Gender:
    Male
    First Name:
    Daniel
    Concord, California
    Vehicle:
    2004 Tacoma ext cab TRD 4x4
    CBI sliders, ADS extend travel with compression adjuster coil overs, 9” Bilstein 5125 rear shocks, Icon Tubular UCA, Alcan custom leafs, All Pro Apex bumper and skids, NWTI rear diy bumper, 295/70/17 Cooper St Maxxs and nitro 4.88s.
    There’s 3 things connected to the post. Ground to fender(10 gauge new) ground to block (2 gauge new) and the negative from my winch

  9. Apr 26, 2021 at 6:48 PM
    Uphillshunter

    Uphillshunter El Taco Diablo

    Joined:
    Nov 6, 2017
    Member:
    #235223
    Messages:
    9,561
    Gender:
    Male
    First Name:
    Matt - KN6DZP
    Hughson, CA
    Vehicle:
    Impulse Red 02 TRD Tacoma Prerunner "now it's 4x4 muthafukas" DC 5vz-fe
    Swapped 4x4, Twin sticks, Tundra Brakes, FOX Resi, AllPro leafs, Pro-Comp 17x8.5, Transgo shift kit, Dual batteries

    I'd up your body ground (fender) to at least 4 guage, and run a 4 (or preferably a 2) guage to the frame directly under your battery.

    Where did you ground to the block? I ran the shortest possible 2 guage to the upper bolt on the alternator. The shorter the ground wire the better.

  10. Apr 26, 2021 at 6:49 PM
    Digiratus

    Digiratus Adventurer

    Joined:
    Mar 26, 2010
    Member:
    #34006
    Messages:
    20,280
    Gender:
    Male
    First Name:
    Mike
    Roaming the PNW
    Vehicle:
    The RedHead
    2002 XtraCab TRD 4x4 v6 Auto Trans With Lots of Mods ADS COs w/Compression Adjusters Camburg Uniball UCAs Whiteline Lower Control Arm Bushings Kartek 7" Limit Straps Plastics Guy Front Bumpstops Custom Alcan Springs +800 lbs +3" ADS 10" Stroke Triple Bypass w/Resi Rear Shocks Custom Rear Shock Relocate All-Pro U-bolt Flip w/Timbren Bumpstops 4.88 Nitro Gears ARB Front Locker ARB Twin Compressor Gunmetal 16x8 SCS Ray10s 255/85r16 Maxxis Bighorns Limited Edition (Relentless) Elite Front Bumper Smittybilt X2O 10K Winch Diode Dynamics SS3 Sport Selective Yellow Fog Lights in the Bumper Diode Dynamics SS3 Pro 4,000K Driving Lights on the Bumper Mini D2S Projectors XB35 Ballasts + 4500K Bulbs Badland Sliders FrankenFab Tire Carrier Swingout bumper w/kitchen BudBuilt Front & Bellypan Skids BAMF Rear Diff Skid Whynter 65 qt. Fridge/Freezer CVT Mt Bachelor RTT Badland Custom Bed Rack GM 140 amp alternator Dual Northstar 24F AGM batteries BlueSea 7622 ML-ACR Battery controller Peak DBI Dual Battery Voltage Monitor Doug Thorley Headers Magnaflow 18" Muffler w/upstream CAT delete 13WL Brake Calipers Braided Steel Brake Lines AFE Pro Dry S air filter ScanGauge II OBDII Scanner Kenwood TM-71A Dual Band Ham Radio Larson 70CM/2M Antenna Uniden 520xl CB radio 3' Firestik Adjustable tip antenna Pioneer DEH-P9400BH HU Alpine Amps & Type R components (F) and coaxials (R) Wet Okole Seat Covers Weathertech Digital Liners Deck Plate Mod 1" Diff Drop Carrier Bearing Drop
    For your voltage drop at idle, might want to recheck each of the main ground connections. Even a little resistance in any of them can cause a voltage drop.

    FWIW, When your battery gets topped off, the voltage output will drop, though 12.9 is a little too low for that. To compare, on cold start mine will be charging at 14.6-14.7 but as the battery starts to get full, that voltage reading from the ECU will drop to 13.9-14.0 typically.

    Also, is that Blue Sea fuse block also connected directly to the negative posst on the battery?

  11. Apr 26, 2021 at 6:49 PM
    Blackdawg

    Blackdawg Dr. Frankenstein

    Joined:
    Dec 31, 2010
    Member:
    #48500
    Messages:
    78,323
    Gender:
    Male
    First Name:
    Monte
    Wyoming/St. Louis
    Vehicle:
    The Trifecta of Taco's
    ALL OF THEM!...Then some more.

    ^^This.

    Keep in mind electrons flow - to +. So the better the ground's the better the flow of current.

  12. Apr 26, 2021 at 6:55 PM
    Dan8906

    Dan8906 Well-Known Member

    Joined:
    Jul 26, 2016
    Member:
    #192977
    Messages:
    4,354
    Gender:
    Male
    First Name:
    Daniel
    Concord, California
    Vehicle:
    2004 Tacoma ext cab TRD 4x4
    CBI sliders, ADS extend travel with compression adjuster coil overs, 9” Bilstein 5125 rear shocks, Icon Tubular UCA, Alcan custom leafs, All Pro Apex bumper and skids, NWTI rear diy bumper, 295/70/17 Cooper St Maxxs and nitro 4.88s.
    I ran to the stock location and just swapped the block to the firewall with 2 gauge. I’ll go make a 2 gauge for the negative to the fender.

    Uphillshunter likes this.
  13. Apr 26, 2021 at 6:56 PM
    Empty_Lord

    Empty_Lord Wallet abuser

    Joined:
    Mar 13, 2016
    Member:
    #181186
    Messages:
    23,853
    Gender:
    Male
    First Name:
    Dan
    Northwest Indiana/Chicagoland
    Vehicle:
    66 Mercedes, 01 Tacoma, 02 Tacoma 05 Tundra + others
    Almost 300k! Doug Thorley headers magnaflow cats & cat-back airaid intake tube color matched grille and mirrors front icon coilovers rear icon absorbers with deaver leafs total chaos upper control arms fj trail team wheels with 265/75r16 cooper discoverer st maxx Soon to be built engine with supercharger soon to be built a340f
    Now your and electrician? Damn. Spend some time to get better at halo! :luvya:

  14. Apr 26, 2021 at 6:56 PM
    Dan8906

    Dan8906 Well-Known Member

    Joined:
    Jul 26, 2016
    Member:
    #192977
    Messages:
    4,354
    Gender:
    Male
    First Name:
    Daniel
    Concord, California
    Vehicle:
    2004 Tacoma ext cab TRD 4x4
    CBI sliders, ADS extend travel with compression adjuster coil overs, 9” Bilstein 5125 rear shocks, Icon Tubular UCA, Alcan custom leafs, All Pro Apex bumper and skids, NWTI rear diy bumper, 295/70/17 Cooper St Maxxs and nitro 4.88s.
    Just unbolted the grounds and cleaned them well. No change.

    blue sea is grounded to the fender

  15. Apr 26, 2021 at 7:02 PM
    Dan8906

    Dan8906 Well-Known Member

    Joined:
    Jul 26, 2016
    Member:
    #192977
    Messages:
    4,354
    Gender:
    Male
    First Name:
    Daniel
    Concord, California
    Vehicle:
    2004 Tacoma ext cab TRD 4x4
    CBI sliders, ADS extend travel with compression adjuster coil overs, 9” Bilstein 5125 rear shocks, Icon Tubular UCA, Alcan custom leafs, All Pro Apex bumper and skids, NWTI rear diy bumper, 295/70/17 Cooper St Maxxs and nitro 4.88s.
    Also it was charging fine at idle at 14.2 volts before the upgrade. But I’ve double checked everything I don’t see any errors

  16. Apr 26, 2021 at 7:03 PM
    Blackdawg

    Blackdawg Dr. Frankenstein

    Joined:
    Dec 31, 2010
    Member:
    #48500
    Messages:
    78,323
    Gender:
    Male
    First Name:
    Monte
    Wyoming/St. Louis
    Vehicle:
    The Trifecta of Taco's
    ALL OF THEM!...Then some more.
    sheeeet. Im the best in our bunch! You're the one that needs to practice!

    Empty_Lord likes this.
  17. Apr 26, 2021 at 7:19 PM
    Dan8906

    Dan8906 Well-Known Member

    Joined:
    Jul 26, 2016
    Member:
    #192977
    Messages:
    4,354
    Gender:
    Male
    First Name:
    Daniel
    Concord, California
    Vehicle:
    2004 Tacoma ext cab TRD 4x4
    CBI sliders, ADS extend travel with compression adjuster coil overs, 9” Bilstein 5125 rear shocks, Icon Tubular UCA, Alcan custom leafs, All Pro Apex bumper and skids, NWTI rear diy bumper, 295/70/17 Cooper St Maxxs and nitro 4.88s.
    So I replaced the 10 gauge to the fender with 2 gauge and now in park it’s 12.7 and 12.5 in drive at idle

  18. Apr 26, 2021 at 7:21 PM
    RandyO

    RandyO Well-Known Member

    Joined:
    Dec 31, 2010
    Member:
    #48522
    Messages:
    52
    Gender:
    Male
    First Name:
    Randy
    SF Bay Area (Calif)
    Vehicle:
    Silver '03 AC PreRunner
    Bed Liner and Bed Tool Box - nothing much...
    Fixed two annoying problems - the passenger side dash rattle and the doors groaning.

    Dash Rattle: Cut off the tapered end of a rubber floor mat about 36" long, 1/2" thick, and wedge shaped. Jammed it between the window and the dash. Noise is gone!

    Doors Groaning: Lubricating the external hinges didn't work so I used some silicon spray with the long tube and sprayed it into the hidden area where the "door check strap" goes (I think that's what it's called anyway). It's probably not how you're supposed to lube it but It worked!

    unstpible, SwampYota and SLAPS 65 like this.
  19. Apr 26, 2021 at 7:22 PM
    Digiratus

    Digiratus Adventurer

    Joined:
    Mar 26, 2010
    Member:
    #34006
    Messages:
    20,280
    Gender:
    Male
    First Name:
    Mike
    Roaming the PNW
    Vehicle:
    The RedHead
    2002 XtraCab TRD 4x4 v6 Auto Trans With Lots of Mods ADS COs w/Compression Adjusters Camburg Uniball UCAs Whiteline Lower Control Arm Bushings Kartek 7" Limit Straps Plastics Guy Front Bumpstops Custom Alcan Springs +800 lbs +3" ADS 10" Stroke Triple Bypass w/Resi Rear Shocks Custom Rear Shock Relocate All-Pro U-bolt Flip w/Timbren Bumpstops 4.88 Nitro Gears ARB Front Locker ARB Twin Compressor Gunmetal 16x8 SCS Ray10s 255/85r16 Maxxis Bighorns Limited Edition (Relentless) Elite Front Bumper Smittybilt X2O 10K Winch Diode Dynamics SS3 Sport Selective Yellow Fog Lights in the Bumper Diode Dynamics SS3 Pro 4,000K Driving Lights on the Bumper Mini D2S Projectors XB35 Ballasts + 4500K Bulbs Badland Sliders FrankenFab Tire Carrier Swingout bumper w/kitchen BudBuilt Front & Bellypan Skids BAMF Rear Diff Skid Whynter 65 qt. Fridge/Freezer CVT Mt Bachelor RTT Badland Custom Bed Rack GM 140 amp alternator Dual Northstar 24F AGM batteries BlueSea 7622 ML-ACR Battery controller Peak DBI Dual Battery Voltage Monitor Doug Thorley Headers Magnaflow 18" Muffler w/upstream CAT delete 13WL Brake Calipers Braided Steel Brake Lines AFE Pro Dry S air filter ScanGauge II OBDII Scanner Kenwood TM-71A Dual Band Ham Radio Larson 70CM/2M Antenna Uniden 520xl CB radio 3' Firestik Adjustable tip antenna Pioneer DEH-P9400BH HU Alpine Amps & Type R components (F) and coaxials (R) Wet Okole Seat Covers Weathertech Digital Liners Deck Plate Mod 1" Diff Drop Carrier Bearing Drop
    Are those readings with the scangauge? Do you have a multimeter? What is it reading at the battery posts?

  20. Apr 26, 2021 at 7:26 PM
    Dan8906

    Dan8906 Well-Known Member

    Joined:
    Jul 26, 2016
    Member:
    #192977
    Messages:
    4,354
    Gender:
    Male
    First Name:
    Daniel
    Concord, California
    Vehicle:
    2004 Tacoma ext cab TRD 4x4
    CBI sliders, ADS extend travel with compression adjuster coil overs, 9” Bilstein 5125 rear shocks, Icon Tubular UCA, Alcan custom leafs, All Pro Apex bumper and skids, NWTI rear diy bumper, 295/70/17 Cooper St Maxxs and nitro 4.88s.
    Seems to be a little higher now at 13.6-13.8 on the scan gauge and 13.8-14.02 at the posts

    Last edited: Apr 26, 2021
