It’s been a minute since I took statics and materials, but isn’t the height the big hitter, like you mentioned? I just vaguely remember the moment of inertia for a beam having that h^3 term. But obviously, that’s not really a knob you can turn in this case unless you’re doing a custom frame section. I’m just indulging my nerdiness at this point anyway



This would explain why the HD versions of Chevy's trucks have 2"-3" taller frame rails



Yep, you nailed it. That’s why the frames on straight-frame box trucks are 12”+ tall. You can thicken the flanges as much as you want but all that added weight won’t be nearly as efficient as increasing frame depth.
You want some flex in it though, otherwise it’s going to ride like a straight frame box truck. If it’s too rigid all that stress is just going to move to the next weakest point, like bed/cab mounts, frame cross members, etc.



Nice! I’m not completely senile at least haha.

Mine seems to ride so much better after boxing in the frame. Like the suspension can really do it’s job now with the added rigidity. But I’m also aware that I really just moved that resonance up in frequency as well, which I can definitely feel with my poly body mounts. It’s enough to keep me away from poly mounts for the motor and drivetrain stuff and just stay with rubber for all of that.

Everything is a trade off, for sure.



That’s a good point, the suspension really starts to play a role here. A high quality suspension system should be able to be tuned for a very rigid frame/cage system. The stuff I design isn’t supposed to move (very much), so I’m getting out of my depth here
