wiring help! is this safe???

Discussion in 'Lighting' started by kinkrider101, Mar 19, 2011.

  1. Mar 19, 2011 at 8:28 PM
    #1
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
    I wired 3 lights together today, all 3 go into 1 wire wich leads to the switch, the a wire from the switch to the battery, is this safe? With no relay with all 14g wire

  2. Mar 19, 2011 at 8:30 PM
    #2
    MyToyTaco

    MyToyTaco ╒╪╕

    Joined:
    Sep 23, 2008
    Member:
    #9417
    Messages:
    4,340
    Gender:
    Male
    First Name:
    Nick
    Port Hueneme
    Vehicle:
    08 Taco
    it'll work.... for how long? this is the question...

  3. Mar 19, 2011 at 8:31 PM
    #3
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
    Will I need extra wire to wire it to a relay? Will that make it a ton safer

  4. Mar 19, 2011 at 8:34 PM
    #4
    MyToyTaco

    MyToyTaco ╒╪╕

    Joined:
    Sep 23, 2008
    Member:
    #9417
    Messages:
    4,340
    Gender:
    Male
    First Name:
    Nick
    Port Hueneme
    Vehicle:
    08 Taco
    when i had my light bar i had all 4 lights on the front wired to 2 different switches. (2 lights on each switch)

    no relay, fuses, etc. It worked fine all the way up until I took the light bar off

    probably not the "right" way to do it, but like i said it should be fine (should)






    (im not liable for any fires you may run into :D)




    edit... i did have fuses between the switchs & the battery now that i think about it.

  5. Mar 20, 2011 at 9:05 AM
    #5
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
    I'm going to add a relay today, will that make it a ton safer and no fires?

  6. Mar 20, 2011 at 9:31 AM
    #6
    2010Tacoma4x4

    2010Tacoma4x4 "Man Ho"

    Joined:
    Jan 19, 2011
    Member:
    #49556
    Messages:
    644
    Gender:
    Male
    First Name:
    Dave
    Jacksonville, Fl
    Vehicle:
    2010 4x4 SR5
    Tinted windows, Bug deflector, Rain guards, Bed mat, Rear leaf TSB, Bilsteins front & rear (front set @ 1.75), 16x8 chrome Helo wheels, Toyo open country AT P265/75/R16 tires. CBI bolt on sliders. BSP color matched M1 Satoshi grill. BHLM. UWS low profile black powder coat crosover truckbox. Pioneer DVD/CD head unit - 4 channel amp - front mids & highs - 8" sub box.
    You should put an inline fuse on the power lead somewhere close to the battery. Depending on how much amperage your lights draw will let you know what size fuse to put in. That way if you have a dead short somewhere the wire won't burn which could potentially start a fire....you will just blow a fuse.
    It is better to use a relay when running lights. You should only use the switch to toggle the relay open and closed. If your switch is capable of handling the amperage your drawing then you can get by without the relay.

  7. Mar 20, 2011 at 9:50 AM
    #7
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
    They are 55w lights thanks!

  8. Mar 20, 2011 at 11:07 AM
    #8
    MrFastLayne

    MrFastLayne Mr SGA

    Joined:
    Dec 5, 2010
    Member:
    #47182
    Messages:
    390
    Gender:
    Male
    First Name:
    Layne
    Lincoln Ca,
    Vehicle:
    07 Tacoma 4x4 SR5 V6 Off Road
    Lift,Winch,Shell,Light Bar,Siren,Radio's
    Use fuses! [​IMG]

  9. Mar 20, 2011 at 11:13 AM
    #9
    fletch aka

    fletch aka www.BeLikeBrit.org

    Joined:
    Jan 4, 2009
    Member:
    #12223
    Messages:
    7,122
    Gender:
    Male
    First Name:
    Gary
    Left Coast
    Vehicle:
    09 Magnetic Gray TRD OffRoad
    TRD cat back exhaust, TRD Cold Air Intake, differential breather mod' Hellwig rear sway bar, 16x8 TRD Ivan Stewart's, Michelin LTX A/T2, DTRL Stealth Mode Mod, custom "Texas Edition" shift knob, Sock's "Classic" bedside decals, MetalMiller custom grill emblem, 20% front tinted windows, tinted taillights, Viper alarm, ScanGauge II, Flyzeye Designs V2W Tacoma Interior LED lighting, de-mud flapped, de-badged, extra D-rings under bed bolts, WeatherTech ED floor mats, G4 Elite Fold a Cover ,Toyota bed mat, tailgate theft deterrent device and absolutely no plasti-dip!
    What he said ^^

  10. Mar 20, 2011 at 11:13 AM
    #10
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
    Would the fuse go from switch to battery?

  11. Mar 20, 2011 at 11:17 AM
    #11
    2010Tacoma4x4

    2010Tacoma4x4 "Man Ho"

    Joined:
    Jan 19, 2011
    Member:
    #49556
    Messages:
    644
    Gender:
    Male
    First Name:
    Dave
    Jacksonville, Fl
    Vehicle:
    2010 4x4 SR5
    Tinted windows, Bug deflector, Rain guards, Bed mat, Rear leaf TSB, Bilsteins front & rear (front set @ 1.75), 16x8 chrome Helo wheels, Toyo open country AT P265/75/R16 tires. CBI bolt on sliders. BSP color matched M1 Satoshi grill. BHLM. UWS low profile black powder coat crosover truckbox. Pioneer DVD/CD head unit - 4 channel amp - front mids & highs - 8" sub box.
    You surely don't want your dash looking like that!!:eek::eek:


    With 3 55w bulbs you will be pulling about 13.75 amps. I would use a relay:cool:

  12. Mar 20, 2011 at 11:23 AM
    #12
    lookylookitzadam

    lookylookitzadam Retrofit Club!

    Joined:
    Jul 16, 2009
    Member:
    #19777
    Messages:
    714
    Gender:
    Male
    First Name:
    Adam
    San Diego
    Vehicle:
    07 DC OffRoad
    are you set up like this:

    battery------switch------light-light-light?

    you really need to make sure that you switch can handle that many amps (min 15amps + you probably should have a factor of safety involved there).

    Run a relay and fuse the +12v at the battery going to the relay

  13. Mar 20, 2011 at 11:29 AM
    #13
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
    Will this fuse work?? I thout you use a inline fuse from the switch the battery?

  14. Mar 20, 2011 at 11:31 AM
    #14
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
    Yes its lightd to switch then switch to battery..i have the oznium switch

  15. Mar 20, 2011 at 11:32 AM
    #15
    bjmoose

    bjmoose Bullwinkle J. Moose

    Joined:
    Aug 31, 2010
    Member:
    #42529
    Messages:
    5,667
    Gender:
    Male
    First Name:
    Steve
    San Jose CA
    Vehicle:
    '11 Std Cab 4x4 5sp
    OME suspension, ARB Air Locker, Yaesu FT 8900 Ham Radio
    Your switch needs to be rated for the amperage.

    At 55w per light, 3 lights, you've got 165w / 12v = 13.75A.

    As long as your switch is rated for that amperage at 12v, you don't need a relay or solenoid. That just adds complexity to the circuit.
    EDIT: Here's a pretty typical switch from radioshack. Note that it's rated at 25A. So check your switch, but it's not hard to find a switch rated for that amperage. http://www.radioshack.com/product/index.jsp?productId=2062534

    Your circuit doesn't mention a fuse. You want a fuse inline, as close as practical to the battery. 15A, obviously, a 10A will blow immediately.

    14g wire may be a little light for the job. Granted, in your house 14g solid runs all over the house on 15A circuits. But for stranded wire in an automotive application, you may want to go a little heavier. I googled up a chart here (there are lots of them, but this one actually shows percentage of power loss at given length, which makes it the most helpful, IMO)

    http://www.windsun.com/Hardware/Wire_Table.htm

    So 8 or 10 gauge is called for, depending on the length of your run, in order to keep power loss due to internal wire resistance at 5% or less.

    Hope this helps.

  16. Mar 20, 2011 at 11:35 AM
    #16
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
  17. Mar 20, 2011 at 11:39 AM
    #17
    dkbigbuds

    dkbigbuds Well-Known Member

    Joined:
    Mar 9, 2011
    Member:
    #52708
    Messages:
    57
    Gender:
    Male
    so cal
    Vehicle:
    2.7L tacoma white on black
    ^^ i would cry... definately worth the extra hour to put in a fuse...i would recommend wire loom too, cant be to careful

  18. Mar 20, 2011 at 11:40 AM
    #18
    bjmoose

    bjmoose Bullwinkle J. Moose

    Joined:
    Aug 31, 2010
    Member:
    #42529
    Messages:
    5,667
    Gender:
    Male
    First Name:
    Steve
    San Jose CA
    Vehicle:
    '11 Std Cab 4x4 5sp
    OME suspension, ARB Air Locker, Yaesu FT 8900 Ham Radio
  19. Mar 20, 2011 at 11:54 AM
    #19
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
    I used male and female connectors so i could simply unplug it to remove my grill...i do have 2 lights going into 1 female connector though then that plugs into another female that goes to the switch

  20. Mar 20, 2011 at 11:58 AM
    #20
    kinkrider101

    kinkrider101 [OP] Well-Known Member

    Joined:
    Sep 29, 2009
    Member:
    #23497
    Messages:
    2,696
    Gender:
    Male
    santa barbara
    Vehicle:
    2007 cummins/2007 tacoma
    wheels and tires
