Your unique mod on the 1st Gens

Discussion in '1st Gen. Tacomas (1995-2004)' started by Desiel, Oct 14, 2010.

  1. Mar 1, 2021 at 12:58 PM
    #1961
    OpeCity

    OpeCity Well-Known Member

    Joined:
    Feb 28, 2021
    Member:
    #357705
    Messages:
    301
    Long Beach, CA
    I installed a powered, heated shower in my 99. Electric pump recirculates water through an under hood heat exchanger, thermostat in glove box ensures I don’t overheat the water, and now I have a 110f shower for winter surfing and camping. V3.0 will have more capacity and a tank under an upcoming camper shell bed setup.

    60-ABF22-C-4555-45-A5-89-CE-E6-EC3-D6-A1_ec45510ae79b31b443cf3e0e50c991afbc6bfd53.jpg
    4324-BE0-D-CB66-4-E9-F-B2-DC-6-E277-AA9-_4b35f080857fb82e3f72984b6aa5b9787d21ab9e.jpg
    DC877-ACE-0-DF4-4976-8188-3379-DE53692-E_95d127d421ad5ab5c28360337d1f55240290a5cf.jpg
    2-E115-B37-921-A-4-A2-F-B7-F6-7-CD1-AC14_da33f5b1e09ec6cdb27800ac41a7d5103be52689.jpg

  2. Mar 2, 2021 at 6:09 AM
    #1962
    aroma

    aroma Well-Known Member

    Joined:
    Sep 7, 2018
    Member:
    #265529
    Messages:
    405
    Gender:
    Male
    Snottsdale AZ
    I would like more details please. Great job!

  3. Mar 2, 2021 at 7:05 AM
    #1963
    OpeCity

    OpeCity Well-Known Member

    Joined:
    Feb 28, 2021
    Member:
    #357705
    Messages:
    301
    Long Beach, CA
    What do you want to know?

    I mounted the pump down beneath the front right side of the bed, just drilled through and mounted it upside down to the bottom of the bed. Water exits the front of the reservoir tube and runs to the pump, then gets sent through the heat exchanger and enters back at the rear of the tube so the temp gets mixed up well. When you close the lever valve on the bottom back of the reservoir tube, that circulation stops and you get 30psi of water out of the quick connect fitting in the bed. It will shoot 10-15’ out of a normal garden hose
    4-FAD845-F-25-B5-4132-8349-8-ABC5-FB667-_1bf6eeacbfb0ab47a482728efbe8435e752b3b10.jpg


    traced the plumbing for the heat exchanger up the right side of the frame into the engine bay. Cut into the heater core lines and plumbed the hot side of the heat exchanger with shutoff valves in case anything starts leaking.


    97976563-1-B2-A-4730-A85-A-93-B4804-F224_d682895027378bfd788c556670f6c89bf65d7c03.jpg

    12v thermostat for aquariums mounted in the glove box stops the circulation when the temp gets to the preset. The probe is mounted on the incoming fresh water line just before the heat exchanger.
    DD5-B8-A05-F48-F-411-C-92-DD-1-B276-F681_2c02f316e37c8fc26b7fa43362c53037bf741858.jpg

    All manually controllable with a six channel remote relay box mounted in the front right of the engine bay and wired to the battery.


    it’s pretty well sorted now. It carried about 3.5gal of water and heats it from 55 to 130 in about 8 minutes. Next one will carry 6-8 gallons, so probably 10-12min heat time

  4. Mar 2, 2021 at 1:45 PM
    #1964
    aroma

    aroma Well-Known Member

    Joined:
    Sep 7, 2018
    Member:
    #265529
    Messages:
    405
    Gender:
    Male
    Snottsdale AZ
    Thanks, great idea.

    OpeCity likes this.
  5. Mar 2, 2021 at 4:24 PM
    #1965
    JKO1998

    JKO1998 Well-Known Member

    Joined:
    Jun 2, 2015
    Member:
    #156578
    Messages:
    39,314
    Gender:
    Male
    Utah
    Vehicle:
    Cement 99 3.4 V6 4x4 Silver 02 3.4 V6 4x4
    Where did you put the fuse box for the switch panel? I have one of those showing up Thursday.

  6. Mar 2, 2021 at 4:28 PM
    #1966
    OpeCity

    OpeCity Well-Known Member

    Joined:
    Feb 28, 2021
    Member:
    #357705
    Messages:
    301
    Long Beach, CA
    The fuses are built into the box along the right side in the photo. If you were worried, you could put a 50a circuit breaker in the main power line but I haven’t bothered yet.

  7. Mar 2, 2021 at 4:30 PM
    #1967
    JKO1998

    JKO1998 Well-Known Member

    Joined:
    Jun 2, 2015
    Member:
    #156578
    Messages:
    39,314
    Gender:
    Male
    Utah
    Vehicle:
    Cement 99 3.4 V6 4x4 Silver 02 3.4 V6 4x4
    I was wondering where you mounted the box.

  8. Mar 2, 2021 at 4:33 PM
    #1968
    OpeCity

    OpeCity Well-Known Member

    Joined:
    Feb 28, 2021
    Member:
    #357705
    Messages:
    301
    Long Beach, CA
    Oh gothca. It’s in the front passenger side of the engine compartment in the space behind the air box. Fits great bolted right to the vertical portion there.

    sorry I didn’t take a pic but I can get you one Thursday if you want

    JKO1998 likes this.
  9. Mar 2, 2021 at 4:37 PM
    #1969
    JKO1998

    JKO1998 Well-Known Member

    Joined:
    Jun 2, 2015
    Member:
    #156578
    Messages:
    39,314
    Gender:
    Male
    Utah
    Vehicle:
    Cement 99 3.4 V6 4x4 Silver 02 3.4 V6 4x4
    Your battery cable looks longer than the one that's coming on mine so I don't think that's gonna work for me.

    But thanks.

  10. Mar 2, 2021 at 4:38 PM
    #1970
    plurpimpin

    plurpimpin Well-Known Member

    Joined:
    Jul 31, 2011
    Member:
    #60895
    Messages:
    1,511
    Gender:
    Male
    PDX
    Vehicle:
    2010 TRD Off Road 4x4
    got any details on the make/model and supplier for the heat exchanger?

  11. Mar 2, 2021 at 4:49 PM
    #1971
    OpeCity

    OpeCity Well-Known Member

    Joined:
    Feb 28, 2021
    Member:
    #357705
    Messages:
    301
    Long Beach, CA
    I got it off Amazon. Not sure if they like Amazon links around here, but it’s listed as “AB Plate Heat Exchanger, 3"x8" 16 Plates”

    It was $90 or so. But my god these things are efficient. The rate of heating is absurd. If you want to look for a cheaper option, and brazed-plate wort chiller for brewing does the same job.
    The 10-plate smaller version would be more than sufficient if you can wait a little longer

    V1.0 used the otherwise empty trans fluid heat exchanger in the bottom of my radiator (my truck’s manual so it doesn’t use it), but I got hardly any heat at all out of the bottom of the radiator.

    Last edited: Mar 2, 2021
  12. Mar 2, 2021 at 5:02 PM
    #1972
    plurpimpin

    plurpimpin Well-Known Member

    Joined:
    Jul 31, 2011
    Member:
    #60895
    Messages:
    1,511
    Gender:
    Male
    PDX
    Vehicle:
    2010 TRD Off Road 4x4
    Thanks! Found it! Probably won't tackle this one for awhile but my lady has been pushing for a shower setup since I built our wedge camper.

    https://www.amazon.com/Brazed-Exchanger-Heating-Melting-BL14-16D/dp/B07R5BQP2L

    OpeCity likes this.
  13. Mar 2, 2021 at 5:05 PM
    #1973
    OpeCity

    OpeCity Well-Known Member

    Joined:
    Feb 28, 2021
    Member:
    #357705
    Messages:
    301
    Long Beach, CA
    You can extend it pretty easily, just get some like sized cable and solder an extension into it. Or mount a CB in between and then you don’t even have to splice it.

    JKO1998 likes this.
  14. Apr 18, 2021 at 6:38 PM
    #1974
    rctoy

    rctoy It's about to get real!!!

    Joined:
    Feb 13, 2012
    Member:
    #72789
    Messages:
    6,950
    Gender:
    Male
    First Name:
    konstantenos
    Pocatello Idaho
    Vehicle:
    First gen 4door monster in progress
    TRD super charger, URD fuel mods and 2.1 super grip pully, Headers, 2.5" glass pack, Dana 60 front 4 linked, 14bolt rears on chev 63's, 5.38 gears, ARB locker in the front, PSC full hydraulic steering, 18" SAW 2.5" triple rate coils overs, FOA 2.5 air bumps, B&M launch controls, B&M trans cooler, 4 alpine 6X8 type R's amped, Red led rock lights, CBI front and rear bumpers (my design) CBI sliders, 4 riggid dualys front 2 in the rear, custom track bar, ARB snorkle, warn VR8000 winch, Viair 480c twin compressers..
    Custom shifters for the triple casses

  15. Apr 21, 2021 at 2:28 PM
    #1975
    SamSpade

    SamSpade Well-Known Member

    Joined:
    Sep 13, 2020
    Member:
    #340671
    Messages:
    76
    Gender:
    Male
    First Name:
    Rob
    Riverside, CT
    Vehicle:
    White ‘01 4x4 2.7L 5M
    love how tight to the body these sliders are.

    Lfaub03 likes this.
  16. Apr 22, 2021 at 11:21 AM
    #1976
    MalinoisDad

    MalinoisDad Well-Known Member

    Joined:
    Jul 16, 2017
    Member:
    #224205
    Messages:
    358
    Gender:
    Male
    First Name:
    Michael
    Sacramento, CA
    Vehicle:
    01 TRD OR PreRunner 5VZ
    5100s w/ 881s, JBA UCAs, J59s, ext SS brake lines, copious under the hood tinkering, preventative maintenance out the raisin, and I F-bombed my GD mud flaps.

    Which Way Out and Area51Runner like this.
  17. Jun 6, 2021 at 4:44 PM
    #1978
    badboypro

    badboypro Well-Known Member

    Joined:
    Feb 9, 2021
    Member:
    #355575
    Messages:
    80
    Gender:
    Male
    First Name:
    Sunnie
    Pittsburgh, PA
    Vehicle:
    1997 Tacoma SX
    crossposted, but thought i'd share here too...

    world's tiniest roof rack basket / toupée <3



    ontarioyota, sandsloth and Jiveydude like this.
  18. Jun 12, 2021 at 6:11 PM
    #1979
    Taco2021LB

    Taco2021LB Well-Known Member

    Joined:
    Jan 3, 2021
    Member:
    #351657
    Messages:
    802
    First Name:
    Don
    WA
    Vehicle:
    2004 DblCab 4x4
    OME 882 Dakars Falken 235/85R16s
    Compare to Truck Vault. I think I scored.
    Heavier, but this is a SERIOUS truck box system. Needs a little TLC and drawer liners.
    AAL's were going to be ordered a while back, but they were OOS. I have them on the way.
    [​IMG]
    https://www.weatherguard.com/products/truck-tool-boxes-equipment/pull-out-storage/HeavyDuty/338-3

    Edit
    I got mine bolted in, lined the drawers, and loaded up a few things. You will definitely need Add-A-Leafs. I'm hoping mine arrive soon.
    The Rat Pack dry weight.= 338 Lbs
    Spare tire/wheel = 77 Lbs.
    High-Lift Jack HL485 = 29 Lbs
    Content weight - Other = unknown.
    Due to the weight, I'm undecided if the box will remain. It's better suited in a full size truck.

    Last edited: Jun 22, 2021 at 8:49 AM
  19. Jun 22, 2021 at 3:22 PM
    #1980
    rctoy

    rctoy It's about to get real!!!

    Joined:
    Feb 13, 2012
    Member:
    #72789
    Messages:
    6,950
    Gender:
    Male
    First Name:
    konstantenos
    Pocatello Idaho
    Vehicle:
    First gen 4door monster in progress
    TRD super charger, URD fuel mods and 2.1 super grip pully, Headers, 2.5" glass pack, Dana 60 front 4 linked, 14bolt rears on chev 63's, 5.38 gears, ARB locker in the front, PSC full hydraulic steering, 18" SAW 2.5" triple rate coils overs, FOA 2.5 air bumps, B&M launch controls, B&M trans cooler, 4 alpine 6X8 type R's amped, Red led rock lights, CBI front and rear bumpers (my design) CBI sliders, 4 riggid dualys front 2 in the rear, custom track bar, ARB snorkle, warn VR8000 winch, Viair 480c twin compressers..
    LS2 swaped, one ton dual locked, tripple case having, Jerk on 46 in tires..

    seen20, chrslefty and POSTacoMike like this.
