Here is what I did over the weekend during my brief detention, I finished up that desk clock I made out of a 1st Gen Jeep ZJ (Grand Cherokee) VIC, or Vehicle Information Center. Stock, it would do things like tell you if the doors were open, if a sensor was bad, if a bulb burned out, or yell at you to change the oil. Now all it's really good for is a clock. It was for a good friend of mine's birthday. Shoutout to @Speedytech7 who found me three of them.



DISCLAIMER: I have never woodworked in my life, so don't be too harsh.

I made the case from a 6" plank of Red Oak Hardwood from Home Depot. I cut it to size to fit the VIC, and glued it together with wood glue. The molding is quarter round cut on a miter saw. I filled in the imperfections with wood filler.



Mistake #1 was wiping the excess wood glue. As you can see, it created areas where the stain would not adhere to. Kind of gives it a rustic look, so I'm not too upset.

Now, I'm on to the wiring. The VIC tells you all sorts of things about the vehicle. I didn't need any of that, just the four total wires that power on the unit.



Pin 2 is for Constant 12v, Pin 3 and 20 are for Ground, and Pin 16 was for Switched 12v (Ignition) I de-pinned everything else to leave those four wires.



In order to keep with the Chrysler tradition, I over-engineered the power delivery system and added in a lighted switch to simulate an ignition. I wanted this to have a removable power supply, so I ordered some 2.1x5.5mm 12v barrel receptacles.

You can see this all in my schematic below. (Thanks to @mechanicjon for helping with this part)



And now, the wiring.





It draws about 1.2 Amps at startup, and settles around 800-950 MA. I tried a 1.5, 2A, and 2.5A power adapter, but they did not work. I had to get a 5A power brick to finally get it to to turn on outside my lab DC power supply.



Originally, I had another board of Oak to seal the back shut. However, when I went to drill my holes for the power jack and button, it split the wood. In my desperation, I found a clipboard and cut it up to use.



And there it is, here is the final product.
