1st gen Tacoma rear shock help

Discussion in '1st Gen. Tacomas (1995-2004)' started by 02blancotaco, Feb 9, 2020.

  1. Feb 9, 2020 at 12:48 PM
    #1
    02blancotaco

    02blancotaco [OP] Well-Known Member

    Joined:
    Mar 12, 2019
    Member:
    #286428
    Messages:
    231
    Gender:
    Male
    First Name:
    Colby
    Vehicle:
    02 Toyota Tacoma 4x4 Trd
    Hey there, I was just reinstalling my factory rear shocks on my 2002 Tacoma as I just removed my airbags on the truck (airbags are for sale if interested) as there are the 5100s that require the lift, and I am not currently at stock height. But does the longer shock go on the drivers side or passenger side. Thanks.

  2. Feb 9, 2020 at 1:40 PM
    #2
    Wyoming09

    Wyoming09 Well-Known Member

    Joined:
    Apr 24, 2015
    Member:
    #153833
    Messages:
    11,015
    Gender:
    Male
    New Tripoli Pa
    Vehicle:
    2000 Work truck 5 speed 4x4 3.4
    Super Springs
    Not having any idea what might have been done.

    Why do you have 2 different length rear shocks ??

    From new they should be the same.

  3. Feb 9, 2020 at 1:42 PM
    #3
    LoveableWerewolf

    LoveableWerewolf Well-Known Member

    Joined:
    Feb 3, 2019
    Member:
    #281708
    Messages:
    524
    Nashville
    Vehicle:
    2014 5 lug
    4 runner seats, storage cubbies
    Should be same length

  4. Feb 9, 2020 at 1:43 PM
    #4
    LoveableWerewolf

    LoveableWerewolf Well-Known Member

    Joined:
    Feb 3, 2019
    Member:
    #281708
    Messages:
    524
    Nashville
    Vehicle:
    2014 5 lug
    4 runner seats, storage cubbies
    I've heard of some people who run different spring rates for more weight on one side, but that's custom and kinda weird. And this has nothing to do with shocks

  5. Feb 9, 2020 at 4:20 PM
    #5
    Kwikvette

    Kwikvette My 4R identifies as a Tacoma

    Joined:
    Feb 27, 2019
    Member:
    #284735
    Messages:
    22,507
    Gender:
    Male
    Salinas, CA
    Vehicle:
    98 4R Limited 4x4
    King 2.5 Front/Rear, OME 906, 33s and Locked
    Longer shock goes on the passenger side; they're not equal length between the 2 of them.

    Last edited: Feb 29, 2020
    Uphillshunter and Rachelsdaddy like this.
  6. Feb 9, 2020 at 4:21 PM
    #6
    Kwikvette

    Kwikvette My 4R identifies as a Tacoma

    Joined:
    Feb 27, 2019
    Member:
    #284735
    Messages:
    22,507
    Gender:
    Male
    Salinas, CA
    Vehicle:
    98 4R Limited 4x4
    King 2.5 Front/Rear, OME 906, 33s and Locked

  7. Feb 9, 2020 at 4:23 PM
    #7
    LoveableWerewolf

    LoveableWerewolf Well-Known Member

    Joined:
    Feb 3, 2019
    Member:
    #281708
    Messages:
    524
    Nashville
    Vehicle:
    2014 5 lug
    4 runner seats, storage cubbies
    Hmm, I guess I know a guy who put the wrong shocks on his truck:rofl:

    cornbread_wy and Kwikvette like this.
  8. Feb 9, 2020 at 4:25 PM
    #8
    Kwikvette

    Kwikvette My 4R identifies as a Tacoma

    Joined:
    Feb 27, 2019
    Member:
    #284735
    Messages:
    22,507
    Gender:
    Male
    Salinas, CA
    Vehicle:
    98 4R Limited 4x4
    King 2.5 Front/Rear, OME 906, 33s and Locked
    Oof

    The way the shocks are setup doesn't attribute to an equal length setup.

    This becomes more apparent when you're upgrading for a more specific purpose such as off-roading where suspension travel is very important.

  9. Feb 10, 2020 at 1:35 AM
    #9
    Wyoming09

    Wyoming09 Well-Known Member

    Joined:
    Apr 24, 2015
    Member:
    #153833
    Messages:
    11,015
    Gender:
    Male
    New Tripoli Pa
    Vehicle:
    2000 Work truck 5 speed 4x4 3.4
    Super Springs
    I guess mine are wrong as well .

    Must have been a bad day learn something new all the time .

  10. Feb 10, 2020 at 7:27 AM
    #10
    kamaaina1

    kamaaina1 Well-Known Member

    Joined:
    Jun 5, 2017
    Member:
    #220748
    Messages:
    167
    Gender:
    Male
    First Name:
    Sean
    Vancouver, WA
    Vehicle:
    2004 TRD Tacoma x-cab
    Two different lengths: Collapsed / Extended lengths:
    • BIL BE5-D559-TO 5100 Rear Shock, 95-04 Tacoma, Driver Side, 13.9" x 21.6"
    • BIL BE5-D560-TO 5100 Rear Shock, 95-04 Tacoma, Passenger Side, 14.7" x 22.6"

    Uphillshunter and Kwikvette like this.
  11. Feb 10, 2020 at 8:42 AM
    #11
    Kwikvette

    Kwikvette My 4R identifies as a Tacoma

    Joined:
    Feb 27, 2019
    Member:
    #284735
    Messages:
    22,507
    Gender:
    Male
    Salinas, CA
    Vehicle:
    98 4R Limited 4x4
    King 2.5 Front/Rear, OME 906, 33s and Locked
    You forgot the other style meant for minimal lift, also Bilstein 5100's

    33-247724 21.26 EXT 13.62 COL Driver side shock
    33-247717 22.09 EXT 14.07 COL Passenger side shock

    kamaaina1 likes this.
  12. Feb 10, 2020 at 12:18 PM
    #12
    adamdsgn

    adamdsgn Well-Known Member

    Joined:
    Sep 21, 2018
    Member:
    #266956
    Messages:
    153
    Gender:
    Male
    First Name:
    Adam
    Vehicle:
    2003 Tacoma Double-Cab - TRD/4x4
    I ran into the same issue during my install. Had to google part numbers and run thru a couple of pages before I found the answer.

  13. Feb 11, 2020 at 7:20 AM
    #13
    Boost JuNkY

    Boost JuNkY Well-Known Member

    Joined:
    Apr 10, 2011
    Member:
    #54706
    Messages:
    361
    Gender:
    Male
    First Name:
    Billy
    Vancouver, BC
    Vehicle:
    2003 TACOMA DC OFF ROAD
    35'S ON 3s
    Shorter shock goes on the driver side since the brake like is there and too much droop with oem length hose is never a good idea.

  14. Feb 29, 2020 at 2:07 PM
    #14
    Kristi with a K

    Kristi with a K Well-Known Member

    Joined:
    Nov 19, 2017
    Member:
    #236406
    Messages:
    833
    Gender:
    Female
    Western MA
    Vehicle:
    01' Red (was Maroon) Tacoma 4x4 SR5 ACab 3.4L AT
    G-Men sticker, driver's side "backseat" window - cracked driver's side headlight cover complete with hazy look - DIY 50 footer paint lift in Safety Red
    Any idea why KYB's appear to be excluded from this requirement?
    I was looking at TRQ shocks & there was a review regarding this R/L thing. The length & I guess the ID of the bushing being another clue. He kept the front assemblies & gave 'em thumbs up, but returned the rears. The whole thing piqued my interest. Went to a taco parts site & sure enough, whether your a TRD or not, R/L. I had noticed the KYB exclusion earlier, so back to this TRQ site to post the following examples....

    "THIS PART REPLACES:

    • KYB 344428
    • OE # 48541A9010
    • OE # 48531A9040
    • Monroe 37113
    • Monroe 37032"
    "THIS PART REPLACES:

  15. Feb 29, 2020 at 2:37 PM
    #15
    ccraider

    ccraider Active Member

    Joined:
    Jan 29, 2020
    Member:
    #317673
    Messages:
    42
    I’m not following you here ?
    The KYB, OE and Monroe numbers are the same on both lists ?

  16. Feb 29, 2020 at 2:56 PM
    #16
    Kristi with a K

    Kristi with a K Well-Known Member

    Joined:
    Nov 19, 2017
    Member:
    #236406
    Messages:
    833
    Gender:
    Female
    Western MA
    Vehicle:
    01' Red (was Maroon) Tacoma 4x4 SR5 ACab 3.4L AT
    G-Men sticker, driver's side "backseat" window - cracked driver's side headlight cover complete with hazy look - DIY 50 footer paint lift in Safety Red
    Correct. Just using two examples to make my point, or rather, pointed question. Although maybe that just confused it cuz the second list has front assemblies & this post is about the rear shocks. My bad.... Point is, using the first list, there are two OE, L & R specific. There are two Monroe, L & R specific. There is one KYB, non side specific.... Why does side specific matter with the others (other brands as well), but not KYB?
