2nd Gen Retrofit Halo Wire Routing

Discussion in 'Lighting' started by plurpimpin, Jan 16, 2020.

Post Reply

Jan 16, 2020 at 9:00 AM

#1

#1
plurpimpin [OP] Well-Known Member

Joined:

Jul 31, 2011

Member:

#60895

Messages:

2,971

Gender:

Male

PDX

Vehicle:

2010 TRD Off Road 4x4

I’m finally wrapping up my retrofit I’ve been working on over the last few months.

The only thing left is installing a 9mm gland seal for the halo wires to pass through and sealing them back up. Anybody have some pictures of how they routed their wires out of the headlight housing? I’m alittle worried about clearance between the gland seal nut and the reflector bowl so trying to find the best spot.

And a progress pic of where I’m at:

plurpimpin, Jan 16, 2020
