3x Unlock Tailgate Opener

Discussion in '3rd Gen. Tacomas (2016+)' started by DSIM, Apr 22, 2019.

  1. Apr 22, 2019 at 6:06 AM
    #1
    DSIM

    DSIM [OP] Well-Known Member

    Joined:
    Feb 5, 2018
    Member:
    #243518
    Messages:
    862
    Gender:
    Male
    First Name:
    Daniel
    Raleigh, NC
    Vehicle:
    2017 MGM Tacoma TRD Off-Road
    Update: Lots of progression made to this mod, moved to the Marketplace thread.
    https://dsimsolutions.com/products/tail-gate-opener-module-v2


    Been working on another small mod as I have had time. I had a spare actuator laying around and was wanting to play with a TR7 module.

    I have a pop n lock setup already that was installed when I bought the truck. This handles the lock/unlock of the tailgate. I was wanting to see if another actuator could be used to open the tailgate. The actuator portion is pretty easy, it just attaches to the tailgate linkage and pulls it back. For testing I just clamped the actuator to the tailgate in line with the tailgate linkage so it would pull it when activated.


    Temporary wiring of the actuator showed that it would work so I got to work programming my TR7 module. The TR7 module is able to recognize 3 unlock button pushes and activate a relay that triggers the actuator to pull for two seconds.

    At first I was thinking there would not be enough pushing the tailgate rearward to get it to pop. I was thinking a set of door poppers would be required, like these. But after testing it seemed there was enough without them.

    So, check it out. Here's the proto.



    So it seems this was pretty easy. Only things left are to consider mounting of the actuator. I like to avoid drillling into the truck so I plan on trying @KTJO 4x4 's mounting brackets from her popnlock kit. Will just need to angle the rod so it pulls correctly as the actuator with that bracket is not lined up with the linkage. Next I need to find an easy power / ground source near the tailgate. Ideally I'd like to find a male/female connector that I can t-harness off of. I still have some more research to do, but the proof of concept is there.

    If I can button up and Plug N Play this setup pretty nice, I am considering selling these. But we will see how development goes.

    Last edited: Oct 21, 2019
  2. Apr 22, 2019 at 6:06 AM
    #2
    DSIM

    DSIM [OP] Well-Known Member

    Joined:
    Feb 5, 2018
    Member:
    #243518
    Messages:
    862
    Gender:
    Male
    First Name:
    Daniel
    Raleigh, NC
    Vehicle:
    2017 MGM Tacoma TRD Off-Road
    Reserved

  3. Apr 22, 2019 at 6:06 AM
    #3
    DSIM

    DSIM [OP] Well-Known Member

    Joined:
    Feb 5, 2018
    Member:
    #243518
    Messages:
    862
    Gender:
    Male
    First Name:
    Daniel
    Raleigh, NC
    Vehicle:
    2017 MGM Tacoma TRD Off-Road
    Reserved x2

  4. Apr 22, 2019 at 6:16 AM
    #4
    muffyinva

    muffyinva Well-Known Member

    Joined:
    Mar 7, 2019
    Member:
    #285707
    Messages:
    124
    Gender:
    Male
    First Name:
    Reid
    Lynchburg, VA
    Vehicle:
    2019 Cement Tacoma DCSB OR
    Awesome! Would be very interested.

  5. Apr 22, 2019 at 6:27 AM
    #5
    commbubba19

    commbubba19 Well-Known Member

    Joined:
    Jan 2, 2018
    Member:
    #240020
    Messages:
    1,081
    Gender:
    Male
    Omaha, NE
    Vehicle:
    2017 Tacoma OR - SOLD
  6. Apr 22, 2019 at 6:45 AM
    #6
    KTJO 4x4

    KTJO 4x4 Well-Known Member

    Joined:
    Oct 10, 2016
    Member:
    #199424
    Messages:
    3,905
    Gender:
    Female
    First Name:
    Katie
    Oregon
    Vehicle:
    2017 TRD OFF-ROAD 4x4 DCSB BARCELONA RED
    Nitro 4.88 Gears OVTune 1.05 91Oct DirtyDeeds Exhaust
    I LOVE IT!!! Brackets come in this week Buddy!!! I cannot wait for this.

    doublethebass and DSIM [OP] like this.
  7. Apr 22, 2019 at 8:07 AM
    #7
    patdeezy

    patdeezy Well-Known Member

    Joined:
    Jun 19, 2016
    Member:
    #190028
    Messages:
    1,056
    Gender:
    Male
    souLcaL
    Vehicle:
    '19 OR 4x4 SuperWhite DCSB
    this is legit!!!

    DSIM [OP] likes this.
  8. Apr 22, 2019 at 8:54 AM
    #8
    panzer716

    panzer716 Well-Known Member

    Joined:
    Jan 3, 2019
    Member:
    #277924
    Messages:
    93
    Gender:
    Male
    First Name:
    Allan
    Vehicle:
    2019 Calvary Blue Tacoma TRD Sport DCLB
    Pro Grill Swap, Leitner Designs ACS, KTJO 4x4 Pop Lock Tailgate Kit, Wet Okole Seat Covers, Meso Gashole.
    Looking forward to seeing this. I have Katie's kit and would love to add this feature on if it works. Hoping you sell this. Haha

    Last edited: Apr 25, 2019
  9. Apr 22, 2019 at 9:16 AM
    #9
    slowlane

    slowlane Well-Known Member

    Joined:
    May 7, 2014
    Member:
    #129313
    Messages:
    2,631
    Gender:
    Male
    AZ
    Vehicle:
    16 double cab MGM
    Buddy of mine did this to his tundra. Pretty cool mod.

  10. Apr 22, 2019 at 9:20 AM
    #10
    MESO

    MESO Major Modder Vendor

    Joined:
    Feb 16, 2015
    Member:
    #148809
    Messages:
    15,908
    Gender:
    Male
    State of Jefferson
    Vehicle:
    2016 DCLB TRD 2JZ
    Rav 4 fob with the 3rd button programmed for tailgate drop would be legit.
    My only concern is accidentally hitting the unlock 1 more time and having the tailgate drop unintentionally
    (depending on what I am backed up against could be trouble)
    Love the innovation though!

    Having a dedicated button (and add that it would require a long hold) rules out any doubt in my mind.

  11. Apr 22, 2019 at 9:50 AM
    #11
    slowlane

    slowlane Well-Known Member

    Joined:
    May 7, 2014
    Member:
    #129313
    Messages:
    2,631
    Gender:
    Male
    AZ
    Vehicle:
    16 double cab MGM
    I was thinking the same. Sometimes I hit the lock and unlock buttons more time than I should. But assuming the remote thing gets worked out, I would interested in this.

  12. Apr 22, 2019 at 11:14 AM
    #12
    DSIM

    DSIM [OP] Well-Known Member

    Joined:
    Feb 5, 2018
    Member:
    #243518
    Messages:
    862
    Gender:
    Male
    First Name:
    Daniel
    Raleigh, NC
    Vehicle:
    2017 MGM Tacoma TRD Off-Road
    Could always tap into the parking sensors to make sure there are no obstacles close. Now THAT would be some wizardry.

    But Im not sure the Fob could work, you'd have to also swap the receiver on the vehicle side wouldnt you? $200 new remote plus the device on the vehicle side would add up quickly. And those oem fobs are rolling code so I doubt it'd be possible to have an arduino or something seperate read the signal from the trunk button.

    I can increase the button count with the fob to like 4 or 5 easily. Would just be a lot of toyota chiming.

  13. Apr 22, 2019 at 11:16 AM
    #13
    uploadadventure

    uploadadventure Well-Known Member

    Joined:
    Jan 30, 2019
    Member:
    #281288
    Messages:
    8,666
    Gender:
    Male
    First Name:
    Rich
    Lake Sherwood, MO
    Vehicle:
    2019 Cavalry Blue Tacoma TRD OR
    OVTune, SOS Armor, MESO stuff, UpTopOverland roof rack, Desert Armor RTT, Softopper, Rigid & BD lights, RCI Armor, ROAM awning, misc stuff
    Sub’d

    Interested to see where this goes

  14. Apr 22, 2019 at 12:10 PM
    #14
    TacoTruck808

    TacoTruck808 Well-Known Member

    Joined:
    May 15, 2017
    Member:
    #219102
    Messages:
    2,032
    Gender:
    Male
    Oahu in the Aloha State!
    Vehicle:
    2016 Tacoma TRD Sport DCSB, Prem & Tech Pkg, MGM
    I had the same thought as you or i would have actually tried to figure out something myself. I wouldnt want the tailgate to open by accident.


    Thats my Garage door 1-2 inches from the rear bumper.

    But having a sensor or something to keep it from opening in those kinds of situations would be good!

    r_to_the_k likes this.
  15. Apr 22, 2019 at 12:21 PM
    #15
    TacoTruck808

    TacoTruck808 Well-Known Member

    Joined:
    May 15, 2017
    Member:
    #219102
    Messages:
    2,032
    Gender:
    Male
    Oahu in the Aloha State!
    Vehicle:
    2016 Tacoma TRD Sport DCSB, Prem & Tech Pkg, MGM
    Actually a 3 times push of the unlock would still work. I have my truck set to unlock all doors on 1 push, to accommodate the Passenger side smart handle so I would have to purposefully push it 3 times. I guess I shouldnt be worried, I was at first when we got my wifes Lexus that has a powered tailgate. It would be exactly the same thing since she parks on the other side of that garage door, almost as close as I do.:)

  16. Apr 22, 2019 at 12:41 PM
    #16
    STrooper

    STrooper For HIS glory!

    Joined:
    Jan 27, 2019
    Member:
    #280870
    Messages:
    1,803
    Gender:
    Male
    First Name:
    Jack
    NC
    Vehicle:
    2018 TRD Sport QuickSand / 2020 TRD Sport Cement!
    GENIUS absolute GENIUS!!!:thumbsup:

    DSIM [OP] likes this.
  17. Apr 22, 2019 at 1:15 PM
    #17
    BlkTaco47

    BlkTaco47 Unhinged

    Joined:
    Apr 9, 2011
    Member:
    #54635
    Messages:
    4,971
    Gender:
    Male
    Vehicle:
    2016 Black AT DCSB 4x4 TRD
    JL Audio C2690tx Speakers Alpine MRV-F300 JL Audio 10" Sub - Full length Ported Sub Box Kicker Tweeters BFG KO2's 265/70/17 Tint N-Fab Bars Husky WB Mats AVS Visors Console Divider Tacoma Tonneau Cover ALL PRO 1.5" wheel spacers aFe CAI w/ Dry filter TRD Wheels Custom Remote Starter TRD Pro Grille ROAV Dash Cam 3" RC Lift Turn-down exhaust pipe TRD PRO Shift Knob vF Tune
    very cool

  18. Apr 22, 2019 at 1:33 PM
    #18
    caribe makaira

    caribe makaira Well-Known Member

    Joined:
    Feb 13, 2011
    Member:
    #51121
    Messages:
    5,078
    Gender:
    Male
    Caribbean, Puerto Rico
    Vehicle:
    05 PreRunner TRD Offroad AutoTrans
    Hood Struts, My version Fogs always ON, Map & Overhead Light Mod,
    There are none, the nearest would be the 7-pin trailer harness connector, the battery charging pin, but that needs ACC on...so no constant hot. Run a dedicated fused line tho the rear.

  19. Apr 23, 2019 at 1:40 PM
    #19
    TacoTruck808

    TacoTruck808 Well-Known Member

    Joined:
    May 15, 2017
    Member:
    #219102
    Messages:
    2,032
    Gender:
    Male
    Oahu in the Aloha State!
    Vehicle:
    2016 Tacoma TRD Sport DCSB, Prem & Tech Pkg, MGM
    @DSIM , was the DEI 524N actuator that you used have enough pulling strength to pop the tailgate on every try? I remember in the past, I had to use the 522T to pop open my trunk because the standard actuators didnt have enough pulling power. That was back in the day when they didnt have the 524N though. I was just curious. Looks like this would be a very cool mod if you could make it plug and play or easy to connect up the module and actuator.

  20. Apr 23, 2019 at 1:46 PM
    #20
    DSIM

    DSIM [OP] Well-Known Member

    Joined:
    Feb 5, 2018
    Member:
    #243518
    Messages:
    862
    Gender:
    Male
    First Name:
    Daniel
    Raleigh, NC
    Vehicle:
    2017 MGM Tacoma TRD Off-Road
    The DEI 524N I had in my garage worked just fine, I am researching some other options however.

    I am currently working on making a PNP solution for the wiring. Think I am on the right track, I've got it drawn up electrically where everything would stay in the cab connecting to KTJO's PopNLock harness. And one chassis ground for the actuator.

    Don't want to get two excited until I prove out my thoughts.

    wahoobie and TacoTruck808 like this.
