5100's installed - alignment specs.

Discussion in 'Suspension' started by NiceTaco, Mar 13, 2013.

  1. Mar 13, 2013 at 5:08 PM
    #1
    NiceTaco

    NiceTaco [OP] Canadian Redneck

    Joined:
    May 1, 2008
    Member:
    #6336
    Messages:
    483
    Gender:
    Male
    Ontario, Canada
    Vehicle:
    2012 TRD Sport
    Aero Turbine 2525, Front bilstein 5100's @1.75, rear 5100's, 1" Toytec rear block, Devil Horns, BGF AT's, 18" Moto Metal 962's
    got 5100's installed today.. Please check out my alignment specs and let me know. If they are off let me know what and let me know what it should be and the range.


  2. Mar 14, 2013 at 3:28 AM
    #2
    NiceTaco

    NiceTaco [OP] Canadian Redneck

    Joined:
    May 1, 2008
    Member:
    #6336
    Messages:
    483
    Gender:
    Male
    Ontario, Canada
    Vehicle:
    2012 TRD Sport
    Aero Turbine 2525, Front bilstein 5100's @1.75, rear 5100's, 1" Toytec rear block, Devil Horns, BGF AT's, 18" Moto Metal 962's
  3. Mar 14, 2013 at 3:47 AM
    #3
    Millertime187

    Millertime187 I'll be your huckleberry!

    Joined:
    Sep 25, 2012
    Member:
    #87698
    Messages:
    1,920
    Gender:
    Male
    First Name:
    David
    Clay City, KY
    Vehicle:
    2012 4x4 Single Cab Taco!
    EZ Lift/Pro Comp 3" lift. Spacer in front, add a leaf in rear, Bilstien 5100 shocks, TC UCA, 5% Tint all around, Painted all trim to match. Magnaflow muffler dumped, drop in k&n air filter, tinted tail lights
    Look good to me. Do you have UCA?

    [​IMG]

    This is mine from Toyota it has ranges on there

  4. Mar 14, 2013 at 4:58 AM
    #4
    NiceTaco

    NiceTaco [OP] Canadian Redneck

    Joined:
    May 1, 2008
    Member:
    #6336
    Messages:
    483
    Gender:
    Male
    Ontario, Canada
    Vehicle:
    2012 TRD Sport
    Aero Turbine 2525, Front bilstein 5100's @1.75, rear 5100's, 1" Toytec rear block, Devil Horns, BGF AT's, 18" Moto Metal 962's
    Stock UCA's... My toe seems on the high side of the specs...

  5. Mar 14, 2013 at 5:04 AM
    #5
    Millertime187

    Millertime187 I'll be your huckleberry!

    Joined:
    Sep 25, 2012
    Member:
    #87698
    Messages:
    1,920
    Gender:
    Male
    First Name:
    David
    Clay City, KY
    Vehicle:
    2012 4x4 Single Cab Taco!
    EZ Lift/Pro Comp 3" lift. Spacer in front, add a leaf in rear, Bilstien 5100 shocks, TC UCA, 5% Tint all around, Painted all trim to match. Magnaflow muffler dumped, drop in k&n air filter, tinted tail lights
    Probably since they have so much caster with the stock UCA. If your tire don't rub when you turn wheels I would say your good. Should drive good with that caster. I'm surprised they got that much with stock UCA.

  6. Mar 14, 2013 at 5:07 AM
    #6
    Millertime187

    Millertime187 I'll be your huckleberry!

    Joined:
    Sep 25, 2012
    Member:
    #87698
    Messages:
    1,920
    Gender:
    Male
    First Name:
    David
    Clay City, KY
    Vehicle:
    2012 4x4 Single Cab Taco!
    EZ Lift/Pro Comp 3" lift. Spacer in front, add a leaf in rear, Bilstien 5100 shocks, TC UCA, 5% Tint all around, Painted all trim to match. Magnaflow muffler dumped, drop in k&n air filter, tinted tail lights
    [​IMG]

    This one is just 3 inch lift with no UCA

    Edit: also drove like crap with this one. Wondering like crazy!

    Last edited: Mar 14, 2013
  7. Mar 14, 2013 at 5:11 AM
    #7
    Large

    Large Red

    Joined:
    Sep 10, 2011
    Member:
    #63268
    Messages:
    16,123
    Gender:
    Male
    I was always under the impression:

    Caster: 2.5 - 3 degrees
    Camber: 0 degrees
    Toe: 0 degrees

  8. Mar 14, 2013 at 5:27 AM
    #8
    NiceTaco

    NiceTaco [OP] Canadian Redneck

    Joined:
    May 1, 2008
    Member:
    #6336
    Messages:
    483
    Gender:
    Male
    Ontario, Canada
    Vehicle:
    2012 TRD Sport
    Aero Turbine 2525, Front bilstein 5100's @1.75, rear 5100's, 1" Toytec rear block, Devil Horns, BGF AT's, 18" Moto Metal 962's
    It drives perfect no wander no pulling..

  9. Mar 14, 2013 at 5:29 AM
    #9
    NiceTaco

    NiceTaco [OP] Canadian Redneck

    Joined:
    May 1, 2008
    Member:
    #6336
    Messages:
    483
    Gender:
    Male
    Ontario, Canada
    Vehicle:
    2012 TRD Sport
    Aero Turbine 2525, Front bilstein 5100's @1.75, rear 5100's, 1" Toytec rear block, Devil Horns, BGF AT's, 18" Moto Metal 962's
    That's why I posted to see what the specs were and get feedback on my results..
    I think those exact specs are in a perfect world.. It looks like I am within the range.

  10. Mar 14, 2013 at 5:30 AM
    #10
    Millertime187

    Millertime187 I'll be your huckleberry!

    Joined:
    Sep 25, 2012
    Member:
    #87698
    Messages:
    1,920
    Gender:
    Male
    First Name:
    David
    Clay City, KY
    Vehicle:
    2012 4x4 Single Cab Taco!
    EZ Lift/Pro Comp 3" lift. Spacer in front, add a leaf in rear, Bilstien 5100 shocks, TC UCA, 5% Tint all around, Painted all trim to match. Magnaflow muffler dumped, drop in k&n air filter, tinted tail lights
    Yea I do believe that's what you wanna shoot for.

  11. Mar 14, 2013 at 5:30 AM
    #11
    Large

    Large Red

    Joined:
    Sep 10, 2011
    Member:
    #63268
    Messages:
    16,123
    Gender:
    Male
    Yeah the caster on your wheels are 3.7-3.8, if it's fine for you I would leave it alone.

  12. Mar 14, 2013 at 5:35 AM
    #12
    T@co_Pr3runn3r

    T@co_Pr3runn3r XXXXXXXXXXXXXXXXXXX

    Joined:
    Jan 20, 2009
    Member:
    #12767
    Messages:
    10,367
    Gender:
    Male
    <----------------->
    Vehicle:
    08 RC Prerunner SR5
    UCAs when lifting are so worth it IMO so you don't have to be marginal on any of your alignment specs.......

  13. Mar 14, 2013 at 5:38 AM
    #13
    Millertime187

    Millertime187 I'll be your huckleberry!

    Joined:
    Sep 25, 2012
    Member:
    #87698
    Messages:
    1,920
    Gender:
    Male
    First Name:
    David
    Clay City, KY
    Vehicle:
    2012 4x4 Single Cab Taco!
    EZ Lift/Pro Comp 3" lift. Spacer in front, add a leaf in rear, Bilstien 5100 shocks, TC UCA, 5% Tint all around, Painted all trim to match. Magnaflow muffler dumped, drop in k&n air filter, tinted tail lights
    They made a HUGE improvement on my truck. I'm so glad I got them.

  14. Mar 14, 2013 at 5:42 AM
    #14
    JonnyBb

    JonnyBb I have to return some videotapes

    Joined:
    Mar 26, 2011
    Member:
    #53778
    Messages:
    2,765
    Gender:
    Male
    Arkansas
    Vehicle:
    2010 TRD Sport DC LB 4x4
    Work in progress, but installed so far; 265/70/17 Duratracs, Spidertrax, OME885X coils with OME lean spacer, OME N140S and N182 shocks, Wheeler's 1.5" 3 Leaf Progressive AAL (kept the overload), LR UCAs. TP14 spacers
    x3

  15. Mar 14, 2013 at 8:38 AM
    #15
    NiceTaco

    NiceTaco [OP] Canadian Redneck

    Joined:
    May 1, 2008
    Member:
    #6336
    Messages:
    483
    Gender:
    Male
    Ontario, Canada
    Vehicle:
    2012 TRD Sport
    Aero Turbine 2525, Front bilstein 5100's @1.75, rear 5100's, 1" Toytec rear block, Devil Horns, BGF AT's, 18" Moto Metal 962's
    Mine are?

  16. Mar 14, 2013 at 8:38 AM
    #16
    NiceTaco

    NiceTaco [OP] Canadian Redneck

    Joined:
    May 1, 2008
    Member:
    #6336
    Messages:
    483
    Gender:
    Male
    Ontario, Canada
    Vehicle:
    2012 TRD Sport
    Aero Turbine 2525, Front bilstein 5100's @1.75, rear 5100's, 1" Toytec rear block, Devil Horns, BGF AT's, 18" Moto Metal 962's
    If I go any higher I will definetley get new UCA's but not for this small of a lift.

  17. Mar 14, 2013 at 8:48 AM
    #17
    Large

    Large Red

    Joined:
    Sep 10, 2011
    Member:
    #63268
    Messages:
    16,123
    Gender:
    Male
    Whoops sorry I was looking at "millertimes" sheet.

  18. Mar 14, 2013 at 8:50 AM
    #18
    NiceTaco

    NiceTaco [OP] Canadian Redneck

    Joined:
    May 1, 2008
    Member:
    #6336
    Messages:
    483
    Gender:
    Male
    Ontario, Canada
    Vehicle:
    2012 TRD Sport
    Aero Turbine 2525, Front bilstein 5100's @1.75, rear 5100's, 1" Toytec rear block, Devil Horns, BGF AT's, 18" Moto Metal 962's
    No problem... I was just confused for a minute..
