A-TRAC for 4cyl.

Discussion in '4 Cylinder' started by itsryan, Mar 24, 2011.

  1. Mar 24, 2011 at 1:11 PM
    #1
    itsryan

    itsryan [OP] Active Member

    Joined:
    Mar 19, 2011
    Member:
    #53314
    Messages:
    25
    Gender:
    Male
    Chino Hills
    Vehicle:
    11 4banger 4x4 SR5- sold
    2.5i 2015 Subaru Outback
    I was curious to know if anyone knows, if Toyota has A-TRAC for the 2.7l.
    In my truck, a 2011 ac 4x4 mt 4cyl, I see the blank switch cover where ATRAC should be. Is there a way you can add this system? Or do u have to buy it with car? Please you answers appreciated!

  2. Mar 24, 2011 at 2:03 PM
    #2
    sambojee

    sambojee Well-Known Member

    Joined:
    Mar 24, 2011
    Member:
    #53629
    Messages:
    292
    Gender:
    Male
    First Name:
    Sam
    Iowa
    Vehicle:
    2011 TRD OffRoad
    Bilstein 5100 all around set at 2.5. 1.5 AAL in the rear. 265/75/16 Hancook Dynapro MTs on Black Moto Metal 951s. Black badges. Aftermarket grill. TRD seat covers.
    I dont think they offer it for the 2.7L but i think for ur year u can perform the "yellow wire mod". haha sorry i dont know a whole lot about it but i wanted to do it to my truck but i couldnt

  3. Mar 24, 2011 at 2:07 PM
    #3
    OZ-T

    OZ-T Quite an experience to live in fear , isn't it ?

    Joined:
    Dec 15, 2009
    Member:
    #27584
    Messages:
    38,725
    Gender:
    Male
    First Name:
    Peter North
    British Columbia
    Vehicle:
    Mag Grey 09 Trd Sport DCLB 4x4
    OME 885x , OME shocks and Dakars , Wheelers SuperBumps front and rear , 275/70/17 Hankook ATm , OEM bed mat , Weathertech digifit floor liners , Weathertech in-channel vents , headache rack , Leer 100RCC commercial canopy , TRD bedside decals removed , Devil Horns by Andres , HomerTaco Satoshi
    You're back

  4. Mar 24, 2011 at 2:24 PM
    #4
    sambojee

    sambojee Well-Known Member

    Joined:
    Mar 24, 2011
    Member:
    #53629
    Messages:
    292
    Gender:
    Male
    First Name:
    Sam
    Iowa
    Vehicle:
    2011 TRD OffRoad
    Bilstein 5100 all around set at 2.5. 1.5 AAL in the rear. 265/75/16 Hancook Dynapro MTs on Black Moto Metal 951s. Black badges. Aftermarket grill. TRD seat covers.
    so u can only do the yellow wire mod if u have ALSD? i thought i saw a youtube video of a guy doing this mod on the same truck as the OP...i could be wrong

  5. Mar 24, 2011 at 2:25 PM
    #5
    sambojee

    sambojee Well-Known Member

    Joined:
    Mar 24, 2011
    Member:
    #53629
    Messages:
    292
    Gender:
    Male
    First Name:
    Sam
    Iowa
    Vehicle:
    2011 TRD OffRoad
    Bilstein 5100 all around set at 2.5. 1.5 AAL in the rear. 265/75/16 Hancook Dynapro MTs on Black Moto Metal 951s. Black badges. Aftermarket grill. TRD seat covers.
    yes sir :D its a long story

  6. Mar 24, 2011 at 2:30 PM
    #6
    sambojee

    sambojee Well-Known Member

    Joined:
    Mar 24, 2011
    Member:
    #53629
    Messages:
    292
    Gender:
    Male
    First Name:
    Sam
    Iowa
    Vehicle:
    2011 TRD OffRoad
    Bilstein 5100 all around set at 2.5. 1.5 AAL in the rear. 265/75/16 Hancook Dynapro MTs on Black Moto Metal 951s. Black badges. Aftermarket grill. TRD seat covers.
    oh really? i didnt know that

  7. Mar 24, 2011 at 2:33 PM
    #7
    sambojee

    sambojee Well-Known Member

    Joined:
    Mar 24, 2011
    Member:
    #53629
    Messages:
    292
    Gender:
    Male
    First Name:
    Sam
    Iowa
    Vehicle:
    2011 TRD OffRoad
    Bilstein 5100 all around set at 2.5. 1.5 AAL in the rear. 265/75/16 Hancook Dynapro MTs on Black Moto Metal 951s. Black badges. Aftermarket grill. TRD seat covers.
    haha thanks

  8. Mar 24, 2011 at 5:40 PM
    #8
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,995
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    Good job boys!

  9. Mar 24, 2011 at 9:51 PM
    #9
    itsryan

    itsryan [OP] Active Member

    Joined:
    Mar 19, 2011
    Member:
    #53314
    Messages:
    25
    Gender:
    Male
    Chino Hills
    Vehicle:
    11 4banger 4x4 SR5- sold
    2.5i 2015 Subaru Outback
    Thanks everyone for clearing that up a bit. So if yellow wire mod works like ALSD? So if I Have ALSD then is yellow wire nessasary.

  10. Mar 24, 2011 at 10:08 PM
    #10
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,995
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    I find that charts and lists make understanding this stuff easier...

    1) 2WD is normally in TRAC MODE... a light limited slip that uses the brakes and also regulates engine output to reduce spinning of low traction tires.

    2) ALSD (AUTO LSD) is a 2WD ONLY MODE... It removes the engine output regulation normally on in 2WD (TRAC MODE) so your limited slip is 'stronger' should you be stuck. You turn it on with a quick push of the VSC button.

    3) If desired, you can turn off the traction controls and have open, free spinning differential action in 2WD or 4WD-HI. You must stop the vehicle and then push and hold down the VSC button for a few seconds until the light come on alerting you that you are in VSC OFF MODE (TRAC is also off).

    4) In 4WD HIGH (H4), you are in TRAC, but the engine output is not regulated (as with AUTO LSD)... nothing to push. This is an effective limited slip traction aid. See #3 if you desire open differentials in H4.

    5) In 4WD LOW, you have NO TRACTION CONTROL (except Off Road TRDs)... Your option is to perform the 4-Lo Trac Mod (yellow wire mod) which tricks your truck into thinking it is in H4 when you are in L4.

  11. Mar 25, 2011 at 4:09 AM
    #11
    HomeGrown

    HomeGrown Well-Known Member

    Joined:
    Jan 11, 2011
    Member:
    #49116
    Messages:
    336
    Gender:
    Male
    First Name:
    Bill
    South Bend, IN
    Vehicle:
    2014 Reg Cab 4WD
    Great overview David, thank you for compiling that information into one easy-to-understand post! :)

    Is the TRAC or ALSD as effective as an old-school limited-slip or posi differential?

  12. Mar 25, 2011 at 4:23 AM
    #12
    alexander323bc

    alexander323bc Well-Known Member

    Joined:
    Nov 20, 2010
    Member:
    #46454
    Messages:
    621
    Gender:
    Male
    First Name:
    Eric
    Buffalo New York
    Vehicle:
    4cyl access cab
    Its kind of hard to have A-Trac on a truck that has rear drum brakes.

  13. Mar 25, 2011 at 8:40 AM
    #13
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,995
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    Glad it was helpful! You're welcome!

    Good question, the guys with the '05-'08 Sport TRDs or who have changed their differentials to posi-traction/ limited slip differentials will tell you no (but how do they know until they have a truck with TRAC to compare?).

    I had an '01 and an '05 OR Tacoma before my '10... and all I can tell you that TRAC in H4 knocks the socks off open differential 4WDs.

    Part of four wheeling is getting stuck or discovering your limitations... lowering air pressure is typically how we improve traction or floatation over difficult terrain. I do a lot of four wheeling in Baja in deep sand (beaches on the Sea of Cortez near San Felipe).

    With 4WD open differentials, and fully inflated tires, you get only so far before a stuck... one tire in front and one tire in the rear spin (and the other two do nothing). Lowering the pressure to 10-15 psi allows you to continue on... this is very soft, deep sand mixed with crushed shells so it doesn't compact like a lot of other beach sand does.

    The first time I drove my 2010 Tacoma onto that beach (with TRAC in H4), it didn't come to a stop and spin tires! I was amazed...

    To test that it was indeed the new TRAC system that mad the difference, I turned off the VSC & TRAC in H4... and after a few feet my truck got stuck !!!

    This gave me a chance to test the A-TRAC... and so I put it in L4 and turned on A-TRAC... gave it the gas... the truck made some noise, and shaked a bit... and then drove itself out of the stuck. All without me getting out to clear away sand or to let any air out of the tires! I went back into H4 with TRAC back on, and drove about the rest of the weekend on the beach and in arroyos (dry washes) with tires at 32 psi.

    Naturally, I was enthusiastic about TRAC and A-TRAC from then on... and in the 16 months since then, the A-TRAC and TRAC have never disappointed me!

  14. Mar 25, 2011 at 8:42 AM
    #14
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,995
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    x2 Yup...

    Drum brakes have more surface area than disc brakes... Semi trucks with their heavy loads use drum brakes, don't they?

  15. Mar 26, 2011 at 6:37 PM
    #15
    HomeGrown

    HomeGrown Well-Known Member

    Joined:
    Jan 11, 2011
    Member:
    #49116
    Messages:
    336
    Gender:
    Male
    First Name:
    Bill
    South Bend, IN
    Vehicle:
    2014 Reg Cab 4WD
    Even MORE excellent info David, thank you once again! :)
    This is valuable info, not to mention good news. I've had experience with the typical posi or limited-slip diffs in the past and love how they work, but I (apparently wrongly) assumed that the TRAC or ALSD was an ineffective and poor substitute for the "real" thing. Looking forward to trying it out when I get my truck next week! Looking forward to reading your thread giving a detailed explanation.

    After reading your post, I see you're from San Diego. My wife and I were there in Dec. '07. I work for Toyota, and we were installing a new door line at the Baja plant. We stayed on San Diego bay at the Hilton. It was work for me, but a nice vacation for my wife. We had an absolutely great time there (3 weeks). Sure miss the REAL tacos & burritos in Tecate. Even the food at the plant was great. Hope to be back there again some day, probably for the Gen 3 launch whenever that is.

  16. Mar 26, 2011 at 9:50 PM
    #16
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,995
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    That sounds great! So, Toyota of North America treats you right? Room at the Hilton on the bay, and all... That's great. My 2010 was made at the Baja plant, and my doors are installed properly... thank you!

    Food in Baja is outstanding! The simple taco stands along the street or in businesses are great... Can't lose weight when in Baja (around towns or cities) because everything tastes so good,... and they have the best beer, crafted by Bavarian brewmasters!

    I have driven by the Tacoma factory going from the coast to Tecate on Hwy. 2... snapped some photos (see my Sept. 2010 trip report 'Las Pintas'). Hope you guys can spend more time on the West Coast and get back to Baja... The place the Off Road TRD was made for!

  17. Mar 27, 2011 at 8:49 AM
    #17
    HomeGrown

    HomeGrown Well-Known Member

    Joined:
    Jan 11, 2011
    Member:
    #49116
    Messages:
    336
    Gender:
    Male
    First Name:
    Bill
    South Bend, IN
    Vehicle:
    2014 Reg Cab 4WD
    I SO wanted to go Off-Roading down there, looks like a great place to go. My wife's nephew lives out there, and he takes his FJ down there all the time. Honestly, I'd be scared to go there now. Our small bus was escorted daily by 2 armored Sequoias driven by what I think are ex-special ops guys.
    We took a long lunch one day and went to the Tacate brewery for a small tour. They actually made me take off my Corona hat! :D

    Here's a few pics from our trip there.

    Pic taken from the parking lot of the Baja plant after work one day
    [​IMG]

    Hilton on San Diego Bay
    [​IMG]

    All I can say is "WOW"
    [​IMG]

  18. Mar 27, 2011 at 10:08 AM
    #18
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,995
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    Cool yacht! Everyone should have a helicopter!!

    Baja is a big place, a peninsula longer than Florida or Italy... over 1,000 miles by road from Tijuana to Cabo San Lucas.

    Problems with drug cartels are centered on border cities or near border cities... Tijuana mostly, then Tecate, Rosarito, Ensenada. The problems are mostly between the cartels and the police.

    I don't go into those areas, or vacation in those areas! American tourists are not the target... and there are so many Americans who live in Baja, that you would hear it if we were a target. The rare incident might happen, but you are far more likely to get robbed in your own town than in Baja.

    To have a look at photos of various places in Baja... to get an idea of what there is to see and do, I have grouped links to my trip pages around various Baja destinations here: http://vivabaja.com/tours all links take you to my trip pages, all grouped by the year of the trip, on my web site: http://vivabaja.com

    What I see and do in Baja? Here is a tiny sample:

    I enjoy the beaches (where it is rare to see anyone else/ near San Felipe):

    [​IMG]

    great sunsets (Laguna Percebu):

    [​IMG]

    Tropical oasis scenes (San Ignacio):

    [​IMG]

    Missions, some over 300 years old! (San Javier):

    [​IMG]

    [​IMG]

    The food! (Fish, shrimp & carne asada tacos, at McLuLu's in Loreto)

    [​IMG]


    The wildlife is everywhere!:

    [​IMG]

    and of course the famous Baja 4WD roads!:

    [​IMG]

    [​IMG]

    As I like to say: SO MUCH BAJA... SO LITTLE TIME!

  19. Mar 27, 2011 at 1:00 PM
    #19
    HomeGrown

    HomeGrown Well-Known Member

    Joined:
    Jan 11, 2011
    Member:
    #49116
    Messages:
    336
    Gender:
    Male
    First Name:
    Bill
    South Bend, IN
    Vehicle:
    2014 Reg Cab 4WD
    I spent some time browsing through your pages and WOW, what an awesome collection of pics and information! Thank you for sharing!

  20. Mar 27, 2011 at 1:39 PM
    #20
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,995
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    You are welcome! I have never been to Kentucky... I bet you could show me some cool places there too!
