Bilstein 6112

Discussion in 'Suspension' started by KnoxTac0713, Mar 15, 2016.

  1. Feb 13, 2018 at 8:12 AM
    #1101
    jztacoma

    jztacoma Trust me I’m an Engineer

    Joined:
    Sep 13, 2013
    Member:
    #112426
    Messages:
    2,282
    Gender:
    Male
    First Name:
    John
    Upsate NY
    Vehicle:
    2019 Ford F150 XLT Sport
    Semi Stockish
    So I had the NH Oil application to my truck this fall (first winter on my 6112s and 5100s rear). Its basically a much much better fluid film and will stick to everything and will actually creep upwards. So they did a good job coating up the shocks and so far I don't see any rust/corrosion on them. They are kind of black colored from the oil still but to me better then corroding away. I try to wash the truck after every snow storm and everything seems to be holding up ok

  2. Feb 15, 2018 at 11:10 AM
    #1102
    dead.fm13

    dead.fm13 Well-Known Member

    Joined:
    Oct 25, 2016
    Member:
    #200656
    Messages:
    900
    Gender:
    Male
    First Name:
    Mike
    Chesapeake, VA
    Vehicle:
    2017 Tacoma TRD Sport
    5100/888's front, JBA UCA's, 5160's/Dakar's rear, Ray 10 MDB 17", 285/70/17 Ridge Grapplers, Hondo Garage Radio Knobs, MESOJDM Ultimate Turn Signals, MESOJDM Ultimate Combo Maps/Dome, MESO Total Tail Stage II, MESO Puddles
    If you’ve got the 3rd gens on 6/5, would they accommodate 17” ray 10’s wrapped in 285/70 ridge graps? I’m prepared to chop a little.

  3. Feb 15, 2018 at 11:43 AM
    #1103
    oscolivar1

    oscolivar1 Well-Known Member

    Joined:
    Oct 30, 2013
    Member:
    #115568
    Messages:
    2,250
    Gender:
    Male
    First Name:
    Oliver
    VA
    Vehicle:
    2017 Tacoma Limited
    Bilstein 8112/8100, JBA UCAs, Icon RXT leaf pack, work wheels 17x8.5;-10os, 285/75/17 cooper LTX AT3, Mobtown HC rear bumper and Sliders, SSO front bumper, BAMF greceased grill.
    Always be ready to chop a little...or a lot lol. But I'm sure you can make them fit on a 2" lift with some modifications because as you said " your ready to chop"

  4. Feb 15, 2018 at 11:46 AM
    #1104
    dead.fm13

    dead.fm13 Well-Known Member

    Joined:
    Oct 25, 2016
    Member:
    #200656
    Messages:
    900
    Gender:
    Male
    First Name:
    Mike
    Chesapeake, VA
    Vehicle:
    2017 Tacoma TRD Sport
    5100/888's front, JBA UCA's, 5160's/Dakar's rear, Ray 10 MDB 17", 285/70/17 Ridge Grapplers, Hondo Garage Radio Knobs, MESOJDM Ultimate Turn Signals, MESOJDM Ultimate Combo Maps/Dome, MESO Total Tail Stage II, MESO Puddles
    Right on. Trying to decide between grabbing this or doing something more along the lines of an Icon/King set up. I just don’t know if I can justify the $ for what I’d be using them for. I do like the look though. Where in VA you at? I’m in Hampton Roads.

  5. Feb 15, 2018 at 11:50 AM
    #1105
    oscolivar1

    oscolivar1 Well-Known Member

    Joined:
    Oct 30, 2013
    Member:
    #115568
    Messages:
    2,250
    Gender:
    Male
    First Name:
    Oliver
    VA
    Vehicle:
    2017 Tacoma Limited
    Bilstein 8112/8100, JBA UCAs, Icon RXT leaf pack, work wheels 17x8.5;-10os, 285/75/17 cooper LTX AT3, Mobtown HC rear bumper and Sliders, SSO front bumper, BAMF greceased grill.
    I'm in VA Beach. :thumbsup: I almost went kings but I couldn't justify getting them...other then being "cool". 6112 does the job just fine for my needs.

    lynyrd3, derf77 and dead.fm13 like this.
  6. Feb 15, 2018 at 12:00 PM
    #1106
    tow-coma

    tow-coma Well-Known Member

    Joined:
    Oct 4, 2017
    Member:
    #231981
    Messages:
    520
    Gender:
    Male
    I'm in the market for these soon. Probably buying from RCA.

    Bilstein is currently on backorder for both 6112 we use for 2nd and 3rd gen Tacoma

  7. Feb 15, 2018 at 1:27 PM
    #1107
    iK0NiK

    iK0NiK Insert custom title here.

    Joined:
    Jul 31, 2015
    Member:
    #160743
    Messages:
    1,668
    Gender:
    Male
    First Name:
    West
    Columbus, GA
    Vehicle:
    2015 DCSB V6 TRDOR 4WD
    Bil 6112/5160's etc.
    Quick question. I'm thinking about going up to the #4 position on mine and throwing in a 3 leaf AAL finally.

    In my head, the simplest way to bump these up without completely dissembling everything like I did to install it would be to to put the truck on jack stands @ full droop height, floor jack the LCA up right beside the ball joint, remove the two lower ball joint bolts, remove the bolt at the top of the shock bucket that centers the shock, then lower the jack/LCA until the tension is completely off of the springs.

    Do you guys think I'd get enough droop doing this, or would I need to loosen the CAM bolts like I had to do when I installed everything?

  8. Feb 15, 2018 at 1:33 PM
    #1108
    Crom

    Crom 2/3 way thru. I'll be back OCT 23, 2021

    Joined:
    Jun 22, 2009
    Member:
    #18782
    Messages:
    9,509
    Gender:
    Male
    First Name:
    Nick
    San Diego, CA
    Vehicle:
    2009 4x4 DCSB Camp Supreme
    Millions
    I've done it more times than I care to share or remember. You MUST loosen the LCA cam bolts if you have OE rubber bushings in the LCA's. If you don't you'll end up fighting the tension in the rubber. Otherwise, your method is fine.

    ODNAREM and iK0NiK like this.
  9. Feb 15, 2018 at 1:36 PM
    #1109
    iK0NiK

    iK0NiK Insert custom title here.

    Joined:
    Jul 31, 2015
    Member:
    #160743
    Messages:
    1,668
    Gender:
    Male
    First Name:
    West
    Columbus, GA
    Vehicle:
    2015 DCSB V6 TRDOR 4WD
    Bil 6112/5160's etc.
    Ah, dang it. I kinda figured that. I'll have to get an alignment either way so I guess it doesn't hurt to go ahead and loosen them up, too. Thanks!

    Crom likes this.
  10. Feb 15, 2018 at 1:49 PM
    #1110
    Crom

    Crom 2/3 way thru. I'll be back OCT 23, 2021

    Joined:
    Jun 22, 2009
    Member:
    #18782
    Messages:
    9,509
    Gender:
    Male
    First Name:
    Nick
    San Diego, CA
    Vehicle:
    2009 4x4 DCSB Camp Supreme
    Millions
    Welcome. You can mark your cams with a paint pen so you can put them back like they were if you want. I usually do that.

    ODNAREM and iK0NiK like this.
  11. Feb 15, 2018 at 3:53 PM
    #1111
    tow-coma

    tow-coma Well-Known Member

    Joined:
    Oct 4, 2017
    Member:
    #231981
    Messages:
    520
    Gender:
    Male
    Firestone doesn't do the best job but i can go as many times as i want

  12. Feb 16, 2018 at 6:19 AM
    #1112
    Crom

    Crom 2/3 way thru. I'll be back OCT 23, 2021

    Joined:
    Jun 22, 2009
    Member:
    #18782
    Messages:
    9,509
    Gender:
    Male
    First Name:
    Nick
    San Diego, CA
    Vehicle:
    2009 4x4 DCSB Camp Supreme
    Millions
    Yep. I'm a regular customer too. First name basis. I usually bring them a box of of bagles or donuts. They all know to do shit right by me because I don't let anything slide when it comes to work on truck. :)

    lynyrd3, ODNAREM and Drainbung like this.
  13. Feb 16, 2018 at 7:20 AM
    #1113
    iK0NiK

    iK0NiK Insert custom title here.

    Joined:
    Jul 31, 2015
    Member:
    #160743
    Messages:
    1,668
    Gender:
    Male
    First Name:
    West
    Columbus, GA
    Vehicle:
    2015 DCSB V6 TRDOR 4WD
    Bil 6112/5160's etc.
    Good advice. I did that during the initial install, and surprisingly the truck handled the ~40 mile trip to the alignment shop just fine. Geometry was WAY off, but it was close enough that it drove and tracked fine.

    Crom likes this.
  14. Feb 18, 2018 at 7:05 PM
    #1114
    nickydon123

    nickydon123 Active Member

    Joined:
    Sep 17, 2011
    Member:
    #63666
    Messages:
    34
    Gender:
    Male
    First Name:
    Nick
    SF Bay Area
    Vehicle:
    01 Tacoma V6 TRD
    +2.5 Front, Bilstein 5100's Firestone Destination MT, 265/75/16

  15. Feb 21, 2018 at 11:15 PM
    #1115
    Dr. Hook

    Dr. Hook Well-Known Member

    Joined:
    Aug 13, 2012
    Member:
    #84713
    Messages:
    142
    Gender:
    Male
    First Name:
    Jeff
    Winnipeg, Canada
    Vehicle:
    14' Tacoma sport
    TRD pro suspension, TRD baja rims w/duratracs, rock armor side steps & tonneau cover
    I'm looking @ getting the 6112/5160 for my DCLB with the setting @ the 3rd notch for the front but after reading other posts on here it looks like most of you are running progressive AAL's for the rear but I don't want to run those I was thinking of just going with the single AAL's from toytec: http://toyteclifts.3dcartstores.com/TAC-AL--ToyTec-Rear-add-a-leafs_p_16.html
    Is anyone on here running these with the 5160's in the rear? I just wanna know the difference in ride quality compared with the progressive AAL's or is it because they can handle more load capacity?

    lynyrd3 likes this.
  16. Feb 22, 2018 at 12:02 AM
    #1116
    Rob Daman

    Rob Daman The Taco Formerly Known as Hard Shell Taco

    Joined:
    Mar 3, 2017
    Member:
    #212255
    Messages:
    5,844
    First Name:
    Rob
    So Cal
    Vehicle:
    17 OR 6MT
    a lot
    Here's Headstrong's AAL opinion below. I have their 3 leaf and with the TRD versions of 5160 and it seems to ride well in the rear.


    Dr. Hook likes this.
  17. Feb 22, 2018 at 12:20 AM
    #1117
    Dr. Hook

    Dr. Hook Well-Known Member

    Joined:
    Aug 13, 2012
    Member:
    #84713
    Messages:
    142
    Gender:
    Male
    First Name:
    Jeff
    Winnipeg, Canada
    Vehicle:
    14' Tacoma sport
    TRD pro suspension, TRD baja rims w/duratracs, rock armor side steps & tonneau cover
    So seems like he's saying that the progressive AAL's have the best of both worlds

  18. Feb 22, 2018 at 12:22 AM
    #1118
    Rob Daman

    Rob Daman The Taco Formerly Known as Hard Shell Taco

    Joined:
    Mar 3, 2017
    Member:
    #212255
    Messages:
    5,844
    First Name:
    Rob
    So Cal
    Vehicle:
    17 OR 6MT
    a lot
    I'd say so next to an entire replacement leaf pack. I kept my overload on mine too because I have a cap as well.

    ODNAREM likes this.
  19. Feb 22, 2018 at 12:24 AM
    #1119
    Dr. Hook

    Dr. Hook Well-Known Member

    Joined:
    Aug 13, 2012
    Member:
    #84713
    Messages:
    142
    Gender:
    Male
    First Name:
    Jeff
    Winnipeg, Canada
    Vehicle:
    14' Tacoma sport
    TRD pro suspension, TRD baja rims w/duratracs, rock armor side steps & tonneau cover
    Ok what do u think of spacer blocks as my 2nd option?

  20. Feb 22, 2018 at 12:29 AM
    #1120
    Rob Daman

    Rob Daman The Taco Formerly Known as Hard Shell Taco

    Joined:
    Mar 3, 2017
    Member:
    #212255
    Messages:
    5,844
    First Name:
    Rob
    So Cal
    Vehicle:
    17 OR 6MT
    a lot
    If you're mostly on road or mild offroading you'll be fine. Even Headstrong sells block spacers but any towing or heavy loads could cause axle wrap. It's not much more money for a AAL but definitely more work. I just did my install and really focussed on what it takes especially if you keep the overload leaf like I did....
