Brake module for towing

Discussion in '2nd Gen. Tacomas (2005-2015)' started by nature, May 23, 2024.

  1. May 23, 2024 at 11:17 AM
    #1
    nature

    nature [OP] New Member

    Joined:
    May 11, 2014
    Member:
    #129596
    Messages:
    2
    Gender:
    Male
    First Name:
    Doug
    Boulder, CO
    Vehicle:
    06 PreRunner
    Add tow hitch
    The trailer has brakes but the 2006 Tacoma is not TRD. Just 2WD. From what I understand I don't have anywhere to plug a brake module into to run it to the 7 pin (blue).

    https://www.amazon.com/Reese-Towpow...l/dp/B000CQSKV8?ie=UTF8&qid=1315974379&sr=8-1

    What are my DIY options to be able to add the trailer brakes? Or am I just missing something?

    I also know I'm missing other things the tow package includes like oil/tranny cooler. Been towing w/o for years but this trailer is a bit bigger than past ones so considering the tranny cooler.

    203K miles on my Taco. Had it since 54K. Runs like a Tacoma.


  2. May 23, 2024 at 11:26 AM
    #2
    TnShooter

    TnShooter The TacomaWorld Stray

    Joined:
    Sep 2, 2010
    Member:
    #42625
    Messages:
    19,737
    Gender:
    Male
    First Name:
    Deogee
    Vehicle:
    07' TRD Off-Road, Auto
    STOCK
    Does your truck have a 7-pin connector in the back?
    Or are you saying the trailer is 7-pin and the truck has no connector?
    Not even a 4 pin?

  3. May 23, 2024 at 11:33 AM
    #3
    nature

    nature [OP] New Member

    Joined:
    May 11, 2014
    Member:
    #129596
    Messages:
    2
    Gender:
    Male
    First Name:
    Doug
    Boulder, CO
    Vehicle:
    06 PreRunner
    Add tow hitch
    Originally it did not even have 4-pin. There's no tow package. Everything has been added by me. I put on the Class 3 hitch and wired in for 4/5 pin (trailer/camper). When I got this trailer I bought the 7pin for the truck (trailer has it) and just wired on the green/yellow/brown/white. And then I rigged up a bad idea for red ;).

    TnShooter[QUOTED] likes this.
  4. May 23, 2024 at 11:54 AM
    #4
    TnShooter

    TnShooter The TacomaWorld Stray

    Joined:
    Sep 2, 2010
    Member:
    #42625
    Messages:
    19,737
    Gender:
    Male
    First Name:
    Deogee
    Vehicle:
    07' TRD Off-Road, Auto
    STOCK
    You'll have to wire in a brake controller. (Like the one linked)
    You'll need to tap in to a brake light wire (in cab) then run the wire from the controller to the 7-pin.

  5. May 23, 2024 at 12:38 PM
    #5
    ThePositiveWay

    ThePositiveWay Well-Known Member

    Joined:
    Jan 25, 2024
    Member:
    #442429
    Messages:
    53
    Gender:
    Male
    First Name:
    Chris
    SE Tennessee
    Vehicle:
    06' DCLB TRD Sport Super White
    Sony XAV-9000ES Headunit, Steering Wheel Controls, Sony ES Series Door Speakers, Alpine PWE-S8 Sub
    Everything you should need to add the tow package equivalent parts is in this thread. It even covers the wiring you are going to need to do with part numbers, though my truck came with the factory tow package so I haven't personally validated this

    The Tacoma Towing Bible | Tacoma World

    deanosaurus likes this.
