Broken Coil Bucket Tower

Discussion in '1st Gen. Tacomas (1995-2004)' started by Taco_Jordan19, May 13, 2016.

  1. May 13, 2016 at 11:18 PM
    #1
    Taco_Jordan19

    Taco_Jordan19 [OP] Member

    Joined:
    May 13, 2016
    Member:
    #186896
    Messages:
    8
    Gender:
    Male
    Hi guys and gals. This is my first post and I'm looking for some help. I have a 2002 Tacoma. The upper coil bucket tower on the passenger side is busted. Completely crowned itself after I went over a speed bump. There's a 3" toy tech lift kit with 33" on it. I'm curious to if anyone's had this issue or knows someone who had this and knows how to fix it or how to go about getting it fixed. Thanks everyone.


  2. May 13, 2016 at 11:23 PM
    #2
    Taco_Jordan19

    Taco_Jordan19 [OP] Member

    Joined:
    May 13, 2016
    Member:
    #186896
    Messages:
    8
    Gender:
    Male
  3. May 13, 2016 at 11:23 PM
    #3
    Taco_Jordan19

    Taco_Jordan19 [OP] Member

    Joined:
    May 13, 2016
    Member:
    #186896
    Messages:
    8
    Gender:
    Male
  4. May 13, 2016 at 11:28 PM
    #4
    Blackouts

    Blackouts Well-Known Member

    Joined:
    Feb 10, 2016
    Member:
    #177762
    Messages:
    433
    Las Vegas, NV
    Vehicle:
    2014 Tacoma TRD Off Road DCSB
    How fast did you hit that speed bump?

    Looks like the coil is completely bent, you'll likely have to replace the whole coilover.

  5. May 13, 2016 at 11:33 PM
    #5
    Taco_Jordan19

    Taco_Jordan19 [OP] Member

    Joined:
    May 13, 2016
    Member:
    #186896
    Messages:
    8
    Gender:
    Male
    No faster than 7 mph

  6. May 13, 2016 at 11:41 PM
    #6
    Blackouts

    Blackouts Well-Known Member

    Joined:
    Feb 10, 2016
    Member:
    #177762
    Messages:
    433
    Las Vegas, NV
    Vehicle:
    2014 Tacoma TRD Off Road DCSB
    Wow that's crazy.

    Have you hit things pretty hard with it before this, ie treated it as if it were a long travel flying truck? If not, it's kinda scary to see that much damage from a speed bump at 7mph.

  7. May 13, 2016 at 11:58 PM
    #7
    Taco_Jordan19

    Taco_Jordan19 [OP] Member

    Joined:
    May 13, 2016
    Member:
    #186896
    Messages:
    8
    Gender:
    Male
    I've used it on fire trails before but nothing too crazy. It's mainly my daily comuter that has seen fire trails every couple months. The suspension is a little rough so I've always gone slow over bumps to avoid being thrown around in the cab

  8. May 14, 2016 at 12:27 AM
    #8
    Blackouts

    Blackouts Well-Known Member

    Joined:
    Feb 10, 2016
    Member:
    #177762
    Messages:
    433
    Las Vegas, NV
    Vehicle:
    2014 Tacoma TRD Off Road DCSB
    I guess the stock buckets are just weak af, but that's really bad!

    Total Chaos makes gussets for them, maybe add them when you do the replacement.

  9. May 14, 2016 at 3:33 AM
    #9
    Wyoming09

    Wyoming09 Well-Known Member

    Joined:
    Apr 24, 2015
    Member:
    #153833
    Messages:
    5,861
    Gender:
    Male
    New Tripoli Pa
    Vehicle:
    2000 Work truck
    Super Springs
    looks to me that was breaking for some time.

    Could have had something to do with the lift install who knows at this point

    That side may have been taking most of the impacts in normal driving

    The speed bump was just the last straw .

    Now this is where things get interesting.

    You can go a few ways here it all depends just what you want .

    After this little mishap have you inspected the other side ??

    You can fix the damaged side and hope to come close remember your dealing with the suspension .

    Hard to tell if the spring is really bent or just looks that way in the pictures.

    It all comes down to what is in the truck repair budget

  10. May 14, 2016 at 3:40 AM
    #10
    DrFunker

    DrFunker Prisoner of the little people circus

    Joined:
    Feb 3, 2014
    Member:
    #122158
    Messages:
    34,433
    :eek: Have never seen something like this.
    breaking at 7 mph over a speed bump seems a little out of the ordinary.
    I would agree with the poster above that it may have been broken before.
    Did you install the lift?
    Can you give a little history of the truck?

  11. May 14, 2016 at 5:57 AM
    #11
    Taco_Jordan19

    Taco_Jordan19 [OP] Member

    Joined:
    May 13, 2016
    Member:
    #186896
    Messages:
    8
    Gender:
    Male
    I'm the second owner of the truck and the guy before me babied it and took real good care of her. I keep up to date on maintenance and repairs. I just never thought anything like that could have happened so I never looked. I had the lift installed by a local 4x4 shop. Guy knows what he's doing and has always done good work for me and the people around town. I bought the truck stock about a year and a few months ago. The lift was put on last July. I agree that it has been a problem building up over time with stress fractures and cracks possibly that ended up resulting in this.

  12. May 14, 2016 at 7:57 AM
    #12
    Wyoming09

    Wyoming09 Well-Known Member

    Joined:
    Apr 24, 2015
    Member:
    #153833
    Messages:
    5,861
    Gender:
    Male
    New Tripoli Pa
    Vehicle:
    2000 Work truck
    Super Springs
    Hard to tell at this point but it could just have been a difference in the two front springs

    The question is just what needs to be done to stop the problem from happening again .

    Give the person who installed the lift a call and see if he can do the repairs

    Also ask if he has any clue about the failure ??

    Taking you at your word that your not out jumping the truck for distance

    That side seems to have been taking the brunt of the front end load .

    If the other side is fine!!

    If you have questions feel free to Message me

  13. May 14, 2016 at 9:00 AM
    #13
    tan4x4

    tan4x4 Well-Known Member

    Joined:
    Nov 30, 2011
    Member:
    #67982
    Messages:
    3,783
    Gender:
    Male
    First Name:
    Rick
    Folsom, CA
    Vehicle:
    99 Tacoma EC 4x4 2.7L Auto
    Bilsteins, OME 881's, 3-leaf AAL, Detroit TruTrac, Tundra brake swap, Michelin LTX AT2, Tranny skidplate, TC skidplate, CBI rear bumper, TG sliders, UltraGauge, PowerTank, Reverse Camera, CB
    Did that lift kit come with extended bump stops?

  14. May 14, 2016 at 9:05 AM
    #14
    devinzz1

    devinzz1 Well-Known Member

    Joined:
    Jun 28, 2014
    Member:
    #132892
    Messages:
    5,573
    Gender:
    Male
    First Name:
    devin
    lewisporte Newfoundland
    Vehicle:
    96 extended cab sr5
    cxracing turbo, fic6, methanol injection, 5100s/eibachs, skyjacker leafs, rear 5125s, no-slip rear locker, 35" grabber x3, magnaflow muffler, throttle body spacer, retrofit headlights, trans cooler, bed lined exterior, excessive stereo etc...
    See the difference in color where it cracked. Most of it is rusted and dark so its been cracked for some time. Think this might just be freak incident. The factory buckets can take a decent amount of abuse.

    ThunderOne likes this.
  15. May 14, 2016 at 10:39 AM
    #15
    Digiratus

    Digiratus Adventurer

    Joined:
    Mar 26, 2010
    Member:
    #34006
    Messages:
    18,121
    Gender:
    Male
    First Name:
    Mike
    Roaming the PNW
    Vehicle:
    The RedHead
    2002 XtraCab TRD 4x4 v6 Auto Trans With Lots of Mods King Extended Travel COs Camburg Uniball UCAs Whiteline Lower Control Arm Bushings Alcan Custom 8-Leaf Rear Spring Packs Fox 2.0 Resi Rear Shocks FrankenFab Rear Shock Relocate All-Pro U-bolt Flip w/Timbren bumps Toytec 1" Extended Shackle 4.88 Nitro Gears ARB Front Locker ARB Twin Compressor Gunmetal 16x8 SCS Ray10s 285/75r16 Cooper STT Pros Limited Edition Relentless Front Bumper Smittybilt X2O 10K Winch 3" LED Pods w/Amber covers in the Bumper 22" Single Row LED Bar on the Bumper Mini D2S Projectors XB35 Ballasts + 4500K Bulbs Badland Sliders FrankenFab Tire Carrier Swingout bumper w/kitchen BudBuilt Front & Bellypan Skids BAMF Rear Diff Skid Whynter 65 qt. Fridge/Freezer CVT Mt Bachelor RTT Badland Custom Bed Rack GM 140 amp alternator Dual Northstar 24F AGM batteries BlueSea 7622 ML-ACR Battery controller Peak DBI Dual Battery Voltage Monitor Magnaflow 18" Muffler 13WL Brake Calipers Braided Steel Brake Lines AFE Pro Dry S air filter ScanGauge II OBDII Scanner Kenwood TM-71A Dual Band Ham Radio Larson 70CM/2M Antenna Uniden 520xl CB radio 3' Firestik Adjustable tip antenna Pioneer DEH-P9400BH HU Alpine Amps & Type R components (F) and coaxials (R) Wet Okole Seat Covers Weathertech Digital Liners Deck Plate Mod 1" Diff Drop Carrier Bearing Drop
    :eek: I think I need to do a close inspection of my coil buckets.

    @Blackdawg

  16. May 14, 2016 at 10:55 AM
    #16
    Blackdawg

    Blackdawg Dr. Frankenstein

    Joined:
    Dec 31, 2010
    Member:
    #48500
    Messages:
    73,688
    Gender:
    Male
    First Name:
    Monte
    Wyoming/St. Louis
    Vehicle:
    The Trifecta of Taco's
    ALL OF THEM!...Then some more.
    See @m3bassman they aren't that strong haha

    Mike, that why I have a coil bucket brace bar going in Frank.

    Digiratus likes this.
  17. May 14, 2016 at 10:56 AM
    #17
    MKW

    MKW Well-Known Member

    Joined:
    Nov 27, 2007
    Member:
    #3623
    Messages:
    2,710
    Gender:
    Male
    Murrells Inlet, SC
    Vehicle:
    2014 RC 4x4
    OME 3" lift MK6 wheels 285 Fierce MTs & 4.88s!!
    Shit, a little duct tape will fix that right up!!

    Mully and scottalot like this.
  18. May 14, 2016 at 11:09 AM
    #18
    m3bassman

    m3bassman Well-Known Member

    Joined:
    Jan 16, 2011
    Member:
    #49376
    Messages:
    35,752
    Gender:
    Male
    Boize
    Vehicle:
    Rust bucket
    So weak that they fail at 7mph??? Dude there's more to the story.

  19. May 14, 2016 at 11:13 AM
    #19
    Digiratus

    Digiratus Adventurer

    Joined:
    Mar 26, 2010
    Member:
    #34006
    Messages:
    18,121
    Gender:
    Male
    First Name:
    Mike
    Roaming the PNW
    Vehicle:
    The RedHead
    2002 XtraCab TRD 4x4 v6 Auto Trans With Lots of Mods King Extended Travel COs Camburg Uniball UCAs Whiteline Lower Control Arm Bushings Alcan Custom 8-Leaf Rear Spring Packs Fox 2.0 Resi Rear Shocks FrankenFab Rear Shock Relocate All-Pro U-bolt Flip w/Timbren bumps Toytec 1" Extended Shackle 4.88 Nitro Gears ARB Front Locker ARB Twin Compressor Gunmetal 16x8 SCS Ray10s 285/75r16 Cooper STT Pros Limited Edition Relentless Front Bumper Smittybilt X2O 10K Winch 3" LED Pods w/Amber covers in the Bumper 22" Single Row LED Bar on the Bumper Mini D2S Projectors XB35 Ballasts + 4500K Bulbs Badland Sliders FrankenFab Tire Carrier Swingout bumper w/kitchen BudBuilt Front & Bellypan Skids BAMF Rear Diff Skid Whynter 65 qt. Fridge/Freezer CVT Mt Bachelor RTT Badland Custom Bed Rack GM 140 amp alternator Dual Northstar 24F AGM batteries BlueSea 7622 ML-ACR Battery controller Peak DBI Dual Battery Voltage Monitor Magnaflow 18" Muffler 13WL Brake Calipers Braided Steel Brake Lines AFE Pro Dry S air filter ScanGauge II OBDII Scanner Kenwood TM-71A Dual Band Ham Radio Larson 70CM/2M Antenna Uniden 520xl CB radio 3' Firestik Adjustable tip antenna Pioneer DEH-P9400BH HU Alpine Amps & Type R components (F) and coaxials (R) Wet Okole Seat Covers Weathertech Digital Liners Deck Plate Mod 1" Diff Drop Carrier Bearing Drop
    I'm pretty sure they failed way before that. The speed bump was just the finishing touch.

    I suggest you do a close inspection on yours. Your sig pic suggests you were going slightly more the 7 mph when you hit that speed bump.

    ThunderOne and Speedytech7 like this.
  20. May 14, 2016 at 11:20 AM
    #20
    m3bassman

    m3bassman Well-Known Member

    Joined:
    Jan 16, 2011
    Member:
    #49376
    Messages:
    35,752
    Gender:
    Male
    Boize
    Vehicle:
    Rust bucket
    I know my bumpstops carried the load so I don't see a reason why the coil bucket would be impacted. The only reason would be if the coilovers is bottoming out internally before the bump stops do their job. Am I off base in this thinking? The 11ga steel that the coil bucket is made out of should be adequate for the loads it sees. I've inspected my buckets and don't see it as any cause for concern
