Changing diff / axle fluid ?

Discussion in 'Technical Chat' started by MadeInMaine, Sep 5, 2010.

  1. Sep 5, 2010 at 6:14 AM
    #1
    MadeInMaine

    MadeInMaine [OP] MadeInMaine

    Joined:
    Nov 28, 2009
    Member:
    #26678
    Messages:
    1,169
    Gender:
    Male
    First Name:
    Owen
    Biloxi, MS
    Vehicle:
    2014 4Runner
    Hey Fellas...

    My neighbor, who has been an engineer on Navy fighter jets for over 20 years, asked if I had changed my diff / axle fluid....

    I have never heard of this, thought of this, but I do have 97k miles on the ol truck, so what do you think?

    How do I do this?
    Anybody done this?

    Can you give a link or write up or something?

    Thanks

    Cheers

  2. Sep 5, 2010 at 6:28 AM
    #2
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    well yours should be changed every 30k
    its very easy

  3. Sep 5, 2010 at 6:35 AM
    #3
    larryde09

    larryde09 Well-Known Member

    Joined:
    Jul 3, 2010
    Member:
    #39759
    Messages:
    560
    Gender:
    Male
    First Name:
    Larry
    Rochester, NY
    Vehicle:
    (Traded-in) 06 2.7L 5-spd SR5 4x4
    K&N Intake, Magnaflow Cat-back Exhaust, Altezza Tail Lights, Pop&Lock Tailgate Lock, Extang Trifecta Tonneau Cover, PIAA foglights with stock switch, DrawTite Hitch, OBX Shift Knob, Hood Protector, Vent Visors, DIY step bars/sliders/running boards, DIY Bed Lights, DIY Running Board/Ground Lights, DIY Tailgate Electrical Box (12V socket, voltage and current gauges), DIY Internal Lighting (coming soon), Aftermarket switches in stock dash blanks, Sony Head Unit, Illuminated 4x4 switch mod
    Your neighbor is referring to the gear oil in the rear differential, front differential (if you have 4x4), transfer case (if you have 4x4), and manual trans oil (if you have manual). As the ring gear in your differential spins, it dips into a pool of oil contained in the differential case which keeps the gears lubricated. Heat generated from hard use, towing, age, and offroading eventually causes it to break down just like your normal motor oil in the engine. Eventually it should be changed to keep it clean and at a full level.

    There are some threads on here if you search for them. Off hand I don't recall when the maintenance manual says to do it, but I did mine at 60k miles because I want to keep the truck running good for years. It is more important to change it if you tow and/or off road often, otherwise, you're probably due just about now.

    The quick procedure is as follows:
    1. find the drain and fill plugs on the differential
    2. crack open the fill plug first to ensure you can get it off (you don't want to drain all the oil only to find out you can't refill it!!)
    3. open the drain plug and drain the differential
    4. clean the metal shavings off the magent on the drain plug...if it is excessive you might have a problem
    5. close drain plug, fill with proper gear oil, close fill plug...you're done.

  4. Sep 5, 2010 at 6:46 AM
    #4
    chugchug

    chugchug Well-Known Member

    Joined:
    Nov 11, 2009
    Member:
    #25761
    Messages:
    157
    Gender:
    Male
    First Name:
    Will
    Frederick MD
    Vehicle:
    2012 Toyota Tundra
    Then I did the rear diff. Here are some pics.
    [​IMG] I took out the top bolt first.

    [​IMG] Then I took out the bottom bolt out.

    [​IMG] It was windy so I had to drop moving blanket from the doors to block the wind so it wouldn't spray the oil all over the place

    [​IMG] When it was finished dripping i clean it up.

    [​IMG] Clean off the nasty crap off the magnet

    [​IMG] CLEAN and put back on nice and tight.

    [​IMG] Then I pumped in the knew oil.

    [​IMG] Then I put the top blot back in and clean it up.

    All done now to clean up and take a shower.



    P.S.

    I did not put 5w-30 motor oil in my rear diff. The stupid pump I bought was a little too big to fit in the mouth of the gear oil bottle. I left this part to tell you for last because I knew you all would have fun with it

    [​IMG] [​IMG] [​IMG] [​IMG] [​IMG]

  5. Sep 5, 2010 at 7:12 AM
    #5
    MadeInMaine

    MadeInMaine [OP] MadeInMaine

    Joined:
    Nov 28, 2009
    Member:
    #26678
    Messages:
    1,169
    Gender:
    Male
    First Name:
    Owen
    Biloxi, MS
    Vehicle:
    2014 4Runner
    Awesome

    thanks fellas

    Just go to car store, get "gear oil"? are there specific kinds?
    and to pour it in... great little mechanism you got rigged up. Where did you buy the bottle top?

  6. Sep 5, 2010 at 7:20 AM
    #6
    larryde09

    larryde09 Well-Known Member

    Joined:
    Jul 3, 2010
    Member:
    #39759
    Messages:
    560
    Gender:
    Male
    First Name:
    Larry
    Rochester, NY
    Vehicle:
    (Traded-in) 06 2.7L 5-spd SR5 4x4
    K&N Intake, Magnaflow Cat-back Exhaust, Altezza Tail Lights, Pop&Lock Tailgate Lock, Extang Trifecta Tonneau Cover, PIAA foglights with stock switch, DrawTite Hitch, OBX Shift Knob, Hood Protector, Vent Visors, DIY step bars/sliders/running boards, DIY Bed Lights, DIY Running Board/Ground Lights, DIY Tailgate Electrical Box (12V socket, voltage and current gauges), DIY Internal Lighting (coming soon), Aftermarket switches in stock dash blanks, Sony Head Unit, Illuminated 4x4 switch mod
    Yeah, gear oil is rated like motor oil...I think it's something like 75W-90 for these trucks, but check your owner's manual, it will tell you what kind and how much. Also, if you have a limited-slip differential, there's a specific kind for that too....the guy at the parts store should be able to help.

    Most gear oil bottles are a squeeze type bottle, but the plunger and hose makes it much easier! Again, any auto parts store will have them.

    Note: if you're looking for longevity and slightly improved gas mileage, consider synthetic gear oils like Royal Purple. They are a lot more expensive, but typically worth it. There are threads on here about that topic too.

  7. Sep 5, 2010 at 7:21 AM
    #7
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    i just did mine and all i used was a piece of surgical tubing for the front and rear diff's worked great.....

  8. Sep 5, 2010 at 7:21 AM
    #8
    chris4x4

    chris4x4 With sufficient thrust, pigs fly just fine. Moderator

    Joined:
    May 8, 2008
    Member:
    #6497
    Messages:
    106,192
    Gender:
    Male
    First Name:
    FlimFlubberJAM
    Tenoe, AZ
    Vehicle:
    2013 Rubicon Unlimited,
    4.10 gears, sliders, and lots of buttons.
    You can get the pump top (Gear oil pump) at the place you buy the oil. Mobil 1 75-90 is a good fluid for your truck. You need 3 quarts for the rear.

  9. Sep 5, 2010 at 7:22 AM
    #9
    MadeInMaine

    MadeInMaine [OP] MadeInMaine

    Joined:
    Nov 28, 2009
    Member:
    #26678
    Messages:
    1,169
    Gender:
    Male
    First Name:
    Owen
    Biloxi, MS
    Vehicle:
    2014 4Runner
    awesome

  10. Sep 5, 2010 at 7:46 AM
    #10
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    oh 1 more thing you need very important
    a big [​IMG]
    hitch cover:stirthepot:

  11. Sep 5, 2010 at 7:54 AM
    #11
    MadeInMaine

    MadeInMaine [OP] MadeInMaine

    Joined:
    Nov 28, 2009
    Member:
    #26678
    Messages:
    1,169
    Gender:
    Male
    First Name:
    Owen
    Biloxi, MS
    Vehicle:
    2014 4Runner
    oh thanks... but i have a better one

    [​IMG]

    New England Patriots Logos.gif

  12. Sep 5, 2010 at 9:01 AM
    #12
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    all i have to say is 18-1
    remeber that
    and did you watch thursday ouch like deja vu

  13. Sep 5, 2010 at 4:48 PM
    #13
    MadeInMaine

    MadeInMaine [OP] MadeInMaine

    Joined:
    Nov 28, 2009
    Member:
    #26678
    Messages:
    1,169
    Gender:
    Male
    First Name:
    Owen
    Biloxi, MS
    Vehicle:
    2014 4Runner
    who cares about preseason....
    i like the giants

    but keep the banter about the thread
