Custom True Dual Exhaust, Pics!!

Discussion in 'Performance and Tuning' started by 6whiteboy9, Mar 7, 2008.

  1. Mar 7, 2008 at 5:39 PM
    #1
    6whiteboy9

    6whiteboy9 [OP] Member

    Joined:
    Mar 2, 2008
    Member:
    #5040
    Messages:
    8
    Gender:
    Male
    Vehicle:
    Black 07 TRD sport 4x4 6 Speed Manuel
    Custom True Dual Exhaust W/ X Pipe & Magnaflow Muffler coming out Sport Truck style on same side. Limo Tinted Windows all the way around. Clifford Alarm system w/ monitering & paging system. ram air intake. black headlights.
    I have done some reading on here & ALOT of people seem to have questions about exhaust systems for there truck.

    I wanted to post some pics of the Custom True Dual setup I hade made so everyone can see how I did it & I also explain why I did mine the way I did. Hopefully people will use this info & get ideas for there own custom setups!!

    & also let everyone see that you can go above & behond whats available besides the typical "bolt ons" that are out there

    I wanted a "true Dual" setup all the way through that would be a high flow/ high velocity system. So I came up with this Sport Truck style setup....


    [​IMG]


    I had the exhaust exit threw the right side of the truck before the back tires. By doing this you eliminate around 6-7 feet or more worth of tubing!

    This means less weight. As well as the exhaust does not have to travel as far & therefore will exit the vehical quicker.

    The quicker the exhaust can get out, the better/snappier your throttle response will be.

    The shorter exhaust system will also give you better gas milaege, better/snappier throttle response, more horspower & torgue, & a very deep aggressive unique sound.
    This setup also eliminates around 5 bends/restrictions or so in the exhaust as it no longer has to curve around the rear axle.


    Anyways enough of my babble Lol, here's some pics!



    [​IMG]


    [​IMG]


    [​IMG]





    Here's how it was done, these pics were taken by a camera phone so they arent the best quality.
    Also I recently went mudding & didnt wash underneith my truck Lol.. So it's a lil dirty!!!


    [​IMG]



    [​IMG]



    [​IMG]


    The system was desgined to use the Factory Hangers


    Right hanger-

    [​IMG]



    Left hanger-

    [​IMG]


    The design is very simple! Cut the stock pipes off, run a straight pipe on the right side. Then use two mandrel bends on the left side! You can either cut your stock pipes before or after your back 2 cats & then weld the new pipes to the old ones! Very simple.


    Believe it or not thats actually a stainless steel Magnaflow muffler those pipes are connecting to!

    I orignnally had this setup done with two Flowmaster mufflers & it sounded HOrrible!!!
    I would not recommend anyone get flowmaster!!

    Not only did it sound like crap but it feels faster & has better response with the magnaflow. Has a real nice deep grow to it also =]



    Specs; The pipes are 2.5" mandrel bent tubing & the muffler is a Stainless Magnaflow with an X-Pipe built into it. Then used two 4" stainless exhaust tips to top it off!

    from the muffler the pipes are then ran straight back a few more inches & then bend out to the right before the back tires, one simple bend! Also notice the angle of the bend, obviously had we used too much piping and done a 90 degree bend instead of a 60 then that would be more restictive!

    again the pipes are a lil dirty Lol.. But you can see how it was done!! is the point!

    [​IMG]


    The hanger on the Right uses the Factory mount, the hanger on the Left was added for extra stregth.

    [​IMG]







    [​IMG]


    Let me know what you guys think! I wanna hear opinions =]

    Also let me know if the pics dont post because this is my first post on here, not sure if I did it right?
