Detailed oil filter instructions

Discussion in '2nd Gen. Tacomas (2005-2015)' started by thom13, Apr 20, 2020.

  1. Apr 20, 2020 at 4:01 PM
    #1
    thom13

    thom13 [OP] Member

    Joined:
    Jan 25, 2016
    Member:
    #176076
    Messages:
    5
    Gender:
    Male
    Vehicle:
    toyota tacoma reg cab 2011
    I have got a 4 cylinder 2011 Toyota short bed and would like to know where the oil filter is located and how to access it. I've got a skid plate underneath by the oil pan and some plastic guards in the wheel wells. Would I have to remove both of these or just 1 to get at the filter to change it. Thanx.

  2. Apr 20, 2020 at 4:12 PM
    #2
    Lester Lugnut

    Lester Lugnut Well-Known Member

    Joined:
    Mar 3, 2010
    Member:
    #32477
    Messages:
    2,822
    Gender:
    Male
    N of Mex-S of Canada-E of LA-W of NC
    Vehicle:
    '15 Tacoma PreRunner V6 SR5 Auto
    If I am not mistaken the 2.7L filter is located where the 1st Gen 2.4 was. If you want to avoid removing skid plates down below, you might be able to elevate the front of the truck - remove RF tire - then access filter thru that side. Any road block from that point will need to be removed before you can see the filter.

    Jimmyh likes this.
  3. Apr 20, 2020 at 4:16 PM
    #3
    Steves104x4

    Steves104x4 Well-Known Member

    Joined:
    Apr 17, 2010
    Member:
    #35468
    Messages:
    16,355
    Gender:
    Male
    First Name:
    Steve
    Buffalo NY
    Vehicle:
    2010 RC 2.7 4x4
    BUCKLE UP! It makes it harder for Aliens to pull you out of your Truck.
    Lay on your back behind the passenger side front wheel and slide underneath. Look up and you’ll see the filter. You can access it going straight up through the control arm. While laying on your back and using your left hand turn counter clockwise to loosen. Good luck! 3C8D6E48-F3DA-4051-BF4D-694DE1D26E8E.jpg

    Jimmyh likes this.
  4. Apr 20, 2020 at 4:54 PM
    #4
    Jimmyh

    Jimmyh Well-Known Member

    Joined:
    May 16, 2012
    Member:
    #78991
    Messages:
    13,953
    Gender:
    Male
    SC
    Vehicle:
    2012 Prerunner SR5
    Exactly as stated above by those two fine men.

    Steves104x4 likes this.
  5. Apr 21, 2020 at 7:50 AM
    #5
    Steve_P

    Steve_P Well-Known Member

    Joined:
    Sep 16, 2009
    Member:
    #22854
    Messages:
    656
    Gender:
    Male
    TN
    Vehicle:
    09 Tacoma SR5 4WD 4cyl
