EL095R with stock bilstein shocks?

Discussion in '3rd Gen. Tacomas (2016-2023)' started by BalutTaco, Sep 19, 2019.

  1. Sep 19, 2019 at 5:21 PM
    #1
    BalutTaco

    BalutTaco [OP] Moja_Przygoda

    Joined:
    Apr 2, 2019
    Member:
    #288885
    Messages:
    3,324
    Gender:
    Male
    Vehicle:
    2019 Cement Limo Trail Edition -> 2022 Magnetic Grey OR
    Bird nest engine bay.
    Noob here!! Can I run El095R with stock bilstein shocks? Or will I need to upgrade them too? thank you!

  2. Sep 19, 2019 at 5:23 PM
    #2
    GHOST SHIP

    GHOST SHIP hates you.

    Joined:
    Mar 9, 2015
    Member:
    #150537
    Messages:
    22,393
    First Name:
    GHOST
  3. Sep 19, 2019 at 5:26 PM
    #3
    Rockefelluh

    Rockefelluh Well-Known Member

    Joined:
    Aug 18, 2018
    Member:
    #263236
    Messages:
    2,051
    Gender:
    Male
    First Name:
    Rocky
    Orange County, CA
    Vehicle:
    2018 DCLB TRDOR 4x4
    You will need to get longer length shocks to avoid over extension of OEM shocks.

    BalutTaco[OP] likes this.
  4. Sep 19, 2019 at 5:26 PM
    #4
    GHOST SHIP

    GHOST SHIP hates you.

    Joined:
    Mar 9, 2015
    Member:
    #150537
    Messages:
    22,393
    First Name:
    GHOST
    Further explanation:

    Yes: they will technically bolt in place and you can drive the truck like that.

    No: the overall length of the stock Bilstein shock is too short (extension) to accommodate the lift that is provided by the EL095R. Meaning your shock will be acting like your limit strap and be operating outside of it's normal parameters. This will cause premature failure of the shock (broken stuff= leaky stuff).

    Crikeymike and BalutTaco[OP] like this.
  5. Sep 19, 2019 at 5:43 PM
    #5
    GHOST SHIP

    GHOST SHIP hates you.

    Joined:
    Mar 9, 2015
    Member:
    #150537
    Messages:
    22,393
    First Name:
    GHOST
    Copied from a PM.
    Probably best discussed here anyway so you can get more responses this way:

    Do you already have the Dakars? If so, the shocks wont provide any additional support for the weight of your gear. The leaf pack does the lifting and the shocks adjust the rebound and compression of the leafs.
    Your question is a bit loaded. What you consider "gear" is different from what my truck looks like all loaded up so take that into account when asking for advice from strangers on the internet. Picking a shock that is compatible with the leaf pack is probably a better suited question to ask but that will change depending on budget and intended purpose of your truck. Since you considered running the stock shocks with the EL095 the closest shock I can think of that will be best compatible would be the B110. They are about right in line with stock as far as valving goes (you probably won't notice a difference) but the stroke of the shock will allow your leaf pack to cycle all through it's range of motion. Once consideration that you'll want to look into is going to be bump stops and their height in relation to your rear end travel.

    If the above seems like a lot of info, then you're in for a surprise- you have some searching/reading to do. It'd be easy for me to say "Buy these shocks." without explaining why or what your other options would be, but you wont learn anything about your vehicle that way. I find it best to present information and let you make an informed choice form there.

    Good luck.

    BalutTaco[QUOTED][OP] likes this.
