Front End Checklist

Discussion in '1st Gen. Tacomas (1995-2004)' started by REDeye jedi, Jul 4, 2020.

  1. Jul 4, 2020 at 10:26 AM
    #1
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    So I'm going to bite the bullet and replace my upper and lower control arm, upper and lower ball joints, inner and outer tire rod. I have 267k miles on my baby and heard people replacing these about 100k before mine. I also read this could be the problem of my stiff steering. So why not. I plan on keeping her for quite a while. While I'm down there. Anything else I should replace, bushings? Thanks in advance.

    check mark.jpg

  2. Jul 4, 2020 at 10:36 AM
    #2
    jammer

    jammer 2003 Toyota PreRunner 3.4L

    Joined:
    Jan 23, 2014
    Member:
    #121272
    Messages:
    1,335
    Gender:
    Male
    First Name:
    Ben
    Bentonville, AR
    Vehicle:
    2003 Lunar Mist Tacoma PreRunner 3.4l
    OME Coils/Bilstein 5100's front / 5125's rear 105 Amp Denso Alternator
    REDeye jedi [OP] likes this.
  3. Jul 4, 2020 at 11:42 AM
    #3
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    Thanks. Ive read about the polyurethane bushings. Have you ever bought from this dealer? I usually fork out the extra cash and buy toyota parts.

  4. Jul 4, 2020 at 12:27 PM
    #4
    jammer

    jammer 2003 Toyota PreRunner 3.4L

    Joined:
    Jan 23, 2014
    Member:
    #121272
    Messages:
    1,335
    Gender:
    Male
    First Name:
    Ben
    Bentonville, AR
    Vehicle:
    2003 Lunar Mist Tacoma PreRunner 3.4l
    OME Coils/Bilstein 5100's front / 5125's rear 105 Amp Denso Alternator
    99% of the parts I purchase are OEM (ToyotaPartsDeal.com) or CamelBack Toyota Parts. But, not the bushings. The polyurethane bushings really stiffen up the feel of the front end.

    Last edited: Jul 4, 2020
    Madjik_Man and REDeye jedi [OP] like this.
  5. Jul 4, 2020 at 1:19 PM
    #5
    Madjik_Man

    Madjik_Man The Rembrandt of Rattle Can

    Joined:
    Dec 2, 2009
    Member:
    #26893
    Messages:
    17,766
    Gender:
    Male
    Boulder County
    Vehicle:
    1998 Ext Cab 3.4 4x4 TRD 5MT
    2004 DC 3.4 4x4 TRD
    I would never use poly bushings on motor, transmission or body mounts. Seems like it would add a harshness to the ride.

    But for sway bar, UCAs, LCAs, steering rack, etc... anything regarding tightening up the feel of the steering and control, I go poly bushings.

    Ordered and used plenty from Energy Suspension. Highly reputable.

    joe25rs, REDeye jedi [OP] and jammer like this.
  6. Jul 4, 2020 at 2:07 PM
    #6
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    Have you used only bushings from this company or have you used any of their actual parts. Control arms, ball joints, etc. Because they have a kit for exactly what im looking for.

  7. Jul 4, 2020 at 2:48 PM
    #7
    Madjik_Man

    Madjik_Man The Rembrandt of Rattle Can

    Joined:
    Dec 2, 2009
    Member:
    #26893
    Messages:
    17,766
    Gender:
    Male
    Boulder County
    Vehicle:
    1998 Ext Cab 3.4 4x4 TRD 5MT
    2004 DC 3.4 4x4 TRD
    Only bushings. Never any parts.

    However they are a very reputable company in the industry. Obviously search for reviews of the parts you are considering buying.

    REDeye jedi [OP] likes this.
  8. Jul 4, 2020 at 3:44 PM
    #8
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    I was looking at the comments for the front end rebuild kit and everyone gave it 5 stars. People off-road with it and say they are perfect. I think I might go ahead and get them. Im just sketched out a little. Ive always bought factory parts.

  9. Jul 4, 2020 at 3:59 PM
    #9
    Madjik_Man

    Madjik_Man The Rembrandt of Rattle Can

    Joined:
    Dec 2, 2009
    Member:
    #26893
    Messages:
    17,766
    Gender:
    Male
    Boulder County
    Vehicle:
    1998 Ext Cab 3.4 4x4 TRD 5MT
    2004 DC 3.4 4x4 TRD
    I hear ya. I’m an OEM guy all the way. And the OEM UCA and LCA have been great for me forever. Can’t go wrong there either.

    Although for my 04 I think I might look at JBA UCAs when I do my suspension.

    tacoma_ca and REDeye jedi [OP] like this.
  10. Jul 4, 2020 at 4:06 PM
    #10
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    man, I'm just cant afford those jba. They would be nice just not at the moment.

  11. Jul 4, 2020 at 4:12 PM
    #11
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    The ball joints and tie rods are greasable and all of the parts are made in the USA. I can get behind that.

    Madjik_Man likes this.
  12. Jul 4, 2020 at 6:04 PM
    #12
    TacomaEli

    TacomaEli Well-Known Member

    Joined:
    Jul 5, 2019
    Member:
    #298355
    Messages:
    347
    Gender:
    Male
    First Name:
    Eli
    Roanoke, Virginia
    Vehicle:
    2000 Tacoma XtraCab SR5 TRD 3.4L Auto
    Most guys here will recommend buying OEM lower ball joints just because the aftermarket ones can be prone to breaking and if they do fail then it can be pretty dangerous.

    REDeye jedi [OP] likes this.
  13. Jul 5, 2020 at 1:44 PM
    #13
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    Yah. I normally buy OEM and most likely will for this when its all said and done and I pull the trigger. But, I'm always up for suggestions and opinions of other brands. And be that this company is from USA with material mined from the USA. It makes me way more optimistic about their parts.

  14. Jul 5, 2020 at 3:28 PM
    #14
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    While doing all this. Should I go ahead and replace upper and lower control arms? Im not a rich man but at the same time, while I have all of this apart. Is it worth it? How often are they to fail? I was going to replace the bushings anyhow. So far Im replacing front upper and lower ball joints. Front outer and inner tire rods. Any advice. Thanks

    Just priced them and man they are expensive. Id guess that if they arent cracked or anything, replacing the bushings would be satisfactory. What do you all think?

    High Noon likes this.
  15. Jul 5, 2020 at 7:55 PM
    #15
    High Noon

    High Noon The worst of humanity

    Joined:
    Jun 13, 2019
    Member:
    #296255
    Messages:
    2,530
    Gender:
    Male
    First Name:
    Sue
    Refugee
    Vehicle:
    03 white ex cab v6 trd
    Oil change
    Unless rust is an issue or you've bent one, just do the bushings. UCA's are either an i want them or need them due to lift height. Hopefully your cam bolts and sleeves are still functioning. Mine turned into a seized rust ball i had to cut out. OEM are pricey but worth it over the aftermarket setup imo.

    REDeye jedi [OP] likes this.
  16. Jul 5, 2020 at 8:00 PM
    #16
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    The truck has been in the desert its whole life. Rust is no issue for me. Just going to replace the bushings and Im getting all Toyota parts. Just getting my list together and checking it twice. Making sure I have all the tools for it. Should be fun. lol

  17. Jul 5, 2020 at 8:09 PM
    #17
    High Noon

    High Noon The worst of humanity

    Joined:
    Jun 13, 2019
    Member:
    #296255
    Messages:
    2,530
    Gender:
    Male
    First Name:
    Sue
    Refugee
    Vehicle:
    03 white ex cab v6 trd
    Oil change
    It's not bad. I had to burn mine out so it got stinky but still not terrible. If I went oem on lca bushings, I would have had to cut the old shells out because there was no chance in hell of pressing them out.

  18. Jul 19, 2020 at 12:43 AM
    #18
    BenevolentMachination

    BenevolentMachination Well-Known Member

    Joined:
    Jan 14, 2018
    Member:
    #241207
    Messages:
    110
    Ground Zero
    Vehicle:
    2000 Tacoma 3RZ 4WD Xtra
    Will oversized sway bar bushings negatively affect the function of our sway bar?

    I did not check my sway bar thickness and my new bushings appear to have a 2mm gap after they and the brackets were mounted and torqued.

    The OEM bushings were a perfect fit.

    On RockAuto, there are choices from 25mm to 27mm. I believe I got the 27mm size, but would do better with 25mm.

    Last edited: Jul 19, 2020
    REDeye jedi [OP] likes this.
  19. Jul 19, 2020 at 11:17 AM
    #19
    REDeye jedi

    REDeye jedi [OP] Well-Known Member

    Joined:
    May 25, 2017
    Member:
    #219919
    Messages:
    272
    Gender:
    Male
    First Name:
    Brendan
    Palm Springs
    Vehicle:
    2001 Tacoma prerunner 3.4l
    As im no expert. I would say yes. That 2mm WILL make a differnence as the whole purpose of bushings is to be tight and not allow wiggle room. That sucks. You have a normal tacona and got the bushing for prerunner/4wd

  20. Jul 19, 2020 at 6:11 PM
    #20
    BenevolentMachination

    BenevolentMachination Well-Known Member

    Joined:
    Jan 14, 2018
    Member:
    #241207
    Messages:
    110
    Ground Zero
    Vehicle:
    2000 Tacoma 3RZ 4WD Xtra
    Well here's the thing: I do own a 4WD. So perhaps it's an undersized sway bar?
    Assuming the sway bars are interchangeable: Previous owner may have been running sway bar-less until they sold the truck.

    Be sure to measure your sway bar before ordering a bushing kit.

    REDeye jedi [OP] likes this.
