Front radar (TSS) sensor error

Discussion in '3rd Gen. Tacomas (2016-2023)' started by polloloco81, Mar 6, 2019.

Page 5 of 7
  1. Jun 25, 2019 at 7:46 PM
    #81
    jdougy

    #81
    jdougy Member

    Joined:
    Jun 25, 2019
    Member:
    #297444
    Messages:
    16
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2019 TACOMA TRD OFF ROAD SHORT BED
    TRD PRO GRILLE
    is does look a bit recessed at the top

    jdougy, Jun 25, 2019
    #81
  2. Jun 25, 2019 at 7:47 PM
    #82
    jdougy

    #82
    jdougy Member

    Joined:
    Jun 25, 2019
    Member:
    #297444
    Messages:
    16
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2019 TACOMA TRD OFF ROAD SHORT BED
    TRD PRO GRILLE
    jdougy, Jun 25, 2019
    #82
  3. Jun 25, 2019 at 7:54 PM
    #83
    jdougy

    #83
    jdougy Member

    Joined:
    Jun 25, 2019
    Member:
    #297444
    Messages:
    16
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2019 TACOMA TRD OFF ROAD SHORT BED
    TRD PRO GRILLE
    does the top of the garnish sit in more than the bottom? It appears to in the pics but hard to tell for sure.

    jdougy, Jun 25, 2019
    #83
  4. Jun 26, 2019 at 6:44 AM
    #84
    Palmer812

    #84
    Palmer812 Well-Known Member

    Joined:
    Jun 18, 2019
    Member:
    #296734
    Messages:
    84
    Gender:
    Male
    First Name:
    Robert
    Vehicle:
    19 SR5 double cab v6 Cement Gray
    Yes it does.

    Palmer812, Jun 26, 2019
    #84
  5. Jun 26, 2019 at 6:44 PM
    #85
    jdougy

    #85
    jdougy Member

    Joined:
    Jun 25, 2019
    Member:
    #297444
    Messages:
    16
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2019 TACOMA TRD OFF ROAD SHORT BED
    TRD PRO GRILLE
    Today i.took it back apart and drilled about 1/8 inch in the top 2 holes of the grille with a step bit. This allowed the studs of the OEM garnish to go a little more on the top. I drove about 10 miles with no error so far. :fingerscrossed:
    I usually get the error on my hilly gravel driveway

    jdougy, Jun 26, 2019
    #85
    Palmer812 and MrBrooks like this.
  6. Jul 9, 2019 at 3:07 PM
    #86
    jdougy

    #86
    jdougy Member

    Joined:
    Jun 25, 2019
    Member:
    #297444
    Messages:
    16
    Gender:
    Male
    First Name:
    John
    Vehicle:
    2019 TACOMA TRD OFF ROAD SHORT BED
    TRD PRO GRILLE
    Well that fixed the error for me. Thanks for the pictures. For anyone with aftermarket grille and OEM garnish and getting the disabled sensor error read the above posts

    jdougy, Jul 9, 2019
    #86
  7. Jul 9, 2019 at 3:10 PM
    #87
    AustinMada

    #87
    AustinMada Thinking About Tacos

    Joined:
    Feb 23, 2019
    Member:
    #284165
    Messages:
    1,062
    Gender:
    Male
    WA.
    Vehicle:
    19 DCSB OR
    Chinese Pro Grille, OEM Garnish. Running it for about 4 months, no problems.


    AustinMada, Jul 9, 2019
    #87
  8. Dec 4, 2019 at 10:27 PM
    #88
    blktaco58

    #88
    blktaco58 Well-Known Member

    Joined:
    Feb 20, 2012
    Member:
    #73226
    Messages:
    192
    Gender:
    Male
    Hawaii
    Vehicle:
    2019 off road dc
    Where is everyone getting the oem pro grille and oem garnish at?

    blktaco58, Dec 4, 2019
    #88
  9. Feb 2, 2020 at 11:56 AM
    #89
    YE2KA

    #89
    YE2KA Well-Known Member

    Joined:
    Jan 19, 2020
    Member:
    #316550
    Messages:
    487
    Gender:
    Male
    First Name:
    JB
    Vehicle:
    19 Cement Grey Tacoma Offroad
    Any updates bud? I have the stock grille and ive been getting the "off" warning light sll the time during cold night. This TSS is crap and annoying wish o knew j would have purchased a 2017

    This site contains affiliate links for which the site may be compensated.
    YE2KA, Feb 2, 2020
    #89
  10. Feb 2, 2020 at 12:02 PM
    #90
    YE2KA

    #90
    YE2KA Well-Known Member

    Joined:
    Jan 19, 2020
    Member:
    #316550
    Messages:
    487
    Gender:
    Male
    First Name:
    JB
    Vehicle:
    19 Cement Grey Tacoma Offroad
    Same issue im completely stock light comes and goes. Still havent been to the dealer. Waiting for my 5k service visit

    Last edited: Feb 3, 2020
    YE2KA, Feb 2, 2020
    #90
  11. Feb 2, 2020 at 12:24 PM
    #91
    mgmdclb

    #91
    mgmdclb Well-Known Member

    Joined:
    Jan 24, 2019
    Member:
    #280479
    Messages:
    1,295
    Gender:
    Male
    The Maritimes, Canada
    Vehicle:
    2018 MGM DCLB Sport
    Mad Hornets grill and garnish.
    No errors since install, never noticed any difference with the functions.
    Light comes on every once in awhile with snow/ice. Snow along the top of the windshield will cause the light to come on as well I believe.

    I do swap back to the stock every time I go to the dealer to avoid any issues with them over it, no issues or errors swapping back and fourth.

    mgmdclb, Feb 2, 2020
    #91
  12. Feb 26, 2020 at 9:02 AM
    #92
    bttrbsch

    #92
    bttrbsch Well-Known Member

    Joined:
    Jan 19, 2020
    Member:
    #316646
    Messages:
    380
    Gender:
    Male
    First Name:
    Michael
    Bellingham, WA
    Vehicle:
    2018 Inferno Tacoma TRD Off-Road
    Kicker speaker upgrade Rockford Sub TRD Grill Raptor Lights Oedro Running Boards Seat Covers Black Emblems MBRP Exhaust Sound dampened doors Blacked out turn signals Pro comp 7069 wheels BFG KO2 285/70/17 Ram mount Joying Head Unit Fogs Soft topper canopy Fox 2.5 RR DSC Fox 2.0 RR rear HS AAL 1.5" rear plus overload (2" total) Center console divider Axe/Shovel Mount Traction boards 32" light bar Shift sense pro v2 iDrive throttle controller Xentec 35W HIDs Vair 88p air compressor Dome LEDs LED reverse lights + pods JBA Upper Control Arms Full size spare tire Driver seat riser
    I've played with my grill and garnish, still getting an error. I've done the following:

    1. Made sure both side bolts on the TSS sensor are tightened down
    2. Checked that grille clips are fully clipped in
    3. Added 1/8" of spacer to top sensor bolt by adding some washers
    4. Added a drop of hot glue to garnish to make sure it holds in place
    5. I am using the following garnish https://www.ebay.com/itm/Genuine-OE...e=STRK:MEBIDX:IT&_trksid=p2060353.m2749.l2649

    There are 390 sold, so I would think it's a reliable source for a garnish? Anyone have additional suggestions for making the error disappear?

    This site contains affiliate links for which the site may be compensated.
    bttrbsch, Feb 26, 2020
    #92
  13. May 5, 2020 at 11:15 AM
    #93
    YE2KA

    #93
    YE2KA Well-Known Member

    Joined:
    Jan 19, 2020
    Member:
    #316550
    Messages:
    487
    Gender:
    Male
    First Name:
    JB
    Vehicle:
    19 Cement Grey Tacoma Offroad
    It was posted on here by a user that even by just disconnecting the TSS during installation of the grill, thats enough to cause the sensor to be thrown out of whack and would need to be recalibrated even if going back to original grill? Is there any truth to that anyone?

    YE2KA, May 5, 2020
    #93
  14. May 5, 2020 at 11:28 AM
    #94
    Dave3359

    #94
    Dave3359 Well-Known Member

    Joined:
    Mar 5, 2019
    Member:
    #285421
    Messages:
    459
    Gender:
    Male
    First Name:
    Dave
    Fl
    Vehicle:
    2018 Blazing blue access cab
    I went from a SR5 grill to a pro grill ( from taco garage and there after market garnish) zero problem easy swap no errors been about 3 months

    Dave3359, May 5, 2020
    #94
  15. Aug 24, 2020 at 9:00 AM
    #95
    Tacomashopper

    #95
    Tacomashopper Ricardo's Taco

    Joined:
    Dec 26, 2018
    Member:
    #276989
    Messages:
    56
    Gender:
    Male
    First Name:
    RICHARD
    Birmingham, Al
    Vehicle:
    2019 Cavalry Blue Sr5 DCSB 4x4
    I installed on my SR5 about 2 weeks ago, getting the clean sensor error. I realized that the sensor is attached to the grill/garnish by only one screw at the top, is this correct? Seems like it was that way when I removed it to replace the grill. Thanks!

    Tacomashopper, Aug 24, 2020
    #95
  16. Feb 17, 2021 at 4:46 PM
    #96
    YE2KA

    #96
    YE2KA Well-Known Member

    Joined:
    Jan 19, 2020
    Member:
    #316550
    Messages:
    487
    Gender:
    Male
    First Name:
    JB
    Vehicle:
    19 Cement Grey Tacoma Offroad
    Sorry I'm super late, did you have any future issues after installing OEM garnish?

    This site contains affiliate links for which the site may be compensated.
    YE2KA, Feb 17, 2021
    #96
  17. Feb 17, 2021 at 4:58 PM
    #97
    StreetsTheWay

    #97
    StreetsTheWay Well-Known Member

    Joined:
    Sep 30, 2020
    Member:
    #342426
    Messages:
    157
    Gender:
    Male
    First Name:
    Justin
    Alberta, Canada
    Vehicle:
    2020 Tacoma TRD Offroad, Cement Grey
    I bought a knockoff TSS garnish from Amazon for ~$40CAD for my 2020 TRD Offroad after swapping to a genuine "heritage style" grille (with the camera space) from sparksparts back in October.
    No issues whatsoever. No recalibration, no shimming. Nothing.
    I just swapped everything from my OEM grille over to the new one, modified my camera bracket (cut it slightly shorter and bent with vise for correct camera angle).

    To this day, I am not positive what "re-calibration" is comprised of. Software based? measurements & shimming? I've never come across a procedure that would take place at a dealership for example.

    My input probably doesn't mean a heck of alot, but from my experience, the knock off garnish at a fraction of the OEM cost was worth it.

    Dealer wanted (parts only, no install):
    $500.00CAD for Grille
    $361.94CAD for Garnish
    $210.00CAD for black emblem overlays
    $85.00CAD for black tailgate lettering
    $250.00CAD for Tailgate lock

    I didn't buy anything from the dealer...
    Edit:
    This was the one I bought:
    https://www.amazon.ca/gp/product/B07XYXN2W7/ref=ppx_yo_dt_b_asin_title_o05_s00?ie=UTF8&psc=1

    2020 Grille with camera housing, I believe I used a robmotive discount code:
    https://www.sparksparts.com/oem-parts/toyota-trd-pro-grille-insert-tacoma-pt22835200aa

    Last edited: Feb 17, 2021
    StreetsTheWay, Feb 17, 2021
    #97
  18. Feb 17, 2021 at 5:11 PM
    #98
    YE2KA

    #98
    YE2KA Well-Known Member

    Joined:
    Jan 19, 2020
    Member:
    #316550
    Messages:
    487
    Gender:
    Male
    First Name:
    JB
    Vehicle:
    19 Cement Grey Tacoma Offroad
    I'm curious as well on what this dealership ship Aholes refer to as "re calibration" i tried to buy a OEM grill today they denied me. I called and asked how much was the recalibrate my sensor they said $420

    YE2KA, Feb 17, 2021
    #98
  19. Feb 17, 2021 at 5:16 PM
    #99
    StreetsTheWay

    #99
    StreetsTheWay Well-Known Member

    Joined:
    Sep 30, 2020
    Member:
    #342426
    Messages:
    157
    Gender:
    Male
    First Name:
    Justin
    Alberta, Canada
    Vehicle:
    2020 Tacoma TRD Offroad, Cement Grey
    Sparks Parts works... but you need to provide a TRD Pro VIN to purchase one now from what I know. Sounds like there are plenty of options for tracking one down. I wouldn't be too scared off about the "recalibration" stories. Worst case, it sounds like you might need to shim a TSS sensor for it to function properly, but that leads me to think that the grille wasn't molded or produced properly in the first place?
    I would say screw it, pull the trigger and do it yourself to save all the $$$. Then troubleshoot yourself if it gives you sensor issues.

    I've had my grille covered in dirt, ice, and slush - still worked just fine.
    Some have reported that it gives them problems if the garnish gets dirty or its raining out...

    StreetsTheWay, Feb 17, 2021
    #99
    YE2KA[QUOTED] likes this.
  20. Feb 17, 2021 at 5:55 PM
    #100
    YE2KA

    #100
    YE2KA Well-Known Member

    Joined:
    Jan 19, 2020
    Member:
    #316550
    Messages:
    487
    Gender:
    Male
    First Name:
    JB
    Vehicle:
    19 Cement Grey Tacoma Offroad
    So do you recommend I buy the China grille and just go with the OEM garnish. How many times would you say you had the sensor light came on?

    YE2KA, Feb 17, 2021
    #100
