Grey wire mod

Discussion in '1st Gen. Tacomas (1995-2004)' started by 2003greenbean, Dec 8, 2007.

  1. Aug 14, 2016 at 8:51 AM
    #561
    indetrucks

    indetrucks Well-Known Member

    Joined:
    Aug 5, 2016
    Member:
    #193810
    Messages:
    295
    Gender:
    Male
    First Name:
    Christian
    Southern CA
    Vehicle:
    2003 TRD Tacoma 4x4 Xtra Cab 5spd
    So to clarify, I am grounding the grey wire that goes into the 4wd CPU and NOT the wire that goes back in to the harness correct?

    Sorry, just want to be 100% before I do this.

  2. Aug 16, 2016 at 2:53 PM
    #562
    Silver02Taco

    Silver02Taco #DevilHornGang

    Joined:
    Aug 22, 2011
    Member:
    #62169
    Messages:
    20,225
    Gender:
    Male
    First Name:
    Will
    San Jose, Ca.
    Vehicle:
    2002 Xtra-Cab 4x4, V6, SR-5, TRD Off-Road
    Some Relentless Fab, some Bay Area Metal Fab, some Total Chaos Fab, some ADS, some King...
    Correct. The end going into the wiring harness should be capped off (or taped) prior to re-sealing the harness.

  3. Aug 17, 2016 at 3:08 AM
    #563
    indetrucks

    indetrucks Well-Known Member

    Joined:
    Aug 5, 2016
    Member:
    #193810
    Messages:
    295
    Gender:
    Male
    First Name:
    Christian
    Southern CA
    Vehicle:
    2003 TRD Tacoma 4x4 Xtra Cab 5spd
    Thank you sir!

  4. Nov 15, 2016 at 2:14 PM
    #564
    MainerDave19995VZ

    MainerDave19995VZ Well-Known Member

    Joined:
    Oct 24, 2015
    Member:
    #167517
    Messages:
    118
    Gender:
    Male
    First Name:
    David
    Maine
    Vehicle:
    1999 Tacoma Extra Cab SR5 TRD 5 Speed 5VZFE
    2nd generation 16" wheels with 1.25" BORA spacers
    I noticed the rear diff locker button when I bought the truck in Florida last October. I think I pushed the button in 4 low to see if I could figure out what it did during my test drive. That was the last time I pushed the button. Until today. Today I decided that the grey wire mod would rise to the top of my list and so I read this entire thread. This took some time and, as usual, I learned a ton! Earlier in the day I confirmed what I knew. I do not have ABS brakes. So, one less light to look at. Just now I went out to see if the locker even works. Went out and started the truck and pulled off the pavement and onto some spongy wet grass and woodchips. Put truck in 4 high then 4 low and drove back and forth and then hit the rear locker button while in 4 low. Blink, Blink, Blink...... Never went solid. Figured maybe I'm going to have to service it. But, I had read the entire thread so I drive back and forth with the locker light blinking all the while in 4 low. No dice. Just keeps blinking. I think that maybe this thing has never even been locked. Undeterred I kept driving back and forth in 4 low and then the light stops blinking...stays solid. I take it out of 4 wheel drive and light starts to blink but that slower blink. I put it in 2 hi and drive down the road and back. Pull onto the grass again and go to 4 lo. Hit the locker and blink blink blink...no dice. Start to drive forward and backward and then bingo! Solid light again. Third time through all this the light went solid instantly upon pressing the locker button. So, tomorrow when the sun is out I'm going to do the grey wire mod! My primary reason is that I get stuck in the least bit off snow when on a slight grade and I just need a little more traction to get moving and then I'm good. After 17 years the rear differential locker is now going to get used at least a dozen times a year. And honestly, if I ever sell the truck, I'm pretty sure that showing this to a buyer is going to make a good impression. THANK YOU to all the posters on this thread who made this whole process understandable. My advice to newbies is to read the whole thread. Then check to see that you have or don't have ABS just so you know what to expect with lights on the dashboard. Cycle your diff locker a few times so you know that it works and how long it takes and all that. Then do the mod. I'll post up my mod photos as soon as I'm done.

    TacoSupremeo and Bulldogs129 like this.
  5. Nov 16, 2016 at 6:48 AM
    #565
    Bulldogs129

    Bulldogs129 Don't find fault, find a remedy

    Joined:
    Sep 8, 2016
    Member:
    #196750
    Messages:
    1,261
    Gender:
    Male
    First Name:
    Malcolm
    Mississippi
    Vehicle:
    2018 TRD, OR, 4wd, Dblcab, 3.5l, & 2002 Tacoma 4wd, SR5, TRD, 3.4L, auto
    Mine is doing the exact same thing. I'll start reading the thread asap. Thanks for posting your truck symptoms.

    MainerDave19995VZ likes this.
  6. Nov 16, 2016 at 7:08 AM
    #566
    cynicalrider

    cynicalrider #NFG

    Joined:
    Jul 25, 2012
    Member:
    #83399
    Messages:
    11,082
    Gender:
    Male
    Jersey
    Vehicle:
    01 SR5 TRD 4x4
    Drop bracket lift and booger welds
    Good to hear you had success! These lockers definitely can go bad if unused. Keep using it and you will likely not have issues.

    MainerDave19995VZ likes this.
  7. Nov 17, 2016 at 10:05 PM
    #567
    taco03Trd

    taco03Trd Doble cab trd v6 now

    Joined:
    Sep 29, 2016
    Member:
    #198568
    Messages:
    640
    Gender:
    Male
    First Name:
    Carlos
    Riverside ca
    Vehicle:
    03 DC prerunner trd v6 2wd
    Non yet
    Can i do this mod on my 2wd trd with elocker? and is it the same color wire aim looking for ? (grey)
    Any help with be a preciated

  8. Nov 18, 2016 at 9:57 AM
    #568
    Bulldogs129

    Bulldogs129 Don't find fault, find a remedy

    Joined:
    Sep 8, 2016
    Member:
    #196750
    Messages:
    1,261
    Gender:
    Male
    First Name:
    Malcolm
    Mississippi
    Vehicle:
    2018 TRD, OR, 4wd, Dblcab, 3.5l, & 2002 Tacoma 4wd, SR5, TRD, 3.4L, auto
    Fall cleaning shop- haul mode


  9. Nov 18, 2016 at 12:32 PM
    #569
    Silver02Taco

    Silver02Taco #DevilHornGang

    Joined:
    Aug 22, 2011
    Member:
    #62169
    Messages:
    20,225
    Gender:
    Male
    First Name:
    Will
    San Jose, Ca.
    Vehicle:
    2002 Xtra-Cab 4x4, V6, SR-5, TRD Off-Road
    Some Relentless Fab, some Bay Area Metal Fab, some Total Chaos Fab, some ADS, some King...
    If you have a Pre-Runner, there's no need to do this Mod. Anytime you press the button, the locker will lock. This mod is only for 4WD Tacomas who want to have the same locking differentail functionality that Pre-Runner's have.

    Sicyota04 likes this.
  10. Nov 18, 2016 at 1:52 PM
    #570
    taco03Trd

    taco03Trd Doble cab trd v6 now

    Joined:
    Sep 29, 2016
    Member:
    #198568
    Messages:
    640
    Gender:
    Male
    First Name:
    Carlos
    Riverside ca
    Vehicle:
    03 DC prerunner trd v6 2wd
    Non yet
    Ooo i see them there something wrong with mine . cuz went i press my button nothing happens . or do i need to be stuck for the locker to activate ?

    Thanks for the reply. silver 02

  11. Nov 19, 2016 at 2:44 PM
    #571
    James Lee

    James Lee 1st gen for the win.

    Joined:
    Jun 4, 2015
    Member:
    #156766
    Messages:
    202
    Gender:
    Male
    Seattle,WA
    Vehicle:
    2001 Tacoma 4x4 Limited TRD
    -OME 882 coils -Jeep Jk 10mm trimpackers -Wheeler's extending rear brake line -OME Dakars+aal -4in Deckplate -nitro sport shocks all around -Star Hid projector headlights -Trail gear rock sliders -Trail Gear low profile front bumper -Pro Comp 51's 15x8 on BFG KO 32" -ARB snorkel -EBC pads and rotors -Rago Fabrication ditch lights+brackets -SpiderTraxx 1.25 wheel spacers -Snugtop Canopy
    How fast can you drive with the e locker engaged in 2wd? Can I be able to drive it on the freeway with it on?

  12. Nov 19, 2016 at 2:48 PM
    #572
    ekul310

    ekul310 Lurker

    Joined:
    Jun 1, 2016
    Member:
    #188443
    Messages:
    107
    Gender:
    Male
    First Name:
    Luke
    Pennsylvania
    Vehicle:
    2003 Black DC TRD
    32 BFG MTs 3" Lift OME 883s All pro leafs/5125s
    Can and should are two different things. You CAN drive with it engaged at freeway speeds, however, you SHOULD not. The locker by design does not allow the rear wheels to spin at different speeds. When you turn even slightly the outside wheel needs to spin faster than the inside wheel. With the locker engaged it will bind if turning on a hard surface increasing tire wear dramatically.

    TACO ROCKO and James Lee like this.
  13. Nov 19, 2016 at 3:03 PM
    #573
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    11,464
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 4 Cree LED lamps Bilstein 5100s Ride Rite Air Bags
    Instead of driving back and forth and hoping it will lock (stop blinking), try (from a stop) turning your steering wheel all the way to the left (or to the right) and begin to roll forward. It should stop blinking within a foot or two!

    This mod is for 4WD Tacomas only (who only have locker available in L4) so they can have a locker in H4 and H2 (2WD). Obviously, 2WD Tacomas don't need the mod since the locker (if equipped) works in 2WD.

    The locker is for getting unstuck. If you are on a paved road, driving fast, etc. YOU ARE NOT STUCK!
    Use it when you begin to have tire spin or before crossing deep mud or climbing a steep, dirt grade where you anticipate tire spin.

    As stated, when locked, the back tires can not rotate at different speeds, as they must when turning. If they can't slip in a turn then you risk damage, or if at a high speed: losing control! Please don't give Toyota a reason to discontinue the locker because you did something stupid and killed yourself!

  14. Nov 20, 2016 at 8:12 AM
    #574
    MainerDave19995VZ

    MainerDave19995VZ Well-Known Member

    Joined:
    Oct 24, 2015
    Member:
    #167517
    Messages:
    118
    Gender:
    Male
    First Name:
    David
    Maine
    Vehicle:
    1999 Tacoma Extra Cab SR5 TRD 5 Speed 5VZFE
    2nd generation 16" wheels with 1.25" BORA spacers
    I'm going to try the wheel all the way left or right suggestion. I find that now that I've used it a few times it is locking much faster but I do need to roll forward or backward a couple feet at a minimum. I'll let you know if it seems faster with the steering wheel all the way over. Thanks for the tip!

  15. Nov 20, 2016 at 10:06 AM
    #575
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    11,464
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 4 Cree LED lamps Bilstein 5100s Ride Rite Air Bags
    De nada! It was something I learned here on TW, and it worked every time. Mind you, I don't use the locker except for testing because my truck has the A-TRAC system which "auto-locks" both the front and back if there is tire spin on either end.

  16. Jan 13, 2017 at 6:39 AM
    #576
    retroboy1989

    retroboy1989 Single Cab 4x4

    Joined:
    Apr 8, 2016
    Member:
    #183693
    Messages:
    746
    Gender:
    Male
    Vehicle:
    99 2.7L 5spd 4x4
    No can do, I gave up at page 3. One of the more painful reads on this website. "Will this work on a pre runner?" "Will this work if I don't have a locker?" "Can I add a switch so I can unlock the diff?"

  17. Jan 13, 2017 at 9:30 AM
    #577
    Sicyota04

    Sicyota04 Slowly but surely.

    Joined:
    Jan 9, 2015
    Member:
    #145940
    Messages:
    2,730
    Gender:
    Male
    NorCal
    Vehicle:
    04 Tacoma DCSB TRD 4x4 V6
    Icon 2.5 Ext. travel coil overs, Camburg UCA's, rear Icon smooth body 0-3" VS 2.0's and a 2" AAL. Custom color matched retrofit HID 4.0 d2s projectors, dual switchback halos w/ RGB Demon eyes. Deck plate mod. Flow master 40 series. 4D optic 22" light bar & 4D optic Pods. 16x8 Method double standards w/ machined lip, wrapped w/ BFG KO2's. Steel grill insert by DB Customz. TG Front & Rear bumpers and sliders. Tundra Brake Upgrade. Complete Interior LED Swap.
    It's a mod. to be able to use your rear locker in 4hi since you can only use your rear locker in 4lo. If you don't have a locker you can't do the grey wire mod. Since it's meant to do what I described above. If you have a prerunner, you don't have 4 wheel drive so you don't need to do it either. Cause prerunner's already have a button to push to use your rear locker and you don't have to worry about 4hi or low.

    36tacundra and David K like this.
  18. Jan 13, 2017 at 12:44 PM
    #578
    retroboy1989

    retroboy1989 Single Cab 4x4

    Joined:
    Apr 8, 2016
    Member:
    #183693
    Messages:
    746
    Gender:
    Male
    Vehicle:
    99 2.7L 5spd 4x4
    I think you missed my point..... I was not asking those questions. I was quoting them from what I read in the first 3 pages of this thread. I gave up on reading this thread because of questions like that.

  19. Jan 17, 2017 at 5:02 PM
    #579
    obs ham

    obs ham Well-Known Member

    Joined:
    Jan 16, 2017
    Member:
    #207753
    Messages:
    50
    Gender:
    Male
    Vehicle:
    99 tacoma trd blower
    Dont let that magic smoke out of the wire

  20. Jan 19, 2017 at 10:43 PM
    #580
    E30325

    E30325 Well-Known Member

    Joined:
    Nov 23, 2016
    Member:
    #203171
    Messages:
    4,128
    Gender:
    Male
    First Name:
    Nick
    Vehicle:
    2000 Tacoma TRD 5spd
    5100's and OME 881's, AAL and KM3's
    Okay random question that may be answered in the thread (sorry I haven't read it)

    I did the grey wire mod the day after I bought my truck so this doesn't apply to me, but I thinking the other day and curiousity made me wonder the following..

    So we know that if you have ABS, any time the diff is locked it defeats the ABS, my question is, if you haven't done the grey wire mod, but hit the button to lock it while in 2wd or 4hi (so the light just flashes and of course won't lock) will this still defeat the ABS while the button is pushed in? Or does it only shut down ABS once the diff physically locks?

    Random question I know, but if that worked that seems like a simple and temporary ABS defeat for someone who hasn't done the grey wire mod.

    Or maybe I've just had to many :cheers:
