Hella 1000 Install - Switch Works But Not Lights

Discussion in 'Technical Chat' started by Reznor88, May 24, 2013.

  1. May 24, 2013 at 3:29 PM
    #1
    Reznor88

    Reznor88 [OP] Well-Known Member

    Joined:
    May 1, 2009
    Member:
    #16668
    Messages:
    646
    Gender:
    Male
    First Name:
    Mike
    Yuba City, CA
    Vehicle:
    '06 PreRunner DC Off Road
    Satoshi Grille, DNX5120
    Just installed a set of Hella 1000s and cannot get the damn things to come on for whatever reason. The lights come with a complete wiring harness with relay/fuse. I'm not the best when it comes to wiring but I thought this would be simple enough with the harness provided.

    The only thing I am attempting to do differently than the provided instructions is tapping into a source dependent upon the ignition rather than tapping into the high-beams.

    I used the sticky'd write up as a guide for tapping into the fuse block. Plugged my adapter into the same source as the wipers...

    No idea why photobucket is flipping my photo but where I tapped in is actually the bottom left corner, not the top right.

    [​IMG]



    I put the original wiper fuse (10) into the bottom slot of the adapter and put another fuse in the top slot (3). My switch is getting power and lights up when I flip it on but I'm getting nothing from the lights themselves. Checked the simple things like the cables being attached to the terminals and everything looks good. Even took the lights apart again to make sure all the connections were good, so unless something came undone as I was putting the lights together again, I have have no idea what's wrong.

  2. May 24, 2013 at 3:40 PM
    #2
    beaver_scott

    beaver_scott Well-Known Member

    Joined:
    Jun 8, 2010
    Member:
    #38609
    Messages:
    199
    Gender:
    Male
    First Name:
    scott
    renton, wa
    Vehicle:
    07 tacoma 4x4 trd off road
    vent shades tinted windows painted to match grille painted to match rear bumper grillcraft grill bamf light bar+4 hella 500ff tinted led tail lights ddm hid light kit moromoto mini retrofit de-badged black trd offroad decals trd license plate frames magnaflow exhaust system afe pro dry s front coil spacers and rear add a leaf rcbs204's 4x4 illuminated switch jvc kw-nt3hdt in dash navigation unit
    did you make sure the lights have a good ground?

  3. May 24, 2013 at 3:42 PM
    #3
    Primo 95

    Primo 95 Well-Known Member

    Joined:
    Jun 23, 2012
    Member:
    #81207
    Messages:
    451
    Gender:
    Male
    First Name:
    Primo!
    San Antonio, TX
    Vehicle:
    2012 DCSB 4X4
    265/75/16 DuraTrac 16X8.5 Level 8 Trackers HID, LED interior, 3" N-Fab step bars
    Do your Hellas work when the wipers are on?

    Just tap into your low beams. I did that with my Hella 700FFs and they worked fine. And yes this means your low beams need to be on to use your lights.

  4. May 24, 2013 at 3:47 PM
    #4
    Polymerhead

    Polymerhead Well-Known Member

    Joined:
    Oct 15, 2010
    Member:
    #44737
    Messages:
    3,339
    Gender:
    Male
    Missouri
    Vehicle:
    '10 4x4 DC SR5
    WeatherTech liners, Kenwood Media Receiver, Alpine S 6x9 speakers, Sound Ordnance 8" Sub, OEM running boards, OR wheels, Dynapro ATs, Tint, Bed Mat, Avid light bar, KC Daylighters
    Is your ignition on when you're testing?

  5. May 24, 2013 at 3:51 PM
    #5
    Reznor88

    Reznor88 [OP] Well-Known Member

    Joined:
    May 1, 2009
    Member:
    #16668
    Messages:
    646
    Gender:
    Male
    First Name:
    Mike
    Yuba City, CA
    Vehicle:
    '06 PreRunner DC Off Road
    Satoshi Grille, DNX5120
    Quick responses...awesome!

    - Lights have good ground.

    - The wiper reference is just where I put the fuse tap in. That way the light switch only works when the truck is on, no accidentally draining my battery. The wipers themselves have nothing to do with it.

    - Ignition is on when testing. The switch lights up when I flip it to on but nothing from the lights.

  6. May 24, 2013 at 4:01 PM
    #6
    Reznor88

    Reznor88 [OP] Well-Known Member

    Joined:
    May 1, 2009
    Member:
    #16668
    Messages:
    646
    Gender:
    Male
    First Name:
    Mike
    Yuba City, CA
    Vehicle:
    '06 PreRunner DC Off Road
    Satoshi Grille, DNX5120
    For whatever it's worth I can hear/feel clicking in the relay when I flip the switch for the lights.

  7. May 24, 2013 at 4:10 PM
    #7
    Chepo

    Chepo Tankoma!

    Joined:
    Sep 8, 2011
    Member:
    #63159
    Messages:
    582
    Gender:
    Male
    Mexico City
    Vehicle:
    '11 TRD Sport
    ARB front bumper, Custom Rear Bumper, Safari Snorkel, Led Lights all over, OME Lift
    Then is the cable that goes from the relay to your lights... Or the fuse, did you check that its not blown? The only thing missing is the power or ground...

  8. May 24, 2013 at 4:16 PM
    #8
    Reznor88

    Reznor88 [OP] Well-Known Member

    Joined:
    May 1, 2009
    Member:
    #16668
    Messages:
    646
    Gender:
    Male
    First Name:
    Mike
    Yuba City, CA
    Vehicle:
    '06 PreRunner DC Off Road
    Satoshi Grille, DNX5120
    I'm going to go take the lights apart AGAIN and make sure everything is connected. I'm hoping its something that simple but I'm also hoping its not something that stupid...

  9. May 24, 2013 at 5:33 PM
    #9
    Reznor88

    Reznor88 [OP] Well-Known Member

    Joined:
    May 1, 2009
    Member:
    #16668
    Messages:
    646
    Gender:
    Male
    First Name:
    Mike
    Yuba City, CA
    Vehicle:
    '06 PreRunner DC Off Road
    Satoshi Grille, DNX5120
    Problem sovled, everything works.

    My theory is that somewhere between the connections to the lights being messed up and said connections being fixed, a fuse blew. I say this because I looked everything over before setting in on the connections. After redoing the connections multiple times I checked everything again for the hell of it and had a blown fuse. Whatever, it's fixed now.
