Help wiring 7" kragens - fuse keeps blowing

Discussion in 'Lighting' started by Infra, Apr 14, 2012.

  1. Apr 14, 2012 at 1:40 PM
    #1
    Infra

    Infra [OP] Well-Known Member

    Joined:
    Apr 29, 2010
    Member:
    #36238
    Messages:
    2,954
    Gender:
    Male
    First Name:
    Jason
    Az
    Vehicle:
    2010 MGM DCSB 4x4 TRD OR 6spd
    CBI Bushmaster 2.0 rear bumper with swing out tire carrier & fold down camp table, CBI Moab 2.0 front bumper, Warn M8000-S, Icon 2.5 RR CDC Extended travel CO's with 700lb springs, Icon 2.5 RR CDC rear shocks, Icon hydro bumps, Total Chaos uniball UCA's, All Pro Expo leafs, U-bolt flip kit, Softopper, diff breather mod, extended rear brake lines, Grillecraft mesh grille, Elusive Elements behind grille light bar with B.A.M.F. LED light bar brackets, okLEDlightbars.com 20" double row LED light bar, Relentless Fabrication hood cb antenna mount, Wilson Silver Load CB antenna, Uniden 520 Pro XL CB radio, Wet okole seat covers, Weather tech floor liners, Weather tech in channel window deflectors, trasharoo spare tire trash bag carrier, Box Rocket 2nd gen bed rack with (2) 2 gallon gas rotopax mounted on drivers side, (2) 2 gallon water rotopax mounted on passenger side, (1) 3 gallon gas rotopax & (1) 2 gallon gas rotopax mounted on CBI swing out, Avid weld on sliders, Mattgecko LED bed light
    I have followed the instructions exactly as posted in this thread
    http://www.tacomaworld.com/forum/technical-chat/6525-diy-wiring-after-market-lights.html


    I am using a 30amp relay. When I initially hooked everything up to the switch the lights came on and worked fine. After installing the switch where I wanted it and hooking everything back up, now the lights will not power up. I have power going to the relay with in inline 20amp fuse, and power coming from the relay into the cab to the switch. Every time I flip the switch the 20amp mini fuse in the fuse tap blows. What could be the problem?

  2. Apr 14, 2012 at 1:44 PM
    #2
    Infra

    Infra [OP] Well-Known Member

    Joined:
    Apr 29, 2010
    Member:
    #36238
    Messages:
    2,954
    Gender:
    Male
    First Name:
    Jason
    Az
    Vehicle:
    2010 MGM DCSB 4x4 TRD OR 6spd
    CBI Bushmaster 2.0 rear bumper with swing out tire carrier & fold down camp table, CBI Moab 2.0 front bumper, Warn M8000-S, Icon 2.5 RR CDC Extended travel CO's with 700lb springs, Icon 2.5 RR CDC rear shocks, Icon hydro bumps, Total Chaos uniball UCA's, All Pro Expo leafs, U-bolt flip kit, Softopper, diff breather mod, extended rear brake lines, Grillecraft mesh grille, Elusive Elements behind grille light bar with B.A.M.F. LED light bar brackets, okLEDlightbars.com 20" double row LED light bar, Relentless Fabrication hood cb antenna mount, Wilson Silver Load CB antenna, Uniden 520 Pro XL CB radio, Wet okole seat covers, Weather tech floor liners, Weather tech in channel window deflectors, trasharoo spare tire trash bag carrier, Box Rocket 2nd gen bed rack with (2) 2 gallon gas rotopax mounted on drivers side, (2) 2 gallon water rotopax mounted on passenger side, (1) 3 gallon gas rotopax & (1) 2 gallon gas rotopax mounted on CBI swing out, Avid weld on sliders, Mattgecko LED bed light
    If I remove the hot wire for the lights from the relay and wire it directly to the battery, the lights power on.

  3. Apr 14, 2012 at 1:51 PM
    #3
    bjmoose

    bjmoose Bullwinkle J. Moose

    Joined:
    Aug 31, 2010
    Member:
    #42529
    Messages:
    5,618
    Gender:
    Male
    First Name:
    Steve
    San Jose CA
    Vehicle:
    '11 Std Cab 4x4 5sp
    OME suspension, ARB Air Locker, Yaesu FT 8900 Ham Radio
    Either you wired it wrong, or you scraped off some insulation and you have a ground fault.


    First, triple check everything against the diagram with a skeptical eye assuming its wrong.

    To check for a ground disconnect power, turn off the lights, and use an ohm meter at the plus terminal of the bulb, and a good chassis ground point. Resistance should be infinite.

  4. Apr 14, 2012 at 2:03 PM
    #4
    Infra

    Infra [OP] Well-Known Member

    Joined:
    Apr 29, 2010
    Member:
    #36238
    Messages:
    2,954
    Gender:
    Male
    First Name:
    Jason
    Az
    Vehicle:
    2010 MGM DCSB 4x4 TRD OR 6spd
    CBI Bushmaster 2.0 rear bumper with swing out tire carrier & fold down camp table, CBI Moab 2.0 front bumper, Warn M8000-S, Icon 2.5 RR CDC Extended travel CO's with 700lb springs, Icon 2.5 RR CDC rear shocks, Icon hydro bumps, Total Chaos uniball UCA's, All Pro Expo leafs, U-bolt flip kit, Softopper, diff breather mod, extended rear brake lines, Grillecraft mesh grille, Elusive Elements behind grille light bar with B.A.M.F. LED light bar brackets, okLEDlightbars.com 20" double row LED light bar, Relentless Fabrication hood cb antenna mount, Wilson Silver Load CB antenna, Uniden 520 Pro XL CB radio, Wet okole seat covers, Weather tech floor liners, Weather tech in channel window deflectors, trasharoo spare tire trash bag carrier, Box Rocket 2nd gen bed rack with (2) 2 gallon gas rotopax mounted on drivers side, (2) 2 gallon water rotopax mounted on passenger side, (1) 3 gallon gas rotopax & (1) 2 gallon gas rotopax mounted on CBI swing out, Avid weld on sliders, Mattgecko LED bed light
    It's not the relay, I bought another one and still have same problem. I have triple and quadruple checked the wiring, everything is wired correctly.

    All crimped connections seem to be good plus I sealed them at the crimping point with heat shrink tubing.

  5. Apr 14, 2012 at 2:04 PM
    #5
    bjmoose

    bjmoose Bullwinkle J. Moose

    Joined:
    Aug 31, 2010
    Member:
    #42529
    Messages:
    5,618
    Gender:
    Male
    First Name:
    Steve
    San Jose CA
    Vehicle:
    '11 Std Cab 4x4 5sp
    OME suspension, ARB Air Locker, Yaesu FT 8900 Ham Radio
    You still might have scraped a wire in routing it.

    Check for a ground fault.

  6. Apr 14, 2012 at 2:10 PM
    #6
    bjmoose

    bjmoose Bullwinkle J. Moose

    Joined:
    Aug 31, 2010
    Member:
    #42529
    Messages:
    5,618
    Gender:
    Male
    First Name:
    Steve
    San Jose CA
    Vehicle:
    '11 Std Cab 4x4 5sp
    OME suspension, ARB Air Locker, Yaesu FT 8900 Ham Radio
    Also, there's no wiring diagram in the original post you linked??

    Sketch a schematic of your wiring and post it so we can double check it.

    SOMETHING is wrong, or you wouldn't be blowing fuses.

  7. Apr 14, 2012 at 2:29 PM
    #7
    Infra

    Infra [OP] Well-Known Member

    Joined:
    Apr 29, 2010
    Member:
    #36238
    Messages:
    2,954
    Gender:
    Male
    First Name:
    Jason
    Az
    Vehicle:
    2010 MGM DCSB 4x4 TRD OR 6spd
    CBI Bushmaster 2.0 rear bumper with swing out tire carrier & fold down camp table, CBI Moab 2.0 front bumper, Warn M8000-S, Icon 2.5 RR CDC Extended travel CO's with 700lb springs, Icon 2.5 RR CDC rear shocks, Icon hydro bumps, Total Chaos uniball UCA's, All Pro Expo leafs, U-bolt flip kit, Softopper, diff breather mod, extended rear brake lines, Grillecraft mesh grille, Elusive Elements behind grille light bar with B.A.M.F. LED light bar brackets, okLEDlightbars.com 20" double row LED light bar, Relentless Fabrication hood cb antenna mount, Wilson Silver Load CB antenna, Uniden 520 Pro XL CB radio, Wet okole seat covers, Weather tech floor liners, Weather tech in channel window deflectors, trasharoo spare tire trash bag carrier, Box Rocket 2nd gen bed rack with (2) 2 gallon gas rotopax mounted on drivers side, (2) 2 gallon water rotopax mounted on passenger side, (1) 3 gallon gas rotopax & (1) 2 gallon gas rotopax mounted on CBI swing out, Avid weld on sliders, Mattgecko LED bed light
  8. Apr 14, 2012 at 2:30 PM
    #8
    Infra

    Infra [OP] Well-Known Member

    Joined:
    Apr 29, 2010
    Member:
    #36238
    Messages:
    2,954
    Gender:
    Male
    First Name:
    Jason
    Az
    Vehicle:
    2010 MGM DCSB 4x4 TRD OR 6spd
    CBI Bushmaster 2.0 rear bumper with swing out tire carrier & fold down camp table, CBI Moab 2.0 front bumper, Warn M8000-S, Icon 2.5 RR CDC Extended travel CO's with 700lb springs, Icon 2.5 RR CDC rear shocks, Icon hydro bumps, Total Chaos uniball UCA's, All Pro Expo leafs, U-bolt flip kit, Softopper, diff breather mod, extended rear brake lines, Grillecraft mesh grille, Elusive Elements behind grille light bar with B.A.M.F. LED light bar brackets, okLEDlightbars.com 20" double row LED light bar, Relentless Fabrication hood cb antenna mount, Wilson Silver Load CB antenna, Uniden 520 Pro XL CB radio, Wet okole seat covers, Weather tech floor liners, Weather tech in channel window deflectors, trasharoo spare tire trash bag carrier, Box Rocket 2nd gen bed rack with (2) 2 gallon gas rotopax mounted on drivers side, (2) 2 gallon water rotopax mounted on passenger side, (1) 3 gallon gas rotopax & (1) 2 gallon gas rotopax mounted on CBI swing out, Avid weld on sliders, Mattgecko LED bed light

    I've checked all wires, there does not seem to be any insulation scraped off of any of the wires. All crimped connections seem to be tightly crimped and as stated above, I sealed them all with heat shrink tubing.

  9. Apr 14, 2012 at 2:53 PM
    #9
    bjmoose

    bjmoose Bullwinkle J. Moose

    Joined:
    Aug 31, 2010
    Member:
    #42529
    Messages:
    5,618
    Gender:
    Male
    First Name:
    Steve
    San Jose CA
    Vehicle:
    '11 Std Cab 4x4 5sp
    OME suspension, ARB Air Locker, Yaesu FT 8900 Ham Radio
    Why is the switch grounded? Is it a lighted switch? If it's a SPDT and you've grounded one "throw" you'll blow a fuse every time.

  10. Apr 14, 2012 at 2:57 PM
    #10
    Infra

    Infra [OP] Well-Known Member

    Joined:
    Apr 29, 2010
    Member:
    #36238
    Messages:
    2,954
    Gender:
    Male
    First Name:
    Jason
    Az
    Vehicle:
    2010 MGM DCSB 4x4 TRD OR 6spd
    CBI Bushmaster 2.0 rear bumper with swing out tire carrier & fold down camp table, CBI Moab 2.0 front bumper, Warn M8000-S, Icon 2.5 RR CDC Extended travel CO's with 700lb springs, Icon 2.5 RR CDC rear shocks, Icon hydro bumps, Total Chaos uniball UCA's, All Pro Expo leafs, U-bolt flip kit, Softopper, diff breather mod, extended rear brake lines, Grillecraft mesh grille, Elusive Elements behind grille light bar with B.A.M.F. LED light bar brackets, okLEDlightbars.com 20" double row LED light bar, Relentless Fabrication hood cb antenna mount, Wilson Silver Load CB antenna, Uniden 520 Pro XL CB radio, Wet okole seat covers, Weather tech floor liners, Weather tech in channel window deflectors, trasharoo spare tire trash bag carrier, Box Rocket 2nd gen bed rack with (2) 2 gallon gas rotopax mounted on drivers side, (2) 2 gallon water rotopax mounted on passenger side, (1) 3 gallon gas rotopax & (1) 2 gallon gas rotopax mounted on CBI swing out, Avid weld on sliders, Mattgecko LED bed light
    It does light up when there is power to it. I'm not sure what a SPDT is, maybe if you spell it out? The switch is grounded because it has a terminal for a ground on the back of it, I just assumed it needed to be grounded.

  11. Apr 14, 2012 at 3:01 PM
    #11
    Ryan07

    Ryan07 Well-Known Member

    Joined:
    Jul 12, 2010
    Member:
    #40109
    Messages:
    351
    Gender:
    Male
    First Name:
    Ryan
    New Brunswick
    Vehicle:
    07 TRD DC,LB Sport 4x4
    Icon Ext. Coilovers, LR UCA's, Icon AAL, Nitro 9000 Shocks, 7"Kragen HID's/Billet Grille, Extang Solid Fold Tonneau Cover, Bed Lights, Diff Breather Mod, D-Rings Mod, LED Interior Lighting/Plate Lights, LED 4X4 Switch, Viper Starter, AVH-P4200DVD, PAC Interface, OEM Backup Camera/Pop&lock, Wet Okole Seat Covers, Weathertech Mats, Husky Mud Flaps, 8000lbs Champion Winch/Winch Cradle and Quick Connect Kit, 4,500lbs Champion Winch/Front Hidden Winch Mount, OEM Painted Rims, Spidertrax 1.25, 265/70R17 BFG KO's
  12. Apr 14, 2012 at 3:05 PM
    #12
    bjmoose

    bjmoose Bullwinkle J. Moose

    Joined:
    Aug 31, 2010
    Member:
    #42529
    Messages:
    5,618
    Gender:
    Male
    First Name:
    Steve
    San Jose CA
    Vehicle:
    '11 Std Cab 4x4 5sp
    OME suspension, ARB Air Locker, Yaesu FT 8900 Ham Radio
    OK, if the switch is labelled for a ground and has a lightbulb in it, it's not an SPDT (single pole dual throw) switch...

    Try disconnecting the "mini fuse tap" and measure the resistance from that to a chassis ground, with the switch both "off" and "on."

    Then, just for laughs, disconnect 85 and 86 on the relay and measure the resistance across those terminals - measure it in both directions with 85 as the positive, and with 86 as the positive.

  13. Apr 14, 2012 at 3:05 PM
    #13
    Infra

    Infra [OP] Well-Known Member

    Joined:
    Apr 29, 2010
    Member:
    #36238
    Messages:
    2,954
    Gender:
    Male
    First Name:
    Jason
    Az
    Vehicle:
    2010 MGM DCSB 4x4 TRD OR 6spd
    CBI Bushmaster 2.0 rear bumper with swing out tire carrier & fold down camp table, CBI Moab 2.0 front bumper, Warn M8000-S, Icon 2.5 RR CDC Extended travel CO's with 700lb springs, Icon 2.5 RR CDC rear shocks, Icon hydro bumps, Total Chaos uniball UCA's, All Pro Expo leafs, U-bolt flip kit, Softopper, diff breather mod, extended rear brake lines, Grillecraft mesh grille, Elusive Elements behind grille light bar with B.A.M.F. LED light bar brackets, okLEDlightbars.com 20" double row LED light bar, Relentless Fabrication hood cb antenna mount, Wilson Silver Load CB antenna, Uniden 520 Pro XL CB radio, Wet okole seat covers, Weather tech floor liners, Weather tech in channel window deflectors, trasharoo spare tire trash bag carrier, Box Rocket 2nd gen bed rack with (2) 2 gallon gas rotopax mounted on drivers side, (2) 2 gallon water rotopax mounted on passenger side, (1) 3 gallon gas rotopax & (1) 2 gallon gas rotopax mounted on CBI swing out, Avid weld on sliders, Mattgecko LED bed light
  14. Apr 14, 2012 at 3:12 PM
    #14
    Infra

    Infra [OP] Well-Known Member

    Joined:
    Apr 29, 2010
    Member:
    #36238
    Messages:
    2,954
    Gender:
    Male
    First Name:
    Jason
    Az
    Vehicle:
    2010 MGM DCSB 4x4 TRD OR 6spd
    CBI Bushmaster 2.0 rear bumper with swing out tire carrier & fold down camp table, CBI Moab 2.0 front bumper, Warn M8000-S, Icon 2.5 RR CDC Extended travel CO's with 700lb springs, Icon 2.5 RR CDC rear shocks, Icon hydro bumps, Total Chaos uniball UCA's, All Pro Expo leafs, U-bolt flip kit, Softopper, diff breather mod, extended rear brake lines, Grillecraft mesh grille, Elusive Elements behind grille light bar with B.A.M.F. LED light bar brackets, okLEDlightbars.com 20" double row LED light bar, Relentless Fabrication hood cb antenna mount, Wilson Silver Load CB antenna, Uniden 520 Pro XL CB radio, Wet okole seat covers, Weather tech floor liners, Weather tech in channel window deflectors, trasharoo spare tire trash bag carrier, Box Rocket 2nd gen bed rack with (2) 2 gallon gas rotopax mounted on drivers side, (2) 2 gallon water rotopax mounted on passenger side, (1) 3 gallon gas rotopax & (1) 2 gallon gas rotopax mounted on CBI swing out, Avid weld on sliders, Mattgecko LED bed light
    Disconnect it from where? From the switch or from the fuse box? Sorry if I am frustrating you, I am not electrically savvy.


    Reading on multimeter is 80.0 both ways.

  15. Apr 14, 2012 at 3:17 PM
    #15
    Ryan07

    Ryan07 Well-Known Member

    Joined:
    Jul 12, 2010
    Member:
    #40109
    Messages:
    351
    Gender:
    Male
    First Name:
    Ryan
    New Brunswick
    Vehicle:
    07 TRD DC,LB Sport 4x4
    Icon Ext. Coilovers, LR UCA's, Icon AAL, Nitro 9000 Shocks, 7"Kragen HID's/Billet Grille, Extang Solid Fold Tonneau Cover, Bed Lights, Diff Breather Mod, D-Rings Mod, LED Interior Lighting/Plate Lights, LED 4X4 Switch, Viper Starter, AVH-P4200DVD, PAC Interface, OEM Backup Camera/Pop&lock, Wet Okole Seat Covers, Weathertech Mats, Husky Mud Flaps, 8000lbs Champion Winch/Winch Cradle and Quick Connect Kit, 4,500lbs Champion Winch/Front Hidden Winch Mount, OEM Painted Rims, Spidertrax 1.25, 265/70R17 BFG KO's
    I was going to use a relay too at first, but if you look though the pictures on my how to there's one of the manufacturers diagram that doesn't use relays.

  16. Apr 14, 2012 at 3:25 PM
    #16
    Rich91710

    Rich91710 Well-Known Member

    Joined:
    Feb 23, 2012
    Member:
    #73470
    Messages:
    16,493
    Gender:
    Male
    First Name:
    Rich
    Los Angeles
    Vehicle:
    08 Base
    Satoshi with FJ badge, factory cruise, factory intermittent wipers, Redline Tuning hood-lift struts, Hellwig Swaybar, Rosen DVD-Nav
    Sounds like you miswired after relocating the switch.

    The POWER from the relay should not be going to the switch.

    Pin 30 on the relay goes to the 20a fuse. The other side of the 20a fuse goes to the battery (or other power source).
    Pin 87 goes to the lights.

    This is all under the hood... NONE of this goes to the dash.

    Pin 85 and 86 are the relay control pins. Ground one.
    The other goes to the switch. The other pin on the switch goes to a smaller fuse (5a or less) that is connected to the fuse box... this power source can be switched with the ignition, or hot 24/7 (good way to kill your battery, but some prefer to be able to run lights with the truck off).

    It sounds like you ran from the 20a fuse to the switch and from the switch to ground.

  17. Apr 14, 2012 at 3:29 PM
    #17
    joes06tacoma

    joes06tacoma Well-Known Member

    Joined:
    Jan 1, 2010
    Member:
    #28588
    Messages:
    3,066
    Gender:
    Male
    First Name:
    Joe
    Central Coast, CA
    Vehicle:
    06 4x4 Off Road Access Cab v6 6spd
    LEER Shell with dome lights operated with 3 way switches, aux backup lights with relay and 3 position switch, modified wiring to compass/temp display and clock to include switch that disables dimming function (poor man's DRL solution), Scan Gauge 2
    From that drawing, you've got the power and acc wires at the switch reversed. When the switch is turned off, you are grounding the power wire from the fuse tap. Reverse the power and acc wires and change the fuse. That should fix your problem.

  18. Apr 14, 2012 at 3:31 PM
    #18
    anthony250f

    anthony250f Well-Known Member

    Joined:
    Feb 18, 2012
    Member:
    #73066
    Messages:
    7,390
    Gender:
    Male
    First Name:
    Anthony
    goleta/santa barbara, ca
    Vehicle:
    97 5 speed 4x4 v6
    lt
    i would say that whjen you moved the switch you hooked the wires up wronge at the switch

  19. Apr 14, 2012 at 3:31 PM
    #19
    Rich91710

    Rich91710 Well-Known Member

    Joined:
    Feb 23, 2012
    Member:
    #73470
    Messages:
    16,493
    Gender:
    Male
    First Name:
    Rich
    Los Angeles
    Vehicle:
    08 Base
    Satoshi with FJ badge, factory cruise, factory intermittent wipers, Redline Tuning hood-lift struts, Hellwig Swaybar, Rosen DVD-Nav
    It depends on the switch.

    If your switch is rated 20a or greater (on a 15a fuse) then you can run direct.

    Most of these lighted switches are only rated for 5-10amps and running them on a 15a fuse is just asking for the contacts to pit and either go open or weld together.

    You are also running high current to the dash... much better to keep the dash wiring running on a lower fuse, reduces the risk of heat and fire.

  20. Apr 14, 2012 at 3:45 PM
    #20
    Infra

    Infra [OP] Well-Known Member

    Joined:
    Apr 29, 2010
    Member:
    #36238
    Messages:
    2,954
    Gender:
    Male
    First Name:
    Jason
    Az
    Vehicle:
    2010 MGM DCSB 4x4 TRD OR 6spd
    CBI Bushmaster 2.0 rear bumper with swing out tire carrier & fold down camp table, CBI Moab 2.0 front bumper, Warn M8000-S, Icon 2.5 RR CDC Extended travel CO's with 700lb springs, Icon 2.5 RR CDC rear shocks, Icon hydro bumps, Total Chaos uniball UCA's, All Pro Expo leafs, U-bolt flip kit, Softopper, diff breather mod, extended rear brake lines, Grillecraft mesh grille, Elusive Elements behind grille light bar with B.A.M.F. LED light bar brackets, okLEDlightbars.com 20" double row LED light bar, Relentless Fabrication hood cb antenna mount, Wilson Silver Load CB antenna, Uniden 520 Pro XL CB radio, Wet okole seat covers, Weather tech floor liners, Weather tech in channel window deflectors, trasharoo spare tire trash bag carrier, Box Rocket 2nd gen bed rack with (2) 2 gallon gas rotopax mounted on drivers side, (2) 2 gallon water rotopax mounted on passenger side, (1) 3 gallon gas rotopax & (1) 2 gallon gas rotopax mounted on CBI swing out, Avid weld on sliders, Mattgecko LED bed light

    Switch is rated at 20a. I'm about fucking fed up with this shit and am just going to hard wire it from the battery.
