It got real...Baxter adapter, spin-on filter, oil change.

Discussion in '3rd Gen. Tacomas (2016+)' started by Dacon, Dec 15, 2018.

  1. Dec 15, 2018 at 6:46 PM
    #1
    Dacon

    Dacon [OP] 2017 Tacoma TRD PRO Quikrete

    Joined:
    Dec 20, 2016
    Member:
    #205354
    Messages:
    2,946
    Gender:
    Male
    First Name:
    Danny
    Gilbert, Arizona.
    Vehicle:
    2017 TRD PRO DCSB. DOP 02.20.2017
    TRD PRO Cement 2017 TRD CAI and AFE Magnum Flow Dry Air Filter Camburg KINETIK Series Billet UCA Icon LCA skid plates Icon Coilover extended travel shocks with 700# springs Icon 2" rear shocks Icon RXT leaf springs full pack (new rims and tires soon)
    Had to wait to till put more miles on the truck (old oil) to get into it. Today was the day.

    The ingredients.
    First had to remove the skid plate, a true PIA, heavy and large.
    Next was to drain the old oil (same as above) after 8500 miles and the magnetic drain plug was clean, no metal particles on it.
    After that the fun part was next to drain the oil filter cartridge.
    So sloooooooow.
    Next removing the beloved oil cartridge.
    And clean it inside.
    And installed the Baxter oil filter adapter.
    Followed by the spin-on Toyota filter.
    As you can see, there is plenty of space left between the filter and lower cross arms, remember the skid plate is below that. I have more that 3" gap between the oil filter can and skid plate.
    It took about 3 hours. Put back the skid plate, new oil and checked for problems under the beast. All OK.

  2. Dec 15, 2018 at 6:50 PM
    #2
    ColoradoTJ

    ColoradoTJ O’Keefe Music Foundation Moderator

    Joined:
    Sep 3, 2018
    Member:
    #265097
    Messages:
    3,947
    Gender:
    Male
    First Name:
    Chris
    Colorado
    A man that enjoys and cares for his truck.

    :thumbsup:

    Not going to run a Fumoto valve?

  3. Dec 15, 2018 at 7:03 PM
    #3
    Arrieta578

    Arrieta578 Well-Known Member

    Joined:
    Nov 28, 2018
    Member:
    #274098
    Messages:
    360
    Gender:
    Male
    Vehicle:
    2019 Tacoma DCSB OR Calvary Blue
    I’m liking that! Imagine... a REAL oil filter!

  4. Dec 15, 2018 at 7:07 PM
    #4
    Lt. Dangle

    Lt. Dangle RIP @stun gun 2016-2020

    Joined:
    Jan 25, 2017
    Member:
    #208645
    Messages:
    3,859
    Ohio
    Vehicle:
    2017 TRDOR
    stuff
    Why not drain the oil through the pan?

    Lol, nvm. I missed the text between the pictures.

  5. Dec 15, 2018 at 7:27 PM
    #5
    Rob Daman

    Rob Daman The Taco Formerly Known as Hard Shell Taco

    Joined:
    Mar 3, 2017
    Member:
    #212255
    Messages:
    5,720
    First Name:
    Rob
    So Cal
    Vehicle:
    17 OR 6MT
    a lot
    pretty cool

    Cpngo likes this.
  6. Dec 15, 2018 at 7:31 PM
    #6
    02Duck

    02Duck manuals make it better

    Joined:
    Feb 18, 2013
    Member:
    #97842
    Messages:
    587
    Gender:
    Male
    Vehicle:
    2018 4WD TRD Off Road 6MT
    TRD Exhaust, Mobtown bolt on sliders and aluminum tailgate reinforcement, Reverse lights changed to yellow turn signals, LED pods added for reverse, ADD W1 oil catch can, Total Chaos bed reinforcement, rear diff breather to taillight mod, 12" combo led bars behind lower grill wired to high beams, Toyota led bed light kit, 400 watt anytime mod, SSO slimeline front bumper.
    Just in case you didn't know. The TRD skid plate has an access panel you can remove with a few allens to change the filter. One of the big benefits to it.

  7. Dec 15, 2018 at 7:38 PM
    #7
    BookieBob

    BookieBob Well-Known Member

    Joined:
    Feb 26, 2017
    Member:
    #211749
    Messages:
    1,586
    Gender:
    Male
    Racine,Wisconsin
    Vehicle:
    2017 blazing blue pearl Trd sport 4x4
  8. Dec 15, 2018 at 7:51 PM
    #8
    Arrieta578

    Arrieta578 Well-Known Member

    Joined:
    Nov 28, 2018
    Member:
    #274098
    Messages:
    360
    Gender:
    Male
    Vehicle:
    2019 Tacoma DCSB OR Calvary Blue
    So where’d ya get that Baxter thinga-ma-gigger?

  9. Dec 15, 2018 at 7:54 PM
    #9
    Dacon

    Dacon [OP] 2017 Tacoma TRD PRO Quikrete

    Joined:
    Dec 20, 2016
    Member:
    #205354
    Messages:
    2,946
    Gender:
    Male
    First Name:
    Danny
    Gilbert, Arizona.
    Vehicle:
    2017 TRD PRO DCSB. DOP 02.20.2017
    TRD PRO Cement 2017 TRD CAI and AFE Magnum Flow Dry Air Filter Camburg KINETIK Series Billet UCA Icon LCA skid plates Icon Coilover extended travel shocks with 700# springs Icon 2" rear shocks Icon RXT leaf springs full pack (new rims and tires soon)
    ***
    I know. Had to remove the skid plate to have enough room to remove the retaining clip and swing a torque wrench. From now on oil change through the access plate.

    rrt49, 02Duck and jwctaco like this.
  10. Dec 15, 2018 at 7:56 PM
    #10
    Dacon

    Dacon [OP] 2017 Tacoma TRD PRO Quikrete

    Joined:
    Dec 20, 2016
    Member:
    #205354
    Messages:
    2,946
    Gender:
    Male
    First Name:
    Danny
    Gilbert, Arizona.
    Vehicle:
    2017 TRD PRO DCSB. DOP 02.20.2017
    TRD PRO Cement 2017 TRD CAI and AFE Magnum Flow Dry Air Filter Camburg KINETIK Series Billet UCA Icon LCA skid plates Icon Coilover extended travel shocks with 700# springs Icon 2" rear shocks Icon RXT leaf springs full pack (new rims and tires soon)
    scottalot likes this.
  11. Dec 15, 2018 at 7:57 PM
    #11
    Itchyfeet

    Itchyfeet Well-Known Member

    Joined:
    Apr 1, 2016
    Member:
    #183054
    Messages:
    7,687
    The only thing that would concern me is more places to leak. I still have nightmares about Jeep 4.0 oil filter housing leaks.

  12. Dec 15, 2018 at 8:18 PM
    #12
    JmsWms

    JmsWms Well-Known Member

    Joined:
    Feb 4, 2018
    Member:
    #243470
    Messages:
    47
    Gender:
    Male
    First Name:
    Jim
    Tennessee
    Vehicle:
    2017 Inferno TRD Sport AC 4x4
    Now if Baxter would come up with a way to fit a transmission fluid dipstick that the dipstick engineers removed, we could change back all of the things they engineered to make more difficult for the consumer.

    TacoManOne, jetfishn, crtx and 12 others like this.
  13. Dec 15, 2018 at 8:19 PM
    #13
    SlappyMcSlapnuts

    SlappyMcSlapnuts Well-Known Member

    Joined:
    Dec 12, 2018
    Member:
    #275635
    Messages:
    112
    Gender:
    Male
    First Name:
    Don
    Vehicle:
    2019 turd
    Curb feelers
    Will this void my warranty

    SOSHeloPilot likes this.
  14. Dec 15, 2018 at 9:37 PM
    #14
    TSmoove

    TSmoove Well-Known Member

    Joined:
    Oct 3, 2017
    Member:
    #231890
    Messages:
    256
    Gender:
    Male
    First Name:
    Trevor
    Atlanta, GA
    Vehicle:
    2017 Tacoma SR5 DCSB
    5W-30 instead of 0W-20?

    BSFord, Axnjxn, ozpall and 6 others like this.
  15. Dec 15, 2018 at 9:43 PM
    #15
    Amanelot

    Amanelot Well-Known Member

    Joined:
    Jul 29, 2018
    Member:
    #260931
    Messages:
    1,713
    Gender:
    Male
    Texas
    Vehicle:
    2016 MGM TRD Sport DCSB
    I can't wait for more people to do this. I'm dying to know if reusable oil filters can be used with this setup.

  16. Dec 15, 2018 at 9:54 PM
    #16
    tdnick

    tdnick Go Vols!

    Joined:
    Apr 13, 2015
    Member:
    #153120
    Messages:
    881
    Gender:
    Male
    Alabamer
    Vehicle:
    2018 Cummins 4x4
    One is sitting in my garage right now with oil all over my brand new starter. Fixing to somehow get my impact on the T60. Shits pissing me off.

  17. Dec 15, 2018 at 9:59 PM
    #17
    the.sight.picture

    the.sight.picture Well-Known Member

    Joined:
    Jan 22, 2012
    Member:
    #71180
    Messages:
    6,584
    Gender:
    Male
    First Name:
    Nick
    Blue Ridge
    Vehicle:
    3rd Gen QS
    Check the build thread in SIG
    this is awesome op. Thanks for the write up. I wasn't even aware something like this existed. Cheers

  18. Dec 15, 2018 at 10:11 PM
    #18
    Rujack

    Rujack Stop Global Whining

    Joined:
    Aug 16, 2016
    Member:
    #194732
    Messages:
    2,407
    Gender:
    Male
    Vehicle:
    2016 Tacoma TRD Off Road 6 speed manual
    What’s benefit of this??

    Bridge4 and alexplb like this.
  19. Dec 16, 2018 at 4:50 AM
    #19
    SlappyMcSlapnuts

    SlappyMcSlapnuts Well-Known Member

    Joined:
    Dec 12, 2018
    Member:
    #275635
    Messages:
    112
    Gender:
    Male
    First Name:
    Don
    Vehicle:
    2019 turd
    Curb feelers
    Easier to change oil when the paper filter shit that toyota put on the truck isnt required

  20. Dec 16, 2018 at 5:15 AM
    #20
    Xena1

    Xena1 Well-Known Member

    Joined:
    Aug 30, 2017
    Member:
    #228556
    Messages:
    400
    Gender:
    Male
    First Name:
    Ron
    Vehicle:
    2017 Tacoma Access Cab
    Told you you would like it! I am using the WIX 51348 because it is shorter than the Toyota OEM filter. Was concerned about the distance to the skid plate but seems you still have enough room. Going on my 4th oil change soon and will also switch to the Amsoil 5-30 next time.
