LED Fogs

Discussion in '3rd Gen. Tacomas (2016+)' started by wingfiry, Feb 8, 2017.

  1. Feb 8, 2017 at 6:19 AM
    #1
    wingfiry

    wingfiry [OP] Well-Known Member

    Joined:
    Sep 14, 2015
    Member:
    #164235
    Messages:
    108
    Gender:
    Male
    Atlanta
    Vehicle:
    2016 TRD Sport 4x4 AC MT White
    I swapped out my factory fogs for some Morimoto LED Fogs from The Retrofit Source. Insanely simple and quick install.. (it took about 40 minutes total) and since I'm a bit old-school when it comes to fogs, I also got the yellow film to go over the fogs because yellow light actually cuts through the fog.

    I had my first chance to really try them out last night here in Atlanta as it was really foggy. I turned them on and the fog... vanished. I couldn't be happier with the results. I highly recommend these LED fogs.

  2. Feb 8, 2017 at 6:35 AM
    #2
    goose443

    goose443 Well-Known Member

    Joined:
    Jun 8, 2016
    Member:
    #189076
    Messages:
    730
    Gender:
    Male
    First Name:
    Austin
    Texas
    Vehicle:
    2016 Tacoma TRD Off Road 4x4
    Did you do just LED bulbs or did you do the complete assembly? Thank you

  3. Feb 8, 2017 at 6:57 AM
    #3
    freeriderchad108

    freeriderchad108 Well-Known Member

    Joined:
    Mar 4, 2016
    Member:
    #180200
    Messages:
    466
    Gender:
    Male
    Boston
    Vehicle:
    2016 Tacoma TRD Sport Silver
    A few minor things...
    wingfiry [OP] likes this.
  4. Feb 8, 2017 at 7:07 AM
    #4
    TRDOBSESSED

    TRDOBSESSED Well-Known Member

    Joined:
    Oct 7, 2016
    Member:
    #199198
    Messages:
    570
    Gender:
    Male
    First Name:
    Blair
    Puyallup, Wa.
    Vehicle:
    2017 TRD ORAC
    OvTuned
    i installed the kit a couple weeks ago...they are awesome.

  5. Feb 8, 2017 at 7:11 AM
    #5
    wingfiry

    wingfiry [OP] Well-Known Member

    Joined:
    Sep 14, 2015
    Member:
    #164235
    Messages:
    108
    Gender:
    Male
    Atlanta
    Vehicle:
    2016 TRD Sport 4x4 AC MT White
  6. Feb 8, 2017 at 7:13 AM
    #6
    goose443

    goose443 Well-Known Member

    Joined:
    Jun 8, 2016
    Member:
    #189076
    Messages:
    730
    Gender:
    Male
    First Name:
    Austin
    Texas
    Vehicle:
    2016 Tacoma TRD Off Road 4x4
    Awesome thanks for the response! I was looking at these... I'm just not sure if I want to spend $170

  7. Feb 8, 2017 at 7:26 AM
    #7
    wingfiry

    wingfiry [OP] Well-Known Member

    Joined:
    Sep 14, 2015
    Member:
    #164235
    Messages:
    108
    Gender:
    Male
    Atlanta
    Vehicle:
    2016 TRD Sport 4x4 AC MT White
    There's a Tacoma World discount code on here somewhere.. ("TacomaWorld" I think) I think it knocked them down to $145. Not sure if the code still works, but worth a try!

  8. Feb 8, 2017 at 7:38 AM
    #8
    Scruffie

    Scruffie Well-Known Member

    Joined:
    Oct 30, 2015
    Member:
    #168154
    Messages:
    255
    Gender:
    Male
    First Name:
    Arsie
    Surrey B.C Canada
    Vehicle:
    2016 QuickSand Access TRD OR Manual
    265/75/16Dura,SSO Hybrid,X20,CruisinSliders,Skids
  9. Feb 8, 2017 at 7:39 AM
    #9
    Nwemerys

    Nwemerys Active Member

    Joined:
    Jan 28, 2017
    Member:
    #208892
    Messages:
    39
    Gender:
    Male
    Was thinking Rigid but I like the round better. Not sure how to remove the current lights...is it easy? Also, is there any room for adjustment of these once installed?

    Thanks.

  10. Feb 8, 2017 at 7:42 AM
    #10
    wingfiry

    wingfiry [OP] Well-Known Member

    Joined:
    Sep 14, 2015
    Member:
    #164235
    Messages:
    108
    Gender:
    Male
    Atlanta
    Vehicle:
    2016 TRD Sport 4x4 AC MT White
    It's *very* easy. one screw and the whole unit tilts out. Installation is the reverse... slide the tabs in one one side and secure the other side with the screw. Adjustment is a screw for up and down. All you'll need is a #2 phillips.

  11. Feb 8, 2017 at 7:45 AM
    #11
    Nwemerys

    Nwemerys Active Member

    Joined:
    Jan 28, 2017
    Member:
    #208892
    Messages:
    39
    Gender:
    Male
    2017 OR...I assume you go in via the wheel well, or is there a way to attack this from under/overhead? Thanks.

  12. Feb 8, 2017 at 7:52 AM
    #12
    Scruffie

    Scruffie Well-Known Member

    Joined:
    Oct 30, 2015
    Member:
    #168154
    Messages:
    255
    Gender:
    Male
    First Name:
    Arsie
    Surrey B.C Canada
    Vehicle:
    2016 QuickSand Access TRD OR Manual
    265/75/16Dura,SSO Hybrid,X20,CruisinSliders,Skids
    I put some painters masking tape on my garage door where my low beams and fogs were hitting prior to changing them out. Spray paint on the ground where my tires sit in order to replicate in future if needed. Made it very easy to adjust my Moromito's XB's as they were quite a bit out. No adjustment was needed when I installed my Xenon HID's as they were right on the money. Excellent one two punch with these lights.

  13. Feb 8, 2017 at 7:55 AM
    #13
    Scruffie

    Scruffie Well-Known Member

    Joined:
    Oct 30, 2015
    Member:
    #168154
    Messages:
    255
    Gender:
    Male
    First Name:
    Arsie
    Surrey B.C Canada
    Vehicle:
    2016 QuickSand Access TRD OR Manual
    265/75/16Dura,SSO Hybrid,X20,CruisinSliders,Skids
    For the ease and the little time it takes, pull the grill and the plastic little side flaps for the easiest install. I tried taking part of the inner fender well off and going in that way but it was just to much of a pain in the ass for my fat short liitle arms.

  14. Feb 8, 2017 at 8:00 AM
    #14
    wingfiry

    wingfiry [OP] Well-Known Member

    Joined:
    Sep 14, 2015
    Member:
    #164235
    Messages:
    108
    Gender:
    Male
    Atlanta
    Vehicle:
    2016 TRD Sport 4x4 AC MT White
    I went in from overhead. pop the hood and reach down behind the headlights. There's enough room to easily work. You might want to use a stubby screwdriver for the removal/install.

  15. Feb 8, 2017 at 8:01 AM
    #15
    Fire Arrow

    Fire Arrow Hanging out at work

    Joined:
    May 1, 2016
    Member:
    #185861
    Messages:
    805
    Gender:
    Male
    First Name:
    Jim
    MD
    Vehicle:
    2016 Black DCSB SR
    I just installed the Rigid D2 fogs yesterday. I was able to do everything by reaching down through the holes in the radiator support frame.

  16. Feb 8, 2017 at 8:03 AM
    #16
    Aw9d

    Aw9d That one guy

    Joined:
    Nov 7, 2011
    Member:
    #66635
    Messages:
    18,587
    Gender:
    Male
    Az
  17. Feb 8, 2017 at 8:34 AM
    #17
    Nwemerys

    Nwemerys Active Member

    Joined:
    Jan 28, 2017
    Member:
    #208892
    Messages:
    39
    Gender:
    Male
    Great, thanks. I have a TRD Pro grill on the way so 2 birds with 1 stone.

  18. Feb 8, 2017 at 5:58 PM
    #18
    TVirus916

    TVirus916 Active Member

    Joined:
    Dec 14, 2016
    Member:
    #204855
    Messages:
    31
    Gender:
    Male
    Vehicle:
    2017 TRD OR DCLB 4x4 BBP
    I agree, in a good way. I would like to see OP's DIY pics.

    Aw9d likes this.
  19. Feb 8, 2017 at 6:08 PM
    #19
    stun gun

    stun gun Well-Known Member

    Joined:
    Nov 18, 2016
    Member:
    #202729
    Messages:
    14,129
    Gender:
    Male
    First Name:
    Aaronski
    Vehicle:
    Tacomas.
    17 4X4 sr5spd/01 LT sr5spd

    EB Group and gr0ver like this.
  20. Feb 9, 2017 at 6:59 AM
    #20
    wingfiry

    wingfiry [OP] Well-Known Member

    Joined:
    Sep 14, 2015
    Member:
    #164235
    Messages:
    108
    Gender:
    Male
    Atlanta
    Vehicle:
    2016 TRD Sport 4x4 AC MT White
    I didn't take pics during the install, but I can take some pics of the finished product over lunch..
