Leveling kit vibration

Discussion in 'Suspension' started by Jeremy2046, Dec 25, 2018.

  1. Dec 25, 2018 at 12:22 PM
    #1
    Jeremy2046

    Jeremy2046 [OP] Member

    Joined:
    Dec 10, 2018
    Member:
    #275416
    Messages:
    16
    Gender:
    Male
    First Name:
    Jeremy
    Vehicle:
    18 tacoma sport
    None
    so just finished my install on a leveling kit 2018 TRD sport 3 inch front 2 rear, haven't done alignment yet waiting for tires to come in but have a pretty good what seems to be driveline vibration. What do you guys usually run into with the leveling kits? Shim rear blocks to an angle? Front diff drop? Thanks!


  2. Dec 27, 2018 at 12:05 AM
    #2
    JDE

    JDE Active Member

    Joined:
    Dec 15, 2015
    Member:
    #172296
    Messages:
    40
    Gender:
    Male
    First Name:
    Jacob
    Vehicle:
    2014 Silver Tacoma TRD Sport
    Camburg Kinetic UCAs King Extended Travel OEM Coilovers w/ RR Deaver J66 Leaf Springs King OEM Rear Shocks 16" Double Standard Method Wheels 33" BFG KO2 Tires
    So you're saying after you installed the leveling kit the truck now vibrates?

  3. Dec 27, 2018 at 12:14 AM
    #3
    Comatose

    Comatose You snuff it, we stuff it.

    Joined:
    Jun 13, 2014
    Member:
    #131870
    Messages:
    8,476
    Gender:
    Male
    First Name:
    Miguel
    Chincoteague, VA
    Vehicle:
    2008 TRD OR Indy Ink
    Missing Critical Hardware Edition
    Whole truck or the steering wheel?

    JDE likes this.
  4. Dec 27, 2018 at 12:16 AM
    #4
    JDE

    JDE Active Member

    Joined:
    Dec 15, 2015
    Member:
    #172296
    Messages:
    40
    Gender:
    Male
    First Name:
    Jacob
    Vehicle:
    2014 Silver Tacoma TRD Sport
    Camburg Kinetic UCAs King Extended Travel OEM Coilovers w/ RR Deaver J66 Leaf Springs King OEM Rear Shocks 16" Double Standard Method Wheels 33" BFG KO2 Tires
    That was going to be my follow up question :D

  5. Dec 27, 2018 at 1:31 AM
    #5
    Tacoknife

    Tacoknife Well-Known Member

    Joined:
    Nov 15, 2018
    Member:
    #272763
    Messages:
    102
    Gender:
    Male
    First Name:
    Stephen
    WV
    Vehicle:
    2018 Tacoma Sport 4DLB 4x4
    DBcustomzfab Grill
    Check and see if the rear blocks are installed correctly. The blocks possibly could already be shimmed, make sure there not installed facing the wrong way!! If the blocks are installed correctly rule of thumb is 1*deg. Of shim per 1” of lift !! Get Your Alingment Done ASAP!! If the truck vibrates in the front after Alingment put the truck in 4hi and if the vibration goes away while in 4hi it’s your needle bearing on the drivers side causing the vibration!! You will need the east coast gear supply bushing. Ecgs bushing!! This will possibly fix your vibration in the front!! Hope this helps

    DIRTT_Fish likes this.
  6. Dec 27, 2018 at 9:28 AM
    #6
    Jeremy2046

    Jeremy2046 [OP] Member

    Joined:
    Dec 10, 2018
    Member:
    #275416
    Messages:
    16
    Gender:
    Male
    First Name:
    Jeremy
    Vehicle:
    18 tacoma sport
    None
    Yes after the install.

  7. Dec 27, 2018 at 9:31 AM
    #7
    Jeremy2046

    Jeremy2046 [OP] Member

    Joined:
    Dec 10, 2018
    Member:
    #275416
    Messages:
    16
    Gender:
    Male
    First Name:
    Jeremy
    Vehicle:
    18 tacoma sport
    None

    I will double check to see if the blocks are installed correctly, I did look to see if there was any angle or one side higher than the other and I didn't see any difference, possible I didn't look close enough though. I should be getting alignment done today, I was waiting on my tires to come in but I haven't driven the truck more than a few streets since then. And yeah it's hard to say if it's a vibration or more of a "shimmy" feel I know that's weird but that's best way to describe it. I'll keep you guys posted. Fingers crossed it's alignment or something I overlooked

  8. Dec 27, 2018 at 9:33 AM
    #8
    Jeremy2046

    Jeremy2046 [OP] Member

    Joined:
    Dec 10, 2018
    Member:
    #275416
    Messages:
    16
    Gender:
    Male
    First Name:
    Jeremy
    Vehicle:
    18 tacoma sport
    None

    Here is a link to the kit I put in

    3"F+2"R Tacoma Leveling Lift Kit, KSP 3" Front and 2" Rear Leveling Strut Spacers For Toyota Tacoma 2WD/4WD 2005-2017, 1 Year Warranty https://www.amazon.com/dp/B077M9S5Y4/ref=cm_sw_r_cp_api_i_IYqjCbTMJGHYM

  9. Dec 27, 2018 at 9:39 AM
    #9
    fatdad2013

    fatdad2013 Active Member

    Joined:
    Feb 11, 2018
    Member:
    #244126
    Messages:
    28
    Gender:
    Male
    First Name:
    Ian
    Vehicle:
    white 2014 toyota tacom trd off road
    3 degree shims for the rear leaf pack and or a carrier bearing drop kit for you drive line will help as well. With lift comes more problems that need to be addressed at the time of installation. Good luck hope one of these fixes your vibration problem.

  10. Dec 27, 2018 at 9:40 AM
    #10
    Jeremy2046

    Jeremy2046 [OP] Member

    Joined:
    Dec 10, 2018
    Member:
    #275416
    Messages:
    16
    Gender:
    Male
    First Name:
    Jeremy
    Vehicle:
    18 tacoma sport
    None

    Crap. Just saw that these are supposedly tapered. So if so is the high side go towards rear or front?

  11. Dec 27, 2018 at 10:52 AM
    #11
    Comatose

    Comatose You snuff it, we stuff it.

    Joined:
    Jun 13, 2014
    Member:
    #131870
    Messages:
    8,476
    Gender:
    Male
    First Name:
    Miguel
    Chincoteague, VA
    Vehicle:
    2008 TRD OR Indy Ink
    Missing Critical Hardware Edition
    Rear, to decrease your pinion angle.

  12. Dec 27, 2018 at 11:02 AM
    #12
    Jonpauldv

    Jonpauldv Taco Off Road

    Joined:
    Oct 16, 2018
    Member:
    #269640
    Messages:
    18
    Gender:
    Male
    First Name:
    Jon
    South West Florida
    Vehicle:
    2019 Tacoma Off Road
    Did you get the problem fixed, or does it still shake?

  13. Dec 27, 2018 at 11:11 AM
    #13
    Jeremy2046

    Jeremy2046 [OP] Member

    Joined:
    Dec 10, 2018
    Member:
    #275416
    Messages:
    16
    Gender:
    Male
    First Name:
    Jeremy
    Vehicle:
    18 tacoma sport
    None
    I'll be surprised if they really are tapered despite the seller says they are, seems like it would have been pretty easy to see by pictures I'm looking at of what 3 degrees would look like

  14. Dec 27, 2018 at 12:58 PM
    #14
    Tacoknife

    Tacoknife Well-Known Member

    Joined:
    Nov 15, 2018
    Member:
    #272763
    Messages:
    102
    Gender:
    Male
    First Name:
    Stephen
    WV
    Vehicle:
    2018 Tacoma Sport 4DLB 4x4
    DBcustomzfab Grill
    Rear bud

  15. Dec 27, 2018 at 2:21 PM
    #15
    Jeremy2046

    Jeremy2046 [OP] Member

    Joined:
    Dec 10, 2018
    Member:
    #275416
    Messages:
    16
    Gender:
    Male
    First Name:
    Jeremy
    Vehicle:
    18 tacoma sport
    None
    Hey guys appreciate all the help, blocks were BACKWARDS didn't realize they had a taper in in em. Shimmy shimmy is gone however will say there feels.like there's still something there. Alignment scheduled for Saturday and IL be putting in diff drop kit tomorrow. Hopefully that will take care of everything

    Tacoknife likes this.
  16. Dec 27, 2018 at 6:21 PM
    #16
    Jonpauldv

    Jonpauldv Taco Off Road

    Joined:
    Oct 16, 2018
    Member:
    #269640
    Messages:
    18
    Gender:
    Male
    First Name:
    Jon
    South West Florida
    Vehicle:
    2019 Tacoma Off Road
    Where did you get the diff drop?

  17. Dec 27, 2018 at 6:59 PM
    #17
    Jeremy2046

    Jeremy2046 [OP] Member

    Joined:
    Dec 10, 2018
    Member:
    #275416
    Messages:
    16
    Gender:
    Male
    First Name:
    Jeremy
    Vehicle:
    18 tacoma sport
    None
  18. Jan 1, 2019 at 7:30 AM
    #18
    My White Tacoma

    My White Tacoma Well-Known Member

    Joined:
    Aug 22, 2018
    Member:
    #263765
    Messages:
    66
    Gender:
    Male
    First Name:
    Andrew
    Springfield, mo
    Vehicle:
    2014 White Tacoma full cab, SR5, 4x4
    Not trying to thread jack, but it looks like the original poster had his question answer.
    I need axle shims for my vibration, I have EL096R-P OME/Dakar. I'm looking at the Toytec TT3DS shims, but it says it needs drilling to work with the Dakar's EL096. Do I need to drill out the leaf packs center hole for the new longer bolt?
    But it also says: "**NOTE- Use RS slotted shims for use with Toytec rear lift block kits or EL095/EL096 Dakar Springs."
    But I can't find "RS slotted shims" It's confusing. lol here's the link to Toytecs site. Thanks for any help.

    https://www.toyteclifts.com/tt3ds-solid-steel-axle-degree-shims.html

    Lumberjackcoma likes this.
  19. Jan 1, 2019 at 9:50 AM
    #19
    Jeremy2046

    Jeremy2046 [OP] Member

    Joined:
    Dec 10, 2018
    Member:
    #275416
    Messages:
    16
    Gender:
    Male
    First Name:
    Jeremy
    Vehicle:
    18 tacoma sport
    None

    Didn’t quite solve it all yet but it is better. I had my blocks in backwards the taper going the wrong way and it obviously improved. I habe since dropped the front diff and added some spacers at the carrier bearing and it's Def better but still needs some modifications. Rather frustrating. I'm thinking I may also need some shims for the back and maybe play with the carrier drop height. This truck is picky!

  20. Jan 1, 2019 at 3:27 PM
    #20
    My White Tacoma

    My White Tacoma Well-Known Member

    Joined:
    Aug 22, 2018
    Member:
    #263765
    Messages:
    66
    Gender:
    Male
    First Name:
    Andrew
    Springfield, mo
    Vehicle:
    2014 White Tacoma full cab, SR5, 4x4
