Lighting help, PLEASE HELP!!!!

Discussion in 'Lighting' started by Stillfly199, Mar 26, 2009.

  1. Mar 26, 2009 at 4:43 PM
    #1
    Stillfly199

    Stillfly199 [OP] ( . )( . )

    Joined:
    Feb 26, 2009
    Member:
    #14098
    Messages:
    5,004
    Gender:
    Male
    First Name:
    J.D.
    Bro Capital of the word
    Vehicle:
    2010 FJ Cruiser
    I'm trying to figure out where i'm supposed to push the wires through the firewall. It doesnt seem like the place I picked will fit. Can anyone give me some help???? Its an 07' Tacoma
    [​IMG]

  2. Mar 26, 2009 at 4:48 PM
    #2
    humanoid

    humanoid bite me

    Joined:
    Jun 27, 2007
    Member:
    #1932
    Messages:
    2,744
    Gender:
    Male
    Sunny SoCal
    Vehicle:
    I had a '99 Xtra Cab PreRunner SR5 V6
    If you're trying to hook up your HID kit, that harness is supposed to hook up to your OEM headlight harness, it's not supposed to go through the firewall.

  3. Mar 26, 2009 at 4:50 PM
    #3
    Stillfly199

    Stillfly199 [OP] ( . )( . )

    Joined:
    Feb 26, 2009
    Member:
    #14098
    Messages:
    5,004
    Gender:
    Male
    First Name:
    J.D.
    Bro Capital of the word
    Vehicle:
    2010 FJ Cruiser
    No, I am hooking up 4 KC lights from the bumper and I have to put them through the fire wall to the switch in the cab

  4. Mar 26, 2009 at 4:52 PM
    #4
    luk8272

    luk8272 Poodoo

    Joined:
    Feb 24, 2008
    Member:
    #4929
    Messages:
    5,879
    Gender:
    Male
    First Name:
    Lucas
    Kaplan, Louisiana
    Vehicle:
    07 Silver4dr. 4x4, V6 Shortbed
    5% Tint, Bug flector, vent Visors, Removed secondary air filter, Rear Spring TSB w/ Wheeler's Add A Leaf HD Pack, Icon 2.0 rear shocks, Toytec 3" lift up front with Total Chaos UCA's, Debadged, Billet Grille,TRD Offroad rims/17x9 Pro comp 6001 rims, Duratracs 265/75/16 or 285/70/17, Fog light anytime mod, Tailgate hose clamp mod, Pro-dry AFE filter. Extended Differential Breather, ABS on/off, 6000k LEDs from CSJumper, heads/fogs, ScanguageII, Devil horns, Devil horns on third brake light, Mounted 60" Highlift, Mounted Tool Box, Wet Okole Front/Rear Seat Covers, TW sticker, Midland Handheld CB,Painted engine cover, Revenge Fab Sliders, ARE Topper, Weather tech Floorliners.
    I ran some wires where the factory wiring goes throught the fire wall. Followed the balck wire with the blue thing on it.

  5. Mar 26, 2009 at 4:53 PM
    #5
    rhoppas

    rhoppas Land of Oz

    Joined:
    Aug 29, 2007
    Member:
    #2564
    Messages:
    1,301
    Gender:
    Male
    Topeka, KS
    Vehicle:
    07 Double Cab V6 TRD Sport Tow
    Earnhardt Cannons, Terra Grapplers, Viper alarm, Hunter4x4 Bull Bar, 6" Pro Comp Off-Road lights, extra set of bed D-rings, Chrome exhaust tip, Metra Ipod/MP3 adapter, Garmin GPS, CarriageWorks grill, Maglite mounted to driver seat, 9" Stubbie Antenna, WeatherTech floor liners, Saddleman Neoprene seat covers, DeeZee bed mat
    I have an 07 and I ran a couple wires through that spot. It wasn't easy but it worked. I used a straightened coat hanger to make it easier...

  6. Mar 26, 2009 at 4:53 PM
    #6
    Stillfly199

    Stillfly199 [OP] ( . )( . )

    Joined:
    Feb 26, 2009
    Member:
    #14098
    Messages:
    5,004
    Gender:
    Male
    First Name:
    J.D.
    Bro Capital of the word
    Vehicle:
    2010 FJ Cruiser
    Was it super tight? I tried that but cant get the clothes hanger in there

  7. Mar 26, 2009 at 4:57 PM
    #7
    rhoppas

    rhoppas Land of Oz

    Joined:
    Aug 29, 2007
    Member:
    #2564
    Messages:
    1,301
    Gender:
    Male
    Topeka, KS
    Vehicle:
    07 Double Cab V6 TRD Sport Tow
    Earnhardt Cannons, Terra Grapplers, Viper alarm, Hunter4x4 Bull Bar, 6" Pro Comp Off-Road lights, extra set of bed D-rings, Chrome exhaust tip, Metra Ipod/MP3 adapter, Garmin GPS, CarriageWorks grill, Maglite mounted to driver seat, 9" Stubbie Antenna, WeatherTech floor liners, Saddleman Neoprene seat covers, DeeZee bed mat
    It was tight. I used the coat hanger to poke a hole in the rubber. I have 2 lights on the front of my truck also...

  8. Mar 26, 2009 at 5:00 PM
    #8
    Stillfly199

    Stillfly199 [OP] ( . )( . )

    Joined:
    Feb 26, 2009
    Member:
    #14098
    Messages:
    5,004
    Gender:
    Male
    First Name:
    J.D.
    Bro Capital of the word
    Vehicle:
    2010 FJ Cruiser
    Ok, it is taped off like hell and doesnt seem like I will be able to get it through. There is the rubber seal that is taped off to all the wires. It seems like the only way is going to be to puncture the rubber seal, would that be a problem

  9. Mar 26, 2009 at 5:01 PM
    #9
    Stillfly199

    Stillfly199 [OP] ( . )( . )

    Joined:
    Feb 26, 2009
    Member:
    #14098
    Messages:
    5,004
    Gender:
    Male
    First Name:
    J.D.
    Bro Capital of the word
    Vehicle:
    2010 FJ Cruiser
    K, I think I'll have to poke a hole through the rubber. Looks like thats the only way.

  10. Mar 26, 2009 at 5:01 PM
    #10
    Ridingontrd

    Ridingontrd Well-Known Member

    Joined:
    May 7, 2008
    Member:
    #6459
    Messages:
    7,955
    Gender:
    Male
    First Name:
    Richard
    Laughlin,N.V
    Vehicle:
    trd sport 4x4 w/towpkg
    aFe prodry,Dynomax ultra flo ss,Scangauge2,Demello front bumper,BudBuilt skids,sliders(local)AllPro rear bumper,Wet O's cobalt blu,w/halfpiping,TRD logo in gold,R/L hood struts,5150's@10"aal 3 pack,T/C uca,Light racing c/o,1"diff.drop,de-badged,
    Same here.The "wires only" went through.

  11. Mar 26, 2009 at 5:05 PM
    #11
    rhoppas

    rhoppas Land of Oz

    Joined:
    Aug 29, 2007
    Member:
    #2564
    Messages:
    1,301
    Gender:
    Male
    Topeka, KS
    Vehicle:
    07 Double Cab V6 TRD Sport Tow
    Earnhardt Cannons, Terra Grapplers, Viper alarm, Hunter4x4 Bull Bar, 6" Pro Comp Off-Road lights, extra set of bed D-rings, Chrome exhaust tip, Metra Ipod/MP3 adapter, Garmin GPS, CarriageWorks grill, Maglite mounted to driver seat, 9" Stubbie Antenna, WeatherTech floor liners, Saddleman Neoprene seat covers, DeeZee bed mat
    A hole in the rubber is not a big deal. The rubber will seal around the wire once it is through there.

  12. Mar 26, 2009 at 5:06 PM
    #12
    headhunter247

    headhunter247 Well-Known Member

    Joined:
    Oct 16, 2008
    Member:
    #10013
    Messages:
    1,394
    Gender:
    Male
    St. Louis, MO area
    Vehicle:
    13 Taco Double Cab TRD
    Bilstein 5100's all around, front set at 2.5", Toytec AAL, 265/75/16 Duratracs, Pro Comp 5001, Weathertech's, AVS In Channel Visors, Nokya Hyper Yellow fogs, CB Set up, Color matched grill surround, ATC Camper Shell with Yakima Racks, SOS Concepts Regular Rear Bumper.
    Thats how I did it, poking a hole through the rubber. It has caused no problems.

  13. Mar 26, 2009 at 5:10 PM
    #13
    rhoppas

    rhoppas Land of Oz

    Joined:
    Aug 29, 2007
    Member:
    #2564
    Messages:
    1,301
    Gender:
    Male
    Topeka, KS
    Vehicle:
    07 Double Cab V6 TRD Sport Tow
    Earnhardt Cannons, Terra Grapplers, Viper alarm, Hunter4x4 Bull Bar, 6" Pro Comp Off-Road lights, extra set of bed D-rings, Chrome exhaust tip, Metra Ipod/MP3 adapter, Garmin GPS, CarriageWorks grill, Maglite mounted to driver seat, 9" Stubbie Antenna, WeatherTech floor liners, Saddleman Neoprene seat covers, DeeZee bed mat
    Hey stillfly...post some pics when you get it done...

  14. Mar 26, 2009 at 5:43 PM
    #14
    Stillfly199

    Stillfly199 [OP] ( . )( . )

    Joined:
    Feb 26, 2009
    Member:
    #14098
    Messages:
    5,004
    Gender:
    Male
    First Name:
    J.D.
    Bro Capital of the word
    Vehicle:
    2010 FJ Cruiser
    Wont be til tomorrow, I have to go to a EMT refresher class. That and I spent too much time trying to get it through the firewall. But I found a couple wires with connectors on the end that were behind the false switches
    [​IMG]
    Does anyone know what these are for?

  15. Mar 26, 2009 at 5:44 PM
    #15
    Stillfly199

    Stillfly199 [OP] ( . )( . )

    Joined:
    Feb 26, 2009
    Member:
    #14098
    Messages:
    5,004
    Gender:
    Male
    First Name:
    J.D.
    Bro Capital of the word
    Vehicle:
    2010 FJ Cruiser
    Also, its a 2007 trd sport 4x4

  16. Mar 26, 2009 at 5:47 PM
    #16
    HerNameIsLucy

    HerNameIsLucy I miss Lucy. :-(

    Joined:
    Jul 31, 2008
    Member:
    #8256
    Messages:
    3,042
    Gender:
    Male
    First Name:
    John
    Equador. Don't know why.
    Vehicle:
    RIP Lucy.
    She's gone but not forgotten.
    You could always run it under the cab and up through one of the rubber plugs there, comes up under the carpet under the seats. It's where I ran the switched line from the switch to the reverse lights relay in mine.

  17. Mar 26, 2009 at 9:49 PM
    #17
    Stillfly199

    Stillfly199 [OP] ( . )( . )

    Joined:
    Feb 26, 2009
    Member:
    #14098
    Messages:
    5,004
    Gender:
    Male
    First Name:
    J.D.
    Bro Capital of the word
    Vehicle:
    2010 FJ Cruiser
    I got one of them ran through the firewall, I gotta finish it up in the morning. I'll be sure to post some pics tomorrow night.

  18. Mar 27, 2009 at 6:43 AM
    #18
    rhoppas

    rhoppas Land of Oz

    Joined:
    Aug 29, 2007
    Member:
    #2564
    Messages:
    1,301
    Gender:
    Male
    Topeka, KS
    Vehicle:
    07 Double Cab V6 TRD Sport Tow
    Earnhardt Cannons, Terra Grapplers, Viper alarm, Hunter4x4 Bull Bar, 6" Pro Comp Off-Road lights, extra set of bed D-rings, Chrome exhaust tip, Metra Ipod/MP3 adapter, Garmin GPS, CarriageWorks grill, Maglite mounted to driver seat, 9" Stubbie Antenna, WeatherTech floor liners, Saddleman Neoprene seat covers, DeeZee bed mat
    The unused wires/connectors behind the switch covers are for options that we did not get on our trucks. They were on mine too. I just pushed them back into the dash. Good luck with your wiring today...

  19. Mar 27, 2009 at 8:19 AM
    #19
    Stillfly199

    Stillfly199 [OP] ( . )( . )

    Joined:
    Feb 26, 2009
    Member:
    #14098
    Messages:
    5,004
    Gender:
    Male
    First Name:
    J.D.
    Bro Capital of the word
    Vehicle:
    2010 FJ Cruiser
    Thats what I figured it was, thanks for the input. I'll post pics of it tonight when I get it wired and test the output

  20. Mar 27, 2009 at 1:02 PM
    #20
    jward2331

    jward2331 Well-Known Member

    Joined:
    Dec 5, 2008
    Member:
    #11313
    Messages:
    540
    Gender:
    Male
    First Name:
    John
    Fleming Island, Fl
    Vehicle:
    '08 PreRunner SR5 TRD Sport
    Debadged, tinted windows, upper/lower Grillcraft (horns relocated), Hella 500's with HID Mod (55W 5000) behind grill, shorty antenna, WeatherTech side window deflectors, suspension TSB, Westin Signature Nerf bars, JVC KD A-615 Head Unit with Sirius Direct tuner, Blacked out headlights, DTDL Mod (Switch for on/off), Hard Wired GPS, NOKYA Arctic Hyper Yellow Fog lights, Fog lights on anytime Mod, Michelin LTX M/S2 (P265/65R17), Powder coated OEM wheels. LED ANZO tail lights, Weather Tech FloorLiners.
    I ran my wires last week and discovered the best way to get them through the firewall. Look at about 8 o'clock outside the "boot" area (near the outter edge) where the factory wires are. You'll notice what looks like rubber glove finger (about 3/8" wide). If you cut the end off near the tip, you'll have free access to the inside of your cab. If you look from the inside of the cab at the 5 o'clock area, you'll see a small hole where the wires come through. My wife has the camera. If you need a few pics, let me know. I'll take some tonight or tomorrow. We're going to get rained on here soon, front is almost on us (the one that hit Miss the other day).
    Once done, seal the end off and your home free.

    I just looked back at your picture and saw it looks slightly different (where the black tube goes in) and also saw you have a '07. Mine is an '08.
