Maxtrac Spindle Lift for 2nd Gen Prerunners

Discussion in 'Suspension' started by markmatters, Feb 11, 2012.

Page 639 of 688
  1. Feb 28, 2019 at 2:06 PM
    #12761
    ChadsPride

    #12761
    ChadsPride Tacoma Owner & Enthusiast

    Joined:
    Nov 26, 2014
    Member:
    #143119
    Messages:
    127,315
    Vehicle:
    Sponsored by TacomaWorld.com
    Never taken the sway bar off

    ChadsPride, Feb 28, 2019
    #12761
  2. Feb 28, 2019 at 2:19 PM
    #12762
    K-DubTaco

    #12762
    K-DubTaco Well-Known Member

    Joined:
    Nov 18, 2018
    Member:
    #273060
    Messages:
    485
    Gender:
    Male
    First Name:
    Ken
    VB
    Vehicle:
    '10 Silver Prerunner & '98 4x4 ext. cab
    Same here. It’s driving me nuts.

    K-DubTaco, Feb 28, 2019
    #12762
    ChadsPride likes this.
  3. Feb 28, 2019 at 6:41 PM
    #12763
    K-DubTaco

    #12763
    K-DubTaco Well-Known Member

    Joined:
    Nov 18, 2018
    Member:
    #273060
    Messages:
    485
    Gender:
    Male
    First Name:
    Ken
    VB
    Vehicle:
    '10 Silver Prerunner & '98 4x4 ext. cab
    Well I took the sway bar completely off and the clunk was still there. I put it all back together and it didn’t make the clunk until a turned the wheels to the left to back into the driveway.

    K-DubTaco, Feb 28, 2019
    #12763
    ChadsPride likes this.
  4. Feb 28, 2019 at 7:30 PM
    #12764
    Thesandaddict

    #12764
    Thesandaddict The dude

    Joined:
    Mar 22, 2016
    Member:
    #182067
    Messages:
    2,773
    Gender:
    Male
    First Name:
    Harley
    West Covina, CA
    Vehicle:
    2010 tundra bro-dozer
    Stock uca?

    Thesandaddict, Feb 28, 2019
    #12764
    ChadsPride likes this.
  5. Feb 28, 2019 at 7:30 PM
    #12765
    Johnnyk33

    #12765
    Johnnyk33 Active Member

    Joined:
    Mar 7, 2018
    Member:
    #246570
    Messages:
    27
    Gender:
    Male
    Orange County, CA
    Vehicle:
    2013 TRD Sport DCLB
    Front: 5100s at 0 Toytec 521600 2.5" Coils Camburg 4" Lift Spindles Light Racing UCAs Rear: Extended Travel 5100s OME Dakar HD Leaf Packs Wheels/Tires: XD Grenade 17x9 -12mm Offset 4.5 BS 285/70/17 KO2s Other: Cab Mount Chop Front and Rear Extended Brake Lines Wheelers U Bolt Flip Kit Wheelers Superbump Stops Front and Rear 4.56 Nitro Gears
    I had a clunking sound a few months after installing my camburg spindles. Found out the 2 bolts on the bottom of the spindle that connect to the ball joint/LCA had come loose. After tightening them back to spec the clunking went away

    Johnnyk33, Feb 28, 2019
    #12765
    ChadsPride likes this.
  6. Feb 28, 2019 at 9:08 PM
    #12766
    08BajaBoy

    #12766
    08BajaBoy Well-Known Member

    Joined:
    Oct 3, 2010
    Member:
    #44164
    Messages:
    444
    Gender:
    Male
    First Name:
    Brian
    Southern Cal
    Vehicle:
    08 Rugged Trail PreRunner
    AFE Pro Dry S air filter, Magnaflow muffler, FabTech DirtLogic UCA, FabTech 2.5 remote resi (front) and 2.25 remote resi (rear)
    @NOLAtaco26 is your brake line free to move? How do you have it routed? If you didn't strap it down to the spindle it's probably the brake line hitting the frame or the bump stop mount. You probably here it with a slow rolling left hand turn

    08BajaBoy, Feb 28, 2019
    #12766
  7. Mar 1, 2019 at 4:08 AM
    #12767
    K-DubTaco

    #12767
    K-DubTaco Well-Known Member

    Joined:
    Nov 18, 2018
    Member:
    #273060
    Messages:
    485
    Gender:
    Male
    First Name:
    Ken
    VB
    Vehicle:
    '10 Silver Prerunner & '98 4x4 ext. cab
    Any idea of the torque spec on those bolts? Mine came with no instructions, so I’m flying by the seat of my pants.

    K-DubTaco, Mar 1, 2019
    #12767
  8. Mar 1, 2019 at 4:10 AM
    #12768
    K-DubTaco

    #12768
    K-DubTaco Well-Known Member

    Joined:
    Nov 18, 2018
    Member:
    #273060
    Messages:
    485
    Gender:
    Male
    First Name:
    Ken
    VB
    Vehicle:
    '10 Silver Prerunner & '98 4x4 ext. cab
    Yes, it’s free to move. It feels like something is loose, but I can’t feel anything loose when I check stuff.

    K-DubTaco, Mar 1, 2019
    #12768
  9. Mar 1, 2019 at 4:12 AM
    #12769
    K-DubTaco

    #12769
    K-DubTaco Well-Known Member

    Joined:
    Nov 18, 2018
    Member:
    #273060
    Messages:
    485
    Gender:
    Male
    First Name:
    Ken
    VB
    Vehicle:
    '10 Silver Prerunner & '98 4x4 ext. cab
    Yes, they are stock. Can’t you run stock ones with a spindle lift since the geometry stays the same? Could it be the bushings on the stock one? I had to replace the inner tie rod afterwards because it was worn out. It just flopped when the outer wasn’t connected.

    K-DubTaco, Mar 1, 2019
    #12769
  10. Mar 1, 2019 at 4:15 AM
    #12770
    BassAckwards

    #12770
    BassAckwards Well-Known Member

    Joined:
    May 3, 2016
    Member:
    #186002
    Messages:
    27,658
    Vehicle:
    AWD Turbo 2TR-FE
    How common is this front end clunking that people are describing with these spindles? :spy:

    BassAckwards, Mar 1, 2019
    #12770
  11. Mar 1, 2019 at 4:24 AM
    #12771
    ChadsPride

    #12771
    ChadsPride Tacoma Owner & Enthusiast

    Joined:
    Nov 26, 2014
    Member:
    #143119
    Messages:
    127,315
    Vehicle:
    Sponsored by TacomaWorld.com
    Depends who's askin :D

    ChadsPride, Mar 1, 2019
    #12771
    BassAckwards[QUOTED] likes this.
  12. Mar 1, 2019 at 4:32 AM
    #12772
    BassAckwards

    #12772
    BassAckwards Well-Known Member

    Joined:
    May 3, 2016
    Member:
    #186002
    Messages:
    27,658
    Vehicle:
    AWD Turbo 2TR-FE
    Lol, i take it it's more common than not? :laugh:

    BassAckwards, Mar 1, 2019
    #12772
    ChadsPride[QUOTED] likes this.
  13. Mar 1, 2019 at 4:33 AM
    #12773
    toyodajeff

    #12773
    toyodajeff Well-Known Member

    Joined:
    Nov 11, 2009
    Member:
    #25817
    Messages:
    2,500
    Gender:
    Male
    First Name:
    jeff
    Vehicle:
    06 reg cab sr5
    Mine clunked some. I think it was the sway bar link hitting the brake line bracket.

    toyodajeff, Mar 1, 2019
    #12773
    ChadsPride likes this.
  14. Mar 1, 2019 at 4:34 AM
    #12774
    ChadsPride

    #12774
    ChadsPride Tacoma Owner & Enthusiast

    Joined:
    Nov 26, 2014
    Member:
    #143119
    Messages:
    127,315
    Vehicle:
    Sponsored by TacomaWorld.com
    Lol, just playin. Not really too sure to be honest.

    ChadsPride, Mar 1, 2019
    #12774
    BassAckwards[QUOTED] likes this.
  15. Mar 1, 2019 at 6:03 AM
    #12775
    Thesandaddict

    #12775
    Thesandaddict The dude

    Joined:
    Mar 22, 2016
    Member:
    #182067
    Messages:
    2,773
    Gender:
    Male
    First Name:
    Harley
    West Covina, CA
    Vehicle:
    2010 tundra bro-dozer
    Yea que just curious. When I did mine I did uca. You already checked sway bar, stock uca, not the brakelines loose? Make sure the end links are torque properly is my next guess. Just double check em

    Thesandaddict, Mar 1, 2019
    #12775
    K-DubTaco[QUOTED] likes this.
  16. Mar 1, 2019 at 6:35 AM
    #12776
    K-DubTaco

    #12776
    K-DubTaco Well-Known Member

    Joined:
    Nov 18, 2018
    Member:
    #273060
    Messages:
    485
    Gender:
    Male
    First Name:
    Ken
    VB
    Vehicle:
    '10 Silver Prerunner & '98 4x4 ext. cab
    I’ll double check those things tonight. Thanks man!

    K-DubTaco, Mar 1, 2019
    #12776
    Thesandaddict[QUOTED] likes this.
  17. Mar 1, 2019 at 9:33 AM
    #12777
    Jimmy92870

    #12777
    Jimmy92870 Well-Known Member

    Joined:
    Apr 2, 2018
    Member:
    #249239
    Messages:
    779
    Gender:
    Male
    Texas (DFW)
    Vehicle:
    07 DCSB PreRunner
    Re-torque everything just to make sure nothing is slightly loose.

    Jimmy92870, Mar 1, 2019
    #12777
    K-DubTaco[QUOTED] and christian06 like this.
  18. Mar 1, 2019 at 11:16 AM
    #12778
    NOLAtaco26

    #12778
    NOLAtaco26 Well-Known Member

    Joined:
    Nov 17, 2015
    Member:
    #169901
    Messages:
    302
    Gender:
    Male
    First Name:
    Blake
    New Orleans,Louisiana
    Vehicle:
    2013 Double Cab Prerunner 2.7
    Rerouted brake lines per instructions. Did some trimming on the brake line bracket for extra clearance. Have been under truck while someone turns the wheel. No binding or rubbing visible. I have a buddy with an F150 with the Maxtrac spindles. He has the same sound. When he contacted Maxtrac they told him that there were no other reports of the issue and something had to be installed wrong.

    NOLAtaco26, Mar 1, 2019
    #12778
  19. Mar 1, 2019 at 5:38 PM
    #12779
    K-DubTaco

    #12779
    K-DubTaco Well-Known Member

    Joined:
    Nov 18, 2018
    Member:
    #273060
    Messages:
    485
    Gender:
    Male
    First Name:
    Ken
    VB
    Vehicle:
    '10 Silver Prerunner & '98 4x4 ext. cab
    Checked the steer stop bolts like you said and torqued them to 112lbs. THE CLUNKING IS GONE! Thanks so much for chiming in!!

    Last edited: Mar 1, 2019
    K-DubTaco, Mar 1, 2019
    #12779
    Johnnyk33[QUOTED], ChadsPride and dumontrider like this.
  20. Mar 2, 2019 at 3:10 PM
    #12780
    NOLAtaco26

    #12780
    NOLAtaco26 Well-Known Member

    Joined:
    Nov 17, 2015
    Member:
    #169901
    Messages:
    302
    Gender:
    Male
    First Name:
    Blake
    New Orleans,Louisiana
    Vehicle:
    2013 Double Cab Prerunner 2.7
    Figured I would give it a shot. Set my trusty Harbor Freight torque wrench at 118 ft/lbs. From what the diagram I found on here said. Wrenched down on all 4 bolts and no clunking for now.

    NOLAtaco26, Mar 2, 2019
    #12780
    K-DubTaco[QUOTED] and christian06 like this.
