Need help installing GMRS radio

Discussion in '2nd Gen. Tacomas (2005-2015)' started by ReeceRiley, Jun 18, 2020.

  1. Jun 18, 2020 at 9:51 AM
    #1
    ReeceRiley

    ReeceRiley [OP] Active Member

    Joined:
    Nov 30, 2019
    Member:
    #312085
    Messages:
    43
    Gender:
    Male
    First Name:
    Reece
    Des Moines iowa
    Vehicle:
    Tacoma in-line 4, 2 door, 5 speed
    I’ve got a 2008 regular cab manual sr5 and I want to install a GMRS radio. I want to the radio to the battery but have it turn off when I shut the truck off, could someone tell me where to run the wires to the engine bay and where to attach the wires to so that the radio shuts off when the car shuts off

  2. Jun 18, 2020 at 9:54 AM
    #2
    SnowroxKT

    SnowroxKT Well-Known Member

    Joined:
    Dec 11, 2011
    Member:
    #68604
    Messages:
    5,288
    Gender:
    Male
    First Name:
    Kyle
    Anchorage Alaska
    Vehicle:
    '18 T4R & '94 FZJ80
    Triple locked and 35s
  3. Jun 18, 2020 at 9:58 AM
    #3
    ReeceRiley

    ReeceRiley [OP] Active Member

    Joined:
    Nov 30, 2019
    Member:
    #312085
    Messages:
    43
    Gender:
    Male
    First Name:
    Reece
    Des Moines iowa
    Vehicle:
    Tacoma in-line 4, 2 door, 5 speed
  4. Jun 18, 2020 at 10:02 AM
    #4
    ReeceRiley

    ReeceRiley [OP] Active Member

    Joined:
    Nov 30, 2019
    Member:
    #312085
    Messages:
    43
    Gender:
    Male
    First Name:
    Reece
    Des Moines iowa
    Vehicle:
    Tacoma in-line 4, 2 door, 5 speed
    What is an add a circuit

  5. Jun 18, 2020 at 11:13 AM
    #5
    Sig45

    Sig45 Well-Known Member

    Joined:
    Jun 21, 2012
    Member:
    #81045
    Messages:
    14,534
    Gender:
    Male
    First Name:
    Mark
    Maine
    Vehicle:
    2011 TRD OFF-ROAD DCSB 4X4
    AVS in-channel window visors Husky Mud Guards Husky Liners X-act Contour Floor Liners Cooper Discoverer AT3 LT- 265/75/16 C Toyota 16" Black TRD Trail Team Edition Wheels Truxedo Lo Pro Tonneau Cover OEM Bed mat OEM Running Boards Marathon custom fit seat covers Front window tint Rear Leaf Spring 4 Pack - TSB Front - 5100's with stock springs set at .85" Rear - OME Sport Nitrochargers
    [​IMG]

  6. Jun 18, 2020 at 11:17 AM
    #6
    JdevTac

    JdevTac Bawnjourno

    Joined:
    Jan 8, 2012
    Member:
    #70234
    Messages:
    5,119
    Gender:
    Male
    First Name:
    Josh
    GA/MD
    Vehicle:
    2013 DC TRD-OR 4x4 Pyrite Mica (sold)
    So the add-a-circuit thing is fine but I wouldn’t run that as my power source. What you can do is set it up as a relayed 12v line from the battery, using an ignition only circuit as your trigger for said relay.

    but ideally you should run power straight to battery and ground to either battery or nearest body ground and leave it at that and make sure to just turn it off when truck is off. It also makes it so you can turn the radio on and use it real quick if the truck is off, rather than have to turn the engine on.

  7. Jun 18, 2020 at 11:20 AM
    #7
    2013XSPX

    2013XSPX Well-Known Member

    Joined:
    Nov 29, 2015
    Member:
    #170975
    Messages:
    1,237
    Gender:
    Male
    First Name:
    Matt
    GA/FL Border
    Vehicle:
    2013 XSP-X
    Perfectly stock?
    I run my MXT 400 right to the battery. It's 40 watts. Just remember to turn it off.

    4x4cajun likes this.
  8. Jun 18, 2020 at 5:47 PM
    #8
    Old Swamper

    Old Swamper Tacoma World Poor

    Joined:
    Mar 26, 2019
    Member:
    #288101
    Messages:
    463
    Gender:
    Male
    First Name:
    Will
    Northern WI.
    Vehicle:
    2012 Black Tacoma TRD OR
    5100 & OME 884 AAL
    Last edited: Jun 18, 2020
  9. Jun 18, 2020 at 7:04 PM
    #9
    rednext

    rednext Well-Known Member

    Joined:
    Oct 28, 2019
    Member:
    #309252
    Messages:
    92
    Gender:
    Male
    I have run 2-way radios in my trucks for years on the farm and the only way it'll kill the battery is if you leave it on for a week straight (and there's lots of traffic on the radio at the same time). If you use your truck daily, or every other day, you'll be fine. Or just turn the radio off when leaving. I tend to agree that it needs to be run straight to the battery with an inline fuse

  10. Jun 18, 2020 at 7:08 PM
    #10
    m603holden

    m603holden @Koditten Pirate Radio member #063

    Joined:
    Oct 18, 2014
    Member:
    #140581
    Messages:
    11,451
    Gender:
    Male
    First Name:
    Marteeen
    New England
    Vehicle:
    2017 Tacoma DCSB OR MT
    Lots of sail boat fuel
    Careful. Those more power gmrs radios can pull 25amps +. Those cigarette outlets have a 10 or 15 amp source

  11. Jun 18, 2020 at 7:57 PM
    #11
    Old Swamper

    Old Swamper Tacoma World Poor

    Joined:
    Mar 26, 2019
    Member:
    #288101
    Messages:
    463
    Gender:
    Male
    First Name:
    Will
    Northern WI.
    Vehicle:
    2012 Black Tacoma TRD OR
    5100 & OME 884 AAL
    His model is a 15 watt one.

    m603holden likes this.
  12. Jun 18, 2020 at 8:00 PM
    #12
    ReeceRiley

    ReeceRiley [OP] Active Member

    Joined:
    Nov 30, 2019
    Member:
    #312085
    Messages:
    43
    Gender:
    Male
    First Name:
    Reece
    Des Moines iowa
    Vehicle:
    Tacoma in-line 4, 2 door, 5 speed
    I set it up today, I rain it straight off the battery. The radio it self is under the drivers seat

  13. Jun 18, 2020 at 8:00 PM
    #13
    ReeceRiley

    ReeceRiley [OP] Active Member

    Joined:
    Nov 30, 2019
    Member:
    #312085
    Messages:
    43
    Gender:
    Male
    First Name:
    Reece
    Des Moines iowa
    Vehicle:
    Tacoma in-line 4, 2 door, 5 speed
    I’ll have pictures tomorrow

  14. Jun 18, 2020 at 8:05 PM
    #14
    Myrtle Beach Taco

    Myrtle Beach Taco Member

    Joined:
    Feb 28, 2013
    Member:
    #98698
    Messages:
    22
    Gender:
    Male
    First Name:
    John
    Myrtle Beach
    Vehicle:
    12 currently stock
    You should actually run an inline fuse on both the positive and the negative line. That is the way a lot of mobile devices in hamreadio are wired.

  15. Jun 19, 2020 at 2:49 AM
    #15
    m603holden

    m603holden @Koditten Pirate Radio member #063

    Joined:
    Oct 18, 2014
    Member:
    #140581
    Messages:
    11,451
    Gender:
    Male
    First Name:
    Marteeen
    New England
    Vehicle:
    2017 Tacoma DCSB OR MT
    Lots of sail boat fuel
    Indeed. I was referring to yours. Was just putting it out there. Didn't know if you had the 50w version. Seems you know the deal though.

    Old Swamper likes this.
  16. Jun 19, 2020 at 6:31 AM
    #16
    DG92071

    DG92071 Well-Known Member

    Joined:
    Nov 29, 2019
    Member:
    #312004
    Messages:
    2,356
    The amount if current that your radio draws is extremely small. A relay is definitely not required. An add a circuit is fine.

    The amplifier section of your radio uses 1.25 amps at 12 volts, the rest of its power consumption is lights for its display.

  17. Jun 19, 2020 at 6:44 AM
    #17
    golfindia

    golfindia Well-Known Member

    Joined:
    Aug 25, 2017
    Member:
    #228000
    Messages:
    1,142
    Gender:
    Male
    Yes.
    Vehicle:
    2017 4x4 access cab AT
    If you are not comfortable constructing your own relay:

    https://powerwerx.com/automotive-dc-timer-lvd-battery-guard

    Not the cheapest, but easy and cheap are usually mutually exclusive.

    I'm not up on GMRS rigs, but lots of ham rigs have auto power off settings. Remember, if you make a key-on relay and you want to use your radio while stationary, your truck will be chiming the whole time your door is open. That's sub optimal.

  18. Jun 19, 2020 at 7:17 AM
    #18
    m603holden

    m603holden @Koditten Pirate Radio member #063

    Joined:
    Oct 18, 2014
    Member:
    #140581
    Messages:
    11,451
    Gender:
    Male
    First Name:
    Marteeen
    New England
    Vehicle:
    2017 Tacoma DCSB OR MT
    Lots of sail boat fuel
    @ReeceRiley

    I mean I probably wouldn't do any of that. If you want to use your radio when the truck is off, you'd have no option.

    Which you will use the radio when the truck is off. Just how it is.

  19. Jun 19, 2020 at 7:39 AM
    #19
    DG92071

    DG92071 Well-Known Member

    Joined:
    Nov 29, 2019
    Member:
    #312004
    Messages:
    2,356
