New brake pad - break in, and smelling hot.

Discussion in '1st Gen. Tacomas (1995-2004)' started by bloated_possum, Oct 26, 2009.

  1. Oct 26, 2009 at 3:29 PM
    #1
    bloated_possum

    bloated_possum [OP] Member

    Joined:
    Sep 21, 2009
    Member:
    #23088
    Messages:
    18
    Gender:
    Male
    Tennessee
    Vehicle:
    04 Tacoma 4x4
    I don't know how else to word it. Installed new front pads (Toyota pads) this weekend, but today is the first day that I've driven it more than around the block. I noticed a pretty strong "hot or burning" odor when I got home. New pads probably have less than 25 miles on them. Is this normal? If so, how long does it last normally? Just want to make sure nothing is amiss.

  2. Oct 26, 2009 at 6:29 PM
    #2
    Andyd103

    Andyd103 Well-Known Member

    Joined:
    Oct 12, 2009
    Member:
    #24193
    Messages:
    91
    Gender:
    Male
    First Name:
    Andrew
    New Hampshire
    Vehicle:
    2002 Tacoma SR5 4WD (3.4L V6)
    Suspension Lift, 40mm Turbo
    it could be normal some pads come with a plasticky coating on them to protect them, its probably that just burning off

  3. Oct 26, 2009 at 6:33 PM
    #3
    YotaComa

    YotaComa Well-Known Member

    Joined:
    Oct 25, 2009
    Member:
    #24892
    Messages:
    58
    Gender:
    Male
    NorCal
    Vehicle:
    2004 Tacoma Double Cab
    make sure that your brake piston was pushed all the way in.

    If it is still in the old position, it will cause the new (thicker) pads to have constant friction against the rotor...and burn em up.

  4. Oct 26, 2009 at 6:48 PM
    #4
    bloated_possum

    bloated_possum [OP] Member

    Joined:
    Sep 21, 2009
    Member:
    #23088
    Messages:
    18
    Gender:
    Male
    Tennessee
    Vehicle:
    04 Tacoma 4x4
    I don't understand how that could be. I pushed all the pistons in in order to be able to install the pads. Do they not just then extend to push against the pads when in use and retract when not being used?

  5. Oct 26, 2009 at 7:11 PM
    #5
    chris4x4

    chris4x4 With sufficient thrust, pigs fly just fine. Moderator

    Joined:
    May 8, 2008
    Member:
    #6497
    Messages:
    112,751,520
    Gender:
    Male
    First Name:
    FlimFlubberJAM
    Tenoe, AZ
    Vehicle:
    2019 Rubicon 4 Door,
    4.10 gears, sliders, and lots of buttons.
    They retract to a point. Sounds like you installed them propperly. How hot do they get? Are you just smelling somthing?

  6. Oct 26, 2009 at 8:30 PM
    #6
    instructor74

    instructor74 Member

    Joined:
    Oct 16, 2009
    Member:
    #24393
    Messages:
    14
    Gender:
    Male
    First Name:
    Paul
    PA
    take a quick look at both rotors for any signs of discoloration of the rotor (blue or purple) If you really dont see anything like that more than likely the pads are just bedding in. to help with this bring the truck up to 60mph brake with firm preasure down to 20mph do this 3 to 4 times. Than let things cool a bit and do 60mph to 0mph 3 to 4 times you might smell hot brakes at this point. let things cool again and you should be good togo

  7. Oct 27, 2009 at 3:36 AM
    #7
    bloated_possum

    bloated_possum [OP] Member

    Joined:
    Sep 21, 2009
    Member:
    #23088
    Messages:
    18
    Gender:
    Male
    Tennessee
    Vehicle:
    04 Tacoma 4x4
    No discoloration. And they don't appear to be getting any hotter than usual. Just the smell. I've actually been riding around with everything off to make sure I could hear any rubbing or anything out of the ordinary. They are as silent as my originals. I've actually VERY pleased with that part. Thanks for the input. I'll give them a few more days and make sure the smell goes away once they have been bed in good.

  8. Jul 6, 2011 at 7:32 PM
    #8
    01 tacoma

    01 tacoma Member

    Joined:
    Feb 18, 2011
    Member:
    #51380
    Messages:
    23
    Gender:
    Male
    Pennsylvania
    Vehicle:
    01 SR5
    I recently had the pads on my front brakes changed at a garage and I've been noticing the same burning smell as OP has mentioned. I have also noticed that my stopping distance seems like it has increased greatly as well. Do you guys think the increased stopping distance is caused by some excess oil or something left behind or is it something else?

  9. Jul 6, 2011 at 8:08 PM
    #9
    4WD

    4WD cRaZy oLdmAn

    Joined:
    Jul 2, 2009
    Member:
    #19185
    Messages:
    23,542
    Gender:
    Male
    First Name:
    Doug
    Lakeside, Ca / Gardnerville, Nevada
    Vehicle:
    2004 DC TRD 4x
    Grey wire MOD, deck plate, diff breather MOD, 2nd gen. OME 883# on Tundra 5100's, OMD custom 3" leafsprings, rear shock relocation, Ivan Stewart TRD rims w/285/75/16's, '02 bumper MOD, Famous Fabrications sliders , LED interior/exterior lights, bed bar, Custom tube bumper, Old school KC day lighters,Red Ring 8" HID flood, Kenwood vhf 2M.. umm some other shit I'm forgetting right now
    Are they standard semi metallic or are they porcelan ?

  10. Jul 7, 2011 at 12:47 PM
    #10
    01 tacoma

    01 tacoma Member

    Joined:
    Feb 18, 2011
    Member:
    #51380
    Messages:
    23
    Gender:
    Male
    Pennsylvania
    Vehicle:
    01 SR5
    Honestly, it doesn't say on the receipt and the mechanic never mentioned it to me. I also got new front rotors so do you think it might be some grease from that? Also, I just got back from a drive a few minutes ago where I did some pretty hard braking and I noticed the burning brakes smell and some smoke coming from the front brakes. I didn't notice any pulling so I don't think it's a stuck caliper.

  11. Jul 7, 2011 at 9:25 PM
    #11
    4WD

    4WD cRaZy oLdmAn

    Joined:
    Jul 2, 2009
    Member:
    #19185
    Messages:
    23,542
    Gender:
    Male
    First Name:
    Doug
    Lakeside, Ca / Gardnerville, Nevada
    Vehicle:
    2004 DC TRD 4x
    Grey wire MOD, deck plate, diff breather MOD, 2nd gen. OME 883# on Tundra 5100's, OMD custom 3" leafsprings, rear shock relocation, Ivan Stewart TRD rims w/285/75/16's, '02 bumper MOD, Famous Fabrications sliders , LED interior/exterior lights, bed bar, Custom tube bumper, Old school KC day lighters,Red Ring 8" HID flood, Kenwood vhf 2M.. umm some other shit I'm forgetting right now
    Smoke, constant burning smell, new rotors,new pads, rotor spins freely, no seized piston in caliper. I dunno, but I think you need to get with your mech. & go over what he did/didn't do, sounding more like an install issue at this point...

  12. Jul 11, 2011 at 8:47 AM
    #12
    01 tacoma

    01 tacoma Member

    Joined:
    Feb 18, 2011
    Member:
    #51380
    Messages:
    23
    Gender:
    Male
    Pennsylvania
    Vehicle:
    01 SR5
    Actually, I drove it a little bit more and everything is fine now. Must have been some extra grease or something because the burning smell/smoking is gone and the stopping distance is back to normal. Thanks for the help anyway, guys.

  13. May 10, 2017 at 11:08 AM
    #13
    aerostar93

    aerostar93 New Member

    Joined:
    May 10, 2017
    Member:
    #218680
    Messages:
    1
    Gender:
    Male
    If brake fluid is low than it's probably a wheel cylinder gone bad and leaking brake fluid. I had same problem with my ford aerostar brand new brakes

  14. May 11, 2017 at 11:28 AM
    #14
    frizzman

    frizzman Well-Known Member

    Joined:
    Sep 25, 2013
    Member:
    #113212
    Messages:
    5,319
    Gender:
    Male
    Pittsburgh, PA
    Vehicle:
    04 XCab 4x4 TRD/OR
    OME 2.5,Tundra 17s,Falken Wildpeak AT3W hitch w/ 7-pin, ARE cap, JVC HU w/BT, HID/LED lights
  15. May 11, 2017 at 11:44 AM
    #15
    ThunderOne

    ThunderOne Well-Known Member

    Joined:
    May 20, 2009
    Member:
    #17473
    Messages:
    10,021
    First Name:
    Mitchell
    Nashville
    Vehicle:
    1ST GEN OR GTFO
    Toyota NERD
    Pretty sure this guy is long gone and will never see your response. Also, he probably has gotten another set of brakes by now. Common sense man..
