Not another Lighting thread....yes I searched first!

Discussion in '3rd Gen. Tacomas (2016+)' started by W8N41, Sep 19, 2018.

  1. Sep 19, 2018 at 10:29 AM
    #1
    W8N41

    W8N41 [OP] Active Member

    Joined:
    Jan 6, 2017
    Member:
    #206745
    Messages:
    36
    Gender:
    Male
    Vehicle:
    Dakka
    I own a 2017 Tacoma Offroad....no tech package(if it matters)

    I too live in a rural area, the deer are starting to move more already. I first considered light bars, baja design fogs, ect. Then I thought, why not just better lights where I already have them?

    I have read about 100 conversion threads(some of them twice), searched 7 ways to Sunday. Thought, maybe a better halogen or xenon bulb or something 'simple'. I run down to the local Napa, awesome H11 premium blah blah blah.

    I get home...THEY DON'T FIT. The connecting plug is slightly different. Same outside shape, different inside shape. Every single lighting thread I find is about H11 lights. So what am I missing here?

    Napa says, and I confirmed with one off the shelf(boring regular replacement bulb)my Taco takes a 1265H9N bulb. Not an H11.

    I would be ecstatic if someone hits me with a "duh moment", but I think not.

    Lay it on me, what did I miss?

  2. Sep 19, 2018 at 10:42 AM
    #2
    Muffdiver

    Muffdiver Growing old is mandatory, growing up is optional

    Joined:
    Jun 16, 2015
    Member:
    #157550
    Messages:
    973
    Gender:
    Male
    First Name:
    Ty
    Elkhart, In
    Vehicle:
    2012 TRD OR DC 4x4
    SportsmanJake likes this.
  3. Sep 19, 2018 at 10:45 AM
    #3
    here4cake

    here4cake Well-Known Member

    Joined:
    Nov 19, 2017
    Member:
    #236447
    Messages:
    624
    Tacoma low beams take the H11b bulb.

    You can also take an H9 bulb, spend 30 seconds with a utility knife to trim a tab, and use that. It'll give you much more light output (H9 bulbs are also used in the high-beams) - way, way more than any "premium" H11b bulb. I ran that setup for a while before switching to a quality HID kit.

    Also - I've got Baja Designs Squadron Sport (wide cornering, amber) lights in my fogs. These things are amazing, but stupidly bright. They will absolutely blind the crap out of any driver coming the other way. If you get the Pro version, (instead of the sport) they will probably set trees on fire as you pass by. These are fantastic on country backroads at night, but you'll need to flick them off if there's oncoming traffic.

    Last edited: Sep 19, 2018
  4. Sep 19, 2018 at 1:01 PM
    #4
    W8N41

    W8N41 [OP] Active Member

    Joined:
    Jan 6, 2017
    Member:
    #206745
    Messages:
    36
    Gender:
    Male
    Vehicle:
    Dakka
    I found a couple of videos, my truck has a different size connector. I'll figure something out.

  5. Sep 19, 2018 at 1:06 PM
    #5
    ELT2JV

    ELT2JV Well-Known Member

    Joined:
    Jan 6, 2018
    Member:
    #240411
    Messages:
    116
    Gender:
    Male
    Vehicle:
    17 TRD OR ACLB
    8112 front 8100 rear. Method NV with 265/75/16 KO2.
  6. Sep 19, 2018 at 1:14 PM
    #6
    BG_Taco

    BG_Taco Member

    Joined:
    Dec 21, 2017
    Member:
    #239093
    Messages:
    16
    Gender:
    Male
    Vehicle:
    2018 AC OR Silver
    There are separate low beam and high beam bulbs. Maybe you tried to put the new H11 bulb (low beam) into the H9 bulb (high beam)?

  7. Sep 19, 2018 at 1:20 PM
    #7
    BG_Taco

    BG_Taco Member

    Joined:
    Dec 21, 2017
    Member:
    #239093
    Messages:
    16
    Gender:
    Male
    Vehicle:
    2018 AC OR Silver
    Bulbs


  8. Sep 19, 2018 at 1:22 PM
    #8
    W8N41

    W8N41 [OP] Active Member

    Joined:
    Jan 6, 2017
    Member:
    #206745
    Messages:
    36
    Gender:
    Male
    Vehicle:
    Dakka
    I checked both hi and lo on drivers side.

    But in the videos it is clearly an H11 connector. I showed my wife and she agree's mine is different. I'll take a picture.

  9. Sep 19, 2018 at 1:32 PM
    #9
    W8N41

    W8N41 [OP] Active Member

    Joined:
    Jan 6, 2017
    Member:
    #206745
    Messages:
    36
    Gender:
    Male
    Vehicle:
    Dakka
    Welp, ding ding ding! I some how pulled the high beam out twice, and you sir are correct. That's what I get for trying to do it last night in the dark.

    But at least I have an answer now.

    Thank you.

    Go ahead with the remarks of publicly posting stupidity and all that, shit happens. ;-)

  10. Sep 19, 2018 at 1:33 PM
    #10
    vicali

    vicali tirekicker

    Joined:
    May 20, 2010
    Member:
    #37503
    Messages:
    819
    Gender:
    Male
    First Name:
    mike
    Kam,BC
    Vehicle:
    2017 TRD Sport 1D6
    I went with aux lights rather than playing around with headlights;

    Stock highbeams;
    [​IMG]

    Highbeams with Squadron Sport Combos in the fog pockets and Squadron Pro Combos on ditch brackets;
    [​IMG]

    InsuredToyota likes this.
  11. Sep 19, 2018 at 1:54 PM
    #11
    seguraandres

    seguraandres Well-Known Member

    Joined:
    Jun 21, 2018
    Member:
    #257064
    Messages:
    66
    Gender:
    Male
    First Name:
    Andres
    Memphis, Tn
    Vehicle:
    2018 Grey Tacoma TRD off-road
    None at the moment
    Where did you get your Baja Designs Squadron Sport?
