OBA -> On Board Air Mega Thread & BS

Discussion in 'Technical Chat' started by Gunshot-6A, Oct 20, 2013.

  1. Sep 10, 2017 at 6:41 AM
    #1421
    AaronArf

    AaronArf Well-Known Member

    Joined:
    Nov 12, 2011
    Member:
    #66926
    Messages:
    4,147
    Gender:
    Male
    First Name:
    Aaron
    King George, VA
    Vehicle:
    krautwagen
    ARB Single with a tank is going to struggle more than it should.

    G.T. likes this.
  2. Sep 10, 2017 at 6:46 AM
    #1422
    jc11taco89

    jc11taco89 Well-Known Member

    Joined:
    May 28, 2016
    Member:
    #188157
    Messages:
    1,861
    Gender:
    Male
    First Name:
    jon
    Naugatuck CT
    Vehicle:
    2011 Tacoma aclb 4wd
    3 inch toytec 5100 SPC uca's Pelfreybilt front plate bumper with center hoop Pelfreybilt rear plate bumper with swing out B.A.M.F. sliders with kick out Mobtown ifs and trans skid. 33's with rims that are to large.
    Recommendation's ?

  3. Sep 10, 2017 at 6:50 AM
    #1423
    AaronArf

    AaronArf Well-Known Member

    Joined:
    Nov 12, 2011
    Member:
    #66926
    Messages:
    4,147
    Gender:
    Male
    First Name:
    Aaron
    King George, VA
    Vehicle:
    krautwagen
    Run it without a tank :thumbsup:

    If you need more air, faster upgrade to a ARB Dual. I'd compare the cost of the fittings, line and tank you wanted to add and see how far away you are from a dual.

    GREENBIRD56 and jc11taco89 like this.
  4. Sep 10, 2017 at 6:53 AM
    #1424
    jc11taco89

    jc11taco89 Well-Known Member

    Joined:
    May 28, 2016
    Member:
    #188157
    Messages:
    1,861
    Gender:
    Male
    First Name:
    jon
    Naugatuck CT
    Vehicle:
    2011 Tacoma aclb 4wd
    3 inch toytec 5100 SPC uca's Pelfreybilt front plate bumper with center hoop Pelfreybilt rear plate bumper with swing out B.A.M.F. sliders with kick out Mobtown ifs and trans skid. 33's with rims that are to large.
    OK awesome thanks Ya I was planning on not running a tank originally but after looking through this thread I see a lot of rigs with the tanks so I figured I'd ask thanks again bud.

    AaronArf likes this.
  5. Sep 10, 2017 at 2:06 PM
    #1425
    Sandman614

    Sandman614 Snarky TWSS elf, Travis #hotsavannahdotcom, LRGRNR

    Joined:
    Oct 26, 2010
    Member:
    #45273
    Messages:
    34,657
    Gender:
    Male
    First Name:
    Tim
    Garner, NC/Boone, NC
    Vehicle:
    '06 SR5 Off Road
    ARB Front Bumper, Projector Headlights w/Slimcubby 4300K HID's, Oznium LED's, LED taillights, DIY Washable Cabin Moose Filter, Sockmonkey SR5 Off Road, Aux Audio plug, OME 886x, OME Nitrochargers, Wheelers 3 Leaf Progressive AAL, ImMrYo Rear-View Mirror Lift Bracket, Dodge D-Rings
    A tire holds more air than a reasonable air tank. I personally would run an air tank for the locker. I like the fact that the compressor can fill the tank and not turn back on all weekend (provided your system doesn't leak..much) . You don't have to run your tank at any higher pressure than the locker needs. The single ARB Compressor will handle it just fine.

    jc11taco89 and Drainbung like this.
  6. Sep 10, 2017 at 7:45 PM
    #1426
    lpfe42

    lpfe42 Well-Known Member

    Joined:
    Jul 2, 2015
    Member:
    #158633
    Messages:
    392
    Gender:
    Male
    First Name:
    Kenny
    Santa Barbara County
    Vehicle:
    20 DCSB CEMENT
    5100/887 Icon uca
    Where did you get the cap for the air fitting?

  7. Sep 10, 2017 at 8:12 PM
    #1427
    Drainbung

    Drainbung Somedays you are the show....

    Joined:
    Sep 2, 2010
    Member:
    #42629
    Messages:
    8,206
    Gender:
    Male
    First Name:
    Bob
    Fallabama, NV
    Vehicle:
    10 DCLB
    TRD Fleshlight
  8. Sep 14, 2017 at 12:28 PM
    #1428
    Skibosstaco

    Skibosstaco Member

    Joined:
    Oct 14, 2014
    Member:
    #140372
    Messages:
    14
    Gender:
    Male
    SF, CA
    Vehicle:
    2014 4x4 dub cab long bed
    I just read through most of this thread and wanted to get some advice if anyone can chime in.

    I'm taking my truck into Mexico in about a month and am trying to figure out a system so I can air up my tires after driving on the beach in the middle of nowhere.

    I'm thinking the Viair 400h is my best bet as it is 100%duty cycle and is within my price range. I am going to try and figure out how to mount it in the cubby bed. I was hoping someone could point me in the right direction as to what I need for wiring/fuses and any other tips for mounting this thing?
    Thanks

  9. Sep 14, 2017 at 12:36 PM
    #1429
    rob1208

    rob1208 Well-Known Member

    Joined:
    Aug 29, 2014
    Member:
    #137169
    Messages:
    1,889
    Gender:
    Male
    First Name:
    Rob
    SF Bay Area
    Vehicle:
    2014 Toyota Tacoma DCSB MGM TRD OR
    TRD Supercharger AFE CAI ProDryS ADS 2.5 Remote Resi Shocks ADS Rear Piggy Back 10" Travel Shocks ADS 2.0 Rear Hydro Bump Kit Deaver U402 Leaf Pack + Add a Leaf MCM Fab Uniball UCAs TC Spindle Gussets BAMF 100% Bolt On Sliders BAMF 1/4" Steel Skid Trilogy BAMF Diff Diaper Brute Force Fab Hybrid Front Bumper with Warn VR10000-s Winch Brute Force Fab High Clearance Dual Swingout Rear Bumper Custom Car Grills Mesh Grill Insert Stealth Custom Series SR8 - Matte Black 16x8 285/75/16 Toyo Tires Open Country AT2 Relentless Fabrication Ditch Light Bracket Mounts 2x2 Ditch Lights Apex Fab Works Flush Lower Grill Light Bar Mounts Caliraised 32" Light Bar Tech Deck Extreme Vagabond Outdoors Drifter
    I mounted my arb single compressor in the driver side cubby. I didn't do anything special except used the bolts + reenforcement plate that came with the arb to mount it in the cubby.

    As far as wiring, I went with a blue sea circuit breaker
    Looks like the 400H has a max draw of 26amps so get one that is the appropriate size. Of course, you can just use a fuse but I liked the option to be able to just reset the breaker.

    I used some 8gauge wire from the battery and chassis ground point back to the cubby.
    Then just ran a 12-18 gauge (cant remember what wire I used, it was whatever leftover I had that was long enough) from the switch in my center console in the cab to the relay which I had installed in the cubby.

    Its really straight forward. The biggest thing will be how well does the compressor fit in the cubby and how much cutting/adjusting you need to do to make it fit.

    Last edited: Sep 14, 2017
  10. Sep 14, 2017 at 1:07 PM
    #1430
    Skibosstaco

    Skibosstaco Member

    Joined:
    Oct 14, 2014
    Member:
    #140372
    Messages:
    14
    Gender:
    Male
    SF, CA
    Vehicle:
    2014 4x4 dub cab long bed
    Ok cool thanks for the quick reply

  11. Sep 29, 2017 at 5:52 PM
    #1431
    Thyces

    Thyces 2 seater taco

    Joined:
    Nov 19, 2015
    Member:
    #170146
    Messages:
    3,101
    Gender:
    Male
    Ontario
    Vehicle:
    2009 DCLB TRD Sport
    Nitrocharger on 886 1" spacer Fox 2.0 12" in the rear Allpro expedition leafs (garbage) Pelfreybilt aluminum single hoop front Full size pickup bedslide modded to fit Satoshi grill Ubolt flip kit Archive garage shackle flip Sumo supersprings 1500lbs SPC uca's Full set RCI skid plates Weld on sliders ABS killswitch Pop'n'lock power tailgate lock Falken Wildpeak mt on FJ rims Plastidipped emblems Ebay projector headlights Smoked aftermarket tail lights High output led reverse lights Hella horns 330w 5d led bumper bar 18w spots on track facing rear (fuck you lights) B&m trans cooler Bussmann fuse box ECGS bushing Big 4 (0 gauge ofc wire) upgrade Mechman 240 amp alternator Jl 10w7 in a 1 1/2" thick wall custom box Alpine 1000w rms mono amp Group 31 AGM battery installed next to sub Yaesu 2800 Bearcat 980 in dash with wireless mic and stainless whip Diff breather mod Hilux snorkel Turbine pre filter Baja Rack low profile cab rack Rifle case on rack Shovel and axe on quick fists in bed Flat and spade shovel mounted in bed Highlift mount in bed Tech deck with magnetic ram mount Tab s4 on ram mount
    [​IMG]
    Need some opinions on this possible set up I have a viair 88p I just purchased to reinflate tiers after wheeling. I also have this ~3 gallon tank I got for free. I'm planning on installing the compressor inside the cab under the rear seats (hardwired to battery) with a 2 lines coming out, 1 going to the box near the cab with a quick connect and another going to the back bumper area also with a quick connect. The one in the box I plan on using with the tank on some mounts attached to the rail. Basically I want to be able to remove the tank when extra space is needed.
    Question is, is it worth the time/trouble of installing the lines and tank?
    Is there that much of a benefit running a tank? What parts would I need to make all connections?
    I'm not planning on going air locker or bags.
    Tank is rated for 200 psi
    Viair 88p is only 1.43cfm and 120 psi.
    I'm not buying a new compressor anytime soon.

  12. Sep 29, 2017 at 9:48 PM
    #1432
    bagleboy

    bagleboy Well-Known Member

    Joined:
    Aug 5, 2017
    Member:
    #226018
    Messages:
    4,689
    Gender:
    Male
    First Name:
    Scott
    Norcal, Santa Rosa
    Vehicle:
    2014 5-lug AC 2.7L VVTI
    Snug top Rebel, Thule tracks, ditch tracks, Bagged rear suspension, F/R anytime camera, intermittent wiper switch...
    For simply airing up you don't need a tank. If you need a source of regulated pressure then it's nice to have a tank. For some things even a 1 gal will do. Small ones can fit in the bedside void or on a frame rail. Bigger ones can occupy the spare tire location if you've gone to a size that no longer fits.

  13. Oct 4, 2017 at 4:16 PM
    #1433
    Tacoma SS

    Tacoma SS Well-Known Member

    Joined:
    Sep 3, 2015
    Member:
    #163341
    Messages:
    5,032
    Gender:
    Male
    First Name:
    John
    Denver
    Vehicle:
    Supercharged 09 on 35s
    Boost and flex and 35s
    I don't have anything in my spare tire spot anymore. Thinking of putting two 2.5 gallon tanks under there. Anybody done that before? Looking at the 2.5 viair tanks

  14. Oct 4, 2017 at 4:18 PM
    #1434
    Drainbung

    Drainbung Somedays you are the show....

    Joined:
    Sep 2, 2010
    Member:
    #42629
    Messages:
    8,206
    Gender:
    Male
    First Name:
    Bob
    Fallabama, NV
    Vehicle:
    10 DCLB
    TRD Fleshlight
  15. Oct 5, 2017 at 10:46 AM
    #1435
    Tacoma SS

    Tacoma SS Well-Known Member

    Joined:
    Sep 3, 2015
    Member:
    #163341
    Messages:
    5,032
    Gender:
    Male
    First Name:
    John
    Denver
    Vehicle:
    Supercharged 09 on 35s
    Boost and flex and 35s
  16. Oct 5, 2017 at 10:52 AM
    #1436
    Drainbung

    Drainbung Somedays you are the show....

    Joined:
    Sep 2, 2010
    Member:
    #42629
    Messages:
    8,206
    Gender:
    Male
    First Name:
    Bob
    Fallabama, NV
    Vehicle:
    10 DCLB
    TRD Fleshlight
    Sorry about that...

    Tacoma SS likes this.
  17. Oct 6, 2017 at 9:01 AM
    #1437
    bagleboy

    bagleboy Well-Known Member

    Joined:
    Aug 5, 2017
    Member:
    #226018
    Messages:
    4,689
    Gender:
    Male
    First Name:
    Scott
    Norcal, Santa Rosa
    Vehicle:
    2014 5-lug AC 2.7L VVTI
    Snug top Rebel, Thule tracks, ditch tracks, Bagged rear suspension, F/R anytime camera, intermittent wiper switch...
    Shouldn't be a problem other than accessing both drain stopcocks regularly. Another choice might be a pancake tank. You'll need a heavy duty compressor to pressurize that much volume. If you don't need high pressure air you can ease the strain on the compressor by using a lower pressure switch. Last night I pulled the trigger on a tank and assorted bits including a 70-100 psi switch. Also found two 1" guages that will hopefully swap in for the 12v sockets in the center console area.

  18. Oct 6, 2017 at 9:09 AM
    #1438
    bagleboy

    bagleboy Well-Known Member

    Joined:
    Aug 5, 2017
    Member:
    #226018
    Messages:
    4,689
    Gender:
    Male
    First Name:
    Scott
    Norcal, Santa Rosa
    Vehicle:
    2014 5-lug AC 2.7L VVTI
    Snug top Rebel, Thule tracks, ditch tracks, Bagged rear suspension, F/R anytime camera, intermittent wiper switch...
    Pretty much any compressor can be doubled up to get more output by triggering a second relay off the switch. It would need its own wire and fuse as well. Edit- and enough juice to supply both.

  19. Oct 6, 2017 at 10:44 AM
    #1439
    Tacoma SS

    Tacoma SS Well-Known Member

    Joined:
    Sep 3, 2015
    Member:
    #163341
    Messages:
    5,032
    Gender:
    Male
    First Name:
    John
    Denver
    Vehicle:
    Supercharged 09 on 35s
    Boost and flex and 35s
    Only reason I want two tanks is to have more volume when I install a four trumpet horn system in the future. I have an ARB twin compressor installed right now. I was planning on setting it up so that I could fill the tanks with my high powered compressor that I have in the garage and just use the ARB as a back up whenever the tanks run low

  20. Oct 6, 2017 at 10:45 AM
    #1440
    Tacoma SS

    Tacoma SS Well-Known Member

    Joined:
    Sep 3, 2015
    Member:
    #163341
    Messages:
    5,032
    Gender:
    Male
    First Name:
    John
    Denver
    Vehicle:
    Supercharged 09 on 35s
    Boost and flex and 35s
    I'm not sure how much air is taken by a horn system so I don't even know if two tanks might be overkill
