OBA -> On Board Air Mega Thread & BS

Discussion in 'Technical Chat' started by Gunshot-6A, Oct 20, 2013.

  1. Sep 26, 2019 at 8:23 AM
    #1961
    Sandman614

    Sandman614 Snarky TWSS elf, Travis #hotsavannahdotcom, LRGRNR

    Joined:
    Oct 26, 2010
    Member:
    #45273
    Messages:
    34,665
    Gender:
    Male
    First Name:
    Tim
    Garner, NC/Boone, NC
    Vehicle:
    '06 SR5 Off Road
    ARB Front Bumper, Projector Headlights w/Slimcubby 4300K HID's, Oznium LED's, LED taillights, DIY Washable Cabin Moose Filter, Sockmonkey SR5 Off Road, Aux Audio plug, OME 886x, OME Nitrochargers, Wheelers 3 Leaf Progressive AAL, ImMrYo Rear-View Mirror Lift Bracket, Dodge D-Rings
    Last edited: Sep 26, 2019
    WormSquirts likes this.
  2. Sep 26, 2019 at 8:42 AM
    #1962
    WormSquirts

    WormSquirts Armageddon

    Joined:
    Dec 18, 2015
    Member:
    #172583
    Messages:
    1,549
    Gender:
    Male
    First Name:
    Braeden
    BC
    Vehicle:
    SWB 2006 DCLB
    I'm pretty sure having a tank actually might slow down air up times because the compressor has to fill an additional 2.5 gallons as well. You do speed up the first tire though, and the compressor can continue to run between tires... Probably a wash in the end.

    I have a tank for other stuff, not filling tires, but you have to consider that 2.5 gallons at 150 psi is a lot more air than 2.5 gallons at 35 psi.

  3. Sep 26, 2019 at 6:26 PM
    #1963
    bagleboy

    bagleboy Well-Known Member

    Joined:
    Aug 5, 2017
    Member:
    #226018
    Messages:
    4,701
    Gender:
    Male
    First Name:
    Scott
    Norcal, Santa Rosa
    Vehicle:
    2014 5-lug AC 2.7L VVTI
    Snug top Rebel, Thule tracks, ditch tracks, Bagged rear suspension, F/R anytime camera, intermittent wiper switch...
    It's not really that much air. Try running it until pressurized then see how many tires it fills back up. It wants to kick on way before it drops to tire pressure so from then on it's trying to fill both the tank and the tire.

  4. Sep 26, 2019 at 10:06 PM
    #1964
    WormSquirts

    WormSquirts Armageddon

    Joined:
    Dec 18, 2015
    Member:
    #172583
    Messages:
    1,549
    Gender:
    Male
    First Name:
    Braeden
    BC
    Vehicle:
    SWB 2006 DCLB
    Totally, I get that. Like I said, I use the tank for other stuff, I don't have it for filling tires. It definitely slows down fill times a little bit.

  5. Sep 27, 2019 at 7:11 PM
    #1965
    WormSquirts

    WormSquirts Armageddon

    Joined:
    Dec 18, 2015
    Member:
    #172583
    Messages:
    1,549
    Gender:
    Male
    First Name:
    Braeden
    BC
    Vehicle:
    SWB 2006 DCLB
    So I got everything all hooked up. Haven't tested actual fill times for tires, but I tested how long it takes to fill my 2.5 gallon tank from 0-150psi.

    Viair 400c only - 3.12
    ARB Twin only - 1.10
    Both combined - 0.55

    Not a huge gain from having both running over just the ARB, time wise. However, that is 20% faster than the ARB alone, so not too bad over a longer duration (ie. Filling up all 4 tires).

    I pressurized the system this morning, and over the course of the day so far it's lost around 10 or 15 psi. Would love to get that down to nothing if anybody has any suggestions? Before adding the twin and lockers I was losing around 10-15psi a week. I used soapy water but I think the leak is too small to tell.

  6. Oct 1, 2019 at 9:45 PM
    #1966
    SaphiraTaco

    SaphiraTaco Well-Known Member

    Joined:
    Feb 8, 2018
    Member:
    #243869
    Messages:
    479
    Gender:
    Male
    First Name:
    Sean
    Seattle WA
    Vehicle:
    2013 DCLB TRD Sport
    About halfway done...
    How did you seal all the threads on your air connections?
    I used this
    https://www.amazon.com/gp/product/B003XZB54O/ref=ppx_yo_dt_b_asin_title_o08_s00?ie=UTF8&psc=1
    haven't had any leaks yet:fingerscrossed:

    Sandman614 likes this.
  7. Oct 1, 2019 at 9:57 PM
    #1967
    WormSquirts

    WormSquirts Armageddon

    Joined:
    Dec 18, 2015
    Member:
    #172583
    Messages:
    1,549
    Gender:
    Male
    First Name:
    Braeden
    BC
    Vehicle:
    SWB 2006 DCLB
  8. Oct 2, 2019 at 7:55 AM
    #1968
    Sandman614

    Sandman614 Snarky TWSS elf, Travis #hotsavannahdotcom, LRGRNR

    Joined:
    Oct 26, 2010
    Member:
    #45273
    Messages:
    34,665
    Gender:
    Male
    First Name:
    Tim
    Garner, NC/Boone, NC
    Vehicle:
    '06 SR5 Off Road
    ARB Front Bumper, Projector Headlights w/Slimcubby 4300K HID's, Oznium LED's, LED taillights, DIY Washable Cabin Moose Filter, Sockmonkey SR5 Off Road, Aux Audio plug, OME 886x, OME Nitrochargers, Wheelers 3 Leaf Progressive AAL, ImMrYo Rear-View Mirror Lift Bracket, Dodge D-Rings
    I get mine on eBay. Got a full bottle from China for cheap, and smaller reseller distributed bottles for cheap too.

  9. Oct 2, 2019 at 9:52 AM
    #1969
    SaphiraTaco

    SaphiraTaco Well-Known Member

    Joined:
    Feb 8, 2018
    Member:
    #243869
    Messages:
    479
    Gender:
    Male
    First Name:
    Sean
    Seattle WA
    Vehicle:
    2013 DCLB TRD Sport
    About halfway done...
    But it's so so nice to not have any leaking at 150psi...

    WormSquirts likes this.
  10. Oct 2, 2019 at 10:09 AM
    #1970
    PNW/TRD Steve

    PNW/TRD Steve Well-Known Member

    Joined:
    Aug 11, 2012
    Member:
    #84527
    Messages:
    1,982
    Gender:
    Male
    First Name:
    Steve
    WA
    Vehicle:
    2012 DCSB TRD
    ImMrYo Rear view mirror lift bracket. Changed out mud flaps. Salex glove box organizer. OEM Ashtray (cup). AVS Step Shields. 16x8 SCS F5 Matte Jet Black. 265/75 16 Cooper St Maxx. OME Bp-51s. U.S. Offroad Winch Mount (in process) Smittybuilt x20 12k synthetic winch (in process) More....
    Here is what I have used in my system that includes six connections at this time.
    Loctite SF 7649 primer followed by the Loctite 545 thread sealant. I have had zero in the three years since. I will not do any changes or additions without using both of these.

    WormSquirts likes this.
  11. Oct 2, 2019 at 12:22 PM
    #1971
    SaphiraTaco

    SaphiraTaco Well-Known Member

    Joined:
    Feb 8, 2018
    Member:
    #243869
    Messages:
    479
    Gender:
    Male
    First Name:
    Sean
    Seattle WA
    Vehicle:
    2013 DCLB TRD Sport
    About halfway done...
    Bummer I didn't know about the primer:anonymous:
    guess we will see what happens over time.

  12. Oct 5, 2019 at 1:07 PM
    #1972
    Salty_Dog

    Salty_Dog Tactical Panda

    Joined:
    Mar 6, 2017
    Member:
    #212502
    Messages:
    6,005
    Gender:
    Male
    First Name:
    Tim
    Fredericksburg, VA
    Vehicle:
    2015 Tacoma Double Cab, Off-Road Edition
    AJT Designs Shifter AJT Designs Battery Hold-Down Amazon Special 40-inch light bar ARB Awning 2500x2500 ARB Twin Compressor w/ Slee Offroad Mounting Bracket Avid Brush Bar Avid Step Bars BFGoodrich All-Terain T/A Tires Black Rock Wheels Series 997 Type 8 Circuit Breaker/Relay Panel Custom TRD Decals Bulletproof Fabricating Raptor Grill Bulletproof Fabricating Cooling Panel Bulletproof Fabricating Tow Hook Exhaust Breather Mod eBay Special 3-Gallon Air Tank EZ Down tailgate damper Flagpole Mounts, Dual Foglight Mod Hella Supertone Horns Iggy Switch Panel Icon Dynamics Stage 3 Suspension Katskin Leather Interior LED Bed Lights LED Interior Lights OEM Audio Plus Reference 500 audio upgrade Plano Cases. 42" roof mounted, X2 Pop-N-Lock Tailgate Handle Prinsu CabRack Prinsu-like Shell Rack Redline Tuning Hood Struts Rigid Industries Ditch Lights Rigid Industries Spotlights Toyota Bed Step Treat-A-Pet Dog Hammock Vixen Air Horns, Four-Trumpet Whole bunch of decals worth about 5HP each.
    Does anyone have a source for ARB Compressor parts other than Poly Performance? Their shipping costs are ridiculous. $16 shipping on a $5 part? I don't think so.

  13. Oct 5, 2019 at 1:39 PM
    #1973
    WormSquirts

    WormSquirts Armageddon

    Joined:
    Dec 18, 2015
    Member:
    #172583
    Messages:
    1,549
    Gender:
    Male
    First Name:
    Braeden
    BC
    Vehicle:
    SWB 2006 DCLB
    have you tried arb direct? They are usually pretty good for that sort of thing

    Salty_Dog likes this.
  14. Oct 5, 2019 at 2:08 PM
    #1974
    foxrcing07

    foxrcing07 KO7FOX

    Joined:
    Aug 12, 2016
    Member:
    #194389
    Messages:
    3,845
    Gender:
    Male
    First Name:
    Morgan
    Modesto, CA
    Vehicle:
    2005 DCLB 2001 Reg cab 4x4
    Dirt
    4wheelparts
    It won’t be on their website but if you call them they can get just about anything

  15. Oct 26, 2019 at 12:42 AM
    #1975
    guwoptaco

    guwoptaco Well-Known Member

    Joined:
    Dec 10, 2018
    Member:
    #275484
    Messages:
    181
    Vehicle:
    2018 Magnetic Long Bed OR
    I’d like to see a parts list. The setup looks very clean.

  16. Oct 26, 2019 at 2:04 PM
    #1976
    ejwan

    ejwan Well-Known Member

    Joined:
    Sep 25, 2016
    Member:
    #198245
    Messages:
    176
    I’ll gather info for you once I find some time. Busy building a camper atm.

  17. Nov 6, 2019 at 3:31 PM
    #1977
    dlopan

    dlopan Well-Known Member

    Joined:
    Oct 3, 2016
    Member:
    #198890
    Messages:
    378
    Gender:
    Male
    First Name:
    Dave
    Albuquerque, NM
    Vehicle:
    2015 Pyrite Mica 4wd DCSB TRDSport
    Camper shell, CB radio. R-pod 179
    One question, are the ARB compressors still made in Aussie land or China?

  18. Nov 14, 2019 at 10:25 AM
    #1978
    ejwan

    ejwan Well-Known Member

    Joined:
    Sep 25, 2016
    Member:
    #198245
    Messages:
    176

    62PMTBH-4

    4

    68PMT-4-4

    7

    164PMT-4

    1

    1120-4A-BLK-100

    1

    1/4 ball valve

    1

    Manifold 4 Way Outlet 1/4 Inch NPT Female

    1

    quick disconnect plug male 1/4 NPT

    2

    quick disconnect coupler male 1/4 NPT

    2

    1/4 male x 1/4 male union NPT

    2

    diaphragm regulator 0- 60 psi (from an hvlp paint gun)

    1

    Coilhose Pneumatics CH15A Open Lock-On Chuck, 1/4-Inch FPT

    4

    zip tie to secure air lines

    Lastly you will need an air source to air up. Hope I didn’t miss anything. I shopped around and was able to purchase all those supplies for around 100

  19. Nov 20, 2019 at 5:02 PM
    #1979
    seafur

    seafur Well-Known Member

    Joined:
    Jul 11, 2014
    Member:
    #133755
    Messages:
    115
    Gender:
    Male
    Pacific Northwest
    Vehicle:
    2014 DCSB MT TRD OR
    Sprinter bed tiedowns, Aux fuse box, AIO key, 3-way canopy light switch, 12V bed outlet, Dual Battery AGM G35, Viair OBA, Uni-filter mod
    Has anyone used the Slee ARB compressor mount, http://www.sleeoffroad.com/products/products_air.htm, to mount a ViAir compressor under the hood? I've got a '14 DC TRD OR and since I mounted an aux battery on the passenger side against the firewall using the OGE bracket and an aux fuse box next to the main fuse box in the driver's I'm sort of running out of option.

  20. Nov 24, 2019 at 9:43 AM
    #1980
    Warles

    Warles Well-Known Member

    Joined:
    May 24, 2015
    Member:
    #155937
    Messages:
    146
    Colorado
    Vehicle:
    2015 Tacoma TRD,
    OME Suspension, Pelfreybilt bumper & skids
    I'm curious also. I have a Viair 088 that I'd like to mount under the hood as opposed to carrying it either in the cab or a bed cubby...
