Removing Overhead Console: Help before I break it!

Discussion in '3rd Gen. Tacomas (2016-2023)' started by RHelton10, May 27, 2016.

Page 1 of 2
  1. May 27, 2016 at 1:17 PM
    #1
    RHelton10

    #1
    RHelton10 [OP] Well-Known Member

    Joined:
    Jul 11, 2015
    Member:
    #159223
    Messages:
    281
    Gender:
    Male
    Atlanta, GA
    Vehicle:
    '16 DCLB MGM TRD Sport 4x4
    Predator bars, Revolver X2 tonneau cover, SwingCase tool box, Husky mats, HID conversion Fuel vapor 17” wheels, 2” front /1” rear lift with Bilstein 5100’s, 285/70R17 Nitto grappler 2’s
    Hey guys I need to remove the overhead console and can't find any guides (yes, I did a search) on how to remove it for the 2016 model. Before I go yanking on it I just wanted to make sure there weren't any hidden bolts or anything that I have to watch out for.

    Thanks in advance!!

    RHelton10, May 27, 2016
    #1
  2. May 27, 2016 at 1:53 PM
    #2
    Invid

    #2
    Invid Well-Known Member

    Joined:
    Dec 18, 2015
    Member:
    #172581
    Messages:
    1,075
    Gender:
    Male
    New Braunfels, Texas
    Vehicle:
    2016 Tacoma Limited
    There are simple pull tabs underneath that hold the console up. I just gently pulled on the drivers side corner nearest the windshield then went counter clockwise to each corner until it popped off. It's really simple to do.

    Invid, May 27, 2016
    #2
  3. May 27, 2016 at 2:37 PM
    #3
    RHelton10

    #3
    RHelton10 [OP] Well-Known Member

    Joined:
    Jul 11, 2015
    Member:
    #159223
    Messages:
    281
    Gender:
    Male
    Atlanta, GA
    Vehicle:
    '16 DCLB MGM TRD Sport 4x4
    Predator bars, Revolver X2 tonneau cover, SwingCase tool box, Husky mats, HID conversion Fuel vapor 17” wheels, 2” front /1” rear lift with Bilstein 5100’s, 285/70R17 Nitto grappler 2’s

    That worked perfectly - thanks!

    Here are some pics for anyone else needing info on removing it. image.jpgimage.jpg

    RHelton10, May 27, 2016
    #3
    HP11 and SamChieftan like this.
  4. May 27, 2016 at 2:48 PM
    #4
    SqFt

    #4
    SqFt Well-Known Member

    Joined:
    Feb 17, 2016
    Member:
    #178465
    Messages:
    110
    Gender:
    Male
    Vehicle:
    2016 Tacoma TRD Sport
    Thats great info. Thanks for posting the pic.

    SqFt, May 27, 2016
    #4
  5. Jul 20, 2016 at 5:34 PM
    #5
    sdsmtengineer

    #5
    sdsmtengineer Member

    Joined:
    Sep 26, 2013
    Member:
    #113316
    Messages:
    17
    Gender:
    Male
    First Name:
    Nick
    Rapid City SD
    Vehicle:
    2013 Tacoma TRD offroad
    Fog Lamp anytime MOD ABS Kill switch MOD Wet Okole Seat Cover Palsti Dip chrome grill Plasti Dip all badges
    sdsmtengineer, Jul 20, 2016
    #5
    Montana_Actual, saf023, HolyReptar and 1 other person like this.
  6. Jul 20, 2016 at 7:15 PM
    #6
    bcnu

    #6
    bcnu Active Member

    Joined:
    Jul 4, 2016
    Member:
    #191198
    Messages:
    37
    Gender:
    Male
    The Big Island, Hawaii
    Vehicle:
    2016 SR5 4x4 Access Cab / V-6 A/T Quicksand
    Thank you for that video. I need to get myself a set of those panel tools.

    bcnu, Jul 20, 2016
    #6
  7. Jul 20, 2016 at 7:17 PM
    #7
    bulldog

    #7
    bulldog Well-Known Member

    Joined:
    Nov 8, 2015
    Member:
    #169066
    Messages:
    2,007
    Gender:
    Male
    SW MO
    Vehicle:
    2023 Pro
    Umm…it’s a Pro Retired 4/29/2023 Dobinsons MRR Dobinsons UCA Dobinsons C59-314 Front Springs Dobinsons I59-110 Rear Springs 4.88 Yukon Gears CMC MobTown Sliders Line-Xed RCI Aluminum Skid BAMF Recessed Grille WARFAB Rear tube bumper SSO Full Plate Hybrid (sitting in the garage still) TTD Carbon Fiber Steering Wheel Clazzio Dark Gray Seat Covers 35% Tint Vinyl Tailgate Letters Undercover Elite Tonneau Apex Stealth Cali LED 31.5" w/upgrade OPT 7 harness and MicTuning Switch V5 Gemtech Homelink 265/75 16 Mickey Thompson Baja Boss A/T Volk Gloss Black 16” 17' Pro Rigid Fog Lights 17' Pro Tail Lights Complete sound proofing
    Harbor Freight has them cheap.

    bulldog, Jul 20, 2016
    #7
  8. Jul 20, 2016 at 7:37 PM
    #8
    Invid

    #8
    Invid Well-Known Member

    Joined:
    Dec 18, 2015
    Member:
    #172581
    Messages:
    1,075
    Gender:
    Male
    New Braunfels, Texas
    Vehicle:
    2016 Tacoma Limited
    Invid, Jul 20, 2016
    #8
    saf023 likes this.
  9. Jul 20, 2016 at 7:41 PM
    #9
    digitaLbraVo

    #9
    digitaLbraVo Derka Derka

    Joined:
    Sep 6, 2012
    Member:
    #86398
    Messages:
    7,514
    Covered in stickers and chrome stick-ons for extra horse torques and foot powers. Icon sticker gets me tons of travel, dozens of milimeters.
    digitaLbraVo, Jul 20, 2016
    #9
  10. Jul 20, 2016 at 7:43 PM
    #10
    Invid

    #10
    Invid Well-Known Member

    Joined:
    Dec 18, 2015
    Member:
    #172581
    Messages:
    1,075
    Gender:
    Male
    New Braunfels, Texas
    Vehicle:
    2016 Tacoma Limited
    I brake for breaks.

    Invid, Jul 20, 2016
    #10
    MR E30, Boghog1 and digitaLbraVo like this.
  11. Oct 12, 2018 at 8:25 PM
    #11
    HolyReptar

    #11
    HolyReptar Well-Known Member

    Joined:
    Jan 23, 2012
    Member:
    #71259
    Messages:
    1,901
    Gender:
    Male
    First Name:
    Bry
    Thousand Oaks
    Vehicle:
    17 TRD Offroad 4x4
    Some Bolt ones here and there
    Post to save this thread thanks for the YouTube video

    HolyReptar, Oct 12, 2018
    #11
  12. Nov 26, 2019 at 7:34 PM
    #12
    SourTacoma

    #12
    SourTacoma Member

    Joined:
    Nov 26, 2019
    Member:
    #311811
    Messages:
    15
    Vehicle:
    White TRD Sport, 3rd Gen
    Oy, so I pulled out the overhead console as suggested and one of the red pull tabs broke. Looks to be easily replaceable. Can anyone advise where to buy this piece? I tried searching for "pull tabs Tacoma" and most results I'm getting seem to be beer related.

    SourTacoma, Nov 26, 2019
    #12
    doublethebass and dubs66 like this.
  13. Nov 26, 2019 at 8:15 PM
    #13
    SourTacoma

    #13
    SourTacoma Member

    Joined:
    Nov 26, 2019
    Member:
    #311811
    Messages:
    15
    Vehicle:
    White TRD Sport, 3rd Gen
    Thanks. I’ll come armed with the above photo.

    SourTacoma, Nov 26, 2019
    #13
  14. Oct 25, 2020 at 9:40 AM
    #14
    doublethebass

    #14
    doublethebass aspiring well-known member

    Joined:
    Jan 1, 2017
    Member:
    #206252
    Messages:
    3,425
    Gender:
    Male
    First Name:
    Antoin
    Minneapolis MN
    Vehicle:
    ’17 6MT Pro
    Did you ever find these red tabs? I just broke mine too

    :frusty:

    doublethebass, Oct 25, 2020
    #14
  15. Oct 25, 2020 at 5:23 PM
    #15
    SourTacoma

    #15
    SourTacoma Member

    Joined:
    Nov 26, 2019
    Member:
    #311811
    Messages:
    15
    Vehicle:
    White TRD Sport, 3rd Gen
    Been a while to be honest can’t remember, sorry!!:playball:

    SourTacoma, Oct 25, 2020
    #15
  16. Oct 25, 2020 at 5:43 PM
    #16
    saf023

    #16
    saf023 Well-Known Member

    Joined:
    Aug 13, 2009
    Member:
    #21124
    Messages:
    1,067
    Gender:
    Male
    East Coast
    Vehicle:
    2nd Gen TRD Sport DCSB 4X4
    Very good video. Anyone ever seen one for a Gen 2?

    saf023, Oct 25, 2020
    #16
  17. Oct 25, 2020 at 6:40 PM
    #17
    doublethebass

    #17
    doublethebass aspiring well-known member

    Joined:
    Jan 1, 2017
    Member:
    #206252
    Messages:
    3,425
    Gender:
    Male
    First Name:
    Antoin
    Minneapolis MN
    Vehicle:
    ’17 6MT Pro
    No worries, found an Amazon link on another thread.
    Thanks though.

    doublethebass, Oct 25, 2020
    #17
  18. Oct 25, 2020 at 7:23 PM
    #18
    GrundleJuice

    #18
    GrundleJuice Well-Known Member

    Joined:
    Mar 15, 2015
    Member:
    #150931
    Messages:
    2,346
    Gender:
    Male
    Michigan
    Vehicle:
    2016 TRD Bro
    [S]Un-Molested[/S] Lightly Molested
    Not sure about a video but on my 2015 there was a single screw inside/above the aft sunglasses compartment that is accessable when it's open. Once that is out, the front edge can be pulled down (had similar clips to the 3rd gen) and the aft end slides forward to disengage some tabs above the headliner.

    GrundleJuice, Oct 25, 2020
    #18
    saf023[QUOTED] likes this.
  19. Feb 21, 2021 at 12:45 PM
    #19
    MillbrookMike

    #19
    MillbrookMike Well-Known Member

    Joined:
    Feb 10, 2021
    Member:
    #355666
    Messages:
    85
    Gender:
    Male
    New York State's Hudson Valley region
    Vehicle:
    2018 Tacoma TRD Sport
    Great Video, but of course, the overhead console is about the only thing he didn't remove! :-(

    MillbrookMike, Feb 21, 2021
    #19
  20. Jan 22, 2022 at 9:14 AM
    #20
    ManualTaco

    #20
    ManualTaco Well-Known Member

    Joined:
    Feb 17, 2016
    Member:
    #178541
    Messages:
    51
    Gender:
    Male
    Vehicle:
    2021 Magnetic Gray Doublecab Shorty TRD-OR
    I set some radio stations. That's about it so far.
    If it’s helpful for 2021 owners, removing the overhead console (to help shove excess wiring for a mirror upgrade from Bob the mirror guy), is fairly straightforward. I didn’t need any tools. Just use fingertips around the edges and pull straight down. There are red clips near each corner. In my case, they popped out without breaking tabs or anything. Reinstalling console was just the reverse. Push gently until all 4 corners click back in place. Super simple install of the mirror. Compass calibration was simple. Now on to Homelink programming!

    ManualTaco, Jan 22, 2022
    #20
