Rust on Frame with A/C drain mod fix

Discussion in '3rd Gen. Tacomas (2016+)' started by Uptown2k, Aug 3, 2016.

  1. Aug 9, 2021 at 9:19 AM
    #801
    Taco_mike73

    Taco_mike73 Well-Known Member

    Joined:
    Nov 22, 2019
    Member:
    #311413
    Messages:
    1,948
    Gender:
    Male
    First Name:
    Mike
    York, PA
    Vehicle:
    2020 Cement SR5 DCSB 4x4
    Lomax tonneau cover, oem bed lights, AJT Design chrome delete, black out badges & tailgate letters, AVS hood deflector & vent visors, Solkie tech hood supports, interior LED lights, Tufskinz mud guards, RedArc TowPro Liberty, bed mat, kicker speaker upgrade, Hikari ultra H11 low beams, Diode Dynamics SS3 fogs in yellow, Meso customs total taillight stage 1. Coming soon: Compact powered sub install Future mods planned: bigger tires (265/75/16) BILLSTIEN 5100 lift
    So when you do this mod do you have to jack up the truck and remove the tire or is there enough access if you turn the wheel?

  2. Aug 9, 2021 at 10:20 AM
    #802
    daveeasa

    daveeasa Slowest crimp in the West

    Joined:
    May 14, 2020
    Member:
    #328079
    Messages:
    2,915
    Gender:
    Male
    First Name:
    David
    San Diego
    Vehicle:
    2016 OR 4x4 DCSB MGM 6MT
    Tons of access, it was my first mod, I'm not mechanically experienced with autos in any way, from what I know of your skills, Mike, you'll be done before the first beer. Hardest part is deciding exactly what color and length of zip tie to use.

    I will add, though, that I avoided them for a long time but when doing my diff fluid I finally bought some rhino ramps. They are just right for getting a bit more space under the front or back of the truck as needed. Definitely not necessary but certainly nice to have.

  3. Aug 9, 2021 at 11:14 AM
    #803
    Taco_mike73

    Taco_mike73 Well-Known Member

    Joined:
    Nov 22, 2019
    Member:
    #311413
    Messages:
    1,948
    Gender:
    Male
    First Name:
    Mike
    York, PA
    Vehicle:
    2020 Cement SR5 DCSB 4x4
    Lomax tonneau cover, oem bed lights, AJT Design chrome delete, black out badges & tailgate letters, AVS hood deflector & vent visors, Solkie tech hood supports, interior LED lights, Tufskinz mud guards, RedArc TowPro Liberty, bed mat, kicker speaker upgrade, Hikari ultra H11 low beams, Diode Dynamics SS3 fogs in yellow, Meso customs total taillight stage 1. Coming soon: Compact powered sub install Future mods planned: bigger tires (265/75/16) BILLSTIEN 5100 lift
    Nice I have an old set of metal ramps I use for oil changes. That should work. Weather resistant Ties only come in black so that's a simple decision.

    daveeasa likes this.
  4. Aug 9, 2021 at 3:47 PM
    #804
    JJ Diablo

    JJ Diablo Well-Known Member

    Joined:
    Jan 18, 2014
    Member:
    #120913
    Messages:
    234
    Gender:
    Male
    First Name:
    Jay
    CT
    Vehicle:
    TRD
    Whelen Hideaway Strobe Kit Pioneer 210 AppRadio , Polk amp, Polk Speakers. Western Snowplow, WeatherTecs, PIAAs, Bilstein 5100s x4, Timbren SES , K-40 Laser Defuser. Uniden HP-1 Scanner.
    Out of curiosity, when you did your diff fluid using your ramps did you have the truck level ?
    In other words if the front was up on ramps, was the rear raised up to the same height ?

  5. Aug 9, 2021 at 4:31 PM
    #805
    daveeasa

    daveeasa Slowest crimp in the West

    Joined:
    May 14, 2020
    Member:
    #328079
    Messages:
    2,915
    Gender:
    Male
    First Name:
    David
    San Diego
    Vehicle:
    2016 OR 4x4 DCSB MGM 6MT
    My driveway is sloped to the point that the ramps made my truck close to level.

    However I did most of the changes with the nose / arse hanging just outside the garage door. Only the last rear diff topoff was with the ramps.

    JJ Diablo likes this.
  6. Aug 31, 2021 at 4:24 PM
    #806
    Bob Jr

    Bob Jr Member

    Joined:
    Aug 12, 2021
    Member:
    #374039
    Messages:
    6
    Gender:
    Male
    First Name:
    Robert
    Southern NJ
    Vehicle:
    2019 Tacoma SR Access Cab
    installed rear speakers, 2" tow receiver
    As many know the AC condensate hose drips onto the frame. I've seen many versions of this mod but thought I'd share my experience in completing this mod.
    I used a 5/8" ID clear reinforced tubing, it's what I had. Videos I watched said to watch you do not crush the stock tube when tightening. This gave me an idea. I've used brass sleeve bushings on plastic pipe being used on compression fittings. I bought a 7/16" sleeve at a local hardware store for $1.89
    [​IMG][​IMG]
    I used this inside the end of the stock drip tube to keep the tube from collapsing when I tightened the hose clamp around the extension hose. It was a snug fit but that's what you want.
    [​IMG] [​IMG]
    Once the sleeve was in the tube, I had to heat the extension tube to flare the end a bit so it would fit easier over the stock tube. I used a propane torch and and a pair of long nose pliers to stretch the 5/8" ID tube slightly. Once this was done, the new tube fit over the stock tube. The hose clamp was placed so that it was over the area of the brass sleeve and tightened.
    [​IMG]
    The hose was routed through the brake hard line loop. I fastened it to the hard line with a zip tie. I used a heat gun to soften the tube so I could form it to the shape I wanted. I ran it on the outside of the frame as shown. I installed a hose / cable clamp with rubber insert to hold the end of the new drip hose.
    [​IMG]
    To fasten the clamp I used a 1/8" x 1/2" hex head self drilling screw into the frame. The hole was drilled and sprayed with undercoating before and after the installation of the clamp. Hose was cut below the frame to finish the job.
    [​IMG]
    Here is the final end result.
    [​IMG]

    I know it's a bit long winded but anytime someone has an idea, it pays to read several listings on it and it helps you form your own conclusion and sometimes improve on the idea.

  7. Aug 31, 2021 at 4:29 PM
    #807
    toku58

    toku58 Well-Known Member

    Joined:
    Oct 10, 2008
    Member:
    #9882
    Messages:
    1,710
    Gender:
    Male
    HAWAII
    Vehicle:
    Mall Crawler!
    OLD (6" ProComp, 18x10" with 35x12.5R18" BFG KM2's.) Current 21' TRD OffRoad
    I normally go over areas that I see rust developing with some good ole Rustoleum and move on!
    I'm sure a bit of water dripping from the AC hose isn't any worse than driving in the rain or in puddles.

    JJ Diablo likes this.
  8. Aug 31, 2021 at 4:40 PM
    #808
    Lawfarin

    Lawfarin Now it’s Titan Tuesdays

    Joined:
    Oct 25, 2015
    Member:
    #167659
    Messages:
    7,130
    Gender:
    Male
    First Name:
    Larry
    NY
    Vehicle:
    2021 Titan Pro-4X
    These people should be more worried about driving around in acid rain or through salted or brined roads, instead they are worried about pretty clean condensed water, that’s better than the drinking water in third world countries.

    Maybe we should tell them that driving around in the rain or having your truck outside in a rain storm is doing more harm to their frames than the drain tube is. :violent:

    JJ Diablo likes this.
  9. Aug 31, 2021 at 6:08 PM
    #809
    Otto-x

    Otto-x Well-Known Member

    Joined:
    Aug 25, 2019
    Member:
    #303318
    Messages:
    107
    Seattle, WA
    Vehicle:
    2021 Cement DCLB OR
    that brass adapter is a great idea

  10. Aug 31, 2021 at 6:52 PM
    #810
    JJ Diablo

    JJ Diablo Well-Known Member

    Joined:
    Jan 18, 2014
    Member:
    #120913
    Messages:
    234
    Gender:
    Male
    First Name:
    Jay
    CT
    Vehicle:
    TRD
    Whelen Hideaway Strobe Kit Pioneer 210 AppRadio , Polk amp, Polk Speakers. Western Snowplow, WeatherTecs, PIAAs, Bilstein 5100s x4, Timbren SES , K-40 Laser Defuser. Uniden HP-1 Scanner.
    That part certainly is pretty ingenious , and extending the hose may keep ac drips off frame when parked. But how does this help when you are driving? Water is still going to splash all over the frame the same as the stock drain. The moving air pressure assures that. Am I missing something?

  11. Aug 31, 2021 at 8:44 PM
    #811
    Homiec

    Homiec Well-Known Member

    Joined:
    Dec 13, 2019
    Member:
    #313204
    Messages:
    104
    Vehicle:
    2020 TRD Sport Access Cab 4X4 MT
    The drain can drip water for quite a bit after you stop driving. With the stock drain it will just pool on top of the frame and sit there. Sure it may eventually evaporate, but if you're in a humid climate that may take a while. With the drain mod, any water that blows around on the undercarriage is also being blown off or more quickly evaporated with the airflow from driving. The undercarriage is much less enclosed than the stock drain area. FWIW, after I did the mod I checked around underneath the first few times after driving and didn't see any residual water on the undercarriage.

    JJ Diablo likes this.
  12. Aug 31, 2021 at 10:08 PM
    #812
    bagleboy

    bagleboy Well-Known Member

    Joined:
    Aug 5, 2017
    Member:
    #226018
    Messages:
    4,877
    Gender:
    Male
    First Name:
    Scott
    Norcal, Santa Rosa
    Vehicle:
    2014 5-lug AC 2.7L VVTI
    Snug top Rebel, Thule tracks, ditch tracks, Bagged rear suspension, F/R anytime camera, intermittent wiper switch...
    Also when you’re driving the hot exhaust system is right there inches away and it’s a drip hose not a garden hose so “splashing” might be more like light spatter spread over a larger area, some of which is SS , some painted underbody, and yes some frame but much less concentrated than before the mod.

  13. Sep 6, 2021 at 2:16 PM
    #813
    MidnightWizard17

    MidnightWizard17 Well-Known Member

    Joined:
    Jun 18, 2020
    Member:
    #331788
    Messages:
    54
    Gender:
    Male
    First Name:
    Ben
    Grand Rapids, MI
    Vehicle:
    2019 Midnight Black Metallic TRD OR 6M/T
    Core short-throw shifter, w/custom weighted knob. MESO side markers, Victory 4x4 roof rack.
    There's overkill and then there's this guy :D looks clean though!

    JJ Diablo likes this.
  14. Oct 11, 2021 at 8:31 AM
    #814
    hotrodder636

    hotrodder636 Well-Known Member

    Joined:
    Jul 11, 2020
    Member:
    #334136
    Messages:
    184
    Gender:
    Male
    Vehicle:
    2020 Tacoma TRD Pro (MGM)
    Used this idea to extend my drain line past the frame rail. Not as fancy but it works. Used a modified .45ACP casing as the ferrule. Tygon tubing connected to the factory line then run down rail and zip-tied in place. Will eventually get the black hose as it should last longer than tygon.
