Sluggo: The 4 banger build

Discussion in '1st Gen. Builds' started by IDtrucks, Dec 17, 2011.

  1. May 15, 2013 at 1:22 PM
    #221
    m3bassman

    m3bassman Professional Web Wheeler

    Joined:
    Jan 16, 2011
    Member:
    #49376
    Messages:
    21,425
    Gender:
    Male
    First Name:
    Captain Jack Sparrow
    On the seven seas!
    Bastard!

  2. May 15, 2013 at 2:17 PM
    #222
    MapleMoose

    MapleMoose Drunk Canadian

    Joined:
    Feb 15, 2011
    Member:
    #51211
    Messages:
    8,610
    Gender:
    Male
    First Name:
    Ian
    West Kootenays
    Vehicle:
    1996 Tacoma SR5
    3" Eibach Coils, 3" AP Springs, AP 6" Shackles Toytec Diff drop, BAMF Sliders, Deck plate mod,Volt meter, Highbeam mod, PIAA fogs, 18" Magnaflow, LED dash swap, Color matched Satoshi Grille, Custom Rear Plate Bumper
    So how do you know if the locker is engaged or not?

  3. May 15, 2013 at 2:22 PM
    #223
    Blackdawg

    Blackdawg Dr. Frankenstein

    Joined:
    Dec 31, 2010
    Member:
    #48500
    Messages:
    50,111
    Gender:
    Male
    First Name:
    Monte
    Wyoming/St. Louis
    Vehicle:
    96.5 FrankenTaco & 03 Stock dbl cab
    BFG KM2 33x12.5 tires, Wheelers Type B rims, Allpro 1.5'' Wheel spacers w/extended thread lug nuts 2 Alpine 10'' Type Xs 2 Kicker 6X9s 4 Sony 5 1/4s Pioneer 4100 HU Sway bar removed 4 Hella 500 HIDs Frankenstein Leaf packs 1'' lift shackles Eibach coils 5100s front 10'' 5150s rear BAMF BPV bracket Deckplate mod Elite Front bumper Magnaflow 14'' muffler Elite Off Road Rear bumper with Tire gate with jerry can and fold down table, BAMF sliders, Custom Homemade Bed, rack/roof rack, CVT Mt. Shasta Roof Top Tent, 20lb CO2 tank, BAMF diff skid custom front skid, GM CS144 140 amp alternator Blitzpro 21s HAWK side LEDs Blitzpro Custom made side mirror lights, LightForce 240 Blitz llights, Piaa 510 ION fogs, XRC8 Winch w/in cab controls,
  4. May 15, 2013 at 2:34 PM
    #224
    MapleMoose

    MapleMoose Drunk Canadian

    Joined:
    Feb 15, 2011
    Member:
    #51211
    Messages:
    8,610
    Gender:
    Male
    First Name:
    Ian
    West Kootenays
    Vehicle:
    1996 Tacoma SR5
    3" Eibach Coils, 3" AP Springs, AP 6" Shackles Toytec Diff drop, BAMF Sliders, Deck plate mod,Volt meter, Highbeam mod, PIAA fogs, 18" Magnaflow, LED dash swap, Color matched Satoshi Grille, Custom Rear Plate Bumper
  5. May 15, 2013 at 2:35 PM
    #225
    Blackdawg

    Blackdawg Dr. Frankenstein

    Joined:
    Dec 31, 2010
    Member:
    #48500
    Messages:
    50,111
    Gender:
    Male
    First Name:
    Monte
    Wyoming/St. Louis
    Vehicle:
    96.5 FrankenTaco & 03 Stock dbl cab
    BFG KM2 33x12.5 tires, Wheelers Type B rims, Allpro 1.5'' Wheel spacers w/extended thread lug nuts 2 Alpine 10'' Type Xs 2 Kicker 6X9s 4 Sony 5 1/4s Pioneer 4100 HU Sway bar removed 4 Hella 500 HIDs Frankenstein Leaf packs 1'' lift shackles Eibach coils 5100s front 10'' 5150s rear BAMF BPV bracket Deckplate mod Elite Front bumper Magnaflow 14'' muffler Elite Off Road Rear bumper with Tire gate with jerry can and fold down table, BAMF sliders, Custom Homemade Bed, rack/roof rack, CVT Mt. Shasta Roof Top Tent, 20lb CO2 tank, BAMF diff skid custom front skid, GM CS144 140 amp alternator Blitzpro 21s HAWK side LEDs Blitzpro Custom made side mirror lights, LightForce 240 Blitz llights, Piaa 510 ION fogs, XRC8 Winch w/in cab controls,
    It's pretty easy to tell tire chirp when you turn.

    Plus the button will be depressed..

  6. May 15, 2013 at 2:40 PM
    #226
    MapleMoose

    MapleMoose Drunk Canadian

    Joined:
    Feb 15, 2011
    Member:
    #51211
    Messages:
    8,610
    Gender:
    Male
    First Name:
    Ian
    West Kootenays
    Vehicle:
    1996 Tacoma SR5
    3" Eibach Coils, 3" AP Springs, AP 6" Shackles Toytec Diff drop, BAMF Sliders, Deck plate mod,Volt meter, Highbeam mod, PIAA fogs, 18" Magnaflow, LED dash swap, Color matched Satoshi Grille, Custom Rear Plate Bumper
    What i was asking was did he setup a light that lets him know if its engaged or not. The button could be pressed but how would he really know it was locked or not. And driving on dirt you wouldnt hear any chirping. Also the actuator may fail too so he wouldnt know if it was engaged or not.

  7. May 15, 2013 at 2:42 PM
    #227
    Blackdawg

    Blackdawg Dr. Frankenstein

    Joined:
    Dec 31, 2010
    Member:
    #48500
    Messages:
    50,111
    Gender:
    Male
    First Name:
    Monte
    Wyoming/St. Louis
    Vehicle:
    96.5 FrankenTaco & 03 Stock dbl cab
    BFG KM2 33x12.5 tires, Wheelers Type B rims, Allpro 1.5'' Wheel spacers w/extended thread lug nuts 2 Alpine 10'' Type Xs 2 Kicker 6X9s 4 Sony 5 1/4s Pioneer 4100 HU Sway bar removed 4 Hella 500 HIDs Frankenstein Leaf packs 1'' lift shackles Eibach coils 5100s front 10'' 5150s rear BAMF BPV bracket Deckplate mod Elite Front bumper Magnaflow 14'' muffler Elite Off Road Rear bumper with Tire gate with jerry can and fold down table, BAMF sliders, Custom Homemade Bed, rack/roof rack, CVT Mt. Shasta Roof Top Tent, 20lb CO2 tank, BAMF diff skid custom front skid, GM CS144 140 amp alternator Blitzpro 21s HAWK side LEDs Blitzpro Custom made side mirror lights, LightForce 240 Blitz llights, Piaa 510 ION fogs, XRC8 Winch w/in cab controls,
    Doesn't mean the light could fail too..so..that's not going to help if the actuator dies.

    Should be an easy circuit to hook up. I'm sure the switch just connects the first for the light.

    But..idk if he even has one being a 96. Idk if Toyota woulda started putting those in or not.

  8. May 15, 2013 at 2:45 PM
    #228
    MapleMoose

    MapleMoose Drunk Canadian

    Joined:
    Feb 15, 2011
    Member:
    #51211
    Messages:
    8,610
    Gender:
    Male
    First Name:
    Ian
    West Kootenays
    Vehicle:
    1996 Tacoma SR5
    3" Eibach Coils, 3" AP Springs, AP 6" Shackles Toytec Diff drop, BAMF Sliders, Deck plate mod,Volt meter, Highbeam mod, PIAA fogs, 18" Magnaflow, LED dash swap, Color matched Satoshi Grille, Custom Rear Plate Bumper
    They did. When i took apart my dash i could see where the bulb lit it up.

  9. May 15, 2013 at 2:48 PM
    #229
    Blackdawg

    Blackdawg Dr. Frankenstein

    Joined:
    Dec 31, 2010
    Member:
    #48500
    Messages:
    50,111
    Gender:
    Male
    First Name:
    Monte
    Wyoming/St. Louis
    Vehicle:
    96.5 FrankenTaco & 03 Stock dbl cab
    BFG KM2 33x12.5 tires, Wheelers Type B rims, Allpro 1.5'' Wheel spacers w/extended thread lug nuts 2 Alpine 10'' Type Xs 2 Kicker 6X9s 4 Sony 5 1/4s Pioneer 4100 HU Sway bar removed 4 Hella 500 HIDs Frankenstein Leaf packs 1'' lift shackles Eibach coils 5100s front 10'' 5150s rear BAMF BPV bracket Deckplate mod Elite Front bumper Magnaflow 14'' muffler Elite Off Road Rear bumper with Tire gate with jerry can and fold down table, BAMF sliders, Custom Homemade Bed, rack/roof rack, CVT Mt. Shasta Roof Top Tent, 20lb CO2 tank, BAMF diff skid custom front skid, GM CS144 140 amp alternator Blitzpro 21s HAWK side LEDs Blitzpro Custom made side mirror lights, LightForce 240 Blitz llights, Piaa 510 ION fogs, XRC8 Winch w/in cab controls,
    Interesting

    Well get busy mark haha

  10. May 16, 2013 at 1:09 AM
    #230
    IDtrucks

    IDtrucks [OP] Just out for a rip are ya bud?

    Joined:
    Jun 2, 2010
    Member:
    #38254
    Messages:
    20,009
    Gender:
    Male
    First Name:
    Mark
    Boise ID
    Vehicle:
    96' X-Cab 4x4 TRD Off Road Clusterfuck
    JVC Deck, 10" sub mountd in rear seat cubby, 2 LED off road lights mounted in grille, amber raptor style grille lights, LED rock lights, square led bed light, custom made fuse block tray, 12 blade Blue Sea fuse block, 100a marine circuit breaker, black plasti dipped full grille, tinted tail lights + third, Uniden 520 with 4' firestik, Bilstein 5100s with 620lb Eibach coils, Diff drop, Chevy 63 leaf swap, TG creeper joints, 14" triangulated biletein 5125s, 8" extended steel braided brake line, TG Rock Sliders, CBI Moab 1.0 front bumper, custom fabbed bed rack, full TRD E-Locker axle swap and matching re-gear with custom stand alone wiring circuit, 29 spline pinion flange from an 06 wishbone runner, tubbed for 35x12.5" general grabbers on Ultra type 181 wheels, crush sleeve eliminator, Mini ARB compressor, front ARB locker, garage fab aluminum front skid plate, custom built high clearence rear bumper, removable mothafuckin doors
    holy talking in the thread!



    yup, the CBI moab 1.0
    u going to moab this year?

    I already want 35s, 33s are so tiny looking.

    LOL
    he always ends up answering questions for me

    on the locker there are 2 plugs, one with 2 wires and one with 5. The one with 5 actually runs the motor, the other plug with 2 wires is a circuit that gets completed when the locker is engaged. I ran that (instead of to the dash light) to the switch light. So when the locker is engaged the circuit will be completed and the light in the switch will light up. Dont know if it works yet because i need to fix the connector for the light wires, the wires ripped out of the connector.

    now that is interesting! is there really a diff lock light in the dash??

    I can't believe there is because I didn't think the 96s came with the option for a diff lock, so why would there be a light for it? I would love to have a light in the dash. but i dont really feel like taking it all apart either. project for another day, if it exists.

  11. May 16, 2013 at 12:38 PM
    #231
    MapleMoose

    MapleMoose Drunk Canadian

    Joined:
    Feb 15, 2011
    Member:
    #51211
    Messages:
    8,610
    Gender:
    Male
    First Name:
    Ian
    West Kootenays
    Vehicle:
    1996 Tacoma SR5
    3" Eibach Coils, 3" AP Springs, AP 6" Shackles Toytec Diff drop, BAMF Sliders, Deck plate mod,Volt meter, Highbeam mod, PIAA fogs, 18" Magnaflow, LED dash swap, Color matched Satoshi Grille, Custom Rear Plate Bumper
    This is a 4runner, but its a non-TRD 4runner. Buddy did an elocker swap

    [​IMG]

  12. May 16, 2013 at 12:45 PM
    #232
    BradyT88

    BradyT88 Skinkwerks Rockware & Fabrication!!

    Joined:
    Nov 3, 2011
    Member:
    #66419
    Messages:
    35,481
    Gender:
    Male
    Idaho
    Vehicle:
    Rock Damage
    Skinkwerks armor and a lot of other stuff!
    I know the non TRD 2nd gens still have the exact same dash and what not, but it seems weird that a rig made before the TRD existed would have it.

  13. May 16, 2013 at 2:27 PM
    #233
    IDtrucks

    IDtrucks [OP] Just out for a rip are ya bud?

    Joined:
    Jun 2, 2010
    Member:
    #38254
    Messages:
    20,009
    Gender:
    Male
    First Name:
    Mark
    Boise ID
    Vehicle:
    96' X-Cab 4x4 TRD Off Road Clusterfuck
    JVC Deck, 10" sub mountd in rear seat cubby, 2 LED off road lights mounted in grille, amber raptor style grille lights, LED rock lights, square led bed light, custom made fuse block tray, 12 blade Blue Sea fuse block, 100a marine circuit breaker, black plasti dipped full grille, tinted tail lights + third, Uniden 520 with 4' firestik, Bilstein 5100s with 620lb Eibach coils, Diff drop, Chevy 63 leaf swap, TG creeper joints, 14" triangulated biletein 5125s, 8" extended steel braided brake line, TG Rock Sliders, CBI Moab 1.0 front bumper, custom fabbed bed rack, full TRD E-Locker axle swap and matching re-gear with custom stand alone wiring circuit, 29 spline pinion flange from an 06 wishbone runner, tubbed for 35x12.5" general grabbers on Ultra type 181 wheels, crush sleeve eliminator, Mini ARB compressor, front ARB locker, garage fab aluminum front skid plate, custom built high clearence rear bumper, removable mothafuckin doors
    exactly, i know later year 4runners and tacos came wired for the light if they didn't have it...but the TRD package with the locker did not exist in 1996 i dont think, so there would be no light for it.

  14. May 16, 2013 at 3:55 PM
    #234
    m3bassman

    m3bassman Professional Web Wheeler

    Joined:
    Jan 16, 2011
    Member:
    #49376
    Messages:
    21,425
    Gender:
    Male
    First Name:
    Captain Jack Sparrow
    On the seven seas!
    some did. Mike had a TRD tacoma before there was an official TRD tacoma. had the locker and all. it was an option possibly back then. it is like how they wire trucks for fog lights even though it isnt equipped with them. same thing with the light.

    maybe your truck doesnt have the light, but to me, it is entirely possible.

  15. May 16, 2013 at 4:19 PM
    #235
    BradyT88

    BradyT88 Skinkwerks Rockware & Fabrication!!

    Joined:
    Nov 3, 2011
    Member:
    #66419
    Messages:
    35,481
    Gender:
    Male
    Idaho
    Vehicle:
    Rock Damage
    Skinkwerks armor and a lot of other stuff!
    That's true. The 8" e-locker diff has been around since like the 80's hasn't it? I just didn't know it was in the Tacoma then.

  16. May 16, 2013 at 4:46 PM
    #236
    white toy taco

    white toy taco 505 Member

    Joined:
    Dec 23, 2011
    Member:
    #69296
    Messages:
    1,799
    Gender:
    Male
    First Name:
    Gian
    Albuquerque, NM
    Vehicle:
    02 4X4 Taco SR5 TRD V6
    All-Pro tube bumper, 5100's at middle setting w/OME 881's, rebuilt leafs w/ 2 chevy leafs, 265/75/16 Km2's, CloudyFab sliders, 6000k HID headlights (35w), 16" LED light bar,100w KC Daylighters, Bedlight mod
    it looks nice man. ive been on TW like 4 times this semester so im not hip on all the latest stuff

    but idk about moab, i really want to. work will be kinda pissed if i go but i might just tell them :brianr:

  17. May 17, 2013 at 1:46 AM
    #237
    IDtrucks

    IDtrucks [OP] Just out for a rip are ya bud?

    Joined:
    Jun 2, 2010
    Member:
    #38254
    Messages:
    20,009
    Gender:
    Male
    First Name:
    Mark
    Boise ID
    Vehicle:
    96' X-Cab 4x4 TRD Off Road Clusterfuck
    JVC Deck, 10" sub mountd in rear seat cubby, 2 LED off road lights mounted in grille, amber raptor style grille lights, LED rock lights, square led bed light, custom made fuse block tray, 12 blade Blue Sea fuse block, 100a marine circuit breaker, black plasti dipped full grille, tinted tail lights + third, Uniden 520 with 4' firestik, Bilstein 5100s with 620lb Eibach coils, Diff drop, Chevy 63 leaf swap, TG creeper joints, 14" triangulated biletein 5125s, 8" extended steel braided brake line, TG Rock Sliders, CBI Moab 1.0 front bumper, custom fabbed bed rack, full TRD E-Locker axle swap and matching re-gear with custom stand alone wiring circuit, 29 spline pinion flange from an 06 wishbone runner, tubbed for 35x12.5" general grabbers on Ultra type 181 wheels, crush sleeve eliminator, Mini ARB compressor, front ARB locker, garage fab aluminum front skid plate, custom built high clearence rear bumper, removable mothafuckin doors
    haha I should have been on 4 times. i wasted a lot of time here. but i feel like I did pretty well on my finals! Except jazz...fuck that class.

    And you should REALLY come to moab man. In case you haven't see the thread...its going to be huge! I've got a nice little roster of trails to run this time.

    DO IT!

  18. May 17, 2013 at 10:59 AM
    #238
    white toy taco

    white toy taco 505 Member

    Joined:
    Dec 23, 2011
    Member:
    #69296
    Messages:
    1,799
    Gender:
    Male
    First Name:
    Gian
    Albuquerque, NM
    Vehicle:
    02 4X4 Taco SR5 TRD V6
    All-Pro tube bumper, 5100's at middle setting w/OME 881's, rebuilt leafs w/ 2 chevy leafs, 265/75/16 Km2's, CloudyFab sliders, 6000k HID headlights (35w), 16" LED light bar,100w KC Daylighters, Bedlight mod
    i probably will. for some reason i was thinking it was next weekend but now that i realized its in 2 weekends, its looking better.

    still gotta do some mods to the front suspension/steering because it literally feels like i drive a boat

  19. May 19, 2013 at 3:10 AM
    #239
    IDtrucks

    IDtrucks [OP] Just out for a rip are ya bud?

    Joined:
    Jun 2, 2010
    Member:
    #38254
    Messages:
    20,009
    Gender:
    Male
    First Name:
    Mark
    Boise ID
    Vehicle:
    96' X-Cab 4x4 TRD Off Road Clusterfuck
    JVC Deck, 10" sub mountd in rear seat cubby, 2 LED off road lights mounted in grille, amber raptor style grille lights, LED rock lights, square led bed light, custom made fuse block tray, 12 blade Blue Sea fuse block, 100a marine circuit breaker, black plasti dipped full grille, tinted tail lights + third, Uniden 520 with 4' firestik, Bilstein 5100s with 620lb Eibach coils, Diff drop, Chevy 63 leaf swap, TG creeper joints, 14" triangulated biletein 5125s, 8" extended steel braided brake line, TG Rock Sliders, CBI Moab 1.0 front bumper, custom fabbed bed rack, full TRD E-Locker axle swap and matching re-gear with custom stand alone wiring circuit, 29 spline pinion flange from an 06 wishbone runner, tubbed for 35x12.5" general grabbers on Ultra type 181 wheels, crush sleeve eliminator, Mini ARB compressor, front ARB locker, garage fab aluminum front skid plate, custom built high clearence rear bumper, removable mothafuckin doors
    So I got my third re geared and into the new axle and the axle under the truck and everything together snug as a bug in a rug. Just as a side note I just drove 270 miles home after we got this done so the re gear and diff are dandy.

    K so the issue. After the truck came off the lift I went to test it and no matter which position I had the locker switch in the tires would stay locked, now take note I wired and installed my own completely separate e locker circuit, but it seemingly worked fine when the third was out of the housing. The motor itself was working because every time I hit the button we could hear the actuator working.

    So we pulled the truck back in and took out the motor and slid the locker slide gear with a screw driver to unlock it and we could spin the tires in open diff mode. We then put the locker motor back in with the locker gear slid a bit differently and when I hit the switch it would slide the locker to engage but it was like it would just barely catch because we could hear the diff ratcheting trying to engage but it couldn't, because our guess is the collar did not slide enough.

    Also odd was that when I had the button depressed it disengaged the locker, and when the button was in the "off position" the locker tried to engage. Admittedly when I tested the wiring before installing I was not sure if being in or out was locked or unlocked, i just saw it move and assumed it was right. So with that, could there be a difference in how the motor works in "reverse" and "engage" mode? Like if the motor is being told to reverse when it should be locking is it spinning more or less than the locked command?

    Tomorrow i am going to test my buddy's motor in my diff to see if the motor or the wiring is the issue. We have eliminated the gears inside the diff as the issue because we were able to slide them into locked and unlocked pretty easily with a screw driver, so if there was a binding issue that could not have happened.




    Other info:

    Wiring diagram



    [​IMG]


    Testing outside the third:

    Out:
    [​IMG]

    In:

    [​IMG]

  20. May 19, 2013 at 7:49 AM
    #240
    BradyT88

    BradyT88 Skinkwerks Rockware & Fabrication!!

    Joined:
    Nov 3, 2011
    Member:
    #66419
    Messages:
    35,481
    Gender:
    Male
    Idaho
    Vehicle:
    Rock Damage
    Skinkwerks armor and a lot of other stuff!
    Interesting... not sure what to tell ya man other than continue testing like you plan. You could always just engage the locker with a screw driver at the start of the trail and then disengage at the end if all else fails haha
