Something is Leaking...

Discussion in '2nd Gen. Tacomas (2005-2015)' started by Maj0rMalfunct10n, Feb 9, 2012.

  1. Feb 13, 2012 at 1:06 PM
    #21
    fixer5000

    fixer5000 the logical one

    Joined:
    Aug 7, 2011
    Member:
    #61293
    Messages:
    895
    Gender:
    Male
    First Name:
    Steve
    massachusetts
    Vehicle:
    2018 4runner limited in nautical blue
    and always remember a little bit of oil goes a long way covering almost everything along the way

  2. Feb 13, 2012 at 1:32 PM
    #22
    ItalynStylion

    ItalynStylion Sounds Gooooood

    Joined:
    Jun 15, 2009
    Member:
    #18467
    Messages:
    5,836
    Gender:
    Male
    First Name:
    Steven
    DFW, Tx.
    Vehicle:
    09 Double Cab TRD Sport 4x4
    I was thinking the same thing. Seems pretty obvious; check out the arc or oil slung up above the shaft.

  3. Feb 13, 2012 at 1:42 PM
    #23
    Asgard

    Asgard Well-Known Member

    Joined:
    Apr 19, 2008
    Member:
    #6078
    Messages:
    1,087
    Gender:
    Male
    First Name:
    Chris
    Vehicle:
    06 PreRunner DC SR5 w/LSD
    This is a known problem with the PreRunners, here is the TSB : http://www.tacomaworld.com/forum/2nd-gen-tacomas/45728-new-tsb.html
    The pan is lower than the leak so you shouldn't lose much fluid unless you're parking on an incline.

  4. Feb 13, 2012 at 3:11 PM
    #24
    Utard

    Utard Well-Known Member

    Joined:
    Nov 5, 2011
    Member:
    #66532
    Messages:
    3,118
    Gender:
    Male
    First Name:
    Mark
    Nyssa, Oregon
    Vehicle:
    2012 DC LB 4WD TRD SPORT NAVI
    ------------------------------------------------------------ Stabilus.EZDown.Tailgate http://www.ezdown.com/home.php ----------------------------------------------- Tekonsha.Primus.IQ.Trailer.brake http://www.tekonsha.com/content/default.aspx---------------------------------------------------------------- Leer 180 CC http://www.leer.com/Truck-Caps#------------------------------------------------ Firestone Air Rite Air Bags--------------------------------------Kargomaster Rack

    Thats just the shaft seal. If you know how to do them they are really easy. If not have a shop do it. Its a $15 seal.

  5. Feb 17, 2012 at 8:24 AM
    #25
    Wired

    Wired Member

    Joined:
    Jan 17, 2012
    Member:
    #70842
    Messages:
    8
    Gender:
    Male
    Chino Hills
    Vehicle:
    06 PreRunner TRD Sport
    Don't smell burning. I can't seem to pinpoint where its coming from exactly. But it is around the knuckles, not a lot but I see it. There aren't much grit around there though.

  6. Feb 17, 2012 at 8:26 AM
    #26
    Wired

    Wired Member

    Joined:
    Jan 17, 2012
    Member:
    #70842
    Messages:
    8
    Gender:
    Male
    Chino Hills
    Vehicle:
    06 PreRunner TRD Sport
    If its really just the seal. I'd be very glad. I am hoping you're right on the money. I am not handy with this. Will probably take it into a shop if indeed its the seal.

  7. Feb 17, 2012 at 8:27 AM
    #27
    Wired

    Wired Member

    Joined:
    Jan 17, 2012
    Member:
    #70842
    Messages:
    8
    Gender:
    Male
    Chino Hills
    Vehicle:
    06 PreRunner TRD Sport
    You are dead on. I am parked on an incline driveway (almost 25 degrees). I noticed its a very slow leak. Slow but I'm concerned it is indeed leaking and its already affecting the tranny.

    After checking out the TSB, I am hoping it is indeed the same problem with mine. I'll get an update once I take it in to the dealer to get this looked at.

    Thanks for the finding and sharing about the TSB.

  8. Feb 17, 2012 at 8:46 AM
    #28
    ruggedT

    ruggedT The Sticker Guy

    Joined:
    Jun 24, 2011
    Member:
    #58788
    Messages:
    3,177
    Gender:
    Male
    First Name:
    Stan
    Midlothian, Va
    Vehicle:
    2016 Ford F250
    Diesel on 35's
    So what happened to the op's problem? I know the guy who posted the tranny leak got his issue resolved

  9. Feb 17, 2012 at 9:50 AM
    #29
    Wired

    Wired Member

    Joined:
    Jan 17, 2012
    Member:
    #70842
    Messages:
    8
    Gender:
    Male
    Chino Hills
    Vehicle:
    06 PreRunner TRD Sport
    Ok. The dealer got back to me on replacing the A750E Transmission Extension Housing Seal. They said its gonna be $338 and they'll include a transmission service. Which in my mind is YIKES! Because they charge $179 for the transmission service but if I got this done together, he was gonna give me a break. Really, I see the only labor comes from replacing the seal. If i didn't want the tranny service, he said it was going to be $288. And the cost of that part number 90311-40034 is only $8.50.

    So I went and found this youtube video on changing tranny fluid. http://www.youtube.com/watch?v=Sdq30go2V7w
    It's not as tough as I had imagine. Just kinda tough getting the new fluid in such a tight area.

  10. Feb 17, 2012 at 12:24 PM
    #30
    maxamillion2345

    maxamillion2345 Well-Known Member

    Joined:
    Feb 20, 2010
    Member:
    #31761
    Messages:
    8,291
    Gender:
    Male
    First Name:
    Max
    Nevada
    Vehicle:
    80 series Land Cruiser
    Cummins, tons, 40s
    Just use a pump. Changing the seal on that would be easy. DIY save a fortune.

  11. Feb 17, 2012 at 12:29 PM
    #31
    maxamillion2345

    maxamillion2345 Well-Known Member

    Joined:
    Feb 20, 2010
    Member:
    #31761
    Messages:
    8,291
    Gender:
    Male
    First Name:
    Max
    Nevada
    Vehicle:
    80 series Land Cruiser
    Cummins, tons, 40s
    Pull the drive shaft. Pull the seal. Tap the new seal in using a socket of appropriate size. Use feeler gauge to make sure it's seated correctly. Reinstall everything. Follow the video and refill your tranny.

  12. Feb 17, 2012 at 6:18 PM
    #32
    Fortech

    Fortech Well-Known Member

    Joined:
    Mar 31, 2008
    Member:
    #5636
    Messages:
    876
    Gender:
    Male
    CANADA
    Vehicle:
    2005 Toyota Tacoma TRD OR
    Bilstein 5100's, rear TSB, Firestone bags
    According to the Toyota FSM, you should slightly overfill the transmission and pull the overflow plug while the engine is idling and replace when the fluid slows to a trickle - and yes it makes a difference (maybe by 300-500 ml)

    The proper level must be achieved while the fluid is circulating around the system, not when its settled in the ATF pan with the engine off.

  13. Feb 17, 2012 at 6:28 PM
    #33
    Fortech

    Fortech Well-Known Member

    Joined:
    Mar 31, 2008
    Member:
    #5636
    Messages:
    876
    Gender:
    Male
    CANADA
    Vehicle:
    2005 Toyota Tacoma TRD OR
    Bilstein 5100's, rear TSB, Firestone bags
    After watching the video a few more times the dude in the video has the right idea, but some misinformation also regarding the proper level, verifying the proper level, and the total capacity of the transmission.

    I did a DIY write up awhile back of the same procedure strictly following the Toyota Factory Service Manual. For something as expensive as an automatic transmission, you want to ensure you're doing it correctly. i tried it both ways, and yes it does make a difference !!

    http://www.tacomaworld.com/forum/2nd-gen-tacomas/63851-how-drain-refill-automatic-transmission.html

  14. Sep 1, 2019 at 9:14 PM
    #34
    Heyitssteve0331

    Heyitssteve0331 Active Member

    Joined:
    Aug 16, 2019
    Member:
    #302435
    Messages:
    40
    Gender:
    Male
    First Name:
    Steve
    Vehicle:
    07 taco
    Procomp leveling kit,carven exhaust,headlights,full JL Audio system
    I have a similar leak I though it was coming from the rack and pinion but the fluid is still topped off it’s a clear liquid that’s on my drive way I can’t figure out where it’s coming from.

  15. Sep 2, 2019 at 6:58 AM
    #35
    Taco-mama

    Taco-mama Well-Known Member

    Joined:
    Jun 19, 2019
    Member:
    #296829
    Messages:
    105
    Gender:
    Female
    Vehicle:
    2015 DCSB Prerunner
    What's it taste like???

  16. Sep 2, 2019 at 10:13 AM
    #36
    Larzzzz

    Larzzzz Grande' Ricardo

    Joined:
    Aug 23, 2009
    Member:
    #21609
    Messages:
    2,710
    Gender:
    Male
    First Name:
    Larry
    MA
    Vehicle:
    '06 dclb 350+ kmiles
    Aux back up lights, Bed lights, Re-located trailer plug, Good dooby, a.k.a. jumper cable mod, Heated seats, back up camera,
    Chicken and kelbasa respectively. :rofl:

  17. Sep 2, 2019 at 10:19 AM
    #37
    outlawtacoma

    outlawtacoma Well-Known Member

    Joined:
    Sep 25, 2007
    Member:
    #2796
    Messages:
    3,321
    Gender:
    Male
    W. TN
    Vehicle:
    2018 T4RTRDOR
  18. Sep 2, 2019 at 10:24 AM
    #38
    Heyitssteve0331

    Heyitssteve0331 Active Member

    Joined:
    Aug 16, 2019
    Member:
    #302435
    Messages:
    40
    Gender:
    Male
    First Name:
    Steve
    Vehicle:
    07 taco
    Procomp leveling kit,carven exhaust,headlights,full JL Audio system
    Coolant
