TOTAL CHAOS - 2016+ Toyota Tacoma Upper Control Arm (UCA)

Upper Control Arms contacting your coil overs?

Can't get your vehicle into proper alignment specs with 2-3" of lift?

Looking to ditch the stock ball joint setup for a much stronger uniball UCA?

TOTAL CHAOS has you covered!



TOTAL CHAOS - 2016+ Toyota Tacoma Upper Control Arm (UCA - #96504)
Click Here

- 100% Bolt-On UCA constructed of 4130 Chromoly.

- Designed with added caster. When you lift a vehicle with factory upper control arms the wheel will move towards the rear of the vehicle (negative caster). With negative caster you will often have wandering or darting of the vehicle. The TOTAL CHAOS UCA's have positive caster built-in for lifted applications. This allows vehicles with 2.5-3" lifts to get back into factory alignment specs.

- TOTAL CHAOS includes 1" I.D. uniballs that feature a heat treated stainless steel ball & heat treated stainless steel race for maximum corrosion resistance and component longevity. These uniball's also features a military grade PTFE woven fabric liner that helps prevent noise.

- Custom profile upper and lower hi-misalignment spacers maximize droop wheel travel and are machined from heat treated 17-4 stainless steel. Will allow for up to 1" of additional wheel travel when paired with extended travel coil over shocks.

- Urethane bushings reduce bushing deflection compared to stock rubber bushings

- 2 stage powder coat process includes a durable clear coat to provide a long lasting finish.

- Complete grade 8 hardware kit is included.



OPTIONAL HEIM PIVOT UPGRADE (#96504-H)
- TC includes 3/4" chromoly heim joints for the pivots.
- Heim upper control arms are fully adjustable to allow maximum tuning of caster and camber
- Designed for use on 6" or higher drop bracket lift kits.




MORE INFO


We have two threads covering TOTAL CHAOS UCA maintenance and preparation. Take a look and don't hesitate to ask any questions:
TOTAL CHAOS - UCA Maintenance (Lubricating Bushings & Uniballs) *VIDEO*
TOTAL CHAOS - UCA Prep (Replacing Bushings & Uniballs) *VIDEO*


For more info on TOTAL CHAOS products visit WWW.CHAOSFAB.COM or our Vendor Section. We'll be posting plenty of photos and information there!
https://www.tacomaworld.com/forums/total-chaos.247/

TOTAL CHAOS
WWW.CHAOSFAB.COM



Looking for a HOW TO install of TOTAL CHAOS UCA's? How about coil over shocks?

We cover everything you need to know for installing TOTAL CHAOS UCA's and aftermarket coil over shocks. Take a look HERE

TOTAL CHAOS
WWW.CHAOSFAB.COM



*** IMPORTANT ***

Please watch this video before greasing your TOTAL CHAOS UCA's. DO NOT pump grease into the UCA without loosening the thru-bolt. Failure to do so will result in bushing damage and require bushing replacement.

https://www.youtube.com/watch?v=xvMdAX2uybs



TOTAL CHAOS Control Arms feature a two-stage powder coat which includes a durable clear coat. This provides a very clean and durable finish that will protect the product for many years.

Want to order a set of Upper Control Arms?
Please email info@chaosfab.com, call 951-737-9682, or visit one of our Authorized Dealers


TOTAL CHAOS
WWW.CHAOSFAB.COM



Are you rocking a set of TOTAL CHAOS Upper Control Arms? We'd love to see your ride!


Comment below with a pic or two of your TC equipped vehicle



TOTAL CHAOS

WWW.CHAOSFAB.COM



TOTAL CHAOS suspension systems & accessories are 100% Made in the USA and handcrafted by our fantastic team in Corona, CA. TC’s experienced fabricators work very hard to provide top performing products that are built to last and also look great. The best companies in the industry provide components like bushings, uniballs, and hardware (all 100% Made in the USA). Each component is hand-picked and tested over thousands of miles to give you maximum performance and durability.


CLICK HERE to learn more about TOTAL CHAOS products and to check out our current offerings for your ride!


TOTAL CHAOS
WWW.CHAOSFAB.COM



: @mademan⁣925


Hope everyone is enjoying the holidays! We are grateful for our extended family of TC customers and the amazing companies that represent our brand across the globe. THANK YOU for a wonderful 2018.⁣

Did you get a set of TOTAL CHAOS Upper Control Arms under the Xmas tree?

If not, give one of our Authorized Dealers a shout to place an order!
Note: We'll be back in the shop 1/7 if you need anything directly. Give us a ring!

See YOU in the NEW YEAR!!!

TOTAL CHAOS
WWW.CHAOSFAB.COM



Almost like you are having a conversation with yourself.



Not anymore

TOTAL CHAOS
WWW.CHAOSFAB.COM



How often should they be greased?



It depends on usage and application. We have some customers that do it every oil change and others that grease the UCA's after every hard use.

Greasing every 5k miles is good practice but you could possibly go longer if you do a lot of hwy miles



Toytec is currently offering a Group Buy on our UCAs
https://www.tacomaworld.com/threads/total-chaos-uca-group-buy-by-toytec-lifts-ends-1-31.587857/



TC FUN FACT⁣⁣

Not all things are created equal. ⁣⁣

- 1 1/4 x .120 4130 chromoly tubing.⁣⁣
- Custom machined uniball cups.⁣⁣
- Production stamp coded.⁣⁣
⁣⁣
Did you know that all TOTAL CHAOS suspension components are part number stamped and production stamp coded?⁣⁣
⁣⁣
UCA's are stamped on the pivot gussets. ⁣⁣
⁣⁣
This information is very helpful to our tech support staff when they are helping customers that have purchased used TC equipment.⁣⁣

https://www.instagram.com/p/BuT-q_OBQHl/



We know this isn't a Toyota but what do you think?!

New Ranger parts coming SOON!

TOTAL CHAOS
WWW.CHAOSFAB.COM



https://www.instagram.com/p/BvZzczUhBlF/



How do the TC UCAs profile compare to the stock 2016+ UCAs? My current wheel/ tire setup is Cooper ST Maxx's in 255/85r16 on stock OR suspension/wheels. I don't have any rub, but the top edge of the tires is definitely close to the UCAs at full lock ( closest point is at the front side of the UCA, ~3 inches forward of the ball joint). I'm looking at swapping suspension for the ADS extended travel.

I've seen that JBA specifically calls out a more negative offset required to run 255/85/16 with their UCAs. I haven't found anything on any other UCAs that would confirm if the stock OR wheels would work or not. Any feedback on how the TC UCAs would work with this setup would be greatly appreciated.



We have a few customers that experience rubbing when running 35x12.5" tires and stock wheels (without wheel spacers). At full lock, the tire does rub a tiny bit on these wider setups.

You shouldn't experience any issues with the size you're trying to run. Proper alignment is key to making sure everything is where it needs to be. Often times a poor alignment will result in rubbing.

I wouldn't expect any issues with the setup you're trying to run. Give us a shout or comment below if you have more questions!

TOTAL CHAOS
WWW.CHAOSFAB.COM



Thanks for the reply. For reference, here's my tightest clearance point with my existing setup:

That photo is from the passenger side with the wheel at full lock to the left. The camera is pointing along the same lines as the tire and is at the same height as the UCA.



As I mentioned above, you shouldn't run into any issues with this setup. Clearance might be a little tight at factory height, once you install the ADS coilovers and add a little lift, everything will be just fine



Do you experience wandering or darting of the vehicle while driving? Are you running a lift kit?

TOTAL CHAOS Upper Control Arms are designed with added caster to aid in retaining factory alignment specs when aftermarket lift kits are installed. This reduces the darting or wandering in the vehicle's steering when 2.5"-3" lift kits are installed.

Click here to learn more about TC UCA's for your ride
