Towing a HEAVY load with my taco

Discussion in 'Towing' started by dougmays, Apr 21, 2008.

  1. Apr 21, 2008 at 1:55 PM
    #1
    dougmays

    dougmays [OP] Well-Known Member

    Joined:
    Nov 19, 2007
    Member:
    #3514
    Messages:
    299
    Gender:
    Male
    First Name:
    Doug
    Gainesville, FL
    Vehicle:
    2007 SR5 Tacoma 4WD/Tow Pkg Black
    Westin Bull Bar, Firestone Destination AT 255/70/16
    i need to tow an antique truck (62' Studebaker) about 150 miles with my tacoma. I have the tow package and 4x4....so i'm able to tow up to 6500lbs according to the specs. The truck is 5200lbs by its self, i'm not sure what the trailer for uhaul weighs but i'm assuming the whole package will be slightly over 6500lbs. What do you guys think...is this a safe venture?

    i've heard people on there towing up to 7000lbs...is this still a safe weight? I currently tow my boat (21 foot) which with trailer and half tank of gas is around 5000+ lbs, and the truck handles it just fine. so i'm thinking that i should be ok....but i dont wanna blow out the transmission or damage the truck in anyway.

    any advice?? also a side note....are there any "cheap" upgrades to improve towing capacities?

    thanks in advance

  2. Apr 21, 2008 at 2:31 PM
    #2
    gdawg25

    gdawg25 Zoom-Zoom

    Joined:
    Oct 25, 2006
    Member:
    #136
    Messages:
    1,021
    Gender:
    Male
    Victoria, BC
    Vehicle:
    '08 Mazdaspeed 3
  3. Apr 21, 2008 at 6:34 PM
    #3
    maverick491

    maverick491 Towing Guru

    Joined:
    Apr 30, 2007
    Member:
    #1462
    Messages:
    1,102
    Gender:
    Male
    South Jersey
    Vehicle:
    07 4x4 Access Cab, TRD off road, 6 cyl, 6 spd
    Activator III brake controller, Extang Fulltilt toneau, Factory bed mat, Extra D-rings in the bed, 2ndary air filter removed, Garmin Ique GPS, Eco-2, AFE Pro Dry-s filter, USASPEC PA12-toy, Pioneer 3-way speakers, SG II on Blendmount, Gulf States Alarm added.
    UHAUL auto transport trailers are heavy as hell.

    From the uhaul site regarding their auto transport trailers

    Capacity
    Max load: 4,000 lbs.
    Gross vehicle weight: 6,000 lbs. max
    Empty weight: 2,000 lbs.

    So you're going to be at 7200 lbs.

    Perhaps another rental place has lighter trailers?

    If you go with Uhaul tell them you are towing a 60 VW bug. They are pissy about their weight rules which go on for nearly half a page on their website.

    Should you do this? No. Can you do it safely? Probably. Try to find a lighter trailer, and in either case KEEP YOUR TRANNY OUT OF OVERDRIVE

    The link gdawg25 will take you to my towing bible. everything else should be covered in there.

    Good luck and be carefull.

  4. Apr 21, 2008 at 8:14 PM
    #4
    BLOCKADE

    BLOCKADE Well-Known Member

    Joined:
    Jan 28, 2008
    Member:
    #4469
    Messages:
    198
    Gender:
    Male
    Vehicle:
    TRD Off Road
    Weather Tech Floor Liners, Front Bed D-Rings...
    I just towed my '69 Camaro with my tow package equipped prerunner using a UHaul auto transport. I kept it slow and had a 2hr highway drive, no problems. I would give that tacoma towing bible a quick look before you go, there were some good tips. It think you'd be able to handle it, but I bet your '52 is a little heavier than my camaro.

  5. Apr 21, 2008 at 8:30 PM
    #5
    dougmays

    dougmays [OP] Well-Known Member

    Joined:
    Nov 19, 2007
    Member:
    #3514
    Messages:
    299
    Gender:
    Male
    First Name:
    Doug
    Gainesville, FL
    Vehicle:
    2007 SR5 Tacoma 4WD/Tow Pkg Black
    Westin Bull Bar, Firestone Destination AT 255/70/16
    according to the bible i shouldn't do it:) but the man who wrote it is telling me i'd probably be fine :) i think it'd be ok plus its only about a hour and half drive and its only one way. i would mostly likely keep it in 3rd and 4th. does anyknow know if uhaul rents those flat bed trucks with the wenches on them? maybe i'd be safer going with that.

    thanks for the info

  6. Apr 21, 2008 at 8:42 PM
    #6
    Hotdog

    Hotdog My hair is all natural Moderator

    Joined:
    Feb 9, 2007
    Member:
    #872
    Messages:
    10,245
    First Name:
    Hotdog
    Vehicle:
    2007 PreRunner SR5 Double Cab
    Wet Okole Underwear
    The towing terrain is also going to have some effect on everything. Level terrain and not too much traffic would be ideal.

  7. Apr 21, 2008 at 8:58 PM
    #7
    j4x4ar3

    j4x4ar3 Well-Known Member

    Joined:
    Feb 13, 2008
    Member:
    #4725
    Messages:
    416
    Gender:
    Male
    First Name:
    Jay
    Austin, TX
    Vehicle:
    05 DC 4x4 - TRD Off Road - White
    Round Step Bars, Bed Mat, Cargo Bars, Rocky Mounts bike mount, JVC MP3 Head Unit, TRD Cat Back Exhaust, Rigid Industries front and rear light pods, dual HAM radio with remote mount heads.
    Have fun.. my travel trailer weighs about 5000# fully loaded. There's no way I would want to pull much more than that. If you don't have a weight distribution hitch for that car trailer as well you're going to put too much weight on the rear of that hitch as well. 60% of any trailer weight should be in front of the axles of the trailer and at least 12% on the tongue to prevent trailer sway. 650# is the max recomended weight on the factory class IV hitch for our trucks when using a straight drop hitch with no weight distribution. Oh and hills.. at 7200# you're going to be awfully slow on any grade. I'd do it for maybe 20 miles but 150.. no thanks.

  8. Apr 22, 2008 at 12:19 AM
    #8
    RelentlessFab

    RelentlessFab Eric @Relentless Fab Vendor

    Joined:
    Feb 17, 2008
    Member:
    #4772
    Messages:
    15,763
    Gender:
    Male
    First Name:
    Eric
    Sparks, NV
    Vehicle:
    07 AC 6mt>03 SR5 >08 Sport and 17 6MT TRD OR
    Relentless Armored! Too many others to list.
    i think you'll be fine as long as you have the proper equipment(trailer brake controller, and some knowledge), go easy with her and dont do it too regularly. heres a pic of our backhoe that i've hauled around behind mine on occasion. she pulls it fine, just keep plenty of room to stop, and dont expect to get up to highway speed too quick.
    [​IMG]

  9. Apr 22, 2008 at 6:49 AM
    #9
    dougmays

    dougmays [OP] Well-Known Member

    Joined:
    Nov 19, 2007
    Member:
    #3514
    Messages:
    299
    Gender:
    Male
    First Name:
    Doug
    Gainesville, FL
    Vehicle:
    2007 SR5 Tacoma 4WD/Tow Pkg Black
    Westin Bull Bar, Firestone Destination AT 255/70/16
    thanks xtreme450, that picture helps me judge how much people are towing. This definitly wont be a common thing, i'm just towing this truck down one time to my uncle to get it up and running. Can you tell me roughly how much that backhoe/trailer combo weighs?

    The only thing i dont have is the brake controller. I have the standard towing package from Toyota. i know the uhaul and budget trailers have the inertia brake systems. I know i'll need to keep safe braking distance....but would this be a no-go if i dont have a brake controller? Is that the only thing you've added to your taco to make it be able to tow that backhoe?

    thanks

  10. Apr 22, 2008 at 6:58 AM
    #10
    maverick491

    maverick491 Towing Guru

    Joined:
    Apr 30, 2007
    Member:
    #1462
    Messages:
    1,102
    Gender:
    Male
    South Jersey
    Vehicle:
    07 4x4 Access Cab, TRD off road, 6 cyl, 6 spd
    Activator III brake controller, Extang Fulltilt toneau, Factory bed mat, Extra D-rings in the bed, 2ndary air filter removed, Garmin Ique GPS, Eco-2, AFE Pro Dry-s filter, USASPEC PA12-toy, Pioneer 3-way speakers, SG II on Blendmount, Gulf States Alarm added.
    You won't need a brake controller for a Uhaul trailer. Because as you said they have surge brakes which make no use of any input signal from the truck itself and are completely self contained (when they actually work that is) (no insult towards surge brakes, just toward U-haul's ability to maintain them)

    After you pick-up the trailer, go to a big empty parking lot and accelerate up to 20 MPH or so and then stomp on the brakes pretty hard, you should be able to see/feel the surge brakes lock-up. If they don't and you feel like you are being pushed by the trailer, go back to uhaul and demand another trailer.

  11. Apr 22, 2008 at 6:59 AM
    #11
    Bart

    Bart Well-Known Member

    Joined:
    Jan 31, 2008
    Member:
    #4512
    Messages:
    273
    Franklin,NC
    Vehicle:
    08 TRD OFFROAD V6 4x4
    metra ipod
    Bring a credit card for the gas. Mine like's gas towing.

  12. Apr 22, 2008 at 7:39 AM
    #12
    Angus_NB

    Angus_NB Well-Known Member

    Joined:
    May 22, 2007
    Member:
    #1642
    Messages:
    88
    Gender:
    Male
    Riverview, NB, Canada
    Vehicle:
    '08 Tundra DC SR5 4x4
    Doug, I was trying to find some info on the truck and found this article; 1961 Studebaker Champ
    Thought you may like to read it if you hadn't already seen it.

  13. Apr 22, 2008 at 12:46 PM
    #13
    RelentlessFab

    RelentlessFab Eric @Relentless Fab Vendor

    Joined:
    Feb 17, 2008
    Member:
    #4772
    Messages:
    15,763
    Gender:
    Male
    First Name:
    Eric
    Sparks, NV
    Vehicle:
    07 AC 6mt>03 SR5 >08 Sport and 17 6MT TRD OR
    Relentless Armored! Too many others to list.
    as maveric said, the uhaul trailers have a surge brake system so the brake controller wont be necessary on their trailer. If it were a trailer from a friend of yours, then you would need one of them since it most likely would have the standard 7pin coupler requiring a brake controller for the trailer brakes. as maveric also stated, check out the brakes on their trailer before hauling your load, you dont want to get pushed around by the trailer- nasty things can happen. as far as the weight of my load there, id estimate about a thousand pounds for the trailer(its aluminum) and then about 6000 for the backhoe. hope this helps ya.:cool: one more thing- make sure to keep the speed to below 60mph when towing, otherwise the trailer can start to swing back and forth, and if violent enough could lead to losing control. usually the amount of tongue weight on the trailer is what keeps this under control, make sure theres enough.

  14. Apr 22, 2008 at 2:59 PM
    #14
    sawdust

    sawdust Unapologetic Texan

    Joined:
    Sep 25, 2007
    Member:
    #2802
    Messages:
    1,284
    Frisco, TX
    Vehicle:
    07 TRD Offroad Radiant Red V6 Auto DC
    Homelink mirror, tailgate lock, 2ndary air filter removal, Access LE tonneau, Bugflector II, hitch-based bed extender, vent visors, suspension TSB, stall mat
    I'm sorry. I must be lost. I was searching for missleman's thread and entered 'wenches' and was brought here :confused:

  15. Apr 22, 2008 at 6:59 PM
    #15
    Versoel

    Versoel Member

    Joined:
    Apr 19, 2008
    Member:
    #6066
    Messages:
    7
    Fayetteville NC
    Vehicle:
    06 SR5 with 3 inch OME lift
    3 inch old man emu lift
    You should be just fine. I towed my jeep wrangler on a u-haul with 650 pounds of extra stuff in the jeep and 1700 pounds of stuff in the truck. I towed it from Clarksville TN, to Fayetteville, NC with no problems except for the fuel mileage. I only got about 13 miles per gallon while towing.

    I even went up a huge mountain or two with no issues, it slowed down to about 55 mph but kept on chugging. then i was able to maintain the normal 70 mph after that for the trip.

    Total trip was close to 900 miles.

  16. Apr 22, 2008 at 7:13 PM
    #16
    piercedtiger

    piercedtiger Devout Atheist

    Joined:
    Oct 29, 2007
    Member:
    #3284
    Messages:
    6,445
    Gender:
    Male
    First Name:
    Jon
    Southern Tier, NY
    Vehicle:
    2015 F150 3.5EB SCEW 6.5ft
    I had to tell UHaul I was towing a Ford Fiesta as a Chevy Lumina was even too heavy according to their computer. Also had to get them to read the door tag (which said 5450lbs) to correct their computer which said 4700lbs for a 4x4 DC. Can't imagine what they would've said if I told them I was towing a 79 ford ranger or ford custom.... :rolleyes:


  17. Apr 22, 2008 at 7:15 PM
    #17
    concrete jedi

    concrete jedi Well-Known Member

    Joined:
    Oct 20, 2007
    Member:
    #3142
    Messages:
    2,734
    Rochester N.Y
    Vehicle:
    06 Tacoma 4 door indigo blue
    Broken and scratched tailgate, cracked rear tail light lens, coffee stain in driver seat.
    You might want to pm piercedtiger, he towed an old ford and could give some real good advice, also check out my pix in the gallery, it shows to the taco pulling the truck.

  18. Apr 23, 2008 at 4:09 AM
    #18
    Angus_NB

    Angus_NB Well-Known Member

    Joined:
    May 22, 2007
    Member:
    #1642
    Messages:
    88
    Gender:
    Male
    Riverview, NB, Canada
    Vehicle:
    '08 Tundra DC SR5 4x4
    He's hauling a '62 not a '51. Different truck entirely but 5200# still seems high. A 4x4, DC, long bed, automatic Tacoma is 4145#.

  19. Apr 23, 2008 at 4:14 AM
    #19
    Angus_NB

    Angus_NB Well-Known Member

    Joined:
    May 22, 2007
    Member:
    #1642
    Messages:
    88
    Gender:
    Male
    Riverview, NB, Canada
    Vehicle:
    '08 Tundra DC SR5 4x4
    Wench
    [​IMG]

    Winch
    [​IMG]

    I have never seen a wench on a U-Haul trailer but I'll keep looking. :)

  20. Apr 23, 2008 at 6:21 AM
    #20
    maverick491

    maverick491 Towing Guru

    Joined:
    Apr 30, 2007
    Member:
    #1462
    Messages:
    1,102
    Gender:
    Male
    South Jersey
    Vehicle:
    07 4x4 Access Cab, TRD off road, 6 cyl, 6 spd
    Activator III brake controller, Extang Fulltilt toneau, Factory bed mat, Extra D-rings in the bed, 2ndary air filter removed, Garmin Ique GPS, Eco-2, AFE Pro Dry-s filter, USASPEC PA12-toy, Pioneer 3-way speakers, SG II on Blendmount, Gulf States Alarm added.
    I prefer this version of the wench, I believe this is wench 2.0.

    I have seen wenches in lots of places, I am pretty sure that they have been spotted on Haulmark trailers before at race tracks usually, so I am sure that it would not be out of the question to see one on a u-haul trailer, but I do agree that I have also personally never seen the two together either. :)
