Towing capacity and payload capacity.

Discussion in 'Towing' started by ecrepeau, Aug 5, 2010.

  1. Aug 5, 2010 at 5:59 AM
    #1
    ecrepeau

    ecrepeau [OP] Well-Known Member

    Joined:
    Feb 9, 2010
    Member:
    #31058
    Messages:
    78
    Gender:
    Male
    I have a question regarding when you are towing a trailer what are the limits of how much you can load into the bed of the truck?

    I know that the tow capacity (2nd gen tacoma with tow pkg) is something like 6500 pounds and the payload capacity (4x4 d-cab) is something like 1380 pounds.

    So for example could you tow a trailer weighing 3000 pounds and still load the bed with 1000 pounds?

  2. Aug 5, 2010 at 7:07 AM
    #2
    Brunes

    Brunes abides. Staff Member

    Joined:
    May 31, 2008
    Member:
    #7011
    Messages:
    17,801
    Gender:
    Male
    First Name:
    Rotorhead
    Big Easy, USA
    Vehicle:
    08 Red/Graphite and Satin Black
    Inside: Tint, Wet Okole 1/2 Piped Red/Black Covers, Black Weathertech Digital Fit Mats, URD Short Throw w/ TWM Weighted Knob, USA Spec iPod adapter. Outside: 4300K Retro w/ Angel Eyes and Red Shrouds, 5000K Blazer Fog Light Retrofit, Debadge, Bed Locking Handle, Satin Black Rims Performance: TRD/Steigmeier Blower w/ 2.7 Pulley. 668 Injectors and 320 LPH AEM Fuel pump. URD UCON and 7th Injector. DTLT Headers, URD Y-Pipe, Wicked Flow Muffler. Suspension: Both: OME Shocks Front: 886X's and TC UCAs Rear: Dakars Armor: Relentless Front Bumper Relentless High Clearance Rear w/ Tire/Rotopax Swing Out Relentless Front, Mid, and TCase skids BAMF Diff Skid Recovery and Spares: Fullsize Spare Tire 2x2 gal Rotopax 1x1 gal Rotopax 1x1 gal Water Rotopax Warn 9.5XP-S Winch Hi-Lift Extreme 60" Ironman Off-Road Recovery Kit Upcoming: ATO Gas Tank Skid and Sliders w/ kickout. ATO Shackle Flip Kit. Down the line: Front/Rear ARB Lockers w/ OBA. 4.56 Gears
    Yes-Kinda. There should be a Gross Vehicle Weight Rating too- And that should be the crub weight+payload+fully loaded trailer. Don't forget that payload includes passengers too....Not just crap in the bed.

    Edit- Good call about the tongue weight... but 1000 + 10% of 3000=1300...Payload capacity.

    You'll notice it tho...Low gas mileage, Longer stopping distances.

  3. Aug 5, 2010 at 7:59 AM
    #3
    skytower

    skytower Well-Known Member

    Joined:
    Jun 7, 2010
    Member:
    #38505
    Messages:
    3,221
    Gender:
    Male
    First Name:
    Dave
    virginia
    Vehicle:
    08 Tacoma 4x4
    Hitch and wiring, aux back-up light, rear strobe lights, radio and underseat sub.
    Negative. You have to take into account the tongue weight.
    There is a gross combined weight rating(GCWR). It is lower than the max ratings for payload and trailer. I'm not sure what the actual value is.

  4. Aug 5, 2010 at 8:01 AM
    #4
    Janster

    Janster Old & Forgetful

    Joined:
    Mar 25, 2007
    Member:
    #1138
    Messages:
    13,693
    Gender:
    Female
    First Name:
    Jandy
    Lancaster, PA
    Vehicle:
    2007 4.0L 4x4 TRD Sport Access Cab A
    Advantage Torza top (tri-fold), Husky floor mats, RuffTuff seat covers, C2C hood struts, Homelink mirror, USA Spec PA15-Toy (120gig Classic & 8gig nano), Garmin Nuvi 660, Protecta Bed mat, Pop-n-lock, TSB Springs, Scangauge II, Heated drivers seat, Fumoto drain valve, Aries pushbar, PIAA 540 fog lights, Hood scoop grahics, Flowmaster 50 series dual catback exhaust, RainX Latitude windshield wipers, Husky rear floor liner (ontop of folded down seats). Console Vault.
    Do some research on GCVWR.

    Gross Combined Vehicle Weight Rating.

    This is the total amount of weight combined including the weight of the truck, people & cargo, along with everything you're hauling and towing. I believe the Tacomas (with tow package) have 11,100 GCVWR.

  5. Aug 5, 2010 at 3:58 PM
    #5
    Isthatahemi

    Isthatahemi Well-Known Member

    Joined:
    Apr 29, 2009
    Member:
    #16582
    Messages:
    1,160
    Gender:
    Male
    Vehicle:
    TRD OFF ROAD
    BFG AT's, Weathertechs, Hoppy's brake controller.
    ******EDITED - TYPED QUICKLY, GOT IT WRONG

    Don't forget GAWR - Gross Axle weight rating.
    As long as you are under GVWR, GCWR, & GAWR at both axles, you are okay.
    As a simple rule of thumb, with no (WD) weight distributing hitch, deduct 1.5X the tongue weight from AXLE capacity, with a distributing hitch, deduct 1X tongue weight. So with a 6000# Trailer with a WD, you can still load 700# lbs in the truck, remember, that is cargo & humans, not just cargo. So with a heavy trailer, basically you can only have people in the truck.

    SORRY FOR THE CONFUSION!

  6. Aug 6, 2010 at 5:22 AM
    #6
    ecrepeau

    ecrepeau [OP] Well-Known Member

    Joined:
    Feb 9, 2010
    Member:
    #31058
    Messages:
    78
    Gender:
    Male
    OK. So if I understand everything correctly.

    Tongue weight is basically 10% of what ever the total weight of the trailer and the cargo you load in it. So if payload cap is 1380 and and you are hauling 3000 pounds subtract 300 pounds (10% of 3000) from the 1380 payload cap leaving you with 1080 payload still to go for additional stuff in the bed, weight of driver, and weight of anything else you have in the truck.

    GCVWR is the total of truck, payload and whatever you are hauling including the trailers weight combined. So basically add up all three and make sure you are under the GCVWR cap which if Janster is correct is 11,100 pounds. Can anyone confirm this number?

    A little lost on the math regarding GAWR. The figures in the example looks like 10% of trailer and cargo and not 1.5x for WD hitch or 2x for non WD. If I am correct the example (for WD hitch) would be as follows. 1.5x tongue weight of a 6000 pound trailer would be 900 pounds leaving only 480 pounds for payload or since it looks like the example rounded up payload cap to 1400 pounds 500 left for payload.

    Also, thank you guys for the info on this as I had no clue how hauling a trailer calculated into what could still be loaded into the truck and the bed itself. Could be useful info to be added to the Towing Bible post as anyone who is going camping with a trailer or the such is bound to throw additional gear in the bed of the truck.

  7. Aug 6, 2010 at 1:26 PM
    #7
    Isthatahemi

    Isthatahemi Well-Known Member

    Joined:
    Apr 29, 2009
    Member:
    #16582
    Messages:
    1,160
    Gender:
    Male
    Vehicle:
    TRD OFF ROAD
    BFG AT's, Weathertechs, Hoppy's brake controller.
    Tongue weight is applied as a leveraged force on the rear axle. 300# at the tongue, = almost 1.5 times that amount on the rear axle, and some weight removed from the front axle. So it only adds 300# to the curb weight, but far more to the axle. Same idea if you loaded all the weight in the rear of the box.
    A WD hitch spreads the weight, and I should have said the WD actually puts 1X, not 1.5X at the rear axle. A WD hitch essentially centers the tongue weight, somewhere around the rear axle. It also transfers some of the weight back onto the trailer axle(s)

  8. Apr 12, 2011 at 1:02 PM
    #8
    Combatoverride

    Combatoverride New Member

    Joined:
    Apr 12, 2011
    Member:
    #54780
    Messages:
    1
    Gender:
    Male
    San Francisco Bay Area
    Vehicle:
    2011 Double Cab V6 Auto SR5
    Here are some calculations I have made that others might find useful:


    Weighed my 2011 Tacoma today.
    Double Cab
    4x4
    V6
    SR5

    No other options. Truck is new and just off the lot. No tools, random junk, etc in the truck.

    Full tank of gas: 21 gal (21gal x 6.1lbs/gal = 128lbs)
    My dressed weight: 160lbs


    Total weight on scale: 4400lbs

    Total dry weight of truck (measured on the scale minus my weight and the weight of the gas) = 4,112lbs

    GVWR (per Toyota) = 5450


    That gives me 1050 to play with once I am filled up and by myself.

    That doesn't leave much payload once I add in a friend or two, gear, etc. I can only imagine that TRD offroad will add additional weight.


    I intend on adding a truck camper, which weighs in a 660lbs dry. That leaves me with 450lbs for everything else. It's going to be close.

  9. Apr 12, 2011 at 4:19 PM
    #9
    skytower

    skytower Well-Known Member

    Joined:
    Jun 7, 2010
    Member:
    #38505
    Messages:
    3,221
    Gender:
    Male
    First Name:
    Dave
    virginia
    Vehicle:
    08 Tacoma 4x4
    Hitch and wiring, aux back-up light, rear strobe lights, radio and underseat sub.
    Trailer loading affects tongue weight. Calculations are just a guide. Take what you plan to tow to the truck scales and measure the weight on each axle. Make sure you get one axle on each weigh plate, or you won't get an accurate weigh.
