TRD Off-Road vs. 20 TRD Pro Wheels - Weight Comparison

Discussion in '3rd Gen. Tacomas (2016+)' started by netmagi, Feb 13, 2020.

  1. Feb 13, 2020 at 9:07 AM
    #1
    netmagi

    netmagi [OP] Membrrrrrr

    Joined:
    Jun 18, 2009
    Member:
    #18608
    Messages:
    175
    Gender:
    Male
    Slatington, PA
    Vehicle:
    09 TRD OR
    Not incredibly scientific, since I'm just using a bathroom scale, but each IS weighed on the same scale. 20 Pro wheels were weighed right out of the box, the other wheels are off my 20 TRD OR. I made sure all wheels weights were removed and cleaned them before weighing. Center caps are weighed separate in the pics, but are almost identical.

    Stock 2020 OR Wheels w/center caps: 24lbs 2.6oz
    2020 TRD Pro Wheels w/center caps: 20lbs 15.3oz
    Difference: 3lbs 3.4oz

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    Last edited: Feb 13, 2020
  2. Feb 13, 2020 at 9:09 AM
    #2
    P-Dawg

    P-Dawg Factory 2 Seater

    Joined:
    Jan 30, 2020
    Member:
    #317755
    Messages:
    432
    First Name:
    Pete
    Chicago
    Vehicle:
    2020 SR AC MGM Utility Pckg.
    Good to know. Looking for some OEM wheels and weight is a factor .

  3. Feb 13, 2020 at 9:14 AM
    #3
    Kevin8se7en

    Kevin8se7en Well-Known Member

    Joined:
    Feb 28, 2018
    Member:
    #245908
    Messages:
    327
    Gender:
    Male
    Vehicle:
    2017 Inferno OR
    Do you think ~13lbs is going to make any noticeable difference?

    DAS Taco likes this.
  4. Feb 13, 2020 at 9:16 AM
    #4
    LazloCO

    LazloCO Well-Known Member

    Joined:
    Apr 5, 2019
    Member:
    #289206
    Messages:
    412
    Gender:
    Male
    First Name:
    Brian
    Morrison, CO
    Vehicle:
    2019 Cav Blue TRD OR DCSB
    Rock Lights, Sliders, Softopper, Fox 2.0 shocks F/R, add-a-leaf
    Totally! $4- $6 in gas........ per annum. Yuuuuuge!

    DAS Taco and ALI3N_123 like this.
  5. Feb 13, 2020 at 9:20 AM
    #5
    DLRIII

    DLRIII Well-Known Member

    Joined:
    Feb 27, 2018
    Member:
    #245744
    Messages:
    1,026
    Gender:
    Male
    First Name:
    David
    Baton Rouge
    Vehicle:
    2018 Quicksand SR5 DCSB V6
    The real factor is the rotational mass, it's basically the weight difference except exponential. That's actually a lot of weight off of the wheels.

    Edit: I looked it up to be sure, due to the effect of rotational mass any weight you add or subtract from the wheels has 3x the impact of static or unsprung mass (like weight in the bed, or fuel). So it's actually more like 39 lbs saved.

    danielgonzzz and LTacoman like this.
  6. Feb 13, 2020 at 9:20 AM
    #6
    netmagi

    netmagi [OP] Membrrrrrr

    Joined:
    Jun 18, 2009
    Member:
    #18608
    Messages:
    175
    Gender:
    Male
    Slatington, PA
    Vehicle:
    09 TRD OR
    I honestly don't know. I didn't buy them for the weight difference. I liked the look. People talk about the 'alleged' weight difference all the time though, and I had both here, so I figured I'd weigh them.

    The data may or may not be important to you, but at least it's data :)

    I WILL say that the truck rides completely different (much less harsh, but still 'firm'). I much prefer the ride now.

    Unfortunately, I changed from the stock tires to Cooper Discoverer AT3 4S in 265/75R16 at the same time, so I have no idea which was the larger contributing factor to the change in ride.

  7. Feb 13, 2020 at 9:23 AM
    #7
    LTacoman

    LTacoman Well-Known Member

    Joined:
    Sep 9, 2015
    Member:
    #163807
    Messages:
    1,378
    Gender:
    Male
    First Name:
    Luis
    Gilbert, Az
    Vehicle:
    2016 DCSB 4X4 TRD SPORT
    [​IMG]

  8. Feb 13, 2020 at 9:26 AM
    #8
    LTG4087

    LTG4087 Well-Known Member

    Joined:
    Jul 3, 2012
    Member:
    #81852
    Messages:
    1,174
    Gender:
    Male
    First Name:
    LT
    DFW
    Vehicle:
    2019 TRD Off Road
    That's 15% more weight on the OR. If it where 13 lbs in the bed or cab there would be no difference that could be measured. But in the wheels it does rob HP. I wouldn't think very much, but science says it makes some difference. In the real world tire construction (aggressive tread vs smooth) and inflation pressure probably has more affect that a few lbs weight.

  9. Feb 13, 2020 at 9:32 AM
    #9
    Kevin8se7en

    Kevin8se7en Well-Known Member

    Joined:
    Feb 28, 2018
    Member:
    #245908
    Messages:
    327
    Gender:
    Male
    Vehicle:
    2017 Inferno OR
    TL;DR
    13lbs of rotational mass = running on half a tank of gas (vs full) in terms of performance.

    Theoretically this matters, but in reality it doesn't. It's kind of like how swimmers need to shave every hair on their body to swim faster. It's to get the extra 0.001 seconds over the other guy. In racing, rotational mass matters because handling is extremely important, and the tiniest of advantages make a world of difference.

    In the real world, no one is shaving all their body hair to swim faster, and you aren't going to notice any difference in 13 pounds of rotational mass, given the overall weight of the vehicle. A good example of this is how your fuel economy and overall performance isn't suddenly and noticeable better when you're almost out of gas vs when your tank is full. Your tank holds up to ~131lbs of gas. On empty, you're probably hovering round a weight loss of 120lbs and I bet you don't even notice a performance difference. Even if we're generous and say 1lb of rotational mass = 5lbs of sprung mass, you're looking at a benefit of 65lbs. So the equivalent of running on about half a tank of gas.

    Now if you run at a half tank with lighter wheels and lighter tires... things start to add up - but it's still barely noticeable at all.

    I'm not arguing BTW. I just don't want to see someone thinking this matters more than just buying the wheels they like. If you like these and they weigh less... thats a bonus!

    I like the wheels. I'm more just curious to see if someone that cares about weight believes it matters that much.

    Last edited: Feb 13, 2020
    Astr0Aar0n, Aqualoon and LTacoman like this.
  10. Feb 13, 2020 at 9:52 AM
    #10
    Ronzio

    Ronzio Well-Known Member

    Joined:
    Feb 20, 2018
    Member:
    #245114
    Messages:
    2,506
    Gender:
    Male
    Pennsylvania
    Vehicle:
    17 DCSB TRDOR
    In order for a vehicle to accelerate it must overcome inertia forces....a lighter Tacoma with the same power as a heavier one will always have the advantage.

    P-Dawg likes this.
  11. Feb 13, 2020 at 9:54 AM
    #11
    DLRIII

    DLRIII Well-Known Member

    Joined:
    Feb 27, 2018
    Member:
    #245744
    Messages:
    1,026
    Gender:
    Male
    First Name:
    David
    Baton Rouge
    Vehicle:
    2018 Quicksand SR5 DCSB V6
    Nice analysis, in perspective the weight difference and even the rotational mass difference is basically negligible, I agree.

  12. Feb 13, 2020 at 10:12 AM
    #12
    P-Dawg

    P-Dawg Factory 2 Seater

    Joined:
    Jan 30, 2020
    Member:
    #317755
    Messages:
    432
    First Name:
    Pete
    Chicago
    Vehicle:
    2020 SR AC MGM Utility Pckg.
    Another way to use a bathroom scale is to stand on it holding the wheel, then step off and back on the scale without the wheel. Some scales are less accurate at the lower end of their range.

    ohheythatguy likes this.
  13. Feb 13, 2020 at 10:15 AM
    #13
    P-Dawg

    P-Dawg Factory 2 Seater

    Joined:
    Jan 30, 2020
    Member:
    #317755
    Messages:
    432
    First Name:
    Pete
    Chicago
    Vehicle:
    2020 SR AC MGM Utility Pckg.
    Reducing the weight only helps acceleration, braking, handling, mileage, wear, ABS, Traction control, and ride quality. Otherwise it doesn’t matter at all. I wouldn’t recommend buying wheels you hate however, everyone will notice if they don’t like how their truck looks. I like all the OEM wheels so I’ll go for lighter since I’m running light stock size tires.

    Last edited: Feb 13, 2020
    Doobfucious likes this.
  14. Sep 16, 2020 at 5:31 PM
    #14
    trdteddyb

    trdteddyb Member

    Joined:
    Sep 13, 2020
    Member:
    #340643
    Messages:
    6
    Gender:
    Male
    Vehicle:
    2020 TRD Pro MGM 6MT
    Bumping this old thread. Is the consensus the 20 Pro wheels weigh around 20lbs? I came from the Subaru community and the forged BBS wheels I had weighed 20lbs. I get the Pro wheels are smaller in diameter, but I have my doubts with the wheels being cast.

  15. Sep 16, 2020 at 7:43 PM
    #15
    outlaw.taco

    outlaw.taco Member

    Joined:
    Sep 12, 2020
    Member:
    #340588
    Messages:
    7
    Vehicle:
    Truck

  16. Sep 16, 2020 at 7:54 PM
    #16
    trdteddyb

    trdteddyb Member

    Joined:
    Sep 13, 2020
    Member:
    #340643
    Messages:
    6
    Gender:
    Male
    Vehicle:
    2020 TRD Pro MGM 6MT
    Haha yeah yeah I saw the read the entire thread and saw the photo. Just curious as to why its listed higher on the box it comes in and a toyota parts website.

  17. Sep 16, 2020 at 8:56 PM
    #17
    Tacodelphia

    Tacodelphia Active Member

    Joined:
    Aug 19, 2020
    Member:
    #338182
    Messages:
    32
    Gender:
    Male
    First Name:
    David
    Philly
    Vehicle:
    2020 TRD OR MT Cement
    CONSPIRACY...

  18. Sep 17, 2020 at 2:57 AM
    #18
    Tacotoast

    Tacotoast Well-Known Member

    Joined:
    Jun 3, 2018
    Member:
    #255379
    Messages:
    252
    Gender:
    Male
    Vehicle:
    2019 Sport DCSB 4x4 6MT
    Absolutely. Unsprung weight has the most effect on a vehicles performance.

  19. Sep 19, 2020 at 11:05 AM
    #19
    TwinTaco31719

    TwinTaco31719 Well-Known Member

    Joined:
    Nov 16, 2019
    Member:
    #310895
    Messages:
    451
    Gender:
    Male
    Vehicle:
    2019 White Tacoma TRD Off-road
    I got the 2020 pro wheels coming from TRD OR wheels and did notice a difference right away. Not huge in mpg or acceleration but noticeable. The thing I liked the most was the wider rim with additional 12mm offset. Almost flush with the flares

    Doobfucious likes this.
  20. Sep 19, 2020 at 11:14 AM
    #20
    Hotwheels85

    Hotwheels85 Well-Known Member

    Joined:
    Jul 28, 2020
    Member:
    #335898
    Messages:
    54
    Vehicle:
    2020 Silver Sky TRD ORDCSB
    None
    The pro rims just look better and rides better
